USER MANUAL
Stanley Heavy Duty Monkey Bars
with Anchor Kit and Basketball Ring
WARNING: The disassembled product may contain small parts
which pose a choking hazard to children under 3.
IMPORTANT:
This product may contain sharp points and small parts prior to assembly. The owner's manual contains
safety, assembly, use and maintenance instructions. This product must be assembled by an adult who
has read and understood these instructions. Keep the packaging away from children and dispose of all
packaging before use.
For the installer and your children's safety, it is important to fully read and understand the instructions
and safety hazards before commencing the assembly of the product.
NOTE:
This manual should not be used to guide your purchasing decision. Your product, and the contents
inside its carton, may vary from what is listed in this manual. This manual may also be subject to
updates or changes. Updated manuals are available through our website at www.lifespankids.com.au.
Find the Digital
Manual Online

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stanley Heavy Duty Monkey Bars and is the answer not in the manual?

Questions and answers

Related Manuals for LifeSpan Kids Stanley Heavy Duty Monkey Bars

Summary of Contents for LifeSpan Kids Stanley Heavy Duty Monkey Bars

  • Page 1 USER MANUAL Stanley Heavy Duty Monkey Bars with Anchor Kit and Basketball Ring Find the Digital Manual Online WARNING: The disassembled product may contain small parts which pose a choking hazard to children under 3. IMPORTANT: This product may contain sharp points and small parts prior to assembly. The owner’s manual contains safety, assembly, use and maintenance instructions.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS I. GENERAL SAFETY INSTRUCTIONS 1.1 Danger for Children 1.2 Risk of Injuries 1.3 Product Damage 1.4 Assembly Advice 1.5 Anchoring II. SAFETY INSTRUCTIONS III. ASSEMBLY INSTRUCTIONS 3.1 Parts List 3.2 Set Up IV. MAINTENANCE V. WOOD ADVICE VI.

  • Page 3: General Safety Instructions

    I. GENERAL SAFETY INSTRUCTIONS NOTE: This product is intended for outdoor domestic use only. Chain swing: 150 kg Monkey Bar: 100kg Max Fall Height: 2.3m Max User: 3 Do not use swings and monkey bar at the same time. 1.1 DANGER FOR CHILDREN WARNING: No eating while using the product at the same time.

  • Page 4: Assembly Advice

    1.4 ASSEMBLY ADVICE • The assembly of the product must be done carefully and by an able-bodied adult. If in any doubt, ask a technically qualified person. • Before you start with the assembly, read the instructions carefully. • Remove all packaging materials and lay down all parts on an open space. This gives you an overview and simplifies the assembly procedure.

  • Page 5: Anchoring

    1.5 ANCHORING NOTE: The unit can be anchored directly into the ground using the anchors provided. You may also use cement for additional stability, please follow the below instructions. 5cm Depth Required • Install the provided anchors (E) by screwing •...

  • Page 6: Safety Instructions

    II. SAFETY INSTRUCTIONS • The safety instructions of the product should always be considered and obeyed. • Using this product incorrectly may result in permanent injury such as paralysis, or even death. Falling off the product may lead to injuries, particularly to the back, neck or head. •...
  • Page 7 Consumer Information Sheet for Playground Surfacing Materials The US Consumer Product Safety Commission (CPSC) estimates that about 100 000 playground equipment-related injuries resulting from falls to the ground surface are treated annually in US hospital emergency rooms. Injuries involving this hazard pattern tend to be among the most serious of all playground injuries, and have the potential to be fatal, particularly when the injury is to the head.

  • Page 8: Assembly Instructions

    III. ASSEMBLY INSTRUCTIONS P A R T S L I S T LK 2061 x 2pcs LK 2062 x 2pcs Green LK 2063 x 8pcs LK 2064 x 4pcs LK 2065 x 2pcs LK 2066 x 2pcs LK 2067 x 4pcs Grey Chain Swing x 2 LK 2068 x 2pcs...

