9963013COM/ 9963815COM/
9963872COM
Franklin Wide Nighstand
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
People needed for assembly: 2
Follow Ameriwood Home
Tube
B349963XXXCOM00MHT
You
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ameriwood HOME Franklin 9963013COM
Summary of Contents for Ameriwood HOME Franklin 9963013COM
- Page 1 Visit: www.ameriwoodhome.com WARNING People needed for assembly: 2 Follow Ameriwood Home - Unit can tip over causing severe injury or death. - Anchor unit to stud in wall (if instructed to). - Do Not allow children to climb on unit.
-
Page 2: Helpful Hints
Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Call us! 1-800-489-3351 Visit ameriwoodhome.com Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 2 ESTIMATED ASSEMBLY TIME: 1.0 HOUR - Open your item in the area you plan to keep it to avoid excessive heavy lifting. - Identify, sort and count the parts before attempting assembly. -
Page 3: Before You Start
Before You Start Read through each step carefully and follow the proper order. Separate and count all your parts and hardware. Give yourself enough room for the assembly process. Have the following tools: #2 Phillips Head Screwdriver and Hammer. Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight. - Page 4 Before You Start Please Note: You may need to lightly tap the wood dowels with a hammer into the holes during your assembly process. Wood Dowel Insertion: Insert wood dowel completely into the hole. Not Actual Size Wood dowel will extend out approximately 3/8".
-
Page 5: Board Identification
Board Identification Not Actual Size Top Panel Left Panel Right Panel Shelf QTY: 1 PC QTY: 1 PC QTY: 1 PC QTY: 1 PC Back Frame Front Frame Drawer Front Panel Drawer Lefl Side Panel QTY: 1 PC QTY: 1 PC QTY: 1 PC QTY: 1 PC Drawer Right Side Panel... - Page 6 Board Identification Not Actual Size For any replacement hardware, see page 7 ameriwoodhome.com Tube...
-
Page 7: Part Number Reference
Part List Part Number Reference Each part has a unique part number. Please reference the appropriate part number when contacting customer service for replacement parts. Before throwing any packaging, please verify all contents and make sure you have received all the parts listed on previous pages!. - Page 8 Part List Actual Size M6X33 mm Ø8X30 mm Ø4X30 mm × 12 × 4 × 25 Wood dowel Screw Cam bolt Ø4X25 mm Ø5/32"X20 mm × 4 × 3 Screw Bolt Not Actual Size Ø15X10 mm × 25 × 4 Cam lock Drawer Knob For any replacement...
- Page 9 Part List Hardware Number Reference Each part has a unique part number. Please reference the appropriate part number when contacting customer service for replacement parts. Before throwing any packaging, please verify all contents and make sure you have received all the parts listed on previous page!.
- Page 10 STEP M6X33 mm × 4 Cam bolt · Attach four Small Cam Bolts (1) into the Drawer Front Panel (G) as illustrated. Do NOT over-tighten. ameriwoodhome.com Tube...
- Page 11 STEP Quick Assembly LOCK Ø15X10 mm × 4 Proper orientation of CAM LOCK Cam lock · Attach Drawer Side (H), (I) to Drawer Front Panel (G) with four Small Cam Locks (6) as illustrated. ameriwoodhome.com Tube...
- Page 12 STEP · Insert Drawer Bottom Panel (J) firmly into slot on Drawer Side Panel (H), (I) and Drawer Front Panel (G) as illustrated. · Insert Drawer Support (L) firmly to Drawer Front Panel (G) as illustrated. ameriwoodhome.com Tube...
- Page 13 STEP Ø4X30 mm × 4 Screw · Lay Drawer Back Panel (K) firmly into Drawer Support (L) and Drawer Bottom Panel (J) as illustrated. · Use four Screws (5) to attach Drawer Side (H), (I) to Drawer Back Panel (K) as illustrated. ameriwoodhome.com Tube...
- Page 14 STEP Ø5/32"X20 mm × 4 × 4 Drawer Knob Screw bolt · Attach four Drawer Knobs (7) to Drawer Front (G) with four Screw bolts (5) as illustrated. ameriwoodhome.com Tube...
