48Gbps 1x2 HDMI Splitter
US E R M ANUA L
BK-102
Follow us on Youtube
and Facebook
www.orei.com
page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BK-102 and is the answer not in the manual?

Questions and answers

Summary of Contents for Orei BK-102

  • Page 1 BK-102 48Gbps 1x2 HDMI Splitter Follow us on Youtube and Facebook US E R M ANUA L www.orei.com page 1...
  • Page 2: Table Of Contents

    Table of Contents Introduction Features Package Contents Specifications Operation Controls and Functions Auto Downscaling & Auto Converting Application Example Thank you for purchasing this product Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product.
  • Page 3 OREI Live Technical Support Hours US team (US/Canada/Mexico): Monday-Friday, 9 a.m. - 6 p.m. Central Time Support Email - info@orei.com |Support Number - 877-290-5530 Chat Live on www.orei.com Send us an instant message now. Our Technical Support Team will respond momentarily.
  • Page 4: Introduction

    Introduction The BK-102 Splitter is an advanced solution for splitting single HDMI signal to 2 HDMI outputs synchronously, with video resolu- tion up to 8K@60 4:2:0 12bit. It supports data rates up to 48Gbps to comply with HDMI 2.1 and HDCP 2.3 requirements. It includes several features for ease of integration, including EDID manage- ment, cable equalization.
  • Page 5: Features

    8K to 4K or 8K/4K to 1080P auto downscaling on all outputs HDR to SDR auto converting on all outputs Advanced EDID management Compact design for easy and flexible installation Package Contents BK-102 Splitter 1pcs 5V/1A Multinational Power Supply 1pcs User Manual...
  • Page 6: Specifications

    Specifications Technical HDCP Compliance HDCP 2.3 HDMI Compliance HDMI 2.1 Video Bandwidth 48Gbps Video Resolution Up to 8K@60Hz 4:2:0 12bit, 4K@120Hz 4:4:4 12bit Color Space RGB, YCbCr 4:4:4, YCbCr 4:2:2 Color Depth 8/10/12-bit HDMI Input/Output: LPCM, Dolby Digital/Plus/EX, Dolby True HD, Dolby Audio Formats Atmos, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS- HD Master Audio, DSD...
  • Page 7 Specifications Mechanical Housing Metal Enclosure Color Black Dimensions 95mm [W] × 68mm [D] × 18mm [H] Weight 177g Input: AC 100-240V 50/60Hz, Output: DC 5V/1A Power Supply (US/EU standards, CE/FCC/UL certified) Power Consumption 3.2W (Max) Operation -10°C ~ 50°C / 14°F ~ 122°F Temperature Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F...
  • Page 8: Operation Controls And Functions

    Operation Controls and Functions Front Panel OUT 1 OUT 2 EDID SERVICE Name Function Description Power LED When the device is powered on, the red LED will be on. When the HDMI IN port connects to an active source IN LED device, the green LED will be on.
  • Page 9: Auto Downscaling & Auto Converting

    Operation Controls and Functions Rear Panel OUT 1 OUT 2 DC 5V Name Function Description HDMI signal input port, connected to HDMI source IN port device such as DVD or PS5 with an HDMI cable. HDMI signal output port, connected to HDMI display OUT port (1~2) device such as TV or Monitor with an HDMI cable.
  • Page 10 Auto Downscaling & Auto Converting Splitter 8K HDR TV 8K Source 8K HDR 8K HDR 8K HDR 8K HDR TV Splitter 8K HDR TV 8K Source 8K HDR 8K HDR 4K HDR 4K HDR TV Splitter 4K HDR TV 8K Source 1080P SDR 8K HDR 1080P SDR...
  • Page 11: Application Example

    Application Example DVD or Blu-ray Player Power Supply OUT 1 OUT 2 DC 5V 8K TV 2 8K TV 1 The terms HDMI and HDMI High-Definition Multimedia interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
  • Page 12 48Gbps 1x2 HDMI Splitter BK-102 www.orei.com © 2023 page 12...
