TruVision S Series Configuration Manual

Hide thumbs Also See for S Series:
Table of Contents

Advertisement

Quick Links

Download this manual
TruVision S-series
Thermal Camera
Configuration Manual
P/N 1059-EN • REV A • ISS 17MAR22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TruVision S Series

Summary of Contents for TruVision S Series

  • Page 1 TruVision S-series Thermal Camera Configuration Manual P/N 1059-EN • REV A • ISS 17MAR22...
  • Page 2 Carrier, except where specifically permitted under US and international copyright law. Trademarks and TruVision and associated names and logos are a product brand of Aritech, patents a part of Carrier. Other trade names used in this document may be trademarks or registered trademarks of the manufacturers or vendors of the respective products.
  • Page 3 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points.

  • Page 5: Table Of Contents

    802.1x 25 Integration protocol 26 Network service 27 HTTP listening 28 SRTP 29 System setup 30 System settings 30 Maintenance 32 Security 34 User Management 36 Video and audio setup 40 Video settings 40 TruVision S-series Thermal Camera Configuration Manual...
  • Page 6 Advanced calibration 77 Temperature measurement setup 80 Automatic thermal imaging 80 Manual thermal imaging 89 Camera operation 90 Login and Logout 90 Live view 90 Playing back recorded video 93 Snapshot 96 Log 96 Index 98 TruVision S-series Thermal Camera Configuration Manual...

  • Page 7: Important Information

    PRODUCTS), SOFTWARE, SERVICES OR OTHER OFFERINGS WILL NOT BE HACKED, COMPROMISED AND/OR CIRCUMVENTED. CARRIER DOES NOT ENCRYPT COMMUNICATIONS BETWEEN ITS ALARM OR OTHER CONTROL PANELS AND THEIR WIRELESS OUTPUTS/INPUTS INCLUDING BUT NOT LIMITED TO, SENSORS OR DETECTORS UNLESS REQUIRED BY TruVision S-series Thermal Camera Configuration Manual...

  • Page 8: Warranty Disclaimers

    CARRIER DOES NOT WARRANT THAT ANY PRODUCT (INCLUDING SECURITY PRODUCTS), SOFTWARE OR SERVICE MANUFACTURED, SOLD OR LICENSED BY CARRIER WILL PREVENT, OR IN ALL CASES PROVIDE ADEQUATE WARNING OF OR PROTECTION FROM, BREAK-INS, BURGLARY, ROBBERY, FIRE, OR OTHERWISE. TruVision S-series Thermal Camera Configuration Manual...

  • Page 9: Intended Use

    Note: Note messages advise you of the possible loss of time or effort. They describe how to avoid the loss. Notes are also used to point out important information that you should read. TruVision S-series Thermal Camera Configuration Manual...

  • Page 10: Introduction

    Introduction Product overview This is the configuration manual for the following TruVision IP thermal camera models:  TVTH-S01-0001-BUL-G (IP Thermal Bullet Camera, 256×192 bi-spectral, 3 mm)  TVTH-S01-0002-BUL-G (IP Thermal Bullet Camera, 256×192 bi-spectral, 7 mm)  TVTH-S01-0003-BUL-G (IP Thermal Bullet Camera, 256×192 bi-spectral, 10 mm) ...

  • Page 11: Access Via A Web Browser

    This manual explains how to configure the camera over the network with a web browser. TruVision IP cameras can be configured and controlled using Microsoft Internet Explorer (IE) and other popular browsers. The procedures below described how to use Microsoft Internet Explorer (IE) and other web browsers.

  • Page 12: Activating The Camera

    There is no default password provided. You can activate a password via a web browser and via TruVision Device Manager to find the IP address of the camera. Activating the camera via a web browser: 1.
  • Page 13 Activating the camera via TruVision Device Manager: 1. Run TruVision Device Manager 9.1 or newer to search for TruVision cameras on your local network. 2. After launching Device Manager, the number of inactive TruVision devices (unconfigured devices recently connected to the network) can be displayed by clicking the Activate Device button.

