Aloka SSD-1000 Service Manual

Echo camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SERVICE MANUAL
ECHO CAMERA
SSD-1000
1 / 1
English Edition
Document Number
: MN2-0218
: 0
Document Revision
©
Copyright
FILE 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SSD-1000 and is the answer not in the manual?

Questions and answers

Related Manuals for Aloka SSD-1000

Summary of Contents for Aloka SSD-1000

  • Page 1 SERVICE MANUAL ECHO CAMERA SSD-1000 1 / 1 English Edition Document Number : MN2-0218 Document Revision © Copyright FILE 1...
  • Page 2 MN2‑0218 SSD-1000 SERVICE MANUAL Contents of SSD-1000 SERVICE MANUAL PAGE Section 1 How to use this service manual page 1-1〜1-4 (4 pages) ‥‥‥‥ ‥‥‥‥ 1-1 Service Manual 1- 1 ‥‥‥‥ ‥‥‥‥ 1-2 Contents of this Service Manual 1- 1 ‥‥‥‥...

  • Page 3: Table Of Contents

    MN2‑0218 SSD-1000 SERVICE MANUAL ‥‥‥‥ ‥‥‥‥ 4-5 Principle of each PCB’s Operation 4- 20 ‥‥‥‥ ‥‥‥‥ 4-5-1 PROBE SELECTOR 4- 20 ‥‥‥‥ ‥‥‥‥ ‥‥‥‥ 4-5-2 TX / PRE AMP 4- 24 ‥‥‥‥ ‥‥‥‥ ‥‥‥‥ 4-5-3 RX FOCUS 4- 28 ‥‥‥‥...
  • Page 4 MN2‑0218 SSD-1000 SERVICE MANUAL ‥‥‥‥ ‥‥‥‥ 5-21 CABLE752 CABLE750 5- 52 5-22 CBL756, CBL758 & PHYSIO. PANEL 1 ‥‥‥‥ ‥‥‥‥ 5- 54 ‥‥‥‥ ‥‥‥‥ 5-23 CBL753 & PHYSIO. PANEL 2 5- 55 ‥‥‥‥ 5-24 CBL302 CBL312 CBL320 5- 56 ‥‥‥‥...
  • Page 5 ‥‥‥‥ ‥‥‥‥ ‥‥‥‥ 8-4-3 Safety Check 8- 10 Section 9 DISASSEMBLING PROCEDURE page 9-1〜9-42 (42 pages) ‥‥‥‥ ‥‥‥‥ 9-1 SSD-1000 Disassembling Procedures 9- 1 ‥‥‥‥ ‥‥‥‥ 9-2 EU-9075 Installation Procedures 9- 29 ‥‥‥‥ ‥‥‥‥ 9-3 DMS-1000 Installation Procedures 9- 35 Section 10 PARTS LIST page 10-1〜10-46...
  • Page 6 MN2‑0218 SECTION 1 How to use this service manual Service Manual This service manual has been prepared for persons in charge of repair at the field. This service manual is compiled according to the following basic principle. For service, pick out a faulty PCB and replace it with a new PCB .”...
  • Page 7 MN2‑0218 SECTION 1 How to use this service manual Contents of Each Section SECTION 1 How to use this service manual Describes the purpose of the Service Manual. SECTION 2 PRECAUTIONS Describes general precautions and preparations for maintenance service. Be sure to follow working procedures if mentioned.
  • Page 8 MN2‑0218 SECTION 1 How to use this service manual SECTION 7 ADJUSTMENT PROCEDURE Gives guides of adjustments of PCBs and units which some PCBs need when they are replaced . SECTION 8 PERFORMANCE CHECK Describes the procedure of checking for proper operation after repair and provides the forms of check sheet.
  • Page 9 MN2‑0218 SECTION 1 How to use this service manual ( Blank page ) 1 ‑ 4...

