- Page 1 Installation manual Washer extractor W4400H, W4600H, W4850H, W41100H Clarus Control Type W4.H. 438921198/US 2025.04.02...
- Page 3 Safety WARNING: ALL OPERATING AND MAINTENANCE PROCEDURES SHOWN ON THE NEXT PAGE OF THIS MANUAL MUST BE FOLLOWED DAILY FOR PROPER OPERATION OF YOUR MACHINE. MAKE CERTAIN TO KEEP THIS MANUAL IN A SECURE PLACE FOR FUTURE REFERENCE. PLEASE ENTER THE FOLLOWING INFORMATION AS IT APPEARS ON THE MACHINE(S) DATA PLATE(S).
- Page 4 Safety IMPORTANT SAFETY INSTRUCTIONS WARNING - To reduce the risk of fire, electric shock, or injury to persons when using your appliance, including the following: 1. Read all instructions before using the appliance. 2. This machine must be securely bolted to an uncovered concrete floor. 3.
- Page 5 Safety NOTICE TO: OWNERS, OPERATORS AND DEALERS IMPROPER INSTALLATION AND INADEQUATE MAINTENANCE, POOR HOUSEKEEPING AND WILLFUL NEGLECT OR BYPASSING OF SAFETY DEVICES MAY RESULT IN SERIOUS ACCIDENTS OR INJURY. TO ASSURE THE SAFETY OF CUSTOMERS AND/OR OPERATORS OF YOUR MACHINE, THE FOLLOWING MAINTENANCE CHECKS MUST BE PERFORMED ON A DAILY BASIS. Prior to operation of the machine, check to make certain that all operating instructions and warning signs are affixed to the machine and legible.
-
Page 6: Notice To Installer
Improper fastening of this machine to its foundation, inferior foundation materials, an undersized foundation, the use of fabricated steel bases not provided by Electrolux Professional or its approved supplier(s), the use of an improper type, number, or size of mounting bolts, or failure to use proper hardware on mounting bolts may result in damage to the machine that will not be covered by the manufacturer's warranty. -
Page 7: Table Of Contents
General safety information......................9 Commercial use only........................9 Copyright ..........................9 Symbols..........................10 2 Warranty terms and exclusions......................11 3 Technical data...........................12 Drawing ..........................12 3.1.1 W4400H ........................12 3.1.2 W4600H ........................13 3.1.3 W4850H ........................14 3.1.4 W41100H ........................15 Technical data .........................16 Connections ..........................16 4 Setup ...............................17 Unpacking ..........................17... -
Page 9: Safety Precautions
• The openings in the base, shall not be obstructed by a carpet. • Maximum mass of dry cloth: W4400H: 45 kg / 99 lbs, W4600H: 65 kg / 143 lbs, W4850H: 90 kg / 198 lbs, W41100H: 120 kg / 265 lbs. -
Page 10: Symbols
Installation manual 1.4 Symbols Caution Caution, high voltage Read the instructions before using the machine... -
Page 11: Warranty Terms And Exclusions
Warranty will be applicable where the customer has used only genuine spare parts and has performed maintenance in accordance with Electrolux Professional AB user and maintenance documentation made available in paper or electronic format. Electrolux Professional AB strongly recommends using Electrolux Professional AB approved cleaning, rinse and des- caling agents to obtain optimal results and maintain product efficiency over time. -
Page 12: Technical Data
Installation manual 3 Technical data 3.1 Drawing 3.1.1 W4400H 11,5° 11,5° Operating panel Door opening, ⌀ 535 mm / 21 1/16 inch Five-compartment detergent box, front (optional) Five-compartment detergent box, right hand side (optional) Cold water Hot water Third water (optional) -
Page 13: W4600H
Installation manual 3.1.2 W4600H 11,5° 11,5° Operating panel Door opening, ⌀ 535 mm / 21 1/16 inch Five-compartment detergent box, front (optional) Five-compartment detergent box, right hand side (optional) Cold water Hot water Third water (optional) Steam connection Drain Electrical connection Compressed air connection External liquid detergent connections, 6 pcs ⌀... -
Page 14: W4850H
Installation manual 3.1.3 W4850H Operating panel Door opening, ⌀ 700 mm / 27 9/16 inch Five-compartment detergent box, front (optional) Five-compartment detergent box, right hand side (optional) Cold water Hot water Third water (optional) Steam connection Drain Electrical connection Compressed air connection External liquid detergent connections, 6 pcs ⌀... -
