- Page 1 All manuals and user guides at all-guides.com E l } 4 c u OPERATOR'S M A N U A L M I L L C R E E K MODELS: 6700P and 8700P PTO SPREADERS � [ 8) • 1-86194 525 Reservoir Road...
-
Page 2: Warranty Information
All manuals and user guides at all-guides.com WARRANTY INFORMATION This Warranty is made in lieu o f all other warranties, expressed or implied, including any warranty of merchantability and fitness for use and purpose and o f all other obligations or liabilities on the Company part and any implied warranty. - Page 3 All manuals and user guides at all-guides.com TABLE OF CONTENTS ..s . » s . . s . . . s o ..s s ......
-
Page 4: Guide To This Manual
All manuals and user guides at all-guides.com Operator's Manual: Millcreek 6700P 8700P PTO Spreaders & SECTION 1 : INTRODUCTION Guide to this Manual NOTE: Procedures provided in this manual apply to spreader models (Model 67000P and Model 8700P) unless specifically noted otherwise. - Page 5 All manuals and user guides at all-guides.com Operator's Manual: Millcreek 6700P & 8700P PTO Spreaders For Your Safety... (continued) the following general precautions apply and must heeded for proper, safe operation. WARNING: WARNING: .41:9. WARNING: .41:9. WARNING: WARNING: WARNING: WARNING:...
- Page 6 All manuals and user guides at all-guides.com & 8700P PTO Spreaders Operator's Manual: Millcreek6700P Safety Labels (continued) Spreader Safety Labels 42792 42710 42756 42772 42783 42778 42779/42780 42786/42787 42778 42783 42778 NOTE: Label 42756 i s provided i n three locations: on rear side shield (as shown), behind the rear side shield, and behind 42778...
-
Page 7: Entanglement Hazards
All manuals and user guides at all-guides.com Operator's Manual: Millcreek 6700P & 8700P PTO Spreaders Safety Labels (continued) N O RIDERS_, D A N G E R W A R N I N G WARNING Entanglement Hazards Moving parts can crush or cut. - Page 8 All manuals and user guides at all-guides.com Operator's Manual: Millcreek 6700P & 8700P PTO Spreaders inspection Warranty Registration NOTE: Supplemental Assembly Instructions. optional endgate ur s e d r. qu r w rran gi tr within 30 d a y s...
-
Page 9: Attaching The Spreader
All manuals and user guides at all-guides.com Operator's Manna!: Millcreek 6700P & 8700P PTO Spreaders SECTION 2: ATTACHING THE SPREADER TO T H E TRACTOR Connecting the Spreader to the Tractor WARNING: ATTENTION: 36 to 5 1 inches the "U" joints. - Page 10 All manuals and user guides at all-guides.com Operator's Manual: Millcreek 6700P 8700P PTO Spreaders &: Attaching the Spreader PTO to the Tractor PTO WARNING: a:tt.
-
Page 11: Operation
All manuals and user guides at all-guides.com Operator's Manual: Millcreek 6700P & 8700P PTO Spreaders SECTION 3: OPERATION Understanding Spreader Operation The Spreader Operating Components Operating the Spreader. Guidelines for Loading the Spreader for Operation • ATTENTION: Operating the Spreader... -
Page 12: Maintenance And Adjustment
All manuals and user guides at all-guides.com Operator's Manual: Millereek 6700P & 8700P PTO Spreaders SECTION 4: MAINTENANCE & ADJUSTMENT Guidelines for Regular Maintenance WARNING: ATTENTION: ATTENTION: ATTENTION: Hardware Torque5Specification Front Drive Assembly Parts Detail... - Page 13 All manuals and user guides at all-guides.com Operator's Manual: Millcreek 6700P & 8700P PTO Spreaders Guidelines for Regular Maintenance (continued) Procedureforchecking/adjustingthefloor apron chain; NOTE: front roper tension is . Make sure that the chains on each side o fthe v d.
-
Page 14: Procedures For Spreader Adjustment
All manuals and user guides at all-guides.com Operator's Manual: Millcreek 6700P & 8700P PTO Spreaders Procedures for Spreader Adjustment Adjusting the Holding Pawl To Reset the Holding Pawl (refer to Figure 4B): g pawl. Short Link Loosen Tighten Crank Arm Sprocket... - Page 15 All manuals and user guides at all-guides.com Operator's Manual: Millcreek 6700P & 8700P PTO Spreaders Procedures Spreader Adjustment (continued) Adjusting the Drive Chains NOTE: Refer t o Figure 4B • Check the drive chains in two positions: Gearbox to Beater Chain:...