  • Page 10: Section 2 Precautions

    MN2‑0218 SECTION 2 PRECAUTIONS Precautions Against Electrical Hazards to Serviceman When disassembling the equipment after checking it for a trouble symptom, give care to the following: Be sure to unplug the equipment before disassembly. Be sure to turn off the main switch on the equipment when removing electrical parts such as PCBs, probe, and cable.
  • Page 11 MN2‑0218 SECTION 2 PRECAUTIONS Precautions for Keeping Electrical Safety Be sure to ground the equipment securely. Perfectness in grounding, screw tightening, and cover installation is essential. Negligence of it could cause a possibility of leakage current from outer fitting which may lead to serious damage to a patient being diagnosed.
  • Page 12 MN2‑0218 SECTION 2 PRECAUTIONS Care to be Taken in the Field Check for trouble symptoms. Check for connection to optional devices and other peripheral devices. Record the contents of the battery backup memory. After working, restore the equipment according to the above mentioned contents of memory if necessary.
  • Page 13 2-10 Handling of S.M.D. PCBs It is an Aloka's policy that neither repair nor upgrade (improvement) of PCBs used for S.M.D. is made in the field as a rule because of the following reasons: [REMARKS] PCB does not need repairing or modifying in the field as a rule.
  • Page 14 MN2‑0218 SECTION 3 BEFORE REPAIRING Repair work on the description of Service Manual The typical processes for the repair work are shown as the Flow Chart on the next page. Do the repair work according to this procedure. In the case of upgrade (improvement) of the Technical Bulletin or Upgrade Kit, see the next item 3-2.
  • Page 15 MN2‑0218 SECTION 3 BEFORE REPAIRING Demand of repair (START) Technical Bulletin Reception and Investigation Section 4〜6, 11 Section 6, 10 Selection and order of required part(s) History Section 3 Preparation at your site at customer side Confirmation Section 2, 6, 9 Repair and adjustment Section 8...
  • Page 16 MN2‑0218 SECTION 3 BEFORE REPAIRING Procedure 1 Reception of repair and investigation Accept the repair request from the customer or distributor. At this time, the following points have to be confirmed and checked, Model name/number, and serial number Name of customer, address, phone number, and name of person in charge Configuration of the connection of peripheral devices Software version or the like shown on the start up display(if possible) Detail of phenomenon appeared on the function of equipment...

  • Page 17: Troubleshooting

    MN2‑0218 SECTION 3 BEFORE REPAIRING Procedure 3 Preparation of visiting the customer Check the required tools, measuring devices and parts to be replaced before the visiting the customer. Then check the special information for the equipment reference with the following section, u Section 3 BEFORE REPAIRING...
  • Page 18 MN2‑0218 SECTION 3 BEFORE REPAIRING Procedure 7 Judgment of the operation quality If the result of “Procedure 6” is passed to the all standards, do the next “Procedure 8”. On the other side, if not, make a judgment of “Procedure 10”. Procedure 8 Confirm by customer, make repair report and approve Reconfirm the solution of trouble phenomenon with the customer.
  • Page 19 MN2‑0218 SECTION 3 BEFORE REPAIRING Upgrade (Improvement) work on the description of Service Manual The typical processes for the upgrade (improvement) work are shown as the Flow Chart on the next page. Do the upgrade (improvement) work according to this procedure. In the case of repair work, see the previous item 3-1.
  • Page 20 MN2‑0218 SECTION 3 BEFORE REPAIRING Demand to upgrade (improvement) (START) Tech.Bulletin Selection and order of Consultation with Instllation requires parts/kits Technical Support Procedure Section 3 Preparation at your site at customer side Section 8 Operation check Work as normal? Do the repair work, according to item 3-1 Upgrade Upgrade (improvement)
  • Page 21 MN2‑0218 SECTION 3 BEFORE REPAIRING Procedure 1 Selection of required parts / kits and order Accept the upgrade ( improvement) request from the customer, distributor or person in charge of sales. At this time, the following points have to be confirmed and checked to decide the parts and kits, Document name that announced the upgrade ( improvement) or kit requested Model name/number, and serial number...

