Millcreek 100P Operator's Manual

Pto spreaders

Hide thumbs Also See for 100P:

Operator's manual (46 pages)

Table of Contents

Quick Links

Download this manual

OPERATOR'S M A N U A L

M I L L C R E E K MODELS:

1 0 0 P a n d 1 2 5 P PTO SPREADERS

Millcreek Manufacturing Company

525 Reservoir Road

Honey Brook PA, 19344

800-311-1323

Phone:

WARNING:

ADMA

Table of Contents

Need help?

Do you have a question about the 100P and is the answer not in the manual?

Questions and answers

Summary of Contents for Millcreek 100P

Page 1 OPERATOR'S M A N U A L M I L L C R E E K MODELS: 1 0 0 P a n d 1 2 5 P PTO SPREADERS Millcreek Manufacturing Company 525 Reservoir Road Honey Brook PA, 19344...
Page 3 TABLE OF CONTENTS & l 1 00 n As...
Page 4 125P SECTION INTRODUCTION Guide to this Manual lOOP NOTE: Procedures provided in this manual apply to both spreader models (Model 100P and Model 125P) unless specifically noted otherwise. For Your Safety. . . • NOTE: • ATTENTION: CAUTION: WARNING: DANGER!
Page 5 Operator's Manual: Millcreek 100P & 125P PTO Spreaders For Your Safety... (continued) the following general precautions apply and must be heeded for proper, safe operation. WARNING: WARNING: WARNING: WARNING: WARNING: WARNING: WARNING: ATTENTION: C AU T I O N DANGER...
Page 6 Operator's Manual: Millcreek lO0P & 125P PTO Spreaders inspection Warranty Registration NOTE: Supplemental Dealer's Instructions f o r Unpacking and Assembly. within 30 d a y s For your safety, be sure locate all safety decals and review their content before proceeding with operating the spreader.
Page 7 Operator's Manual: Millcreek 100P & 125P PT O Spreaders SECTION 2: ATTACHING THE S P R E A D E R TO THE TRACTOR Connecting the Spreader Hitch to the Tractor Hitch .l),. WARNING: r if a properly-sized (3/4" diameter) hitch pin...
Page 8 Assembling the Safety Chain NOTE: The s a f e ty chain m a y be ordered as an optional component for the Millcreek 100P/125P PTO Spreaders and i s strongly recommended...
Page 9: Operation
Operator's Manual: Millcreek 100P & 125P PTO Spreaders S E C T I O N 3 : OPERATION Understanding Spreader Operation The Spreader Operating Components Operating the Spreader. Guidelines for Loading the Spreader for Operation • ATTENTION: Operating the Spreader...
Page 10: Maintenance And Adjustment
Operator's Manual: Millcreek 100P & 125P PTO Spreaders SECTION 4: MAINTENANCE & ADJUSTMENT Guidelines for Regular Maintenance WARNING: ATTENTION: • ATTENTION: v ry IO l ATTENTION: fitt fitt he fi O NOT -- h W o rn fa t r.) grease fittings that will not hold the gun and/or fittings with a stuck check ball must be replaced.
Page 11 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Guidelines for Regular Maintenance (continued) Procedure for checking/adjusting the floor apron chain: front Make sure that the chains on each side o f the apron are equally taut. I I I Figure...
Page 12 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Procedures for Spreader Adjustment Adjusting the Apron Speed Note that the factory setting at the slow speed which holds every second notch. Maximum Apron Chain Speed: For Slower Apron Chain Speed: EI F T...
Page 13: Parts Reference
Operator's Manual: Millcreek 100P & 125P PTO Spreaders A P P E N D I X A: PARTS REFERENCE The following information is provided for your reference in understanding how the spreader is assembled and how spare parts can be identified an d ordered properly.
Page 14: Ordering Information
Operator's Manual: Millcreek 100P & 125P PTO Spreaders Ordering information When ordering replacement parts, please provide the following information to your local Millcreek dealer: • Model an d Serial Number of the unit (located on the front right comer of the spreader) •...
