Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
Wear protective
instructions
gloves
1.
SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using a creeper.
Locate creeper in a suitable working area.
9
WARNING! Use creeper on level and solid ground, preferably concrete.
Keep the creeper clean and tidy in accordance with good workshop practice.
9
DO NOT use the creeper for any purpose other than that for which it is designed.
8
DO NOT stand on the creeper.
8
DO NOT get the creeper wet or use in damp or wet locations or areas where there is condensation.
8
DO NOT clean the creeper with any solvents which may damage the paint surface or padded areas.
8
2.
INTRODUCTION
Stand handles for the SCR75 and similar creepers, that allow the creeper to be stored vertically. Saving valueable space in a garage or
workshop. Steel frame with powder coat paint finish. Simply connect to your existing creeper with a single bolt.
3.
SPECIFICATION
Model No:
Nett Weight:
4.
ASSEMBLY
4.1.
Remove the stand handles from the protective packaging.
4.2.
Lay the parts out on the floor and position the creeper ready to assemble the stand handles.
4.3.
Locate the mounting holes on the creeper's frame. See fig.1.
4.4.
Attach one castor wheel to the bottom of the creeper's frame, and one stand handle to the top each side. See fig.1.
4.5.
Attach supplied crush washer and lock nut to each castor wheel bolt. Tighten lock nut using the supplied hex key wrench.
fig.1
5.
MAINTENANCE
Before each use inspect the overall condition of the creeper for broken, cracked or bent parts that may effect the proper operation.
© Jack Sealey Limited
STAND HANDLES FOR SCR75
SCR75.F
MODEL NO:
Wear eye
protection
SCR75.F
0.28kg
Original Language Version
