OPERATOR'S MANUAL
MILLCREEK MODELS:
100P and 125P PTO SPREADERS
PUBLICATION DATE: 9/1/02, Rev. 3
MILLCREEK PART # 43806
Millcreek Manufacturing Company
34 Zimmerman Road
Leola, PA 17540
Phone: 717-656-3050 / Fax: 717-556-0279
WARNING: DO NOT assemble, operate, or maintain this equipment without first
reading and understanding the information provided in this manual and the
ADMA Safety Manual for Agricultural Implement Drivelines. Failure to follow
all safety precautions as stated in these manuals may result in serious personal injury
or death.
Advertisement
Table of Contents
Related Manuals for Millcreek 100P
Summary of Contents for Millcreek 100P
- Page 1 OPERATOR'S MANUAL MILLCREEK MODELS: 100P and 125P PTO SPREADERS PUBLICATION DATE: 9/1/02, Rev. 3 MILLCREEK PART # 43806 Millcreek Manufacturing Company 34 Zimmerman Road Leola, PA 17540 Phone: 717-656-3050 / Fax: 717-556-0279 WARNING: DO NOT assemble, operate, or maintain this equipment without first reading and understanding the information provided in this manual and the ADMA Safety Manual for Agricultural Implement Drivelines.
-
Page 3: Warranty Information
Limited Warranty. High density, polyethelene floors are warranted for 20 years from cracking, rotting, splitting, or peeling. TRADEMARKS The Millcreek logo is a trademark of the Millcreek Manufacturing Company. All other brand or product names mentioned are the registered trademarks or trademarks of their respective owners. COPYRIGHT Copyright ©... -
Page 5: Table Of Contents
Beater Drive/Axle Group ....................A-16 Spreader Box Extension Sides (Model 125P Only) ............A-18 APPENDIX B: SPREADER OPTIONS PARTS REFERENCE ........B-1 Endgate Assembly (Model 100P) ................... B-2 Endgate Assembly (Model 125P) ................... B-4 Fines Pan Assembly ......................B-6 Upper Beater Assembly ....................B-8... -
Page 7: Section 1: Introduction
SECTION 1: INTRODUCTION Guide to this Manual This manual contains all the information necessary to safely operate and maintain the Millcreek 100P or 125P PTO Spreader. Consult the Table of Contents for a detailed list of topics covered. You'll find this manual's step-by-step procedures easy to follow and understand. - Page 8 Be sure to keep the safety decals clean and readable. If the decals ever become damaged or illegible, contact your Millcreek dealer for replacements.
-
Page 9: Inspection And Warranty Registration
Most spreader models are shipped from your Millcreek Dealer completely assembled and ready for operation. Inspect your new spreader thoroughly upon receipt to ensure that it has been shipped to you in a satisfactory manner. Immediately notify the freight company and your Millcreek dealer in case of shipping damage, shortage(s), and/or errors. - Page 10 Operator's Manual: Millcreek 100P & 125P PTO Spreaders...
-
Page 11: Section 2: Attaching The Spreader To The Tractor
Operator's Manual: Millcreek 100P & 125P PTO Spreaders SECTION 2: ATTACHING THE SPREADER TO THE TRACTOR Connecting the Spreader Hitch to the Tractor Hitch The spreader hitch is designed to work with a standardized tractor hitch. To connect the spreader hitch to the tractor hitch, refer to Figure 2A and adhere to the following guidelines: •... -
Page 12: Attaching The Spreader To The Tractor Pto
Assembling the Safety Chain NOTE: The safety chain may be ordered as an optional component for the Millcreek 100P/125P PTO Spreaders and is strongly recommended if the spreader is to be moved any time on a public roadway. -
Page 13: Section 3: Operation
Operator's Manual: Millcreek 100P & 125P PTO Spreaders SECTION 3: OPERATION Understanding Spreader Operation Proper and safe operation of the Millcreek 100P/125P Spreader requires: (1) being familiar with the spreader's operating components and (2) heeding all safety precautions as stated in this manual. The Spreader Operating Components By definition, the left and right sides of the spreader are determined while sitting on the tractor seat. - Page 14 Operator's Manual: Millcreek 100P & 125P PTO Spreaders...
