LDX 110 / LDX 135 /
LDX 150
Live production camera
User Guide
13-00126-000 AC
2025-02-28
www.grassvalley.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LDX 110 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GRASS VALLEY LDX 110

  • Page 1 LDX 110 / LDX 135 / LDX 150 Live production camera User Guide 13-00126-000 AC 2025-02-28 www.grassvalley.com...
  • Page 2: Fcc Compliance

    150 Series documentation, you agree to the following terms and conditions. Grass Valley hereby grants permission and license to owners of LDX 110 / LDX 135 / LDX 150 Series to use their product manuals for their own internal business use. Manuals for Grass...
  • Page 3: Important Safety Information

    Use anti-static procedures, equipment and surfaces during servicing. The presence of this symbol in or on Grass Valley equipment means that it has been tested and certified as complying with applicable Underwriters Laboratory (UL) regulations and recommendations for USA.
  • Page 4 Notices Warnings A warning indicates a possible hazard to personnel, which may cause injury or death. Observe the following general warnings when using or working on this equipment: • Any instructions in this manual that require opening the equipment cover or enclosure are for use by qualified service personnel only.
  • Page 5: Electrostatic Discharge (Esd) Protection

    • Avoid extreme highlights as these can cause various kinds of optical reflections. • Be careful when connecting and disconnecting fiber cables. • Do not connect Grass Valley camera systems with other manufacturer’s camera system parts. • Make connections swiftly and firmly to avoid false error messages.
  • Page 6: Environmental Information

    Grass Valley believes this environmental information to be correct but cannot guarantee its completeness or accuracy since it is based on data received from sources outside our company. All specifications are subject to change without notice.
  • Page 7: Laser Safety

    LDX 110 / LDX 135 / LDX 150 User Guide Laser Safety - Fiber Output SFP and QSFP Modules Warning LASER SAFETY The average optical output power does not exceed 0 dBm (1mW) under normal operating conditions. Unused optical outputs should be covered to prevent direct exposure to the laser beam.
  • Page 8: Safety And Emc Standards

    Notices Safety and EMC Standards This equipment complies with the following standards: Safety Standards IEC62368-1:2018 Audio/video, information and communication technology equipment: part 1 EN 62368-1:2018 EU national deviations. EMC Standards This unit conforms to the relevant Union harmonization legislation and the requirements of the following directive/standards: RED 2014/53/EU EMC testing;...
  • Page 9 LDX 110 / LDX 135 / LDX 150 User Guide WARNING (Part 15.21) Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Information to the User (Part 15.105 (b)) ☞...
  • Page 10: Eu Declaration Of Conformity

    EN 62479: 2010 ROHS Directive 2011/65/EU Restriction of the use of certain hazardous substances in electrical and electronic equipment. Signed for and on behalf of Grass Valley Nederland B.V. _______________________________ Patrick Wielders, VP, Global Manufacturing Montreal, Quebec, Canada – Issued on February 25, 2025...
  • Page 11 LDX 110 / LDX 135 / LDX 150 User Guide UK DECLARATION OF CONFORMITY (DoC) Hereby we, Name of Manufacturer: Grass Valley Nederland B.V. Address: Bergschot 69 Post Code & City: 4817PA Breda Country: The Netherlands Telephone Number: +31 763032100...
  • Page 12: Emc Performance Of Cables And Connectors

    Notices EMC performance of cables and connectors Grass Valley products are designed to meet or exceed the requirements of the appropriate European EMC standards. In order to achieve this performance in real installations it is essential to use cables and connectors with good EMC characteristics.
  • Page 13: Table Of Contents

    Table of Contents FCC Compliance..................ii Patent Information .
  • Page 14 Table of Contents PTP locking ................. . . 17 PTP setup .
  • Page 15 LDX 110 / LDX 135 / LDX 150 User Guide Indicators ..................54 On screen marker indicators .
  • Page 16 Table of Contents LED Wall Filter................. 77 Color.
  • Page 17 LDX 110 / LDX 135 / LDX 150 User Guide Baseband video signals ................146 Signal Settings .
  • Page 18: Introduction

    Technology Work Field The LDX 110 / LDX 135 / LDX 150 is designed for flexibility, with the ability to be used for both dramatic productions and live broadcasts, especially sports. The use of compact broadcast 2/3-inch lenses with a B4-mount gives you the large zoom range, speed and depth of field which is required for demanding live and many dramatic productions.
  • Page 19: Remote Production

    Remote production The LDX 110 / LDX 135 / LDX 150 is the best choice for At-Home/REMI (REMote Integration) productions. With the implementation of Grass Valley’s NativeIP transmission, the LDX 110 / LDX 135 / LDX 150 is the first studio system camera that is fully IP based. Thanks to NativeIP, the camera connects directly to your IP infrastructure in studio and OB-production environments.
  • Page 20: Superior Digital Processing

    To make images look their best, the LDX 110 / LDX 135 / LDX 150 incorporates TrueTexture™—a unique feature to preserve texture throughout all processing parameters.
  • Page 21: System Components And Accessories

    LDX 110 / LDX 135 / LDX 150 User Guide System components and accessories System components and power supply options: XCU Universe UXF XF Transmission Fiber Base Station HPE-300 300 W Hybrid Power Extender with single AC mains input HPE-300-2AC...
  • Page 22: Installation

    The LDX 135 and LDX 150 cameras is shipped without a (Q)SFP module. Before operating the LDX 110 / LDX 135 / LDX 150 make sure that the right (Q)SFP module is installed that suits your transmission configuration. Refer to Appendix E for more information about how to install (or exchange) a (Q)SFP module.
  • Page 23: Ec 2-100 Viewfinder

    LDX 110 / LDX 135 / LDX 150 User Guide Caution Do not attach a lens weighing more than 5 kg (11 lbs) to the camera without a proper lens support. When a new lens is fitted to the camera it may be necessary to carry out some adjustments to optimize its use, for example, back focus or shading.
  • Page 24 Installation Mounting the viewfinder • Connect the viewfinder cable to the viewfinder connector socket (4) under the recess at the right side of the camera. • Guide the cable through the upper cable clip (4a) and down along the cable holder (4b).
  • Page 25: Mounting A Microphone

    LDX 110 / LDX 135 / LDX 150 User Guide Mounting a microphone To attach a microphone to the camera proceed as follows: • Open the microphone holder by unscrewing the knurled screw (1) of the microphone support bracket (2) on the viewfinder and open the bracket: •...
  • Page 26: Positioning The Viewfinder