  • Page 14: Using Non-Internet Explorer Web Browsers (Plugin-Free Browser)

    PC. Once the plugin is installed, you can reopen the browser to view and configure the camera. During installation of the plugin, Windows Defender may show a pop-up message which you should accept by clicking the “Allow access” button. TruVision S-series Thermal Camera Configuration Manual...

  • Page 15: Overview Of The Camera Web Browser

    The camera web browser lets you view, record, and play back recorded videos as well as manage the camera from any PC with Internet access. The browser’s easy-to-use controls give you quick access to all camera functions. See Figure 11 on page 91. TruVision S-series Thermal Camera Configuration Manual...

  • Page 16: Local Configuration

    Select the image format of snapshots: JPEG or BMP. Display Temperature Info. Enable to display the temperature information in live view. Display Rules Info on Enable to display rules information in captured files. Capture TruVision S-series Thermal Camera Configuration Manual...
  • Page 17 Specify the directory for saving snapshots in live view mode. View To Save Snapshots when Specify the directory for saving snapshots in playback mode. Playback To Save Clips during Playback Specify the directory for saving video clips in playback mode. TruVision S-series Thermal Camera Configuration Manual...

  • Page 18: Network Setup

    A valid password range must be at least eight characters. You can use a combination of numbers, lower- and upper-case letters, and special characters. The installer and/or end user are responsible for password management. TCP/IP You can set up the following TCP/IP parameters: Figure 2: TCP/IP parameters TruVision S-series Thermal Camera Configuration Manual...

  • Page 19: Ddns

    7. Reboot the device for the changes to take effect. DDNS DDNS is a service that maps Internet domain names to IP addresses. It is designed to support dynamic IP addresses, such as those assigned by a DHCP server. TruVision S-series Thermal Camera Configuration Manual...
  • Page 20 NO-IP web site. Then enter the user name and password that are registered with the No-IP network. 4. Click Save to save changes. 5. Reboot the device for the changes to take effect. TruVision S-series Thermal Camera Configuration Manual...

  • Page 21: Pppoe

    Server Port: The default server port is 8000, and it can be changed to any port number from 2000 to 65535. Enhanced SDK Service Port: The default server port is 8433, and it can be changed to any port number from 2000 to 65535. TruVision S-series Thermal Camera Configuration Manual...

  • Page 22: Port Mapping

    A NAT (Network Address Translation) is used for network connection. Select the port mapping mode: auto or manual. To set up the NAT parameters: 1. Click Configuration > Network > Basic Settings > NAT. TruVision S-series Thermal Camera Configuration Manual...

  • Page 23: Multicast

    UPnP TM function at the router. Note: If you choose Auto 4. Click Save to save changes. Multicast Multicast is a protocol for discovering devices on networks. Configure multicast to make the device discoverable. TruVision S-series Thermal Camera Configuration Manual...

  • Page 24: Snmp

    Video Stream and inputting port number in Video Port and Audio Port. SNMP SNMP is a protocol for managing devices on networks. Enable SNMP to get the camera status and parameter related information. TruVision S-series Thermal Camera Configuration Manual...
  • Page 25 2. Select the corresponding version of SNMP: v1 or v2c. 3. Configure the SNMP settings. The configuration of the SNMP software should be the same as the settings you configure here. 4. Click Save to save changes. TruVision S-series Thermal Camera Configuration Manual...

  • Page 26: Ftp

    Subdirectory is selected, you can use the Camera Name or Camera No. as the name of the directory. Upload Picture: To enable uploading the snapshots to the FTP server. 3. Click Save to save changes. TruVision S-series Thermal Camera Configuration Manual...

  • Page 27: Email

    Encrypt via SSL, TLS. NONE is default. Attached Image: Select this check box if you want to send emails with attached alarm snapshots. Interval: This is the time between two actions of sending attached images. TruVision S-series Thermal Camera Configuration Manual...

