- Page 1 LDX 82 LDX 86 LDX 85N LDX 86N LDX 92 LDX 96 LDX 98 High Frame Rate/HD/3G/4K Camera Platform Maintenance Manual 13-00061-000 April 2023 v4.0 www.grassvalley.com...
-
Page 3: Patent Information
Grass Valley. Warranty information is available from the Legal Terms and Conditions section of Grass Valley’s website (www.grassvalley.com). LDX 82, LDX 86, LDX 85N, LDX 86N, LDX 92, LDX 96, LDX 98 High Frame Rate/HD/3G/4K Title Camera Platform... -
Page 4: Important Safety Information
LDX 82, LDX 86, LDX 85N, LDX 86N, LDX 92, LDX 96, LDX 98 High Frame Rate/HD/3G/4K Camera Platform Maintenance Manual Important Safety Information This section provides important safety guidelines for operators and service personnel. Specific warnings and cautions appear throughout the manual where they apply. Please read and follow this important information, especially those instructions related to the risk of electric shock or injury to persons. - Page 5 Notices Warnings A warning indicates a possible hazard to personnel, which may cause injury or death. Observe the following general warnings when using or working on this equipment: • Any instructions in this manual that require opening the equipment cover or enclosure are for use by qualified service personnel only.
- Page 6 LDX 82, LDX 86, LDX 85N, LDX 86N, LDX 92, LDX 96, LDX 98 High Frame Rate/HD/3G/4K Camera Platform Maintenance Manual intake exhaust intake Precautions To ensure continual high performance from the camera take the following precautions into consideration: • Avoid damp places. If the environment is wet or damp a rain cover must be used to protect the camera.
-
Page 7: Electrostatic Discharge (Esd) Protection
Grass Valley believes this environmental information to be correct but cannot guarantee its completeness or accuracy since it is based on data received from sources outside our company. All specifications are subject to change without notice. -
Page 8: Laser Safety
LDX 82, LDX 86, LDX 85N, LDX 86N, LDX 92, LDX 96, LDX 98 High Frame Rate/HD/3G/4K Camera Platform Maintenance Manual Laser Safety - Fiber Output SFP and QSFP Modules Warning LASER SAFETY The average optical output power does not exceed 0 dBm (1mW) under normal operating conditions. -
Page 9: Safety And Emc Standards
Notices Safety and EMC Standards This equipment complies with the following standards: Safety Standards IEC62368-1:2018 Audio/video, information and communication technology equipment: part 1 EN 62368-1:2018 EU national deviations. EMC Standards This unit conforms to the relevant Union harmonization legislation and the requirements of the following directive/standards: RED 2014/53/EU EMC testing;... - Page 10 LDX 82, LDX 86, LDX 85N, LDX 86N, LDX 92, LDX 96, LDX 98 High Frame Rate/HD/3G/4K Camera Platform Maintenance Manual This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
- Page 11 Notices...
- Page 12 LDX 82, LDX 86, LDX 85N, LDX 86N, LDX 92, LDX 96, LDX 98 High Frame Rate/HD/3G/4K Camera Platform Maintenance Manual EMC performance of cables and connectors Grass Valley products are designed to meet or exceed the requirements of the appropriate European EMC standards.
- Page 13 Notices...
- Page 14 LDX82/86/85n/86n (All versions) List of Field Replacable Units (FRUs): Part Number Description 510‐00006‐01 SIDEGRIP ASSY 3922 407 57423 V‐BLOCK MACHINED 510‐00009‐01 SHOULDERPAD ASSY...
- Page 15 All versions...
- Page 16 GNDLS HEAD LDX82-86-85n-86n List of Field Replacable Units (FRUs): Part Number Description Quantity 91-00095-000 FRONT MODULE CMOS 4K U23C For LDX85n/LDX86n/LDX98 500-00003-01 FRONT MODULE CMOS HS For LDX82/86/92/96 3922 407 51582 UV/IR FILTER ASSY 3922 407 61233 OPTICAL SWITCH ASSY 4-000000030-00 FRU kit DUSTCAP 524-00029-03...