Page 15: W41100H
Installation manual 3.1.4 W41100H Operating panel Door opening, ⌀ 700 mm / 27 9/16 inch Five-compartment detergent box, front (optional) Five-compartment detergent box, right hand side (optional) Cold water Hot water Third water (optional) Steam connection Drain Electrical connection Compressed air connection External liquid detergent connections, 6 pcs ⌀... -
Page 16: Technical Data
Installation manual 3.2 Technical data W4400H W4600H W4850H W41100H Weight, net 1095–1450* 1380–1480* 2200–2300* 2300–2400* 2414–3197 3042–3263 4850–5071 5071–5291 Drum volume litres 1100 14.1 21.2 38.8 Drum diameter 1220 1220 inch 36 1/4 38 9/16 48 1/16 48 1/16 Drum speed during wash Drum speed during extraction G-factor, max. -
Page 17: Setup
Installation manual 4 Setup 4.1 Unpacking The direction from which the machine must be lifted and the machine centre of gravity are shown on the packaging. Remove the side panels, the rear panel and the lower front panel. fig.5542 Remove the eight bolts securing the machine’s outer- and inner frame onto the pallet. Note! If the machine is equipped with weighing equipment, take extra care when removing the bolts, since the load cells fitted by the machine’s feet are sensitive to knocks and impacts. - Page 18 Installation manual Use a fork-lift truck to lift the machine. fig.5545 Position the four blocks of wood supplied, one beneath each machine foot (on the outer frame), within the recesses in the pallet. fig.7222 Lower the machine (A) and withdraw the truck forks (B). The machine should now be standing on the four blocks, and the pallet will be on the floor, clear of the machine.
- Page 19 Installation manual Lift the machine and remove pallet and blocks. fig.5548 The feet can be of two types: fixed feet or rotating feet if the machine is to be fitted with tilt or weighing equipment. For machines with tilt or weighing equipment: screw on the machine’s feet. Note! If the machine is to have the tilt function, this is a suitable time to install the corner posts which hold the pro- tective plates, and also, where applicable, the position sensors.
-
Page 20: Recycling Instruction For Packaging
Installation manual 4.2 Recycling instruction for packaging fig.X02411 Fig. Description Code Type Wrapping film LDPE 4 Plastics Screw FE 40 Steel Packaging FOR 50 Wood Pallet FOR 50 Wood Screw FE 40 Steel Washer FE 40 Steel Plastic bag PET 1 Plastics... -
Page 21: Siting
Installation manual 4.3 Siting The machine must not be sited over an open floor drain. Check that the floor has an even surface and is in level. The machine should be positioned so that there is plenty of room for working, both for the user and service personnel. The figure shows minimum distance to a wall and/or other machines. -
Page 22: Drilling Points
Installation manual 4.4.1 Drilling points The following tables shows the correct drilling points. 4.4.1.1 Standard machines W4400H W4600H W4850H W41100H inch 1325 1390 1640 1640 52 3/16 54 3/4 64 9/16 64 9/16 1445 1605 1635 1850 56 7/8 63 3/16... - Page 23 Installation manual 4.4.1.2 Machines with tilt or weighing equipment W4400H W4600H W4850H W41100H inch 1325 1390 1640 1640 52 3/16 54 3/4 64 9/16 64 9/16 1445 1605 1635 1850 56 7/8 63 3/16 64 3/8 72 13/16 1325 1380...
- Page 24 Installation manual Use a spirit level and, where necessary, the washers (or rectangular metal plates) supplied, to ensure that the floor mountings are in level. fig.3742 Put the machine in place. Use a spirit level on suitable surfaces of the outer frame to check that the machine is in lev- el.
-
Page 25: Water Connection
• Cold water (A) • Hot water (B) • Third water (C) Connection size (W4400H, W4600H): DN 25 (1" BSP). Connection size (W4850H, W41100H): DN 32 (1 1/4" BSP). fig.5869A There are DN (BSP) threads at the inlet valves for position (A), (B) and (C). - Page 26 Installation manual Water pressure: Continuous operating pressure: 50–800 kPa / 8–116 psi (0.5-80 kp/cm Maximum: 1000 kPa / 145 psi (10 kp/cm Recommended: 200–600 kPa / 30–90 psi (2–6 kp/cm Recommended water hardness: 3 grains per gallon Recommended pH-range: 7.0–8.0 Acceptable range for chloride concentration: 0–30 ppm Note! If the water pressure is below the minimum value, the wash result can not be guaranteed for certain program.