  • Page 28: Https

    2. Select Enable HTTPS and allow FTP to allow connections using HTTPS or HTTP. 3. Select Force HTTPS Browsing forces to use HTTPS instead of HTTP. HTTPS certificates can be managed from this page TruVision S-series Thermal Camera Configuration Manual...

  • Page 29: Qos

    DSCP value is, the higher the priority is. 3. Click Save to save changes. 802.1x When the feature is enabled, the camera data is secured, and user authentication is needed when connecting the camera to the network. TruVision S-series Thermal Camera Configuration Manual...

  • Page 30: Integration Protocol

    CGI function. If you need to access the camera through the ONVIF protocol, you can configure ONVIF from this interface. Refer to ONVIF standard for detailed configuration rules. To set up the integration protocol parameters: 1. Click Configuration > Network > Advanced Settings > Integration Parameters. TruVision S-series Thermal Camera Configuration Manual...

  • Page 31: Network Service

    Websockets: To access the camera, enable this function if using Microsoft Internet Explorer. • SDK Service and Enhanced SDK Service: Enable these functions to be able to use the device with a VMS (like TruVision Navigator or a third-party software using the SDK). SDK Service uses the SDK protocol.

  • Page 32: Http Listening

    Alarm information can be sent to destination IP or Host via HTTP protocol. To set up the HTTP listening parameters: 1. Click Configuration > Network > Advanced Settings > HTTP Listening. 2. Enter the destination IP or host name, URL, protocol type and port number. TruVision S-series Thermal Camera Configuration Manual...

  • Page 33: Srtp

    To set up the SRTP parameters: 1. Click Configuration > Network > Advanced Settings > SRTP. 2. Select the server certificate type: No certificate or Default. 3. Select the desired encrypted algorithm. 4. Click Save to save changes. TruVision S-series Thermal Camera Configuration Manual...

  • Page 34: System Setup

    NTP (Network Time Protocol) is a protocol for synchronizing the clocks of network devices, such as IP cameras and computers. Connecting network devices to a dedicated NTP time server ensures that they are all synchronized. TruVision S-series Thermal Camera Configuration Manual...
  • Page 35 DST (Daylight Savings Time) function and set the dates of the DST period. 5. Click Save to save changes. RS-232 RS-232 is used by Technical Support or to access a peripheral device. TruVision S-series Thermal Camera Configuration Manual...

  • Page 36: Maintenance

    There are two options available:  Restore: Restore all the parameters, except the IP parameters and user information, to the default settings.  Default: Restore all the parameters to the default settings. TruVision S-series Thermal Camera Configuration Manual...
  • Page 37 Only the new features are added with their default settings. In some cases, a factory default might be required after upgrade. Always refer to the FW release note when upgrading. TruVision S-series Thermal Camera Configuration Manual...

  • Page 38: Security

    This function allows you to give or deny access rights to defined IP addresses. For example, the camera can be configured so that only the IP address of the server hosting the video management software can access the camera. TruVision S-series Thermal Camera Configuration Manual...
  • Page 39 (no different times of attempts for the admin/operator/user). B. If the IP address is blocked, you can try to log in to the device again after 30 minutes. TruVision S-series Thermal Camera Configuration Manual...

  • Page 40: User Management

    Configure the server settings under Advanced Settings. Figure 5: Security Audit Log window User Management This section describes how to manage users. You can: • Add or delete users • Modify permission • Modify passwords TruVision S-series Thermal Camera Configuration Manual...
  • Page 41 4. Select the type of user from the Level drop-down list. The options are User and Operator. 5. Enter the Admin Password 4. In the Password and Confirm fields enter and confirm a password for the new user. The passwords must meet following requirements: TruVision S-series Thermal Camera Configuration Manual...
  • Page 42 4. Click Save to save the changes. Online users Use this menu to display users currently connected to the camera. You can see the following user information: user name, level, IP address, and operation time. TruVision S-series Thermal Camera Configuration Manual...
  • Page 43 TruVision S-series Thermal Camera Configuration Manual...