    Installation Positioning the viewfinder • Connect the microphone cable to the MIC audio XLR connector on the right side of the camera. To avoid mechanical pick-up, do not let the microphone cable touch the holder. Other microphones with a diameter of 21 mm (0.83 in) can also be used, however, ensure that the sensitivity of the input that match that type of microphone are correctly selected in audio section of the camera Configuration menu.
  • Page 27 LDX 110 / LDX 135 / LDX 150 User Guide viewfinder eyepiece Angular Hold the viewfinder eyepiece with your hand and rotate it to the desired angle. Laterally The viewfinder can be positioned backwards and forwards along the camera axis (lateral): •...
  • Page 28: Distance Viewing

    Installation Distance viewing ☞ Note Note Moving the handgrip also changes the weight balance of the camera. Make sure to balance the camera with the lens mounted and the cables attached. Distance viewing The viewfinder display can also be viewed from a distance: •...
  • Page 29 LDX 110 / LDX 135 / LDX 150 User Guide Caution Failure to attach the camera to the tripod adapter plate in the correct manner could result in an unsecured camera. Ensure that the rear stud (2) is engaged and that the camera clicks into place.
  • Page 30: Adjusting The Shoulder Pad

    Installation Adjusting the shoulder pad Adjusting the shoulder pad To change the position the shoulder pad press and hold the adjustment lever at the bottom left of the camera body, just behind the handgrip. The shoulder pad can now be moved backwards and forwards along the axis of the camera.
  • Page 31: Adjusting The Handgrip Position

    LDX 110 / LDX 135 / LDX 150 User Guide Adjusting the handgrip position The handgrip position can be adjusted along the axis of the camera body. • Loosen the locking disc by turning it counterclockwise using your thumb and index finger.
  • Page 32: Configuration

    Configuration Camera system configurations The camera can be used in three different camera modes: • NativeIP mode (LDX 135 and LDX 150 only) • XCU mode (also called cabled mode or XF mode) • Local mode To set or change the camera mode, enter the camera menu, go to the Transmission menu and use the Camera Mode function to select IP (for NativeIP mode), XCU (for XCU mode) or Local (for Local mode).
  • Page 33: Xcu Mode

    LDX 110 / LDX 135 / LDX 150 User Guide hybrid fiber 2x single mode fiber Hybrid to SM fiber LDX 135 / LDX 150 Network Switch converter or SHED-C power supply unit XCU mode Power is delivered by the XCU through the hybrid fiber cable: hybrid fiber...
  • Page 34: Control Network

    • in NativeIP mode: use a tagged VLAN for the C2IP network on the IP Media network (Note: NativeIP is not for LDX 110); • in XCU mode: connect the C2IP network to the C2IP Ethernet connector on the back panel of the XCU;...
  • Page 35: Ptp Setup

    LDX 110 / LDX 135 / LDX 150 User Guide ✎ Many PTP settings and detailed diagnostics on PTP can be monitored in the XCU menu: go to the Diagnostics > Media Network > PTP menu to view them. PTP setup (this section is valid both in NativeIP and XCU mode) •...
  • Page 36: Free Running

    Configuration Free running • <AES> BNC connector is used as a Digital Audio AES input (this audio source can be selected in the audio section of the camera) • <TriLvl> HD Tri-Level reference output, can be used as a locking source for a second camera.
  • Page 37: Main Video Workflows

    LDX 110 / LDX 135 / LDX 150 User Guide Main video workflows NativeIP mode: 1X speed UHD 2110-20 single raster (For LDX 135 and LDX 150 only) NativeIP transmission 1x 25Gb SFP 1x 25Gb SFP LDX 135/ SFP 1...
  • Page 38: Nativeip Mode: 3X Speed Uhd 2110-20 Single Raster (For Ldx 150 Only)

    Configuration NativeIP mode: 3X speed UHD 2110-20 single raster (For LDX 150 only) NativeIP mode: 3X speed UHD 2110-20 single raster (For LDX 150 only) NativeIP transmission 1x 100Gb QSFP 1x 100Gb QSFP IP streams from LDX C150 to IP switch LDX C150 3x speed UHD Single Raster 2110 LIVE UHD + LIVE 3G...
  • Page 39: Ip Media Setup

    Note Make sure the version of Camera Connect 1.69 or higher. Camera Connect is Grass Valley’s configuration and setup tool for camera systems. The software comes pre-installed on the CCS-One Cameras Control Server and can be accessed through the C2IP network by a web-browser that runs on a PC or tablet computer.
  • Page 40: Ip Media Network Setup

    IP Media Setup IP Media Network setup Video, Live | Mon, Ext. Video, Audio, Audio Ch., Intercom, Intercom Ch., PTP, Priv. Data, C2IP, Direct IP and Direct IP+. IP Media Network setup Network ports setup The list of camera systems is shown, sorted by camera number. Click the Network Ports tab: Here you can configure (local) IP addresses, subnet mask and default gateway for Primary Port (A1) and Secondary port (B1).
  • Page 41: Nmos

    LDX 110 / LDX 135 / LDX 150 User Guide ☞ Note Note A green light does not indicate a correct communication link between the camera and the IP switch. Click the camera system you want to set up. A popup window appears and you can edit the...
  • Page 42 IP Media Setup NMOS The Conn.Type column indicates the settings done in the camera(XCU). The interface that is using NMOS can be selected as well; it is either C2IP or Media. IP Address, Port Number, Version and Status are visible when a connection is made with the NMOS server. The indicator(s) in the Status column show the status of the NMOS server connection: Indicates a connection is made with the NMOS server.
  • Page 43: Main Video

    LDX 110 / LDX 135 / LDX 150 User Guide Main video In the IP Main tab you can set up IP address and port number for the Main video outgoing stream for the Primary and Secondary IP Media Network Port. The transport standard (protocol) for Main video is also selected in this tab next to the PID (Payload ID).
  • Page 44: Main Video In 4K Uncompressed Mode

    IP Media Setup Main video in 4K uncompressed mode Stream 1: Dest. IP address — the destination IP address to which the stream is sent. Dest. Port — the destination port number for the stream. ☞ Note Note When the same IP address is used for the Main video, Monitoring video and/or Live video streams, the port numbers for each stream MUST be set to different values.
  • Page 45 LDX 110 / LDX 135 / LDX 150 User Guide Main Video Enabled — selects whether the Main video is included in the IP Media Network stream: • Yes: Main video is included in the IP Media Network stream • No: Main video is NOT inserted into the IP Media Network stream (this is also indicated with the indication off in front of stream 1).
  • Page 46: Ip Mon\Live Tab

    IP Media Setup IP Mon\Live tab ☞ Note Note This is not applicable for receivers with two 10G ports. A single IP destination address causes the Ethernet switch to flood both ports with all four streams. This can only be used for 25G and 40G port receivers.
  • Page 47: Live Video

    LDX 110 / LDX 135 / LDX 150 User Guide Click the camera system you want to set up. The edit popup window appears in which you can edit the following parameters: Live video ☞ Note Note Live video is only present when HDR is enabled and/or when the XCU is running in a 4K video mode.
  • Page 48: Jpeg Streams

