SteamSpa BLACK Series User Manual

Steam bath generator
Hide thumbs Also See for BLACK Series:

Advertisement

Quick Links

Download this manual
BLACK SERIES
MODELS
4.SKW
6KW
7.SKW
9KW
10.SKW
12KW
STEAM BATH GENERATOR
USER GUIDE
fci\
�

Advertisement

loading
Need help?

Need help?

Do you have a question about the BLACK Series and is the answer not in the manual?

Questions and answers

Related Manuals for SteamSpa BLACK Series

Summary of Contents for SteamSpa BLACK Series

  • Page 1 STEAM BATH GENERATOR USER GUIDE BLACK SERIES MODELS 4.SKW 7.SKW 10.SKW 12KW fci\ �...

  • Page 2: Product Registration

    PRODUCT REGISTRATION* IMPORTANT: Your warranty will not be recognized unless this card is fully completed and returned or online registration is completed. To ensure that your warranty is registered and confirmed please do one of the following: 1.You will be asked to fill out the same information you would in the registration card.
  • Page 3 Page 3...

  • Page 4: Important Safety Instructions

    WARNING steam to 10-15 minutes until you are certain of 1.Electrical grounding is required on all your bady’s reaction. SteamSpa Generators. 2.All electrical supplies should be disconnected D. Excessive temperatures have a high potential for when servicing generators. causing fetal damage during the early months of 3.To reduce the risk of explosions,...
  • Page 5 IMPORTANT SAFETY INSTRUCTIONS 6.Be certain that steam bath enclosures are 11.The steam outlet carries hot vapor! A separate properly sealed to avoid water damage from steam line is required for each steam outlet. Do escaping steam. It's recommended that not connect a valve or shut-off in the steam line! 100% silicone caulk be used to seal all pipes Avoid traps and valleys in the steam line where and fittings.
  • Page 6 APP MANUAL FOR STEAM GENERATOR Page 6...
  • Page 7 4. SteamSpa shall not be responsible for product damage or malfunction caused by self-installation or installation procedures which do not comply with user manual. Page 7 14. Always install generator in horizontally so that the water level sensor works normally.
  • Page 8 Steam outlet Safety valve Water inlet Water drainage Fuse for wire power supply Controller wire Power wire hole and light wire hole Fuse for wire power supply Steam outlet Safety valve Water inlet Water drainage Fuse for wire power supply Power wire hole Controller wire and light wire hole...
  • Page 9 Steam outlet Safety valve Water inlet Water drainage Fuse for wire power supply Power wire hole Controller wire and light wire hole Fuse for wire power supply Ampere Meter Electricity Electricity Specifications for 1. Test the voltage of the power supply Type Power KW supply (1PH)
  • Page 10 Page 10...
  • Page 11 Illustration 1.4 Page 11...
  • Page 12 INSTALLATION DRAWING OF DUAL STEAM GENERATORS Bluetooth Box Power supply cable for bluetooth box Adaptor Control cable Control panel Steam Supply Generator1 (Not provide) Pressure Relief Valve Steam Generator2 Dual Steam Outlet for Water Inlet 3/8"stainless 10.5kw 12kw stell braided flex hose Water Drain Valve Single Steam Water Shutoff Valve All piping must...
  • Page 13 6" Service clearance Service clearance minmum minmum Illustration 1.6.2 Illustration 1.6.3 Page 13...
  • Page 14 15 to 20 PSI. if necessary, decrease the pressure accordingly. 5. A hydro pneumatic pressure reducing valve must be installed. The SteamSpa quick release & pressure reducing kit comes with a pressure reducing device calibrated to work with any SteamSpa generator unit.
  • Page 15 Page 15...
  • Page 16 Supply Water Level Senor To Control Panel Red(ShortPin) Terminal Block Black(LongPin) Yellow/Green Yellow(MiddlePin) Black Black Black Supply Water Level Senor To Control Panel Red(ShortPin) Terminal Block Black(LongPin) Yellow/Green Yellow(MiddlePin) Black Black Black Page 16...
