LifeSpan Kids Spiral Tube Slide - Green User Manual

Advertisement

Quick Links

USER MANUAL
Spiral Tube Slide
- Green
WARNING: The disassembled product may contain small parts
which pose a choking hazard to children under 3.
IMPORTANT:
This product may contain sharp points and small parts prior to assembly. The owner's manual contains
safety, assembly, use and maintenance instructions. This product must be assembled by an adult who
has read and understood these instructions. Keep the packaging away from children and dispose of all
packaging before use.
For the installer and your children's safety, it is important to fully read and understand the instructions
and safety hazards before commencing the assembly of the product.
NOTE:
This manual should not be used to guide your purchasing decision. Your product, and the contents
inside its carton, may vary from what is listed in this manual. This manual may also be subject to
updates or changes. Updated manuals are available through our website at www.lifespankids.com.au.
Find the Digital
Manual Online

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Spiral Tube Slide - Green and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LifeSpan Kids Spiral Tube Slide - Green

  • Page 1 USER MANUAL Spiral Tube Slide - Green Find the Digital Manual Online WARNING: The disassembled product may contain small parts which pose a choking hazard to children under 3. IMPORTANT: This product may contain sharp points and small parts prior to assembly. The owner’s manual contains safety, assembly, use and maintenance instructions.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS I. GENERAL SAFETY INSTRUCTIONS 1.1 Danger for Children 1.2 Risk of Injuries 1.3 Product Damage 1.4 Assembly Advice II. SAFETY INSTRUCTIONS III. ASSEMBLY INSTRUCTIONS IV. MAINTENANCE V. CLEANING VI. WARRANTY...
  • Page 3: General Safety Instructions

    I. GENERAL SAFETY INSTRUCTIONS This product is intended for outdoor domestic use only. Maximum Weight: 50kg Age: 3-10 Years Old 1.1 DANGER FOR CHILDREN WARNING: No eating while using the product. • Children do not recognize potential dangers from this product. The product must be stored out of reach of children and pets.
  • Page 4: Assembly Advice

    1.4 ASSEMBLY ADVICE • The assembly of the product must be done carefully and by an able-bodied adult. If in any doubt, ask a technically qualified person. • Before you start with the assembly, read the instructions carefully. • Remove all packaging materials and lay down all parts on an open space. This gives you an overview and simplifies the assembly procedure.
  • Page 5: Safety Instructions

    II. SAFETY INSTRUCTIONS • The safety instructions of the product should always be considered and obeyed. • Using the product may result in permanent injury such as paralysis, or even death. Falling off the product may lead to injuries, particularly to the back, neck or head. •...
  • Page 6 Consumer Information Sheet for Playground Surfacing Materials The US Consumer Product Safety Commission (CPSC) estimates that about 100 000 playground equipment-related injuries resulting from falls to the ground surface are treated annually in US hospital emergency rooms. Injuries involving this hazard pattern tend to be among the most serious of all playground injuries, and have the potential to be fatal, particularly when the injury is to the head.
  • Page 7: Assembly Instructions

    III. ASSEMBLY INSTRUCTIONS P A R T S L I S T x 60 x 88 x 139 +1 (spare) +1 (spare) +1 (spare) M6*15 M6*20 x 86 x 60 +1 (spare) +1 (spare) M6*25 M8*10 ASSEMBLY INSTRUCTIONS...
  • Page 8 x 15 ASSEMBLY INSTRUCTIONS...
  • Page 9 S E T U P STEP 1 x 32 x 32 1. Join two m5 parts together using 6x screws (h) and 6x nuts (b) on the longer side. Take note o how the screws are facing, 3x screws facing left and the other 3x screws facing right. 2.
  • Page 10 STEP 3 1. Using the parts joined in step (2); When connecting M7 to M5, first align the three center holes of M7 using 3 x Screws (h), 3 x Washers (d), and 3 x Nuts (b) for positioning. STEP 4 1.
  • Page 11 STEP 5 x 12 x 24 x 12 1. Use one of the joined m5 part to secure to the m5/m6 piece. Align the bolt holes using the arrow (pointing down) to the Y on m5/m6 piece. Refer to zoom image. 2.
  • Page 12 STEP 7 x 36 x 72 x 36 1. Join the remaining m5/m5 piece together and to m4/m4 as pictured. Align the arrow to Y (see zoom image) and secure using 36x screws (g), 72x washers (d) (on both sides of bolt) and 36x = nuts (a).
  • Page 13 STEP 9 x 12 x 24 x 12 1. Join m2/m3 piece to m4/m4 piece (step 6) using 12x screws (g), 24x washers (d) (on both sides of screw) and 12x nut (a). The screws can be facing the same direction. STEP 10 1.
  • Page 14 STEP 11 1. Join the assembled u5 parts (from step 7) to the bottom on the m5 piece using the last m9 piece (see zoom image for placement), 4x screws (i), 4x washers (d) and 4x nuts (b). x 15 x 15 STEP 12 1.
  • Page 15 ANCHORING INTO GROUND Use a mallet to push the anchors into ground. Anchors should go in at an angle as pictured. IMPORTANT: - Ensure the ground is flat and leveled. - Do not install on a slop. ASSEMBLY INSTRUCTIONS...
  • Page 16: Maintenance

    IV. MAINTENANCE WARNING: Please keep for future reference. We recommend regular maintenance to be conducted at the beginning of each season as well as at regular intervals during the usage season for your play equipment to ensure all main parts/fixings are tightly secured, well-oiled and intact to avoid failure, injury or hazards.
  • Page 17 ATTACHING TO PLATFORM The Slide comes with four bolt holes on each side and two bolt holes top and bottom. Screws are not included for mounting on existing playground. Size of screws required is M6. Bolt Hole Locations + 1476mm Dimensions MAINTENANCE...
  • Page 18: Cleaning

    If you have purchased this product from the Official Lifespan Kids website, please visit www.lifespankids.com.au/warranty-form For support outside of warranty, if you wish to purchase replacement parts or request a repair or service, please visit www.lifespankids.com.au/warranty-form and fill in our Repair/Service Request Form or...
