Summary of Contents for Xo XOUIMN1585NOP
- Page 1 UNDERCOUNTER NUGGET ICE MAKERS I worked really hard on this manual - MODELS: so please read it... XOUIMN1585NO, XOUIMN1585NOP XOUIMN1585NOA, XOUIMN1585NOPA...
- Page 2 Before you proceed, take just a moment to register your XO at: www.xoappliance.com/register-your-product/ REGISTRATION HELPS YOU BY - Ensuring warranty coverage should you need service Providing ownership verification for insurance purposes Let’s XO notify you in the event of product changes or recalls.
-
Page 3: Where Things Are
where things are Before You Get Started 4 - 7 Installer Checklist Find Your Model Safet y Instructions Electrical and G rounding In structions Installation Inst ruc tions 8 - 1 9 izes and Installation Dimensions Plumbing With & Without Drain Pump Reversing the Door Door panel Installation 20 - 22... - Page 4 heres’s ten steps for a quick & easy install Inspect cabinet opening for water, drain and electrical connections. The 1/4” O.D. water supply line must include isolation valve and should include an inline water filter (consult manual). Do NOT use a self-piecing valve for the supply connection. Water supply must have a minimum pressure of 20 psi and a maximum of 80 psi.
- Page 5 INDOOR NUGGET GOURMET ICE MAKER STANDARD HEIGHT XOUIMN1585NO & XOUIMN1585NOP ADA HEIGHT XOUIMN1585NOA & XOUIMN1585NOPA take a minute to circle your model above and record your serial number here in case you need it later...
- Page 6 For maximum efficiency, keep the door tightly shut unless removing ice. Before installing, allow your XO unit to sit upright for 2 hours at the install site. This will allow the cooling system to stabilize after transportation. Failure to follow this step may cause problems.
- Page 7 In regions where high humidity exists (greater than 70%) condensation may appear on the door and/or door gaskets. This is normal and will disappear as humidity Your XO unit is built to operate on 115V 60Hz and drops. should be plugged directly into a dedicated 15 amp 3 prong outlet.
- Page 8 ALL XO UNDERCOUNTER UNITS ARRIVE PRE-WIRED WITH LOW PROFILE PLUGS Standard Height Units FOR EASY INSTALLATION 33-3/4” MINIMUM (853mm) 7" ADA Height Units (178mm) 31-7/8” MINIMUM (808mm) 4" (100mm) 15-1/4” (387mm) MINIMUM WHEN INSTALLING WITH...
- Page 9 ( or small, as the case would be height & width XOUIMN1585__ & XOUIMN1585__A ICE MAKER 9/16” STANDARD HEIGHT (853mm) 31-13/16” STANDARD HEIGHT (808mm) 14-15/16” WIDE (379mm) depth TOP VIEW 22-25/32” (579mm) THE OVERALL DEPTH SHOWN (22-25/32”) INCLUDES THE DOOR WITH 3/4”...
- Page 10 before you install check a few things Water source tub 120V Outlet Drain hose Is the installation location COOL, DRY, LEVEL and away from direct sun. The water supply valve must provide positive shut off capability and be readily accessible. Does the unit have a dedicated 115V three prong, properly grounded outlet? The Cold Water supply is 1/4”...
-
Page 11: Water Quality
All water contains some impurities and minerals. Your XO Ice Maker is designed to produce chewable, nugget ice. It does this by compressing ice flakes as they are forming. PURER WATER YIELDS PURER ICE. Cubes are formed by cold water spraying against a chilled mold. Pure water freezes faster than water containing impurities. -
Page 12: Water Supply
the plumbing Plan the arrangement of the water supply pipes. You will need both a water supply line and a drain (see section on installing a gravity drain unit or pump drain unit) 1/4” O.D. If the tap water has a high level of minerals, an inline filter will be required. Attach the water supply line to the rear of the unit with flexible tube to the fitting indicated here. - Page 13 with gravity drain INSTALLING THE XOUIMN1585 without a drain pump. Position the ice maker in front of the opening. Level the unit using the leveling legs. Wash and flush the water supply tube and connect the unit to the cold water isolation valve. Prepare the drain.
- Page 14 with drain pump INSTALLING THE XOUIM1565SP with DRAIN PUMP. Position the ice maker in front of the opening. Level the unit using the leveling legs. Wash and flush the water supply tube and connect the unit to the cold water isolation valve. Cut the 3/8”...
- Page 15 Your XO Ice Maker is shipped with the hinge on the right hand side but it can be easily reversed. 1. Remove the inner most screw holding the top and bottom hinges (shown here) 2. Loosen the outer screw holding the top and bottom hinges (as show here) 3.
- Page 16 installing the door panel The panel is held in place by self tapping screws and/or machine screws. To install your panel, follow these simple steps: 1. First prepare your custom panel. The panel must be 14-7/8” wide and no more than 3/4” thick. It cannot weigh more than 20 lbs. The height of the panel can vary but cannot block the free exchange of air through the toekick.
- Page 17 Use the upper hole Optional Stainless Steel Panel Use the lower hole PANEL MAXIMUM WEIGHT: 20 lbs. MAXIMUM PANEL THICKNESS 3/4”...