-
Page 16: Parts Reference
All manuals and user guides at all-guides.com Operator's Manual: Millcreek 6700P &. 8700P PTO Spreaders APPENDIX A: PARTS R E F E R E N C E The following information is provided for your reference in understanding how the spreader is assembled and how spare parts can be identified and ordered properly. -
Page 17: Ordering Information
All manuals and user guides at all-guides.com Operator's Millcreek 6700P & 8700P PTO Spreaders Manual: Ordering Information Hitch Assembly 1 - 8 5 1 83 Figure A1 - Hitch Assembly Parts Detail... - Page 18 All manuals and user guides at all-guides.com Operator's Mannal: Millcreek 6700P 8700P PTO Spreaders & Hitch Assembly (continued) Qty. Component Description I t e m # MC Part# & &...
- Page 19 All manuals and user guides at all-guides.com Operator's Manual: Millcreek 6700P & 8700P PTO Spreaders Wheel and Hub Assembly 1-86074 Figure A2 - Wheel and Hub Assembly Parts Detail...
- Page 20 All manuals and user guides at all-guides.com Operator's Manual: Millcreek 6700P & 8700P PTO Spreaders Wheel and Hub Assembly (continued) Qty. C o m p o n e n t Description P a rt # t e m #...
- Page 21 All manuals and user guides at all-guides.com Operator's Manual: Millcreek 6700P & 8700P PTO Spreaders Rear Drive Assembly Figure A3 - Rear Drive Assembly Parts Detail...
- Page 22 All manuals and user guides at all-guides.com Operator's Manual: Millcreek 6700P 8700P PTO Spreaders & Assembly (continued) Rear Drive Q t y. Component Description MC Part 261227 1-1/2Washer 1 - 1 / 8 Washer x 3/4 Carriage 1-1/8"2-Flange Bearing 210428...
- Page 23 All manuals and user guides at all-guides.com Operator's Manual: Millereek 6700P & 8700P PTO Spreaders Front D rive Assembly Figure A4-Front Drive Assembly Parts Detail...
- Page 24 All manuals and user guides at all-guides.com & Front Drive Assembly (continued) Component Description Part Qty.
- Page 25 All manuals and user guides at all-guides.com Operator's Manual: Millcreek 6700P & 8700P PTO Spreaders Apron Chain Sprocket Assembly ·,' • • Figure A5 - Apron Chain and Sprocket Assembly Parts Detail A-10...
- Page 26 All manuals and user guides at all-guides.com Operator's Manual: Millcreek 6700P & 8700P PTO Spreaders Apron Chain and Sprocket Assembly (continued) Qty." Component Description t e m # Part lies fo **NOTE; A-11...
- Page 27 All manuals and user guides at all-guides.com Operator's Manual: Millcreek 6700P & 8700P PTO Spreaders Safety Shields & Guards Figure A6-Safety Shields aud Guards Parts Detail A-12...
- Page 28 All manuals and user guides at all-guides.com Operator's Manual: Millcreek 6700P 8700P PTO Spreaders & Safety Shields (continued) Qty. Component Description ltem Part A-13...
-
Page 29: Pto Shaft Assembly
All manuals and user guides at all-guides.com Operator's Manual: Millcreek 6700P & 8700P PTO Spreaders PTO Shaft Assembly -86090 Figure A7-PTO Shaft Assembly Parts Detail A-14... - Page 30 All manuals and user guides at all-guides.com Operator's Manual: Millcreek 6700P & 8700P PTO Spreaders PTO Shaft Assembly (continued) Qty. Component Description Item Part A-15...
- Page 31 All manuals and user guides at all-guides.com Operator's Manual: Millcreek 6700P & 8700P PTO Spreaders APPENDIX B: OPTIONS SPREADER PARTS R E F E R E N C E Model 6700P/8700P Spreader Options • Safety Chain...
- Page 32 All manuals and user guides at all-guides.com Operator's Manual: Millcreek 6700P 8700P PTO Spreaders & Endgate Assembly 1-86190 Figure B1 - Endgate Parts Detail Qty. Component Description P a rt # Item# Endgate Handle 261365 5/16 Flange Nut 34367 5/16...
- Page 33 All manuals and user guides at all-guides.com Operator's Manual: Millcreek 6700P & 8700P PTO Spreaders C h a i n Assembly Safety NOTE: 6700P/8700P WARNING: Safety Chain Kit Millcreek Part# 261494 Item# Part# Description 215299 Chain 34254 1/2 2 Bolt...