-
Page 15: Section 4: Maintenance & Adjustment
WARNING: All shields must be replaced after maintenance or adjustment procedures are performed. Failure to do so could result in serious personal injury or death. Performing regular maintenance on you Millcreek Spreader will help ensure optimal performance. Please follow these guidelines for maintaining your spreader: •... - Page 16 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Guidelines for Regular Maintenance (continued) • Check that implement tires have adequate air pressure. • Inspect the safety chain regularly to check the condition of the links and locking/hooking mechanisms; replace the chain as soon as weakness/breakage is noted.
-
Page 17: Procedures For Spreader Adjustment
Operator's Manual: Millcreek 100P & 125P PTO Spreaders Procedures for Spreader Adjustment Problems with spreader operation may indicate that certain adjustments are required to restore proper functioning. The following procedures address common problems which may be encountered in spreader operation. - Page 18 Operator's Manual: Millcreek 100P & 125P PTO Spreaders...
-
Page 19: Appendix A: Parts Reference
Operator's Manual: Millcreek 100P & 125P PTO Spreaders APPENDIX A: PARTS REFERENCE The following information is provided for your reference in understanding how the spreader is assembled and how spare parts can be identified and ordered properly. General Spreader Specifications... -
Page 20: Ordering Information
Operator's Manual: Millcreek 100P & 125P PTO Spreaders Ordering Information When ordering replacement parts, please provide the following information to your local Millcreek dealer: • Model and Serial Number of the unit (located on the front right corner of the spreader) •... - Page 21 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Spreader Box Assembly (continued) Item # Millcreek Part # Qty. Component Description 260635 Right Rear Shield 260444 Gear Box Shield 260583 Front Shield 260442 Side Shaft Shield 260386 Left Beater Shield 34234...
-
Page 22: Hitch And Jack Assemblies
Operator's Manual: Millcreek 100P & 125P PTO Spreaders Hitch & Jack Assemblies Figure A2 - Hitch and Jack Parts Detail... - Page 23 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Hitch & Jack Assemblies (continued) Item # Millcreek Part # Qty. Component Description 260432 Beater Guard 34203 5/16 Lock Washer 34020 5/16 Nut 34221 5/16 x 1 Bolt 34199 3/8 x 1 Bolt 34035 ½...
-
Page 24: Wheel And Hub Assembly
Operator's Manual: Millcreek 100P & 125P PTO Spreaders Wheel and Hub Assembly Figure A3 - Wheel and Hub Assembly Parts Detail... - Page 25 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Wheel and Hub Assembly (continued) Item # Millcreek Part # Qty. Component Description 215158 Grease Seal 215203 Outer Bearing Cone 215162 Hub (includes items 12, 13) 215164 Washer 215161 Dust Cap 215160...
-
Page 26: Pto Drive Line Assembly
Operator's Manual: Millcreek 100P & 125P PTO Spreaders PTO Drive Line Assembly Figure A4 - PTO Drive Line Assembly Parts Detail... - Page 27 Operator's Manual: Millcreek 100P & 125P PTO Spreaders PTO Drive Line Assembly (continued) Item # Millcreek Part # Qty. Component Description 34214 1/4 x 1 Bolt 210144 Spherical Bearing 260370 Side Shaft 210131 1/4 x 1-1/4 Key 34200 5/16 x 3/4 Bolt...
-
Page 28: Pto Shaft Assembly
Operator's Manual: Millcreek 100P & 125P PTO Spreaders PTO Shaft Assembly Figure A5 - PTO Shaft Assembly Parts Detail A-10... - Page 29 Operator's Manual: Millcreek 100P & 125P PTO Spreaders PTO Shaft Assembly (continued) Item # Millcreek Part # Qty. Component Description 210164 Complete PTO Shaft 210285 5 Rib Shield Cone 210286 Outer Shield Tube 210291 Safety Chain 210290 Inner Shield Tube...
