For outdoor Use Only
● This instruction manual contains important information necessary for the proper assembly and safe use
of the appliance.
● Read and follow all warnings and instructions before assembling and using the appliance.
● Follow all warnings and instructions when using the appliance.
● Keep this manual for future reference.
Pour usage extérieur uniquement
● Ce manuel d'instructions contient des informations importantes nécessaires pour un assemblage
correct et une utilisation en toute sécurité de l'appareil.
● Lisez et suivez toutes les avertissements et instructions avant d'assembler et d'utiliser l'appareil.
● Suivez toutes les avertissements et instructions lors de l'utilisation de l'appareil.
● Conservez ce manuel pour référence future.
FR: IMPORTANT: A LIRE ATTENTIVEMENT ET A CONSERVER POUR VOUS Y
REFRERER ULTERIEUREMENT
EN: IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY.
IN250100036V01_US_CA
846-174V30
WN-013T
Advertisement
Related Manuals for Outsunny 846-174V30
Summary of Contents for Outsunny 846-174V30
- Page 1 IN250100036V01_US_CA 846-174V30 WN-013T For outdoor Use Only ● This instruction manual contains important information necessary for the proper assembly and safe use of the appliance. ● Read and follow all warnings and instructions before assembling and using the appliance. ● Follow all warnings and instructions when using the appliance.
- Page 2 Read and follow all warnings and instructions before assembling and using the appliance. Safety Information DANGER ·If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. Remove hood 4. If odor continues, keep away from the appliance and immediately call your local fire department.
- Page 3 ·Do not operate the grill under unprotected combustible construction. · Inspect hoses before each use for excessive abrasion, wear, or cuts that may affect safe operation of the oven. If there is evidence of excessive abrasion or wear, or the hose is cut, it must be replaced prior to the oven being put into operation.
- Page 4 transit and warehousing. These webs can lead to gas flow obstruction, which could result in a fire in and around burner tubes. This type of fire is known as "flash-back"and can cause serious damage to your grill and create an unsafe operating condition for the user. Although an obstructed burner tube is not the only cause of flashback, it is the most common cause.
- Page 5 12 IN MIN 24 IN MAX 12IN WARNING Do not step over the propane hose,always walk around it.Stepping over the fuel hose may cause tipping of the gas cylinder. WARNING This appliance is not intended for and should never be used as a heater.
- Page 6 LP Tank Remo val, Transpor t and Stor age Turn OFF all control knobs and LP tank valve. Turning coupling nut counterclockwise by hand only--- do not use tools to disconnect. “Place dust cap on cylinder valve outlet whenever the cylinder is not in use. Only install the type of dust cap on the cylinder valve outlet that is provided with the cylinder valve.
- Page 7 Connecting Regulator to the LP Tank OPD Hand 1. Place LP tank on a secure, level, and stable surface. Wheel 2. Turn control knob to the OFF position. 3. Turn LP tank OFF by turning hand wheel clockwise to a full stop. Safety Type 1 outlet Relief...
- Page 8 Turn all control knob(s) to OFF. be stopped, do not try to repair. Operating the Gas Oven ·Failure to open the lid prior to igniting the barbecue's burners,or not waiting 5 minutes to allow the gas to clear if the barbecue does not light,may result in an explosive flame-up which can cause serious injury or death.
- Page 9 USE GAS BURNER Your gas will have following method of ignition: Ignition device Control Knob (AA battery should be installed inside.) Gas connection Intake Pulse igniter valve Switch button lgnition: 1. With control knobs on the Gas in the "OFF" position" OFF", turn on the gas cylinder. To create a spark, you must push &...
- Page 10 Lire et sivere toutes les mises en garde et totes les instructions avant I'assemblage et I'utilisation de I'appareil. Safety Information DANGER ·Si vous sentez une odeur de gaz: 1. Coupez I'admission de gaz de I'aapareil. 2. Éteindre toute flamme nue. 3.
- Page 11 ·Ne pas utiliser le gril sous une structure combustible non protégée. · Vérifiez le tuyau avant chaque utilisation pour l'usure excessive, l'usure ou les incisions qui peuvent affecter le fonctionnement sûr du four. S'il y a des signes d'usure excessive ou d'usure, ou si le tuyau est coupé, il doit être remplacé...
- Page 13 12 IN MIN 24 IN MAX 12IN...
- Page 14 Toujours placer un bouchon cache- poussière sur la sortie du robinet de la bouteille lorsque la bouteille n'est pas en service. Utiliser uniquement le type de bouchon cache poussière fourni avec le robinet de la bouteille. D'autres types de bouchons peuvent entraîner une fuite de propane.
- Page 17 Soupape d’admission Allumeurs à impulsions Bouton de commutation élevé. S’il n’y a pas d’allumage dans les 5 secondes, éteindre la commande du brûleur et attendre 5 minutes avant de répéter la procédure d’allumage.Si vous avez encore des problèmes d’éclairage, veuillez contacter votre distributeur.
- Page 18 TABLE OF CONTENTS Top Handle Gas Burner Pizza Peel Regulator Screw M5*12 Screw M4*8 Nut M4...
- Page 19 ASSEMBLING THE PIZZA OVEN STEP 1 A x 3 STEP 2...
- Page 20 ASSEMBLING THE PIZZA OVEN STEP 3 A x 4 STEP 4 B x 3 C x 3...