-
Page 27: Steam Connection
Connect the hose so it hangs in a gentle arc. (This is particularly important if the machine is fitted with a tilting function). Connect an approved hose between filter and machine. Connection size at filter (W4400H, W4600H): DN 20 (3/4" BSP). Connection size at filter (W4850H, W41100H): DN 32 (1 1/4" BSP). W4400H, W4600H... -
Page 28: Compressed Air Connection
Installation manual 7 Compressed air connection A pressure regulator complete with water separation device is to be installed on the machine. When the machine is supplied, the angled coupling (A), hose (B) and bracket (C) for the pressure regulator will al- ready be installed. -
Page 29: Drain Connection
Installation manual Connect the hose from the compressed air supply to the bushing on the pressure regulator. Connect the hose so it hangs in a gentle arc. (This is particularly important if the machine is fitted with a tilting function). The connecting hose must be rated for a pressure of at least 1 MPa. -
Page 30: Ventilation
Installation manual 9 Ventilation The vent (A) from the machine drum is at the back of the machine. If bleach or other additives are used, the pipe should be extended and connected to a ventilation system. fig.5872A 10 Detergent supply injector If only non-liquid detergents are to be used in the detergent supply injector, the following adaptation is recommended: Drill two ⌀... -
Page 31: Connection Of External Dosing Systems
Installation manual 11 Connection of external dosing systems 11.1 Connection of the hoses Note! All external equipment which is connected to the machine must be CE/EMC-approved. The machine is prepared for connection of external dosing systems or water re-use systems etc. The connections are closed at delivery. -
Page 32: Electrical Connection Of External Dosing System
Installation manual 11.2 Electrical connection of external dosing system The electrical installation may only be carried out by qualified personnel. The external dosage unit connects to the X146 via the upper terminal in the coin operation unit. There are a total of 8 outlets for the dosing of washing detergent. - Page 33 Installation manual Note! Check that the motor controller is energized. If not; the machine is connected with wrong phase sequence. If so; swap two phases according to the illustration. Depending on different machine model, the connection terminal can be one of the examples. fig.X04642 Check that the earth conductor is correctly connected.
-
Page 34: Electrical Connections
Installation manual Reconnect the primary power supply to the transformer as follows: W4400H Move the cables from position A to position B for a 208 V supply. Move the cables from position A to position C for a 200 V supply. - Page 35 Installation manual W4850H Heating alternative Main voltage Heating power Total power Recommended ITCB A Non heated/Steam 208-240V 3 ~ heated 440/480V 3 ~ W41100H Heating alternative Main voltage Heating power Total power Recommended ITCB A Non heated/Steam 208-240V 3 ~ heated 440/480V 3 ~...
-
Page 36: Installation Of Machines With Tilt Function
Installation manual 13 Installation of machines with tilt function Remove the side panels, the rear panel and the lower front panel. fig.3449 For machines with tilt both forwards and backwards Insert the two cylinder units (A) from the side of the machine underneath the machine frame. If there is vinyl floor-covering on the floor: To protect the floor from wear, a sheet of stainless steel should be laid be- neath each cylinder. - Page 37 Installation manual Secure the cylinder units using four bolts and nuts. Note! It is important to fit four washers (B) (each 5 mm thick) between each cylinder unit and the machine frame. fig.3453A Fit the four corner posts, one for each corner of the machine, using the bolts which secure the machine feet to the floor.
- Page 38 Installation manual For machines with tilt both forwards and backwards Fit two pneumatic position sensors (C) on two of the machine feet: at left-hand front and right-hand rear, diagonally opposed. The position sensors are to be fitted using the inner two fastening bolts of the feet, mounted on the corner posts just installed.
- Page 39 Installation manual Note that the tubes for the pressure sensors must be connected correctly. • Connection 1 – same side as data plate. • Connection 2 – same side as the inset white plate. fig.6026 For machines with forward tilt only The compressed air line to be connected to the air bellows is supplied bundled on the machine rear.
- Page 40 Installation manual Before refitting the panels, test the tilt function: • Switch on the machine electrical switch(es) and turn on the compressed air supply. • Open the door and lock it open. • The uppermost switch on the tilt control unit tilts the machine either backwards (turn switch counter clockwise) or forwards (turn switch clockwise).
- Page 41 Installation manual Fit the rubber dampers (E) and sleeves (F) to the front end of each side panel strip. Washer (G), nut (H), screw (I). fig.3485A Position and fasten the side panel strips. fig.3486...
- Page 42 Installation manual Fit the two counterweights to the front panel strip. The bolt heads should be at the bottom. fig.3487 Hang the front panel strip on the two sleeves fitted to the side strips. Protective plates are mounted on the front and rear.
-
Page 43: Disposal Information
Installation manual 14 Disposal information 14.1 Disposal of appliance at end of life Before disposing of the machine, make sure to carefully check its physical condition, and in particular any parts of the structure that can give or break during scrapping. The machine’s parts must be disposed of in a differentiated way, according to their different characteristics (e.g. - Page 44 www.electroluxprofessional.com...
