F or Outdoor Use Only
This instruction manual contains important information necessary
for the proper assembly and safe use of the appliance.
Read and follow all warnings and instructions before assembling
and using the appliance.
Follow all warnings and instructions when using the appliance.
Keep this manual for future reference.
Warning！
Do not cover the chimney cap and the door at the same
time when burning. An enclosed environment may cause an explosion.
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
INSTRUCTION MANUAL
Advertisement
Related Manuals for Outsunny 846-174V70
Summary of Contents for Outsunny 846-174V70
- Page 1 IN250100035V01_UK 846-174V70 WN-013T F or Outdoor Use Only This instruction manual contains important information necessary for the proper assembly and safe use of the appliance. Read and follow all warnings and instructions before assembling and using the appliance. Follow all warnings and instructions when using the appliance.
- Page 2 Read and follow all warnings and instructions before assembling and using the appliance. Safety Information DANGER ·If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. Remove hood 4. If odor continues, keep away from the appliance and immediately call your local fire department.
- Page 3 ·Do not operate the grill under unprotected combustible construction. · Inspect hoses before each use for excessive abrasion, wear, or cuts that may affect safe operation of the oven. If there is evidence of excessive abrasion or wear, or the hose is cut, it must be replaced prior to the oven being put into operation.
- Page 4 transit and warehousing. These webs can lead to gas flow obstruction, which could result in a fire in and around burner tubes. This type of fire is known as "flash-back"and can cause serious damage to your grill and create an unsafe operating condition for the user. Although an obstructed burner tube is not the only cause of flashback, it is the most common cause.
- Page 5 12 IN MIN 24 IN MAX 12IN WARNING Do not step over the propane hose,always walk around it.Stepping over the fuel hose may cause tipping of the gas cylinder. WARNING This appliance is not intended for and should never be used as a heater.
- Page 6 LP Tank Remo val, Transpor t and Stor age Turn OFF all control knobs and LP tank valve. Turning coupling nut counterclockwise by hand only--- do not use tools to disconnect. “Place dust cap on cylinder valve outlet whenever the cylinder is not in use. Only install the type of dust cap on the cylinder valve outlet that is provided with the cylinder valve.
- Page 7 Connecting Regulator to the LP Tank OPD Hand 1. Place LP tank on a secure, level, and stable surface. Wheel 2. Turn control knob to the OFF position. 3. Turn LP tank OFF by turning hand wheel clockwise to a full stop. Safety Type 1 outlet Relief...
- Page 8 Turn all control knob(s) to OFF. be stopped, do not try to repair. Operating the Gas Oven ·Failure to open the lid prior to igniting the barbecue's burners,or not waiting 5 minutes to allow the gas to clear if the barbecue does not light,may result in an explosive flame-up which can cause serious injury or death.
- Page 9 USE GAS BURNER Your gas will have following method of ignition: Ignition device Control Knob (AA battery should be installed inside.) Gas connection Intake Pulse igniter valve Switch button lgnition: 1. With control knobs on the Gas in the "OFF" position" OFF", turn on the gas cylinder. To create a spark, you must push &...
- Page 10 Technical data of Burner Moon & King Union GmbH Moon & King Union GmbH Product name: Pizza oven Product name: Pizza oven Pin Number:2531CU -0013 Pin Number:2531CU -0013 Hauptstr.12, 89143 Blaubeuren, Germany Hauptstr.12, 89143 Blaubeuren, Germany Serial Number: Serial Number: Model no.: DADA-001 Model no.: DADA-001 Main Burner...
- Page 11 TABLE OF CONTENTS Top Handle Gas Burner Pizza Peel Regulator Screw M5*12 Screw M4*8 Nut M4...
- Page 12 ASSEMBLING THE PIZZA OVEN STEP 1 A x 3 STEP 2...
- Page 13 ASSEMBLING THE PIZZA OVEN STEP 3 A x 4 STEP 4 B x 3 C x 3...
- Page 14 IMPORTER ADDRESS: Importador/REP: MH STAR UK LTD Spanish Aosom, S.L. Unit 27, Perivale Park, C/ Roc Gros, nº 15. 08550, Els Hostalets de Balenyà, Horsenden lane South Spain. Perivale, UB6 7RH B66295775 MADE IN CHINA HECHO EN CHINA Importé par/REP : MH France 2, rue Maurice Hartmann 92130 Issy-les-Moulineaux...
