- Page 1 User’s Guide Shop online at omega.com e-mail: info@omega.com For latest product manuals: www.omegamanual.info NORWALK, CT CONNECTION HEAD STYLE PRS SERIES Spring Loaded Sanitary RTD Sensors with Thermowells...
- Page 2 M-4913-J Instruction Manual for Connection Head Style PRS Series Spring Loaded Sanitary RTD Sensors With Thermowells WIRING CONFIGURATION: GENERAL DESCRIPTION The Omega PRS Style sensors are supplied The OMEGA PRS series sensors are with 4-wire connections as shown in the designed for use in Sanitary Clean-In-Place schematic diagrams below.
- Page 3 M-4913-J Instruction Manual for Connection Head Style PRS Series Spring Loaded Sanitary RTD Sensors With Thermowells Resistance Vs. Temperature Table: (Resistance Values Stated in Ohms) Temperature °C 80.32 79.92 79.52 79.13 78.73 78.33 77.93 77.54 77.14 76.74 84.28 83.88 83.48 83.09...
- Page 4 Authorized Return (AR) number immediately upon phone or written request. Upon examination by OMEGA, if the unit is found to be defective, it will be repaired or replaced at no charge. OMEGA’s WARRANTY does not apply to defects resulting from any action of the purchaser, including but not limited to mishandling, improper interfacing, operation outside of design limits, improper repair, or unauthorized modification.