  • Page 44: Video And Audio Setup

    2. Select the channel number (1): normal (Camera 01) or thermal (Camera 02). 3. Modify the desired video functions: Function Description Channel number Select the channel mode: normal (Camera 01) or thermal (Camera 02). Stream Type Specifies the streaming method used. Select Main Stream or Substream. TruVision S-series Thermal Camera Configuration Manual...

  • Page 45: Audio Settings

    However, the video quality may be impacted. Display VCA Info Select the display media as Player or Video. Player: The VCA info can displayed only by the TruVision player provided. Video: The VCA info can displayed by any general video player. 15. Click Save to save the changes.

  • Page 46: Display Info On Stream

    When Dual-VCA mode is enabled, the camera sends video analytics metadata to an NVR or other platforms when reporting a VCA event. For example, with a TruVision NVR (please check our website for the latest NVR models supporting this feature), you can draw a virtual line in the NVR playback window, and search the objects or people crossing this virtual line.
  • Page 47 Region Name: Enter the desired region name. 5. Using the mouse, draw an area on the image. 6. Repeat steps 3 to 5 to set other regions. Up to eight regions can be set. 7. Click Save to save changes. TruVision S-series Thermal Camera Configuration Manual...

  • Page 48: Image Setup

    Applies to both normal camera mode (Camera 01) and thermal camera mode (Camera 02). Saturation and Adjust the saturation and sharpness parameters. Sharpness Applies to both normal camera mode (Camera 01) and thermal camera mode (Camera 02). TruVision S-series Thermal Camera Configuration Manual...
  • Page 49 ON: The IR LEDs are ON when the camera changes to night mode. OFF: The IR LEDs are OFF when the camera changes to night mode Note: The IR LEDs are always OFF in day mode. TruVision S-series Thermal Camera Configuration Manual...
  • Page 50 Default is 50. Defog Mode You can enable the defog function when the environment is foggy and obscures the image. It enhances the subtle details so that the image appears clearer. Default is OFF. TruVision S-series Thermal Camera Configuration Manual...
  • Page 51 Select the desired colors for the thermal view. Select White Hot, Black Hot, Fusion 1, Rainbow, Fusion 2, Ironbow 1, Ironbow 2, Sepia, Color 1, Color 2, Ice Fire, Rain, Red Hot, Green Hot, or Dark Blue. Default is White Hot. TruVision S-series Thermal Camera Configuration Manual...
  • Page 52 The red rectangle will appear in a set area on screen if you click up, down, left, right, center_50%, or center_75%. Select “Custom Area” from the drop-down list to a draw the desired area as a customized size anywhere on screen. TruVision S-series Thermal Camera Configuration Manual...
  • Page 53 This option can be used, for example, to display emergency contact details. Each text line can be positioned anywhere on screen To position the date/time and name on screen: 1. Click Configuration > Image > Settings. TruVision S-series Thermal Camera Configuration Manual...

  • Page 54: Privacy Masks

    The masking appears as a blank area on screen. You can create up to four privacy mask areas per camera. See Figure 7 on page 51 for an example. TruVision S-series Thermal Camera Configuration Manual...

  • Page 55: Picture Overlay

    The Picture Overlay function enables you to overlay a picture, such as a company logo, on the image, for example. The picture must be in BMP format and the maximum size of the picture is 128*128. TruVision S-series Thermal Camera Configuration Manual...

  • Page 56: Defective Pixel Correction

    > DPC. 2. Select the channel number: normal (Camera 01) or thermal (Camera 02). 3. Select Manual Mode. 4. Click the defective pixel on the image. A cursor appears on the image in live view. TruVision S-series Thermal Camera Configuration Manual...
  • Page 57 Table, select the desired colors for Normal (average), Pre-alarm and Alarm temperatures that are displayed in normal configuration mode. 5. Click Save to save changes. The changes are immediately visible in the Thermal channel screen. TruVision S-series Thermal Camera Configuration Manual...

