Sealey SCR84.V3 Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear eye
instructions protection
1. SAFETY
WARNING! Ensure health & safety, local authority and general workshop practice regulations are strictly adhered to when using this
‰
equipment.
Familiarise yourself with product application and limitations, as well as the specific potential hazards peculiar to this product.
9
Maintain creeper in good condition. Use an authorised service agent.
9
Replace or repair damaged parts. Use only genuine parts only. Non authorised parts will invalidate warranty.
9
WARNING! Use the creeper on level and solid ground, preferably concrete.
‰
DO NOT use the creeper for any purpose other than that for which is designed.
8
DO NOT stand on the creeper.
8
DO NOT get the creeper wet or use in damp or wet locations or areas where there is condensation.
8
DO NOT clean the creeper with any solvents which may damage the paint surface or padded areas.
8
2. INTRODUCTION
Solid and stable powder coat painted steel frame. Additional legs at the base of the frame allow vertical storage. Six Ø75mm Swivel
castors with composite wheels provide a smooth, non-marking and low-noise movement. Deep padding, and wide ergonomical vinyl
covered back and headrest.
3. SPECIFICATION
MODEL NO:
Capacity:
Size(s):
Wheels:
4. ASSEMBLY
Refer to Parts List attached
4.1. ATTACH THE HEADREST SUPPORT BAR
4.1.1. Position the headrest support bar within the main frame. Fit the top
two castors through main and headrest frames, and secure with spring
washer and castor wheel nut.
4.2. ATTACH THE HEADREST
4.2.1. Screw the headrest cushion onto the headrest frame using four cross
head screws from underneath.
4.3. ATTACH THE REMAINING 4 CASTOR WHEELS
4.3.1. Fix the remaining 4 castor wheels to the creeper frame using castor wheel nuts.
5. OPERATION
WARNING! If you raise the vehicle to work under it, set the vehicle on jack stands.
‰
DO NOT work under a vehicle raised on a jack(s).
8
5.1. If the vehicle is on the ground, block the tyres, apply the handbrake and put it into gear or Park mode.
5.2. As you slide under the vehicle and prior to sliding out on the creeper, keep your head flat on the headrest.
5.3. If storing the creeper vertically, store near a wall and with the cushions facing the wall.
6. MAINTENANCE
6.1. Before each use inspect the overall condition of the creeper for broken, cracked or bent parts that may effect the proper operation.
6.2. Periodically check tightness of fixings.
© Jack Sealey Limited
DELUXE STEEL CREEPER
MODEL NO:
SCR84.V3
180kg
1135 x 510 x 185mm
6
Original Language Version
SCR84.V3
FIG.1
VERTICAL
STORAGE
LEGS
HEADREST
CASTORS
SCR84.V3 Issue 1 18/01/24