-
Page 30: Apron Chain And Sprocket Assembly
Operator's Manual: Millcreek 100P & 125P PTO Spreaders Apron Chain and Sprocket Assembly Figure A6 - Apron Chain and Sprocket Assembly Parts Detail A-12... - Page 31 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Apron Chain and Sprocket Assembly (continued) Item # Millcreek Part # Qty. Component Description 260269 Slot Cover 220101 Lube Fitting 260276 Idler Bracket (includes item 2) 210154 Idler Sprocket 260271 J-Bolt 34018...
-
Page 32: Apron Drive Group
Operator's Manual: Millcreek 100P & 125P PTO Spreaders Apron Drive Group A-14... - Page 33 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Apron Drive Group (continued) Item # Millcreek Part # Qty. Component Description 260278 Sprocket Bracket 220101 Lube Fitting 34209 Cotter Pin 34201 3/4 SAE Washer 34018 3/8 Washer 34141 3/8 Lock Washer...
-
Page 34: Beater Drive/Axle Group
Operator's Manual: Millcreek 100P & 125P PTO Spreaders Beater Drive/Axle Group A-16... - Page 35 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Beater Drive/Axle Group (continued) Item # Millcreek Part # Qty. Component Description 34241 3/8 x 4-1/2 Bolt 34018 3/8 Washer 210130 1/4 x 1 Key Set Screw 210159 12 Tooth Sprocket (includes item 4)
-
Page 36: Spreader Box Extension Sides (Model 125P Only
Operator's Manual: Millcreek 100P & 125P PTO Spreaders Spreader Box Extension Sides (Model 125P ONLY) Figure A9 - Extension Sides for Model 125P Parts Detail Item # Millcreek Part # Qty. Component Description 34003 1/4 Nut 34235 1/4 Lock Washer... -
Page 37: Appendix B: Spreader Options Parts Reference
End Gate* • Fines Pan • Upper Beater *NOTE: In this section, two End Gates are shown--one for the Model 100P, and one for the Model 125P. Be sure to reference the appropriate parts list and drawing for your model spreader. - Page 38 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Endgate Assembly for Model 100P Spreaders Figure B1 - Model 100P Endgate Parts Detail...
-
Page 39: Endgate Assembly (Model 100P
Operator's Manual: Millcreek 100P & 125P PTO Spreaders Endgate Assembly (Model 100P) (continued) Item # Millcreek Part # Qty. Component Description 34234 1/4 x 3/4 Bolt 34199 3/8 x 1 Bolt 34259 3/8 x 3 Bolt 260554 Endgate Hinge 34211... - Page 40 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Endgate Assembly for Model 125P Spreaders Figure B2 - Model 125P Endgate Parts Detail...
-
Page 41: Endgate Assembly (Model 125P
Operator's Manual: Millcreek 100P & 125P PTO Spreaders Endgate Assembly (Model 125P) (continued) Item # Millcreek Part # Qty. Component Description 34234 1/4 x 3/4 Bolt 34199 3/8 x 1 Bolt 260599 Hinge 34259 3/8 x 3 Bolt 34094 1/2 Washer... -
Page 42: Fines Pan Assembly
Operator's Manual: Millcreek 100P & 125P PTO Spreaders Fines Pan Assembly Figure B3 - Fines Pan Assembly Parts Detail... - Page 43 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Fines Pan Assembly (continued) Item # Millcreek Part # Qty. Component Description 34234 1/4 x 3/4 Bolt 34052 1/4 Washer 260434 Rubber Hold Down 260435 Rubber Strip 260577 Hinge Bracket 260894 Fines Pan...
-
Page 44: Upper Beater Assembly
Operator's Manual: Millcreek 100P & 125P PTO Spreaders Upper Beater Assembly Figure B4 - Upper Beater Assembly Parts Detail... - Page 45 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Upper Beater Assembly (continued) Item # Millcreek Part # Qty. Component Description 260823 Upper Beater 34200 5/16 x 3/4 Bolt 260899 Right Beater Bracket 210144 Spherical Bearing 34203 5/16 Lock Washer 34020...
- Page 46 Operator's Manual: Millcreek 100P & 125P PTO Spreaders B-10...