  • Page 58: Event Setup

    1. From the menu toolbar, click Configuration > Basic Event > Alarm Input. 2. There is only one alarm input, A<1. 3. Select the alarm input type, NO (normally open) or NC (normally closed). Default is TruVision S-series Thermal Camera Configuration Manual...
  • Page 59 4. The alarm status cannot be changed. It is OFF. 5. Select the alarm output type, NO (normally open) or NC (normally closed). Default is 6. Optional. You can enter a name for the alarm. TruVision S-series Thermal Camera Configuration Manual...
  • Page 60 IP Address Conflicted: Conflict in IP address setting. • Illegal Login: Wrong user ID or password used to log in to the cameras. To define exception alarms: 1. From the menu toolbar, click Configuration > Basic Event > Exception. TruVision S-series Thermal Camera Configuration Manual...
  • Page 61 4. Click Save to save changes. Flashing alarm LED output Use this menu to set up how the strobe light on the camera responds to an alarm, such as the flashing duration and frequency. TruVision S-series Thermal Camera Configuration Manual...
  • Page 62 4. When you hover the mouse above a timeline a small green copy button appears at the end of the bar. Click it to copy the selected schedule of that day to another day and click OK. 5. Click Save to save changes. TruVision S-series Thermal Camera Configuration Manual...

  • Page 63: Audible Alarm Output

    Custom Audio: Upload a custom audio file. The file must be .wav format no larger than 512KB. Its sampling rate should be 8 KHz. 4. Under Repeat Warning enter the number of times the warning will be repeated. TruVision S-series Thermal Camera Configuration Manual...

  • Page 64: Audio Exception Detection

    1. From the menu toolbar, click Configuration > Smart Event > Audible Exception Detection. 2. From the camera list, select Camera 1 (only Camera 1 is available). This function is not available in the bi-spectral thermal camera (Camera 2). TruVision S-series Thermal Camera Configuration Manual...
  • Page 65 Trigger external alarm outputs when an event occurs. Select the desired which alarm outputs. Note: This option is only supported by cameras that support alarm output. Trigger Recording Trigger the recording to start in the camera. 6. Click Save to save changes. TruVision S-series Thermal Camera Configuration Manual...

  • Page 66: Storage Setup

    5. Advanced button. Click to set extra recording settings such as pre- and post-recording times, stream type, and the number of days to keep videos/snapshots. 6. Copy button. Click to copy schedules between cameras. TruVision S-series Thermal Camera Configuration Manual...
  • Page 67 Enable Auto Delete Mode: When enabled, recorded video older than the number of days defined by “Delete after” will be automatically deleted, even if the full storage capacity has not been reached. Click Save to save changes. TruVision S-series Thermal Camera Configuration Manual...
  • Page 68 FTP if this option is disabled. To set up continuous and event-triggered snapshots: 1. From the menu toolbar, click Configuration > Storage > Schedule Management > Capture > Capture Schedule. Note: Continuous is the only recording type available. TruVision S-series Thermal Camera Configuration Manual...
  • Page 69 2. Click and-drag the mouse on the timeline of the desired days to set the capture schedule. 3. Click Advanced to select the stream type. 4. Select the Capture Parameters tab to configure the captured snapshot parameters. TruVision S-series Thermal Camera Configuration Manual...

  • Page 70: Storage Management

    Number, enter the total number of snapshots that can be taken. 7. Click Copy to… to copy the recording schedules to another camera. 8. Click Save to save changes. Storage management SD card and NAS parameters can be managed in the Storage Management menu. TruVision S-series Thermal Camera Configuration Manual...
  • Page 71 3. Select the HDD No. check box of the desired storage device. Select the check box of the uninitialized disk and click the Format button to start initialization. When completed, the status changes to “Normal”. TruVision S-series Thermal Camera Configuration Manual...
  • Page 72 To set up a NAS system: 1. Add the network disk. a) From the Configuration panel, click Configuration > Storage > Storage Management > NAS. TruVision S-series Thermal Camera Configuration Manual...
  • Page 73 2. Initialize the disk that has been added. From the Configuration panel, click Configuration > Storage > Storage Management > Management. See “HDD Management” on page 67 for further information. TruVision S-series Thermal Camera Configuration Manual...