    IP Media Setup JPEG Streams JPEG Streams Camera Series Video Mode Mixed mode: All compressed 25G and 100G 25G only Outgoing streams – Camera signals / Local Ext. input LDX 135 / LDX 150 HD / 3G / UHD / Filmic 3 uncompressed or 1 2x JPEG XS streams modes...
  • Page 49 LDX 110 / LDX 135 / LDX 150 User Guide The Extern 1, Extern 2 and Extern 3 / TP columns show the present indicator, transport standard, port number and Multicast IP address for each incoming video stream. Click the camera system you want to set up. The edit popup window appears in which you...
  • Page 50: Ip Audio Tab

    IP Media Setup IP Audio tab ✎ It is recommended to use port numbers in the 1000 .. 49152 range. IP Audio tab The list of camera systems is shown, sorted by camera number. In this tab the outgoing and incoming IP Audio streams can be set up.
  • Page 51 LDX 110 / LDX 135 / LDX 150 User Guide AES67 Audio In Present — indicates whether an AES67 Audio input is present on the IP Media Network. It can have the following status indications: no indication Steam is not present or not available.
  • Page 52: Ip Intercom Tab

    IP Media Setup IP Intercom tab IP Intercom tab The list of camera systems is shown, sorted by camera number. In this tab the incoming and outgoing IP Intercom streams can be set up. Click the camera system you want to set up. The edit popup window appears in which you can edit the following parameters: Source —...
  • Page 53 LDX 110 / LDX 135 / LDX 150 User Guide • No: AES67 intercom is NOT inserted into the IP Media Network stream (this is also indicated with the indication off in front of Stream 1). • Yes: AES67 intercom is inserted into the IP Media Network stream.
  • Page 54: Ptp Tab

    IP Media Setup PTP tab Ch 1 Ch 2 Ch 3 Ch 4 Ch 5 to 8/16 Audio A1 Prog intercom Prog spare (not used) (not used) (not used) Intercom A1 Prod Prog intercom Prog spare (not used) PTP tab The XCU can be synchronized over the IP Media Network to a PTP grandmaster clock using the Precision Time Protocol (PTP).
  • Page 55 LDX 110 / LDX 135 / LDX 150 User Guide Status — shows PTP locking status. The following status indications are possible: locked XCU is locked to the PTP grandmaster clock. calibrating XCU has found a PTP grandmaster and is calibrating to the grandmaster.
  • Page 56: Operating Instructions

    There are several ways of supplying power to the camera, depending on the system configuration: • by a hybrid power extender such as Grass Valley’s HPE-300 or LDK 4425 through the hybrid cable connector (in NativeIP or DirectIP/DirectIP+ modes); • by an XCU through the hybrid fiber cable and connector (in XCU mode);...
  • Page 57: Location Of Controls And Indicators

    LDX 110 / LDX 135 / LDX 150 User Guide Location of controls and indicators Camera front panel (1) Rear Tally lamp Lights Red when the camera is On Air. (2) White Balance button Press and hold two seconds to start the Auto White Balance procedure.
  • Page 58: Headset Volume

    Operating instructions Camera front panel (5) Intercom Prod This button is used to activate the intercom Production channel (‘talk’). (6) Headset volume Adjusts the overall audio volume of the intercom headset. (7) Intercom Eng This button is used to activate the intercom Engineering channel (‘talk’). (8) Return A This button can be assigned to an External/Return Video channel.
  • Page 59: Camera Left Panel

    LDX 110 / LDX 135 / LDX 150 User Guide Camera left panel FILTER BARS COLOR EXP. GAIN TEMP TIME (1) Gain up/down switch Press plus or minus to select a Gain preset or hold the plus to set a variable gain value.
  • Page 60: Camera Back Panel

    Operating instructions Camera back panel (5) Bars buttons Switches the test bars on and off and selects bar type. (6) Standard Recall (or ‘Green button’) Press and hold two seconds to recall standard values for the camera. (7) User button SW1 Assignable user button SW1.
  • Page 61 LDX 110 / LDX 135 / LDX 150 User Guide (2) Intercom Prod volume Headset volume for the intercom Production channel. (3) Intercom Prog volume Headset volume for the intercom Program channel. (4) Intercom Eng button This button is used to activate the intercom Engineering channel (‘talk’).
  • Page 62: Info Button And Indicator

    Operating instructions Camera back panel Indicator: Color/Status: Description: CABLE Yellow Camera runs in XCU mode Purple Camera runs in NativeIP mode Orange Camera runs in DirectIP mode No (Q)SFP module present (Q)SFP module mismatch Yellow (Q)SFP module is present but no network link Green (Q)SFP module is present and the network link is OK Camera is not receiving IP Media data...
  • Page 63: Controlling The Camera

    LDX 110 / LDX 135 / LDX 150 User Guide button is pushed once, the first info page with most important camera settings is shown in combination with the IP diagnose indicators. Press again to show the IP info page with more detailed info about the IP link. The IP diagnose indicators stay active.
  • Page 64: Entering The Camera Menu

    Operating instructions Entering the camera menu ☞ Note Note Some of the menu items may not appear if the user level is not set to 3 or S (Service). Entering the camera menu Push the menu button after the camera is switched on, the message Menu off appears in the viewfinder.
  • Page 65: Leaving The Camera Menu

    LDX 110 / LDX 135 / LDX 150 User Guide PREVIOUS Levels >> Exposure >> Color >> Image Control >> Files >> Production Setup Video Mode 720p50 Sensitivity Leaving the camera menu If you are deep within the menu structure, the recommended way of leaving the menu is to press the back button a number of times until the menu is abandoned.
  • Page 66: Undoing Changes

    Operating instructions Undoing changes If there are only two values associated with the function, then pressing the select button toggles between these two values. If a value is displayed next to a function that is one of several possible values, then pressing the select button places the cursor in a list menu indicating the value currently selected.
  • Page 67: Left Side And Lens Buttons

    LDX 110 / LDX 135 / LDX 150 User Guide Left side and lens buttons VTR Lens RET Lens FILTER BARS COLOR EXP. GAIN TEMP TIME User button SW1 can be assigned to: The VTR Lens button can be assigned to: •...
  • Page 68: Handgrip Button

    Operating instructions Handgrip button Handgrip button The right handgrip button is assigned to: The left handgrip button can be assigned • Switch to Return Video A (Ret A) - default • Production intercom (Prod) - default • Switch to Return Video B (Ret B) •...
  • Page 69: Viewfinder Controls

    LDX 110 / LDX 135 / LDX 150 User Guide Viewfinder controls Front (1) User button (A) This user button can be assigned in the viewfinder menu. (2) User button (B) This user button can be assigned in the viewfinder menu.
  • Page 70: Back