- Page 15 STEP M6X33 mm × 21 Cam bolt · Attach twenty-one Cam Bolts (1) into the Top Panel (A), Left Panel (B), Right Panel (C), Back Frame (E) & Front Frame (F) as illustrated. Do NOT over-tighten. ameriwoodhome.com Tube...
- Page 16 STEP Ø8X30 mm Dowels extend out 3/8".For × 12 more details, please see Wood dowel page 4 · Insert twelve Wood Dowels (2) into boards (B), (C) and (D) as illustrated. FRONT ameriwoodhome.com Tube...
- Page 17 STEP Quick Assembly Ø15X10 mm LOCK × 4 Proper orientation of CAM LOCK Cam lock · Attach Panel (B), (C) to Shelf (D) with four Cam Locks (6) as illustrated. FRONT FRONT ameriwoodhome.com Tube...
- Page 18 STEP Quick Assembly Ø15X10 mm LOCK × 6 Proper orientation of CAM LOCK Cam lock · Attach sample finished at Step 8 to Back Frame (E) with six Cam Locks (6) as illustrated. FRONT FRONT ameriwoodhome.com Tube...
- Page 19 STEP Quick Assembly Ø15X10 mm LOCK × 6 Proper orientation of CAM LOCK Cam lock · Attach Front Frame (F) to sample finished at Step 9 with six Cam Locks (6) as illustrated. ameriwoodhome.com Tube...
- Page 20 STEP Quick Assembly Ø4X25 mm Ø15X10 mm LOCK × 6 × 3 Proper orientation of CAM LOCK Cam lock Screw · With 2 people, turn the sample finished at Step 10 upright. · Attach Top Panel (A) to sample finished at Step 10 with six Cam Locks (6) and three Screws (3) as illustrated.
- Page 21 STEP · Insert drawer box finished at Step 5 to sample finished at Step 11 as illustrated. Slide track Slide runner ameriwoodhome.com Tube...
- Page 22 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. Warning: Risk of injury to persons - do not place a television on this furniture. This furniture is not approved for use with a television.
- Page 23 Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You" to all of our customers for taking the time to assemble this Ameriwood Home product, and to give us your valuable feedback. ameriwoodhome.com Tube...
- Page 24 Español Cubierta Delantera Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-800-489-3351 (Gratis) Visitar: www.ameriwoodhome.com PRECAUCION Este mueble puede volcarse y causar graves heridas y/o muerte.
- Page 25 Español Identificación de los Paneles (Página 5-7) - Cada pieza tiene un número de pieza único. Consulte el número de pieza correspondiente cuando se ponga en contacto con el servicio de atención al cliente para obtener piezas de repuesto. - Antes de tirar cualquier embalaje, verifique todo el contenido y asegúrese de haber recibido todas las piezas enumeradas anteriormente.
- Page 26 Visite el sitio web de su distribuidor local, califique el producto que compró y déjenos sus comentarios. Nos gustaría enviar un gran "Agradecimiento" a todos nuestros clientes por tomarse el tiempo de ensamblar este producto de Ameriwood Home, y por darnos sus valiosos comentarios. Gracias ameriwoodhome.com...
- Page 27 Français Couverture Avant CE LIVRET D'INSTRUCTION CONTIENT DES INFORMATIONS IMPORTANTES SUR LA SÉCURITÉ. VEUILLEZ LIRE ET GARDER POUR UNE RÉFÉRENCE FUTURE Ne retournez pas ce produit! Contactez notre équipe de service à la clientèle amicale d'abord pour obtenir de l'aide. Appelez-nous: 1-800-489-3351 (sans frais) - Visitez: www.ameriwoodhome.com ATTENTION Le meuble peut basculer et causer des blessures graves ou la mort.
- Page 28 Français Identification des matériaux (Page 5-7) Each part has a unique part number. Please reference the appropriate part number when contacting customer service for replacement parts. Before throwing any packaging, please verify all contents and make sure you have received all the parts listed on previous pages!.
- Page 29 Visitez le site Web de votre détaillant local, évaluez le produit que vous avez acheté et laissez-nous vos commentaires ! Nous tenons à offrir un grand "Merci" à tous nos clients pour avoir pris le temps d'assembler ce produit "Ameriwood Home", et de nous donner vos commentaires précieux. Merci ameriwoodhome.com Tube...