  • Page 74: Vca Setup

    Live View parameters window. Enable Display Rules Info on Capture and click Save 2. From the menu toolbar, click Configuration > > Basic Settings. 3. Select the desired settings: Display on Stream: TruVision S-series Thermal Camera Configuration Manual...

  • Page 75: Camera Calibration

    If it fails to take the four photos, you then need to manually calibrate the camera. To automatically calibrate the camera: 1. From the menu toolbar, click Configuration > > Camera Calibration. TruVision S-series Thermal Camera Configuration Manual...
  • Page 76 6. Verify the result of the calibration. See “To verify the calibration result” below for more information. To manually calibrate the camera: 1. From the menu toolbar, click Configuration > > Camera Calibration. 2. Select Manual Calibration. TruVision S-series Thermal Camera Configuration Manual...
  • Page 77 1. From the menu toolbar, click Configuration > > Shield Region. 2. Click and draw an area to be masked. Click to draw each area. To delete an drawn area, select the desired area and click TruVision S-series Thermal Camera Configuration Manual...
  • Page 78 You can set up rules to determine when VCA events trigger alarms. There can be a maximum number of eight rules. To add a VCA rule: 1. From the menu toolbar, click Configuration > > Rule. TruVision S-series Thermal Camera Configuration Manual...
  • Page 79 Cross line: Select Bi-directional, A-to-B, or B-to-A. Target Detection: Select Person, Vehicle, or Person & Vehicle (recommended). Intrusion Duration: Select the alarm sensitivity between 0 and 100. TruVision S-series Thermal Camera Configuration Manual...
  • Page 80 10. Set up the linking method for a rule. Click Alarm Linkage to trigger an action when the motion event occurs. Select one or more response methods for the system when a motion detection alarm is triggered: TruVision S-series Thermal Camera Configuration Manual...

  • Page 81: Advanced Calibration

    To adjust the detection and restore parameters: 1. From the menu toolbar, click Configuration > > Advanced Configuration. 2. Adjust the desired parameters. TruVision S-series Thermal Camera Configuration Manual...
  • Page 82 The higher the value, the greater the analysis done on the target’s movement. Default is 2. It is recommended to use a lower value so that a detection box is more quickly generated and triggers an alarm. TruVision S-series Thermal Camera Configuration Manual...
  • Page 83 Use Leaves Interfered View if there are shaking items in view such as leaves. Default is General. 8. Restore Defaults Restore the defaults values of the VCA configuration parameters. 9. Restart VCA Restart the VCA function. 3. Click Save to save changes. TruVision S-series Thermal Camera Configuration Manual...
  • Page 84 To set up the parameters for thermal imaging: 1. From the Configuration panel, click Configuration > Local Configuration. To ensure that temperature information is displayed: Enable Display Temperature Info. TruVision S-series Thermal Camera Configuration Manual...
  • Page 85 Display Rules Info on Capture. Click Save to save changes. 2. From the Configuration panel, click Configuration > Temperature Measurement > Basic Settings. Note: The parameters available depend on the camera model. 3. Select the parameters: TruVision S-series Thermal Camera Configuration Manual...
  • Page 86 The Normal configuration menu lets you define how to display the temperature range on the camera image. It shows the maximum, minimum and average temperatures. It also lets you select where the average temperature information is displayed on screen. TruVision S-series Thermal Camera Configuration Manual...
  • Page 87  Yellow text: The pre-alarm temperature threshold has been triggered.  Red text: The alarm temperature threshold has been triggered. Figure 9: An example of the overview of the temperature range in a camera image TruVision S-series Thermal Camera Configuration Manual...
  • Page 88 Pre-alarm Output Select to link the pre-alarm to the connected device. Alarm Output Select to link the alarm to the connected device. Click Save to save changes. TruVision S-series Thermal Camera Configuration Manual...
  • Page 89 53. Create rules for point, line, and area thermal-imaging targets You can set up the camera so that it can monitor the temperature of specific points, lines, or areas in the camera image. TruVision S-series Thermal Camera Configuration Manual...
  • Page 90 Line: Left click two points on the live view viewer to draw the line. Area: Left click three or more points to create an area on the live view viewer. Right click to stop adding a point to the area. TruVision S-series Thermal Camera Configuration Manual...
  • Page 91 52°C will the alarm be cancelled Pre-alarm and Alarm Outputs: Select the alarm outputs to be triggered. Click to save the changes. 8. Optional: Click the Area’s Temperature Comparison button to set the alarm output rules for temperature. TruVision S-series Thermal Camera Configuration Manual...
  • Page 92 Flashing Alarm Trigger an LED on the camera to flash. Audible Warning Trigger an audible beep when an alarm is detected by the camera. Trigger Recording Trigger the recording to start in the camera. TruVision S-series Thermal Camera Configuration Manual...
  • Page 93 Enable Temperature Measurement. Click Save to save changes 3. Go to Live View and under the PTZ menu select . Then click any area in the live view image to see the actual temperature displayed. TruVision S-series Thermal Camera Configuration Manual...