    Operating instructions Back Back Set up the viewfinder according to your own preferences; adjust viewing parameters, select markers, message boxes and on-screen display times in the Operator Toolbox menu. M ode Tal l y SW C M enu-Peak Of f On Of f (1) Mode switch This switch determines the function of the Menu/Peak rotary control below.
  • Page 71: Viewfinder Information

    LDX 110 / LDX 135 / LDX 150 User Guide (6) Brightness control Turn this rotary control clockwise to adjust the brightness of the viewfinder picture according to your preferences. The range runs from 0 (very dark) to 99 (very bright).
  • Page 72: On Screen Marker Indicators

    Operating instructions On screen marker indicators (4a) Filter indicator Shows the selected optical filter(s). (4b) Depth of Field indicator Shows Depth of Field (DOF) of the current lens position. F = Far limit in meters, N = near limit in meters. Note: this feature must be supported by the lens. ☞...
  • Page 73: Viewfinder Led Indicators

    LDX 110 / LDX 135 / LDX 150 User Guide Viewfinder LED indicators Batt Call On Air PickMe Zoom Foc+ Call On Air PickMe Gain (1) Return video indicator Lights if one of the return video channels is switched on.
  • Page 74: Non-Standard Indicator

    Operating instructions Information pages (10) Range Extender indicator Lights when a Range Extender is enabled. (15) Gain indicator Lights when gain is lower than 0 dB or if gain is higher than +3 dB. (16) Non-standard indicator The non-standard video settings indicator (!) lights when one or more of the following conditions occur: •...
  • Page 75 LDX 110 / LDX 135 / LDX 150 User Guide (3) User button assignments Displays the assignments for the user buttons on the camera. (4) Video settings Displays video mode, master gain, ND filter, FX filter, color temperature, selected Gamma...
  • Page 76: Focus Assist

    Operating instructions Focus assist Focus assist The focus assist function can be switched on or off in the Operator Toolbox menu. This function adds a motion effect in the viewfinder to objects in sharp focus. The FOC+ indicator in the viewfinder lights when this function is on. Viewfinder zoom The viewfinder zoom function is another feature that helps you focus.
  • Page 77: Aria

    LDX 110 / LDX 135 / LDX 150 User Guide ARIA The Automatic Restoration of Illumination (ARIA) compensates for shading effects by utilizing data from compatible lenses. To ensure proper functionality, set the lens interface to Digital in the Lens > Lens Settings > Lens IF Type menu. When ARIA is set to Auto, the camera will automatically detect and compensate for shading effects.
  • Page 78: Extended Iris

    Operating instructions Extended Iris measurement areas: one for Peak and one for Average values. Auto Iris combines the readings from these two areas and uses the outcome to control the Iris opening. Aver age m easur em ent ar ea Pea k meas ur em ent ar ea Changing Auto Iris advanced settings ☞...
  • Page 79: Precision Focus

    LDX 110 / LDX 135 / LDX 150 User Guide When Extended Iris is on, the non-standard indicator in the viewfinder lights, and gain and exposure controls are blocked. Settings for the Extended Iris function can be changed in the Production Setup > Exposure > Extended Iris menu.
  • Page 80: Lens Indicators In The Viewfinder

    Operating instructions Lens indicators in the viewfinder Lens indicators in the viewfinder The RE indicator in the viewfinder lights when a lens range extender is selected. The Iris indicator in the viewfinder shows the value of the iris opening (when enabled in the camera menu).
  • Page 81: Digital Audio

    LDX 110 / LDX 135 / LDX 150 User Guide The (analog) audio channels are available: • as audio channels 1 and 2 embedded in the HD-SDI video signal • on the XCU at the XLR 3 audio output connectors •...
  • Page 82: Selecting Intercom Channels

    Operating instructions Selecting intercom channels FRONT Production Engineering (Eng) (Prod) selection selection button button Main intercom volume control BACK Production (Prod) Production (Prod) channel volume channel selection Program (Prog) Engineering (Eng) channel volume channel selection Engineering (Eng) Call button channel volume Selecting intercom channels Push the engineering (Eng) channel selection button to talk to the engineering intercom channel.
  • Page 83: Routing Signals

    LDX 110 / LDX 135 / LDX 150 User Guide Routing signals By default, all three intercom channels are audible on both muffs (left and right) of the camera headset. The routing of the intercom channels can be changed to personal preference.
  • Page 84: Setting Up The Tracker Headset

    Operating instructions Setting up the Tracker headset Setting up the Tracker headset Go to the Audio/Intercom > Intercom > Tracker menu to change settings for the Tracker headset. Function Values Default Description Tracker Mic To Off, Cam, Eng, Selects the Tracker microphone routing. Prod, All Tracker Mic 0 dB, 12 dB, 24...
  • Page 85: Communication

    LDX 110 / LDX 135 / LDX 150 User Guide Communication Return video channels FRONT Return B button Return A button BACK Return A button Return B button Return A and B buttons can be assigned to one of the three available External video channels or the teleprompter channel in the camera menu.
  • Page 86: Pickme Button

    Operating instructions PickMe button PickMe button Press the yellow PickMe button on the left side of the camera or on the back panel to send an attention signal directly to the program director. This function can be used when the camera operator is shooting critical or high priority footage that needs immediate action by the director.
  • Page 87: Operator Files

    LDX 110 / LDX 135 / LDX 150 User Guide ☞ Note Note The standard Customer Scene file is stored via the Security menu, not the Files menu. The decision to use the factory defined file or the customer defined file as the standard file is also made in this menu.
  • Page 88: Customer Standard Files

    Operating instructions Favorites files Customer standard files You can define a customer standard file for the standard Scene file and for the standard Operator file. The contents of the customer files for both these standard files is stored via the Configuration > Security menu. The selection of a factory defined or a customer defined file for use as a standard file is also made in this menu.
  • Page 89: Video Setup

    V ideo setup Video settings Standard settings To make sure that (some of ) the camera functions are not set to unusual values, a standard file has been defined that contains the default values for most video functions. The Reference tables, on page 85 list the (default) values that are set when the standard file is recalled.
  • Page 90: Color Bar

    Video setup Color bar • High Quality mode — for studio locations and other environments with very good lighting conditions. This mode provides superior quality pictures with very low noise. • Nominal mode — for general purpose situations with variable lighting conditions. This mode provides very good pictures with low noise.
  • Page 91: Gain

    LDX 110 / LDX 135 / LDX 150 User Guide Gain Depending on the available light level it may be necessary to adjust the video gain settings of the camera. Turn the upper ring on the stick to vary Gain in steps of 0.1 dB.
  • Page 92: Optical Filters

    • Star 4P - 4 Point Star filter • Sft Fcs - Soft focus filter (Note: In the LDX 110, the soft focus filter is replaced with a 2K optical Lowpass filter.) • Cap - Lens is capped (closed) ☞...
  • Page 93: Exposure