  • Page 9: Set Up

    S E T U P STEP 1.1: FRAME ASSEMBLY NOTE: Please pay attention to the hole direction. LK 2 062 LK 2 061 LK 2 061 LK 2 062 A-M10x85MM A-M1 0X 90MM 4PCS(Washer/Nut/Cap) STEP 1.2: RUNGS ASSEMBLY LK 2 063x 8P CS B-M1 0X 45MM 1 6P CS ASSEMBLY INSTRUCTIONS...
  • Page 10 STEP 2.1: UPPER LEG ASSEMBLY NOTE: Lay down the frame for easy leg assembly. A-M10x85MM A-M1 0X 90MM 8PCS(Washer/N ut /Cap) LK 2 064x 4P CS STEP 2.2 LOWER LEG ASSEMBLY(REPEAT THIS STEP TO BUILD THE OTHER LEG SET) ATTENTION! DO NOT FASTEN BOLTS FOR NEXT STEP ASSEMBLY 2.
  • Page 11 STEP 2.3 LOWER LEG ASSEMBLY NOTE: Please check all the bolts and make sure they are properly fastened. A-M10X85MM 8pcs (Washer/Nut/Cap) TURN OVER Fully tighten all the bolts. STEP 3 SWING ASSEMBLY Optional: These 2 hole positions are available for 1m Web swing Please DO NOT use the swing/web swing/Monkey bar function at the same time.
  • Page 12 P A R T S L I S T F O R U N D E R G R O U N D A N C H O R LK 2071 x 4pcs LK 2074 x 4pcs LK 2072 x 4pcs Nylock Nut M8 x 32 D-M8x55mm x 24 LK 2073 x 4pcs...
  • Page 13 A S S E M B L Y D-M8X55mm 4pcs (Nut) LK 2074 x 2pcs LK 2071 x 2pcs D-M8X55mm 4pcs (Nut) LK 2072 x 2pcs E-M8X15mm 4pcs (Nut) LK 20723 x 2pcs ASSEMBLY INSTRUCTIONS...
  • Page 14 D-M8X55mm 8pcs (Washer/Nut) IMPORTANT: Underground Anchor is available for the span of leg under 107cm. - The product should be installed on grass or dirt ground with mulch or bark covered on top after anchoring. It is not 107CM recommended to install on hard surfaces or concrete.
  • Page 15 P A R T S L I S T - B R A C K E T P A R T S L I S T LK 2081 LK 2082 M10 x 115MM Nylock Nut M10 Nylock Nut M8 2pcs. 2pcs.
  • Page 16 P A C K C O N T E N T S - S W I S H B A S K E T B A L L H O O P Backboard Ring Flat Plate Connection Plate Clamp Short Long ASSEMBLY INSTRUCTIONS...
  • Page 17 P A R T S L I S T S E T U P F I T T I N G S PREPARATION Remove all parts and hardware from the carton and place them on a clean soft surface. Check carefully to make sure nothing is missing.
  • Page 18 NOTE: This part is used for fitting a basketball board to LK206 Stanley Heavy Duty Monkey bars. Check that all parts are there before set up. Spanners are required for assembly and gloves are recommended for safety. M8 x 35MM 2pcs.
  • Page 19 NOTE: Some components may have been pre-assembled. STEP 1 Attach the net on the loop as the picture showing. STEP 2 Connect the ring with connection plate using bolt through the joint and locked with NOTE: Ensure the bracket is fitted the right way up (larger section down) to allow the hoop to swing upwards against the backboard.
  • Page 20 STEP 3 Attach the flat plate on the backside of backboard locked by using two bolts and two washers then to attach the ring on the front of backboard at the joint by using three nuts through six washers and three .
  • Page 21 STEP 4 Attach the whole basketball set onto the ideal safety poles of your trampoline, lock it with two clamps by using four bolts through four washers and four nuts NOTE: Ensure the bracket is fitted the right way up (larger section down) to allow the hoop to swing upwards against the backboard.

  • Page 22: Maintenance

    IV. MAINTENANCE WARNING: Please keep for future reference. We recommend regular maintenance to be conducted at the beginning of each season as well as at regular intervals during the usage session for your play equipment to ensure all main parts/fixings are tightly secured, well-oiled and intact to avoid failure, injury or hazards.

  • Page 23: Wood Advice

    V. WOOD ADVICE Our products are manufactured from premium timber. Great care is taking in selecting, machining, and treating the timber before it is sold to you. 1. Inspect wood parts monthly. The grain of the wood sometimes will lift in dry periods causing splinters to appear.
  • Page 24 3. Mould and Mildew Protecting against mould and mildew on your outdoor equipment is an important step in maintaining your backyard. Mould may develop for several reasons, such as certain weather conditions, improper drainage or infrequent usage. Here we’ll share our tips for keeping your outdoor areas free of mould and mildew so that you can enjoy your backyard with peace of mind.

  • Page 25: Cleaning

    If you have purchased this product from the Official Lifespan Kids website, please visit www.lifespankids.com.au/warranty-form For support outside of warranty, if you wish to purchase replacement parts or request a repair or service, please visit www.lifespankids.com.au/warranty-form and fill in our Repair/Service Request Form or...
  • Page 28 www.l if esp a nkids .c om .a u...