  • Page 94: Camera Operation

    The thermal imaging information displayed on screen depends on the Live View parameter settings under “Local configuration” on page 12:  Display Rule information  Display Temperature information  Display Trajectory For the VCA image information displayed, see “Basic settings” on page 70. TruVision S-series Thermal Camera Configuration Manual...
  • Page 95 Click to manually start/stop recording and stored it in the directory configured. Click to start/stop digital zoom function. Click to move to previous page. Click to move to next page. Live view with main stream or substream. Turn on/off microphone. TruVision S-series Thermal Camera Configuration Manual...
  • Page 96 The instructions below assume that you have set up both normal and advanced temperature measurement settings (see “Automatic thermal imaging” on page 80 for more information). To display temperature measurements on screen, ensure that:  Configuration > Local Configuration > Display Temperature Info is enabled. TruVision S-series Thermal Camera Configuration Manual...

  • Page 97: Playing Back Recorded Video

    Note: You must configure NAS or insert an SD card in the camera to be able to use the playback functions. To search recorded video stored on the camera’s storage device for playback, click Playback on the menu toolbar. The Playback window appears. See Figure 12 on page TruVision S-series Thermal Camera Configuration Manual...
  • Page 98 Download functions Download video files. Recording type The color code displays the recording type. Recording types are continuous recording, alarms recording, and manual recording. Zoom in/out Click to zoom in or out of the timeline. TruVision S-series Thermal Camera Configuration Manual...
  • Page 99 To archive recorded video files: 1. Click to open the recorded file search window. 2. Select the file type and set start and end time. 3. Click Search to search for the recorded video files. TruVision S-series Thermal Camera Configuration Manual...
  • Page 100 When this capacity is reached, the system will start overwriting older logs. To view log events stored on storage devices, click on the menu toolbar to open the log menu. TruVision S-series Thermal Camera Configuration Manual...
  • Page 101 Major Type Minor Type drop-down list, select the desired options. 3. Set start and end time of the log. 4. Click Search to start the search operation. The results appear in the left window. TruVision S-series Thermal Camera Configuration Manual...
  • Page 102 22 description, 63 Hard drive QoS parameters capacity, 67 set up, 25 formatting, 67 HTTP listening parameters set up, 28 HTTPS parameters Reboot camera, 32 set up, 24 Recording playback, 92 Recording settings, 62 TruVision S-series Thermal Camera Configuration Manual...
  • Page 103 Time format set up, 49 Security audit log, 36 Snapshots archive, 94 Video clips event-triggered snapshots, 64 archive, 94 scheduled snapshots, 64 SNMP parameters set up, 20 System time Web browser set up, 30 interface overview, 11 TruVision S-series Thermal Camera Configuration Manual...