    LDX 110 / LDX 135 / LDX 150 User Guide Exposure Exposure time The exposure time value of up to 1/2000 is used to capture fast moving objects so that these can be played back sharply in slow motion. On the camera, exposure time is selected by the exposure time switch on the left side panel...
  • Page 94: Led Wall Filter

    Video setup LED Wall Filter In the camera menu, navigate to the Video > Setup > Acq Timing menu and switch on the V-Shift item. Use the V-Shift time item to change the time shift until the horizontal bar disappears. ✎...
  • Page 95: Color Filter

    LDX 110 / LDX 135 / LDX 150 User Guide Color Filter In the auto-white positions (FL50, FL60, AW1 and AW2) a color filter can be set up in the Video > Color > Color Temp > Color Filter menu. This varies the color balance to obtain warmer or colder color effects.
  • Page 96: Variable Color Temperature

    Video setup Variable color temperature The viewfinder also displays the measured color temperature. The range of the auto-white balance is from 2000 K to 21000 K. Variable color temperature The color temperature switch on the left-front side of the camera can also be used to vary the color temperature continuously between its minimum and maximum value (2000 K to 21000 K).
  • Page 97 LDX 110 / LDX 135 / LDX 150 User Guide 3 The following appears in the viewfinder: AWHITE: window ☞ Note Note If you did not select one of the memory positions FL50, FL60, AW1 or AW2, a message (“Set Color Temp”) appears in the viewfinder.
  • Page 98: Saturation

    Video setup Saturation 8 The measured color temperature is now stored in the selected memory position and can be recalled as required. 9 If the auto-white measurement has been unsuccessful, an error appears in the WHITE BALANCE button on the CGA. ☞...
  • Page 99: Sharpness

    LDX 110 / LDX 135 / LDX 150 User Guide Sharpness Detail Detail is an image enhancement used to improve picture sharpness perception. The detail function raises the contrast at the dark-to-light and light-to-dark transitions, thus making edges of objects appear sharper. This process is applied in video post processing within the camera by overshooting the signal at the edges.
  • Page 100: Auto Skin Detail

    Video setup Skin Detail Auto Skin Detail Carry out the Auto Skin Detail procedure as follows: 1 In the camera menu, navigate to the Video > Enhance > Skin Detail and use the Skin Gate item to select 1, 2 or 3. Do not select any of the combined options. 2 Place the cursor in front of the Auto Skin Dtl function.
  • Page 101: Image Control

    LDX 110 / LDX 135 / LDX 150 User Guide ☞ Note Note In XS (6X)1080p video modes, the view and the color view do not show the selected color in the B/W picture of the monitoring output. Image control Freeze Frame ☞...
  • Page 102: Menu References

    Menu references Reference tables All camera functions are grouped into 7 main menus: • Viewfinder menu—contains all settings to configure the viewfinder setup. • Lens menu—contains all lens functions. • Audio/Intercom menu—contains all functions to configure the audio settings. • Buttons & Leds menu—contains all functions to define the actions of the assignable buttons and LEDs.
  • Page 103: Viewfinder Menu

    LDX 110 / LDX 135 / LDX 150 User Guide ☞ Note Note Menu items may not be available depending on camera type and camera settings. Viewfinder menu Function: Values: U: F: Description: VF Boxes Box 1 Off, On Box 1...
  • Page 104 Menu references Viewfinder menu Function: Values: U: F: Description: Box 4 Off, On Box 4 0 O Switch Box 2 on or off Box, Line, Full Type 0 O Box type Color White, Red, Green, Blue, 0 O Box color Yellow, Magenta, Cyan, Purple 0..99 (9)
  • Page 105 LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: Off, On OK Indication OK Range +/- 0.1 deg..5 deg (1 deg) Off, On Center Cross 0 O Switch Centre Cross indicator on or off...
  • Page 106 Menu references Viewfinder menu Function: Values: U: F: Description: HDR Kn Point 20%..100% (70%) VF Peaking 0..99 (20) Peaking Lvl 0 O Peaking level applied to the viewfinder signal (same control as peaking level rotary on the viewfinder) 0..99 (0) Peaking (Return) 0 O Peaking level applied to the Return video signal in the viewfinder (when enabled)
  • Page 107: Lens Menu

    LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: 0..99 (70) Menu White Lvl 2 O White level (brightness) of the characters of the menu VF Mon Mode Loc, Loc+Rem Show, Hide Empty Favorites...
  • Page 108 Menu references Lens Menu Function: Values: U: F: Description: Control Off, On - Switch on to carry out the Remote Back Focus of the lens. note: the lens must support the Remote Back Focus functionality. Position 0..99 - Stored value of the back focus adjustment (in the lens) Lens Corrections ARIA Auto, Off...
  • Page 109: Audio/Intercom Menu

    LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: 0..99 (50) G Saw H - Sawtooth (Horizontal) for Green channel. G Par H 0..99 (50) - Parabola (Horizontal) for Green channel. 0..99 (50) G Saw V - Sawtooth (Vertical) for Green channel.
  • Page 110 Menu references Audio/Intercom Menu Function: Values: U: F: Description: Audio 1 Source Line, Mic, Mic48V - Selects source input sensitivity for the Audio 1, either Line or Mic level or Mic level with phantom power. Audio 1 Level -22dB, -28dB, -34dB, - - Selects input gain level for Audio channel 1 (when 40dB, -46dB, -52dB, - Audio Gain Mode is set to Local).
  • Page 111 LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: Off, On Tracker Mic Power Tracker Prod Off, Left, Right, Both Off, Left, Right, Both Tracker Eng Tracker Prog Off, Left, Right, Both Tracker ProgExt...
  • Page 112: Buttons & Leds Menu

    Menu references Buttons & Leds menu Function: Values: U: F: Description: Input IP-Audio, IP-Icom, 2022- 6, SDI Ch1, Ch2, Ch3, Ch4, Ch5, Channel Ch6, Ch7, Ch8, Ch9, Ch10, Ch11, Ch12, Ch13, Ch14, Ch15, Ch16 Prog-Mon2 IP-Audio, IP-Icom, 2022- Input 6, SDI Channel Ch1, Ch2, Ch3, Ch4, Ch5, Ch6, Ch7, Ch8, Ch9,...
  • Page 113 LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: Mom, Alt Eng Mode 0 O Switching mode for the Eng button at the back panel of the camera: momentary (push) or alternating (toggle) Mom, Alt...
  • Page 114 Menu references Buttons & Leds menu Function: Values: U: F: Description: RET2 Mode Mom, Alt 1 O Switching mode for the RET2 button: momentary (push) or alternating (toggle). Viewfinder Btn 1 None, Call, Box1, Box2, 1 O Assigns a function to button 1 of the VF 7-100 Box3, Box4, Box5, Box6, viewfinder.
  • Page 115: Configuration Menu

    LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: Multiview, Mix SXP Y/Ext Configuration menu Function: Values: U: F: Description: User Level Operate, Setup, Serv 1, - User access level. Serv 2, Serv 3, Devel...
  • Page 116 Menu references Configuration menu Function: Values: U: F: Description: Files Scene Files Store File Select Standard, SCam1, - Selects a Scene File for storing. SCam2, SCam3, SCam4 Store Exec, ... - Stores the Scene settings in the selected Scene file. Recall Standard, SCam1, File Select...
  • Page 117 LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: Store Exec, ... - Stores the Operator settings in the selected Scene file. Recall Standard, OCam1, File Select - Selects a Operator File for recall.
  • Page 118 Menu references Configuration menu Function: Values: U: F: Description: Video Mode 1080i50, 1080i59, 1080p50, 1080p59, 1080p23, 1080p24, 1080p25, 1080p29, 4K/ 50, 4K/59, 4K/150, 4K/ 179, 4K/23, 4K/24, 4K/25, 4K/29, 1080i150, 1080i179, 1080p150, 1080p179, 1080i300, 1080i359, 1080p300, 1080p359, None Mixed, HDR, SDR Video Workflow SDR LUT SDR LUT...
  • Page 119 LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: Native, Scaled Ext2 Ext3 Native, Scaled Native, Scaled Ext4 Ext1, Ext2, Ext3, Ext4, TP Ext1, Ext2, Ext3, Ext4, TP Live, VF, Ext Proxy Video Destinations...
  • Page 120 Menu references Configuration menu Function: Values: U: F: Description: Time Left 0 sec..65535 sec (0 sec) - Shows time left in seconds for the UHD 1x license Unknown, Not UHD 1x - Shows status of the UHD 1x license Applicable, ..., ... Time Left 0 sec..65535 sec (0 sec) - Shows time left in seconds for the UHD 1x license...
  • Page 121 LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: Unknown, Not LaterPay - Shows status of the LaterPay license Applicable, ..., ... 0 sec..65535 sec (0 sec) Time Left - Shows time left in seconds for the LaterPay license...
  • Page 122 Menu references Configuration menu Function: Values: U: F: Description: Time Zone UTC-12:00 .. UTC+11:00 (UTC+01:00) 0..65535 day (0 day) Duration Trial license None, GPS, NativeIP, Select Type UHD, UHD_3X, DirectIP+ Activate Exec, ... 0 sec..65535 sec (0) Time left Reference SDI Input, PTP, TriLvl, Reference Composite, FreeRun...
  • Page 123 LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: Off, On SDI embedding - ??? Aux Connector Off, On Menu Control - ??? Pin_14 Disable, TallyR, TallyY, - ??? TallyG Disable, TallyR, TallyY, Pin_17...
  • Page 124 Menu references Configuration menu Function: Values: U: F: Description: Sfp2 Off, Unknown, Active, Unavail Off, Unknown, Active, QSfp Unavail <IP address> - Selects Name Server 1 IP address. Apply Settings Exec, ... - Select Exec to apply the new IP settings Nameserver 2 No, Yes Use Server...
  • Page 125: Transmission Menu

    LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: Off, ProgInt, ProgExt, TestTone MPB PrgMon1, PrgMon2, Eng, Prod, Ch7, Ch8, Mon1Sdi, Mon2Sdi, Mon1Aes, Mon2Aes, Ch13, Ch14, Ch15, TstTrns, All TestTone Out Off, Audio 1, Audio 2,...
  • Page 126 Menu references Transmission menu Function: Values: U: F: Description: 0..31 (16) - Subnet Mask for SFP1 port [IP addr] (10.11.6.1) - Default Gateway for SFP1 port Port SFP2 Mode DHCP, Manual - Management protocol for SFP2 port [IP addr] (10.11.7.2) - IP address for SFP2 port 0..31 (16) - Subnet Mask for SFP2 port...
  • Page 127 LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: [IP addr] (192.168.1.2) 0 M IP address for NMOS server Port [Port No] (6000) 0 M IP port number for NMOS server v1.0, v1.1, v1.2, v1.3...
  • Page 128 Menu references Transmission menu Function: Values: U: F: Description: Port [Port No] (20004) 0 M IP port number for High Speed Video phase 2 No, Yes Enabled - Enable/disable High Speed Video phase 2 Phase 3 [IP addr] (224.11.5.5) 0 M IP address for High Speed Video phase 3 Port [Port No] (20005) 0 M IP port number for High Speed Video phase 3...
  • Page 129 LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: No, Yes Multicast 0 M Enable/disable Multicast for Video RX 2 [IP addr] (224.11.5.13) 0 M IP address for Video RX 2 Port [Port No] (20013)
  • Page 130: Diagnostics Menu

    Menu references Diagnostics menu Function: Values: U: F: Description: Src IP [IP addr] (10.11.8.5) 0 M Source IP address for Intercom Diagnostics menu Function: Values: U: F: Description: C2IP Network Communication 0..99 (0) C2IP Panels - Shows number of C2IP control panels connected to the camera.
  • Page 131 LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: Packets Sent <nnn> Panel Recv <nnn> SFP Modules QSFP present DHCP, Manual Mode - Management protocol for QSFP port [IP addr] (10.11.5.2) - IP address for QSFP port 0..31 (16)
  • Page 132 Menu references Diagnostics menu Function: Values: U: F: Description: Live Video No, Yes Enabled 0 M Enable/disable Live Video [IP addr] (224.11.5.10) 0 M IP address for Live Video Port [Port No] (20010) 0 M IP port number for Live Video ST2022-6, ST2110-20 Protocol 0 M IP Transport Protocol for Live Video...
  • Page 133 LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: 0.125 ms, 0.250 ms, Packet Time 0 M Packet Time for Intercom 1 ms 96..127 (97) PayloadID 0 M Payload ID for Intercom 2, 4, 8, 16...
  • Page 134 Menu references Diagnostics menu Function: Values: U: F: Description: Buffer Size 1,2,4,8,16, 32 ms 0 M Buffer size for Audio 96..127 (97) PayloadID 0 M Payload ID for Audio 1, 2, 4, 8, 16 Number of Ch 0 M Number of audio channels for Audio [IP addr] (10.11.8.4) Src IP 0 M Source IP address for Audio...
  • Page 135 LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: Unknown, NoSignal, VideoMode SD, 1080i59, 1080i50, 1080psf23, 1080psf24, 1080psf30, 1080p59, 1080p50, 1080p59_B, 1080p50_B, 1080p60, 4K59, 4K50, 4K47, 4K29, 4K25, 4K23, 4K24, 4K60, 1080p29, 1080p25, 1080p23, 1080p24,...
  • Page 136 Menu references Diagnostics menu Function: Values: U: F: Description: Cable Status OK, Critic, Error, NoSig OK, Critic, Error, NoSig Signal Status -100 dB..100 dB (0 dB) RX Margin Signal Error Cnt 0..65535 (50) Fib A (CAM->XCU) Cable Status OK, Critic, Error, NoSig OK, Critic, Error, NoSig Signal Status -100 dB..100 dB (0 dB)
  • Page 137 LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: 0..65535 (0) Stream RxBuf_1 Stream RxBuf_2 0..65535 (0) 0..65535 (0) Stream RxBuf_3 Streams Tx Available Tx Not Used Rx Requested Rx Subscribed Ethernet Tunnel Ok, Error...
  • Page 138 Menu references Diagnostics menu Function: Values: U: F: Description: Camera UNKNOWN, INVALID, Type LDX100, LDX150, LDX- C135, LDX135, LDX- C150, LDX100RF, LDX135RF, LDX150RF, LDX110, LDX-C110, LDX110RF v1, v2 HW Version Alias Alias Device ID 1..99 (18) Number Number 0..99 (0) MPB Image IMG 0, IMG 1, IMG 2, IMG 3, IMG 4, IMG 5,...
  • Page 139 LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: Type Component Valid Code Version Service Package Code Version Component Code Version Temperature Warning None, Front, Head, Mpb Fpga, Txb Fpga, Fan, Fan+T, !STOP! Off, Var, Manual...
  • Page 140 Menu references Diagnostics menu Function: Values: U: F: Description: Sensor Red -197 F..261 F (0 F) -197 F..261 F (0 F) Sensor Green -197 F..261 F (0 F) Sensor Blue Backpanel -197 F..261 F (0 F) Front Code 0..255 (0) Status Status PCB Status...
  • Page 141: Video Menu

    LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: Exec, Busy Abort Quick scan No location, Ok, Last Status known, Approx. Latitude 0..99 (0) Longitude 0..99 (0) No Fix, Auto Fix, Diff Fix, Fix Qual...
  • Page 142 Menu references Video Menu Function: Values: U: F: Description: SDR Mapping Manual, BBC 8-1, BBC 8- 2, BBC 9-1, BBC 9-2, BBC 12-1, BBC 12-2, NBC A.3, NBC B.5 Output Mode YCrCb 422, YCrCb 444, RGB 444 SMPTE2084, HLG, HDR Standard S HDR Standard: SMPTE 2084 (or PQ, Perceptual SLOG3, Lin Quantization) or HLG (= Hybrid Log-Gamma), S-Log3 or...
  • Page 143 LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: SawT, Step Test Select - Select Sawtooth or Stepped signal Acq Timing Off, On V-Shift S Switches V-Shift (acquisition timing shift) on or off. V-Shift Time 0..99 (0)
  • Page 144 Menu references Video Menu Function: Values: U: F: Description: Min Iris F1.4, F1.5, F1.7, F1.8, F2.0, F2.2, F2.4, F2.6, F2.8, F3.1, F3.4, F3.7, F4.0, F4.4, F4.8, F5.2, F5.6, F6.2, F6.7, F7.3, F8.0, F8.7, F9.5, F10.0, F11.0, F12.0, F13.0, F15.0, F16.0, F17.0, F19.0, F21.0, F22.0, F25.0 Max Iris F1.4, F1.5, F1.7, F1.8,...
  • Page 145 LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: Peak 0..99 (57) Custom measurement area for Auto Iris Peak 0..99 (86) Bottom measurement, when Area = Custom 0..99 (24) Left Right 0..99 (76) Average 0..99 (27)
  • Page 146 Menu references Video Menu Function: Values: U: F: Description: Max Gain 0 dB..15 dB (15 dB) Exposure Lighting Off, On Lighting S Enables/disables Lighting function -10 .. 0 .. +10 Correction S Sets the correction to fine-adjust for ambient lighting frequency when exposure time is set to 50 Hz or 60 Hz.
  • Page 147 LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: 0..99 (50) Slope M Point M 0..99 (60) Advanced Knee Mode Compat, PwrCurves Knee Limit 0..99 (99) Off, On Desat Desat Level 0..99 (50) 0..99 (30)
  • Page 148 Menu references Video Menu Function: Values: U: F: Description: Color Color gamut REC709, REC2020, LMS HDR ColorGamut S Selects Color Gamut to be used in HDR mode: REC709 = default color gamut REC2020 = extended color gamut LMS = LMS color space (LMS = Long, Medium and Short wavelengths) SDR Color Gamut REC709, REC2020...
  • Page 149 LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: 0%..150% (75%) Col Prot Lvl Col Corr Off, On Col Corr Col Corr View Off, On VF View Off, On 1, 2, 3, 4, 5, 6...
  • Page 150 Menu references Video Menu Function: Values: U: F: Description: 4K Detail Off, On Detail - Switches 4K Detail on or off. 0..99 (50) Detail Level - Sets the level of detail added to the video signal. Detail Source R+G, R, G, Y - Selects the video component that is used to generate 4K Detail signal.
  • Page 151: Service Menu

    LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: Keying Selection Width Red 0..99 (0) - Sets width level (Red). 0..99 (0) Width Blue - Sets width level (Blue). Color Red 0..99 (0) - Sets color level (Red).
  • Page 152 Menu references Service menu Function: Values: U: F: Description: Diag Files File Selection No, Yes Camera AppLog - Select Yes to include Camera Applog in diagnostics file Config Info No, Yes - Select Yes to include Camera Config in diagnostics file No, Yes Settings Info - Select Yes to include Settings Info in diagnostics file...
  • Page 153 LDX 110 / LDX 135 / LDX 150 User Guide Function: Values: U: F: Description: Black Calibr Black Calibr Off, Running Select to run Black Calibration Note: this takes up to 80 seconds to complete Status Unknown, OK, Error, Shows status of the Black Calibration procedure...
  • Page 154: Right Front Side

    C onnectors Right front side Bottom view Lens view- Front connector finder connector connector...
  • Page 155: Front Microphone Connector

    LDX 135 / LDX 150 User Guide Front microphone connector Microphone impedance >200 Ω Description Nominal input level is adjustable from Audio shield -22 dBu to -64 dBu in the camera menu. Phantom power (+48 V) on this socket Audio In (+) can be switched on or off.
  • Page 156: Right Side Connector Panel

    BNC E* HDMI* ☞ Note Note BNC C, BNC E, and HDMI are present in LDX 135 and LDX 150, but not in LDX 110. Ethernet Trunk/IP connector Ethernet 10/100/1000 Base-T compliant Description with IEEE-802.3 (edition 2000) Transmit Data 1+ (TX_D1+ )
  • Page 157: Ref/Aes Connector

    These BNC connectors can be programmed for different video output signals. Refer to Appendix C for more information about the video signals on these connectors. Note: BNC C and BNC E connectors are not available in the LDX 110. BNC connector...
  • Page 158: Back Panel