  • Page 17 Supply Water Level Senor To Control Panel Red(ShortPin) Terminal Block Black(LongPin) Yellow/Green Yellow(MiddlePin) Black Black Black Supply Water Level Senor Red(ShortPin) To Control Panel Terminal Block Black(LongPin) Yellow/Green Yellow(MiddlePin) Black Black Black Page 17...
  • Page 18 Page 18...
  • Page 19 Page 19...
  • Page 20 Page 20...
  • Page 21 REMARKS: The control panel comes with internal TEMP sensor, but external TEMP sensor is optional, when control panel is installed inside steam room,Internal TEMP sensor is ok. when control panel is installed outside steam room, external Page 21 TEMP sensor is necessary.
  • Page 22 AROMA PUMP Page 22...
  • Page 23 Page 23...
  • Page 24 Page 24...
  • Page 25 Outside secondary On/Off Control Page 25...
  • Page 26 outside secondary On/Off control outside secondary On/Off control secondary control Page 26...
  • Page 27 Page 27...
  • Page 28 Page 28...
  • Page 29 Page 29...
  • Page 30 Page 30...
  • Page 31 APP MANUAL FOR STEAM GENERATOR With the addition of the WF50 WIFI box, the steam generator be controlled remotely via our APP on your mobile. Please note that you will need an existing wireless router. ATTENTION: WIFI box is compatible with SS-BCT01BK control panel only, APP instructions part is only for user who purchased the WiFi box.
  • Page 32 2.USER REGISTRATION AND SIGN IN Click APP logo“Smart Life” to enter into login interface as picture shown, if it’s first time login, need to register new user account as guide. Register a new user account Click sign up if you have user account already 3.Adding your steam generator to the APP List On the first time use, you have to add your steam generator to the device list.
  • Page 33 Operations are needed as follows before inputting the password and clicking the Next" button. 1. Power on the control panel and proceed steps as follows in the first 5 minutes. 2.Touch the icon to enter the setting interface as displayed in picture. 3.
  • Page 34 4.OPERATION INTERFACE OF STEAM GENERATOR Exit the APP interface Change the title name Steam working time Steam TEMP. Aroma Chroma light Light Steam ON/OFF Appointment Timing Power on/off Setting Page 34...
  • Page 35 5.FUNCTION A.Steam temperature Setting Scroll up or down to set steam TEMP and click“confirm” Steam function on, Click“Tempe_Set” Click steam button B.Working Time Setting Scroll up or down to set steam TEMP and click“confirm” Steam function on， click“Timing”to enter timing setting interface Page 35...
  • Page 36 C.Appointment Setting Scroll up or down to set steam working time. Click Monday to Sunday to set working mode Click“Confirm”to sure setting and quit the interface Click“Appointment” D.Chroma Light Open the steam and chroma light at same time, press relative color icon to set light color we want. When we choose the chroma light icon, light change color automatically.
  • Page 37 E.Normal Light and Aroma Steam function on, click on the "light" button switch on/off the normal light. When steam function on, click aroma button to switch on/off the aroma function. F.Setting 1. Auto. clean function When steam function off, click the “Automatic wash” to start cleaning function.
  • Page 38 H.Share device and remove device Click“Shared devices” Click to remove device Click“Add sharing” To enter interface Enter the user account who you would like to share the device with him. But this user account should be registered on “smart life ”APP. After input the user account, click "Done"...
  • Page 39 The steam generator automatically performs a water discharge operation after each use. Page 39...
  • Page 40 Page 40...
  • Page 41 Bl ue B ro wn Page 41...
  • Page 42 WIRING CONNECTION DRAWING OF DUAL STEAM GENERATORS Page 42...
  • Page 43 Page 43...
  • Page 44 Page 44...
  • Page 47 SIZING CHART OF STEAM GENERATOR...
  • Page 48 SIZING CHART OF DUAL STEAM GENERATORS 265-370 15kw(total) 300-423 16.5kw(total) 350-460 18kw(total) 360-500 19.5kw(total) 380-530 21kw(total) 406-565 22.5kw(total) 440-600 24kw(total)

This manual is also suitable for:

Black 4.5kwBlack 6kwBlack 7.5kwBlack 9kwBlack 10.5kwBlack 12k