- Page 17 Set of 3 flexes Set of 3 flexes GNDLS HEAD...
- Page 18 CAMERA HEAD BASIC List of Field Replacable Units (FRUs): Part Number Description Quantity 3922 407 40211 DIG.ZOOM HANDGRIP ASSY 4-000000029-00 FRU kit PCB F--- GENERIC FPC 45P 0.3MM L=68MM Au 524-00023-03 PCB F--- FPC 45P 0.3MM TL=160MM Au 4-000000020-00 FRU kit COMBI SCR PAN STL ST M3X6 522-00048-01 PCBA HS 4K RPB 4-000000007-00 FRU kit CLB FLEX...
- Page 20 3922 407 55801 - BOTTOM PLATE ASSY List of Field Replacable Units (FRUs): Part Number Description 3922 406 56001 INTERCON. POWER BRD 4-000000007-00 FRU kit CLB FLEX ↓ FRU kit contains Parts cannot be ordered separately 2422 015 18546 CLB FLEX 30P FFC 0.5 SUMICARD TL=81MM 30V 3922 205 00005 CLB FLEX 10P FFC 0.5 SUMICARD TL=46MM 30V 2422 015 19425...
- Page 22 3922 407 55811 - FRONT PLATE ASSY List of Field Replacable Units (FRUs): Part Number Description Quantity 4-000000023-00 FRU kit PAN CAP SCR STL.ST M3x10 4-000000020-00 FRU kit COMBI SCR PAN STL ST M3X6 3922 406 55981 FRONT SWITCH PANEL 4-000000015-00 FRU kit Misc parts camera head ↓...
- Page 24 500-00006-01 - TOP PLATE ASSY List of Field Replacable Units (FRUs): Part Number Description 3922 406 56021 PCBA Handgrip IF Board 4-000000020-00 FRU kit COMBI SCR PAN STL ST M3X6 4-000000007-00 FRU kit CLB FLEX ↓ FRU kit contains Parts cannot be ordered separately 2422 015 18546 CLB FLEX 30P FFC 0.5 SUMICARD TL=81MM 30V 3922 205 00005...
- Page 26 3922 407 55841 - COVER LEFT ASSY List of Field Replacable Units (FRUs): Part Number Description Quantity 4-000000023-00 FRU kit PAN CAP SCR STL.ST M3x10 4-000000020-00 FRU kit COMBI SCR PAN STL ST M3X6 3922 406 55991 PCBA LSP BOARD 3922 406 56141 PCBA LSP Rotary Board 4-000000007-00 FRU kit CLB FLEX...
- Page 28 500-00004-01 - COVER RIGHT ASSY List of Field Replacable Units (FRUs): Part Number Description Quantity 4-000000029-00 FRU kit PCB F--- GENERIC FPC 45P 0.3MM L=68MM Au 4-000000023-00 FRU kit PAN CAP SCR STL.ST M3x10 4-000000020-00 FRU kit COMBI SCR PAN STL ST M3X6 3922 406 57271 PCBA HS RCB 90-00157-000...
- Page 30 500-00052-01 - DOCKINGPLATE ASSY 4K List of Field Replacable Units (FRUs): Part Number Description Quantity 4-000000038-00 FRU kit 4K AIR GUIDE...
- Page 32 3922 407 40211 - DIG.ZOOM HANDGRIP ASSY List of Field Replacable Units (FRUs): Part Number Description Quantity 3922 407 40211 DIG.ZOOM HANDGRIP ASSY 3922 407 39502 ZOOMCONTROL ASSY 4-000000015-00 FRU kit Misc parts camera head ↓ FRU kit contains Parts cannot be ordered separately 3922 400 08501 SEALING VF-CONNECTOR 3922 400 10041...