    Connectors Back panel Back panel Hybrid fiber transmission connector C2IP connector USB connector SERVICE ONLY RS-232 Intercom headset connector connector RS-232 AUDIO 2 LOCK Auxiliary CTRL Audio 2 input connector DC IN 12-17V AUDIO 1 DC Power Audio 1 input Output DC OUT 12V 4A...
  • Page 159: Usb Connector

    LDX 135 / LDX 150 User Guide USB connector USB type A connector (host) compatible Description with USB 2.0 standard + 5 VDC Data - USB type A Data + host connector (panel view) Intercom headset connector Microphone level: -64 dBu/-24 dBu Description (switchable) Microphone return...
  • Page 160: Dc Power Input Connector

    Connectors DC Power input connector DC Power input connector CAUTIONS: Description Input voltage must not exceed 17 V Pins 1 & 2 are Total input current must be <= 16A bridged Always use all 4 power pins +12 to +17 V Pins 3 &...
  • Page 161: Auxiliary Connector

    LDX 135 / LDX 150 User Guide Auxiliary connector Description Description Return A Tracker Microphone return Return B Tracker Microphone Tracker intercom to Production Tracker intercom to ENG Menu select Tracker telephone left Call indication 20-pin Hirose Tracker telephone return female connector Tracker telephone right Menu Up...
  • Page 162: Rs-232 Connector

    Connectors RS-232 connector RS-232 connector Serial connection 1: can be used for serial Description (private) data. Serial connection 2: can be used for TxD1 (serial connection 1) camera control or pan and tilt systems. TxD2 (serial connection 2) Signals are at RS-232 levels, 115 kB/s max. 6-pin Hirose RxD1 (serial connection 1) female connector...
  • Page 163: Introduction

    Media network, or the baseband connector panels on the camera head or the Base Station. ☞ Note Note The LDX 110 does not support NativeIP signals. ☞ Note Note One or more options/licenses may be required to operate the camera in the desired mode(s).
  • Page 164: Signal Settings

    Camera Graphic Panel (CGP). For LDX 135 and LDX 150, the BNC-E and HDMI outputs are preset to display the monitoring signal, which includes the camera menu. In the LDX 110, the monitoring signal is available on BNC-D (or BNC-B if BNC-D is set as an input).
  • Page 165 LDX 110 / LDX 135 / LDX 150 User Guide Phase/Link Configuration Standard VPID Resolution 4K50/59 2SI Single SMPTE 425-5:2019 SMPTE 352M link A-D 4K23/24/25/29 Single ST 2082 ST 292-1:2018 Merged phase and combined signals in 3x speed 1080i150/179 Combined, Phase 1, 2, 3...
  • Page 166: Licenses

    Procedures Licenses About options With Grass Valley licenses it is possible to temporarily or permanently add one or more options to your camera. Contact your local Grass Valley representative for information about the availability and prices of the different options.
  • Page 167 NFC stands for Near Field Communication which allows the camera to communicate with an NFC enabled device like a smartphone. For the LDX 100 Series, Grass Valley created the LDX Scanner, a free of charge application (app) for NFC enabled smartphones, both Android and IOS.
  • Page 168: Trial Licenses

    Calibrations Black Calibration In high-end broadcast cameras such as Grass Valley’s LDX 110 / LDX 135 / LDX 150, Black Calibration is an automated procedure that improves the image quality by re-mapping black level for each pixel to keep a consistent sensitivity over the entire image.
  • Page 169: How To Apply

    LDX 110 / LDX 135 / LDX 150 User Guide • recommended: when the ambient temperature changes by more than 20 °C / 36 °F. ✎ The best results are achieved when camera settings and calibration conditions are similar to the intended shooting situation, for example, shortly before a shooting.
  • Page 170: Full Black

    Updating camera software The basic procedure to update a camera package is as follows: • Go the Grass Valley to find the latest software package for your camera and download it to your local PC. • Connect your PC to the C2IP network (make sure you use the correct IP range) •...
  • Page 171: (Q)Sfp Modules Configurations

    Installation of (Q)SFP modules ☞ Note Note This chapter provides information on the Installation of (Q)SFP modules for LDX 135 and LDX 150 only. (Q)SFP modules configurations Depending on the workflow the optical connections of the camera need to be properly installed.
  • Page 172 Installation of (Q)SFP modules Changing (Q)SFP modules • Lift the panel by using the small recess at the left. Remove the panel. The optic cabling and Q(SFP) module(s) become visible. ☞ Note Note The inside of the panel holds the cooling pads for the (Q)SFPs. Make sure that they stay in place and do not get deformed.
  • Page 173 LDX 110 / LDX 135 / LDX 150 User Guide Caution Only use (Q)SFP modules that comply to LASER CLASS 1. Configuration 1 (1x 25G SFP module) (also valid for 1x 10G/10G+25G dual-rate SFP module) • Remove • Insert fiber A into the top LC socket of the SFP module and insert fiber B into the...
  • Page 174: List Of (Q)Sfp Modules

    • The camera is now ready for operation with the new (Q)SFP configuration. List of (Q)SFP modules The following (Q)SFP modules have been released for use with the LDX 110 / LDX 135 / LDX 150: manufacturer part number:...
  • Page 175 LDX 110 / LDX 135 / LDX 150 User Guide ☞ Note Note Make sure that the matching (‘other end’) (Q)SFPs in the IP switch have the same specifications.
  • Page 176: Specifications

    First wheel: Clear, 1/4 ND, 1/16 ND, 1/64 ND, capped; Second wheel: Clear, 4 point star, Soft focus (for LDX 135 and LDX 150), 2k OLP (for LDX 110); Fixed: 2.5µ Optical Low Pass filter Electronic color correction: 3200 K, 5600 K, 7500 K, FL, 2 AWB presets, Variable,...
  • Page 177: Video

    Reference input,output or AES digital audio BNC A to E connectors: Video BNC baseband connectors (1.5G, 3G or 12 G) Note: No BNC C and BNC E for LDX 110 Camera control network (C2IP) RJ-45 Ethernet connector (1 Gb/s) Ethernet/IP Trunk...
  • Page 178: Dimensions

    Specifications Dimensions Audio inputs (rear): 2x XLR-3 female, balanced, with +48 V phantom power Intercom: XLR-5 with Engineering, Production and Program channels DC Power input: 12 V (12 to 17 V), XLR-4 male <16 A DC Power output: 13 V, XLR-4 female < 4 A Dimensions 5 mm 92.7 mm...
  • Page 179: Contact Us

    Technical Support is available online in the GV Support Portal at community.grassvalley.com. For details on how to get Technical Support, Knowledge Base Articles, Software Downloads and more, see our FAQs in the Support Portal. For other Product Information and Grass Valley company information, go to www.grassvalley.com.

This manual is also suitable for:

Ldx 135Ldx 150

Table of Contents