Page 15 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Spreader Box Assembly (continued) Millcreek Part Qty. Component Description Item...
Page 16 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Hitch Jack Assemblies & - - - - - - - - - _,.,- Figure A2 - Hitch and Jack Parts Detail...
Page 17 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Hitch & Jack Assemblies (continued) Item # Millcreek Part # Component Description...
Page 18: Wheel And H U B Assembly
Operator's Manual: Millcreek 100P & 125P PTO Spreaders Wheel and H u b Assembly Figure A3 - Wheel and Hub Assembly Parts Detail...
Page 19 Operator's Manual: Millcreek 100P 125P PTO Spreaders & Wheel and Hub Assembly (continued) Item Millcreek Part# Qty. Component Description...
Page 20: Pto Drive Line Assembly
Operator's Manual: Millcreek 100P 125P PT O Spreaders & PTO Drive Line Assembly Figure A 4 - P T O Drive Line Assembly Parts Detail...
Page 21 Operator's Manual: Millcreek 100P & 125P PTO Spreaders PTO Drive Line Assembly (continued) Component Description Millcreek Part # Item #...
Page 22: Pto Shaft Assembly
Operator's Manual: Millcreek 100P & 125P PTO Spreaders PTO Shaft Assembly ft ~ > '' l' '," / ij / Figure A5 -PTO Shaft Assembly Parts Detail A-10...
Page 23 Operator's Manual: Millcreek 100P 125P PT O Spreaders & PTO Shaft Assembly (continued) Item Millcreek Part Qty. Component Description A-11...
Page 24 Operator's Manual: Millcreek 100P & 125P PT O Spreaders Apron Chain and Sprocket Assembly ''"'�- Figure A6 - Apron Chain and Sprocket Assembly Parts Detail A-12...
Page 25 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Apron Chain and Sprocket Assembly (continued) Component_Description Millcreek Part Item # A-13...
Page 26 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Apron Drive Group £ -" A-14...
Page 27 & Apron Drive Group (continued) Qty. 1 Washer A-15...
Page 28 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Beater Drive/Axle Group • - � "' '"' "' '"' " " . ± c aape '"' £ �/I < • A-16...
Page 29 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Beater Drive/Axle Group (continued) # Qty. Item Mi[lereek Part Component Description A-17...
Page 30 Operator's Manual: Millcreek 100P & 125P PT O Spreaders Spreader Box Extension Sides (Model 125P ONLY) -86102 Figure A9 - Extension Sides Model 125P Parts Detail Component Description Millcreek Part It e m # 1/ 4 Nut 34003 1/4 Lock Washer...
Page 31 Operator's Manual: Millcreek 100P & 125P PTO Spreaders APPENDIX B : SPREADER OPTIONS PARTS R E F E R E N C E Model 1 OOP and 125P Spreader Options NOTE: , and 1 2 5 P . parts li...
Page 32 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Endgate Assembly for Model 1 0 0 P Spreaders � S CC 2 0 Figure BI - Model lOOP Endgate Parts Detail...
Page 33 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Endgate Assembly (Model 100P) (continued) Component Description Item Millcreek Part # Oty.
Page 34 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Endgate Assembly for Model 1 2 5 P Spreaders Figure B2 - Model 125P Endgate Parts Detail...
Page 35 Operator's Manual: Millcreek 10OP & 125P PTO Spreaders Endgate Assembly (Model 125P) (continued) Item #...
Page 36 Operator's Manual: Millcreek 100P & 125P PTO Spreaders Fines Pan Assembly -8610.3 Figure B3 - Fines Pan Assembly Parts Detail...
Page 37 Operator's Manual; Millcreek 100P & 125P PTO Spreaders Fines Pan Assembly (continued) Item Millcreek Part Component Description...
Page 38 Operator's Manal: Millcreek 100P & 125P PTO Spreaders Upper Beater Assembly Figure B4 - Upper Beater Assembly Parts Detail...
Page 39: Component Description
Operator's Manual: Millcreek 100P & 125P PTO Spreaders Upper Beater Assembly (continued) Component Description Millcreek Part # Item #...