- Page 18 & xouimn1585nop ouimn1585noada & xouimn1585nopada 14-7/8" (378mm) Standard Height 29-13/32” (747mm) FRONT ADA Height 27-5/8” (702mm) PANEL HEIGHTS ARE MINIMUMS, PANEL MAY BE TALLER. PANEL MUST NOT INTERFERE WITH TOEKICK VENTS. AFTER INSTALLATION UNDERCOUNTER DOOR MUST BE ABLE TO OPEN 90 MAXIMUM PANEL THICKNESS 3/4”...
- Page 19 the toekick PANELS MAY EXTEND HIGHER OR LOWER THAN THE DOOR BUT MUST NOT OBSTRUCT THE FREE EXCHANGE OF AIR THROUGH THE TOEKICK.
-
Page 20: Features & Specs
features & specs Produces up to 85lbs of nugget ice per day Stores 24.3lbs of ice in bin Chewable, Nugget Ice Gravity drain and pump drain models available Reversible Door | Panel Ready (optional SS panel) Rated for Indoor use (50 - 100 ) Front venting - designed for under counter installation Automatically pauses ice production when bin is full MAXIMUM CAPACITY... -
Page 21: Initial Operation
You XO Ice Maker is simple to operate. When you open the door you will see the electronic button/display located at the top center of the appliance. The first button, LAMP, allows you to cycle through the 5 different interior LED Light colors (white, Dark Blue, Green, Red and Light Blue). -
Page 22: During Operation
operation cont. DURING OPERATION: After turning the switch to the ICE position, ice production will begin and continue until the ice bin has been filled. Once the bin is filled, production will automatically be paused. Remove ice using the handy scoop located in a holder in the top left hand side of the interior. -
Page 23: Maintenance
maintenance Proper maintenance, cleaning and santizing is essential to ensure your ice is safe, fresh and odor free. WASH FEATURE: Regular maintenance is the key to delicious, wholesome ice. The WASH feature helps make this easy to perform. When the WASH Position of the switch is selected, the cleaning process takes approximately 10 minutes and the following action take place: BEFORE BEGINNING - REMOVE ALL ICE FROM THE ICE BIN. - Page 24 maintenance cont. Proper maintenance, cleaning and santizing is essential to ensure your ice is safe, fresh and odor free. CLEANING: BEFORE BEGINNING - REMOVE ALL ICE FROM THE ICE BIN. 1. Prepare by mixing 0.25ℓ of a non-toxic, nickle-safe Ice Maker cleaning solution and 5ℓ...
- Page 25 maintenance cont. Proper maintenance, cleaning and santizing is essential to ensure your ice is safe, fresh and odor free. SANITIZING: BEFORE BEGINNING - REMOVE ALL ICE FROM THE ICE BIN. 1. Prepare by mixing 0.25ℓ of a Ice Maker sanitizer solution and 5ℓ of water. WARNING: Observe all safety precautions including the use of protective eyewear and gloves while using sanitizer.
-
Page 26: Stainless Steel
stainless steel cleaning the exterior Stainless Steel: Stainless steel does not stain, corrode, or rust as easily as ordinary steel, but it is not stain or corrosion proof. Stainless steels can discolor or corrode if not maintained properly. Stainless steels differ from ordinary carbon steels by the amount metals such as chromium and nickel used in the alloy. - Page 27 the condenser improve efficiency & performance Cleaning the condenser Remove dust and dirt from the surface of the condenser coils with a vacuum cleaner Remove two screws on the front panel at the center of the inside Vacuum the condenser coils Reassemble the panel using the two screws to after cleaning...
-
Page 28: Maintenance Schedule
maintenance schedule The following maintenance schedule is a guideline. Maintenance and repairs should be performed more frequently where required by water quality, equipment usage and local hygiene regulations. FREQUENCY AREA TASK DAILY Scoop Clean with neutral cleaner / rinse thoroughly MONTHLY Water filter Check dressure drop / change as needed... - Page 29 what the control lights mean PROBLEM POSSIBLE CAUSE ACTION ICE NO WATER DRAIN Making Ice Switch in “ICE” position Washing Switch in “WASH” position Switch in “WASH” position ICE lamp blinks once per second ICE lamp blinks once per second Bin Full ICE lamp blinks every 2 seconds Will turn off when sensor detects release...
-
Page 30: Troubleshooting
troubleshooting PROBLEM POSSIBLE CAUSE ACTION Ice maker not No power Unit unplugger / plug in operating Breaker thrown / rest breaker Switch in wrong position Change switch to ICE position Storage bin full Operating normally - production ceases when bin is full Room temp below 50 / raise room temp. - Page 31 XO warrants to the original purchaser of every new XO ice maker unit, the cabinet and all parts thereof, to be free from defects in material or workmanship under normal and proper use and maintenance as specified by XO and upon proper installation and start-up in accordance with the instruction packet supplied with each XO unit. XO’s obligation under this warranty is limited to a period of one (1) year from the date of original purchase.
- Page 32 SEE ALL THE LATEST XO PRODUCTS AND ACCESS PARTS AT: WWW.XOAPPLIANCE.COM...
