INVERTER
FR-E700
INSTRUCTION MANUAL (BASIC)
FR-E720-0.1KSC to 15KSC
FR-E740-0.4KSC to 15KSC
FR-E720S-0.1KSC to 2.2KSC
Thank you for choosing this Mitsubishi Inverter.
This Instruction Manual (Basic) provides handling information and precautions for use of the equipment.
OUTLINE ...................................................................................1
1
INSTALLATION AND WIRING ...................................................6
2
PRECAUTIONS FOR USE OF THE INVERTER.........................20
3
4
DRIVING THE MOTOR.............................................................23
5
6
PARAMETERS .........................................................................34
7
TROUBLESHOOTING ..............................................................39
8
9
SPECIFICATIONS ....................................................................46
10
To obtain the Instruction Manual (Applied) and the
Safety stop function instruction manual
Contact where you purchased the inverter, your Mitsubishi sales
representative, or the nearest Mitsubishi FA Center for the following
manual:
 Instruction Manual (Applied) [IB(NA)-0600277ENG]
 Safety stop function instruction manual [BCN-A211508-004]
These manuals are required if you are going to utilize functions and
performance.
The PDF versions of these manuals are also available for download at
"MELFANS Web," the Mitsubishi Electric FA network service on the
world wide web (URL: http://www.MitsubishiElectric.co.jp/melfansweb).
CONTENTS
700
1
2
3
4
5
6
7
8
9
10
