Summary of Contents for Speedata J-COM SD55
-
Page 2: Appearance And Keypad
SD55LG Quick start guide_Beta_V1. 0 Appearance and Keypad Pilot lamp Microphon Flash lamp Flashlight SIM card Volume + Volume - &SD card Scanning Hot key Wireless charging 第2页，共 12 页... -
Page 3: Wifi & Network
SD55LG Quick start guide_Beta_V1. 0 SIM Card 1 Dual SIM cards use standard Nano-SIM cards. Please use professional equipment to open the SIM card cage to avoid damage to the equipment and affect the protection performance. 2 When placing the SIM card, the position of the notch is placed into the card slot toward the upper left, and the buckle is pushed to the "Lock"... - Page 4 SD55LG Quick start guide_Beta_V1. 0 Basic Settings Click "Settings"-"Scan" to enter the scan settings. Turn on / off the barcode scanning function. Scan engine on/off: Results of scanned barcode displayed at focus. Out to Cursor： After the barcode scanning is finished, the tone will sound. Scan Sound：...
- Page 5 SD55LG Quick start guide_Beta_V1. 0 Add custom prefix: add custom characters, numbers, letters, etc. before the barcode output (add for demonstration) Add a custom suffix: add custom characters, numbers, letters, etc. after the setting:Configure the barcode parameters of one-dimensional and two-dimensional code. barcode output (add for demonstration) Code 第5页，共...
- Page 6 SD55LG Quick start guide_Beta_V1. 0 ■__________ < * ・• T” Artec Code dniii 口 Codell Hsn xin Code Codt124 Code UK ODiCcdo ^■Nlcodv 顷 的 MicmPCMi Micro OR Cod» CodatHir PDFill7 2-c>f-5 Cede 贓 !i<HW EAKl-13 Choose code-1 d-EAN-13-Enable such as the scan result after scanning "EAN-13" barcode, one less. You can select "EAN-13"...
- Page 7 SD55LG Quick start guide_Beta_V1. 0 enabled,the result show 12345678901,and when the "Check transmit Digit" is enable,the result show 123456789012. Choose code-1 d-Code39-Enable such as the scan result after scanning "Code39" barcode, one less. You can select "Code39" type, enable "Transmit Start/Stop Characters ", and scan later the results show normal.
- Page 8 SD55LG Quick start guide_Beta_V1. 0 Check update:Show scan hand type.And can check update after connecting to the internet. Note: "Check update"requires the scanning service version 5. 1 or higher. This is used to set a custom broadcast. Custom broadcast:action: This is used to set a custom broadcast content. Custom broadcast barcode:key: This is used to set a custom broadcast type.
-
Page 9: Product Parameters
SD55LG Quick start guide_Beta_V1. 0 2 It is recommended not to operate the devices while charging, and not to cover objects on the device and charger. 3 When the device is in low power, there will be an indicator light and a desktop pop-up reminder. - Page 10 SD55LG Quick start guide_Beta_V1. 0 Resolution ： 720 * 1440 Type: IPS Pixel Density : 320 Touch screen: 5-point touch screen Processor CPU: Octa-core, 8*2.0 GHz Android 8.1 Memory RAM: 4GB ROM: 64GB Micro SD Extension max128GB Battery 4500mAh Typical value Charging: 2.0 fast charging, full no more than 4 hours Wireless charging QI standard Camera...
- Page 11 SD55LG Quick start guide_Beta_V1. 0 B2/B3/B5/B8 CDMA 1x/CDMA2000 BC0 Data connect WI-FI: 802.11a/b/g/n 2.4G & 5G WI-FI hotspot: support Support card reader mode, peer-to-peer mode, card emulation mode NFC: 14443A/B, ISO 15693, NFC Bluetooth: BT4.0 fast charging USB: Type-C, OTG, USB tethering, USB Location GPS/GLONASS /Beidou Barcode...
- Page 12 SD55LG Quick start guide_Beta_V1. 0 Sensor Gravity sensor Light sensor Gyroscope sensor Geomagnetic sensor Packing list Standard: SD55 (with battery) X 1 Power Adapter X 1 USB Type-C cable X 1 Instruction manual X 1 CONTACT US 86-18682381750 Phone: info@speedatagroup.com E-mail: www.jcombyspeedata.com Website...