  • Page 22: Installation Procedure

    MN2‑0218 SECTION 3 BEFORE REPAIRING Procedure 3 Operation check before upgrade (improvement) On the basis of work, the upgrade (improvement) to the defective equipment is prohibited. Because, before upgrade (improvement) work, check the behavior of equipment whether normal or not according to following section and document, u Section 8 PERFORMANCE CHECK u Operation Manual...
  • Page 23 MN2‑0218 SECTION 3 BEFORE REPAIRING Procedure 8 Confirmation by customer Reconfirm any functions of equipment with the customer. Then, if need, introduce and explain about the new functions and specification added by this upgrade (improvement). Furthermore, if need, make a report to be approved by the customer. The report shows not only the treatment but also the method of operation check.
  • Page 24 MN2‑0218 SECTION 3 BEFORE REPAIRING Procedure 13 Report to the customer Report to the customer that the upgrade (improvement) has not been completed because of the problem on the upgrade (improvement) work. Then make a schedule to fix and complete it. Procedure 14 Asking to the Technical Support Report to the Technical Support about the happening of problem on the upgrade (improvement) work, make an examination to solve and order the additional parts.
  • Page 25 MN2‑0218 SECTION 3 BEFORE REPAIRING Messages In this equipment, messages are displayed warning that the equipment is malfunctioning or advising the correct operation method. There are two types of message, differing according to their content. WARNING This appears at the center of the screen and an alarm tone is also emitted. (You can switch over the warning display position at the bottom of screen by selecting WARNING DISPLAY in Common Preset of PRESET, then selecting “BOTTOM”.) Assistance Messages...

  • Page 26: Memory Full

    MN2‑0218 SECTION 3 BEFORE REPAIRING 1) WARNING Message Cause Treatment Invalid probe connected. A probe was connected not Connect a suitable probe. intended for use with the equipment. Store memory clear The NEW PATIENT switch If it is permissible to erase image data, press the SET switch.

  • Page 27: Range Limit

    MN2‑0218 SECTION 3 BEFORE REPAIRING Message Cause Treatment RANGE LIMIT When a setting was made Selection is not available. exceeding the change limit in case of changing a setting value with the rotary encoder. USE <TRACKBALL> to move the You attempt to shift a body Shift the body mark with the mark.

  • Page 28: System Specifications

    MN2‑0218 SECTION 4 Principle of System Operation 4-1. System Specifications ： Electronic linear scanning Scanning method Electronic convex scanning Mechanical sector scanning (Requires SCU-1000) Mechanical radial scanning (Requires SCU-1000) Simultaneously connectable probes Electronic scanning probes: 2 Mechanical scanner probes: 2 (Requires SCU-1000) ：...
  • Page 29 MN2‑0218 SECTION 4 Principle of System Operation Ultrasound focusing method Electronic scanning probe：Transmit focusing B mode ..4 steps max. B/M mode..1 of 4 steps M mode ..1 of 4 steps Acoustic lens              ：Receive focusing Max. 16 levels, continuously variable Acoustic lens ：...
  • Page 30 MN2‑0218 SECTION 4 Principle of System Operation ： Basic measurement Measurement functions Obstetric measurement (with OB report function) Cardiac function measurement ： Available Annotation function ： ID ......14 characters x 1 line Characters and automatic display Age ......3 characters x1 line Heart rate..
  • Page 31 MN2‑0218 SECTION 4 Principle of System Operation .......CARDIO .......PV .......SMALL PART .......Four limbs Cine memory (optional) ： Yes (Max. 32 frames in B mode) Search function ： Yes Scroll function ： Yes Store function ： Yes Review function ：...
  • Page 32 MN2‑0218 SECTION 4 Principle of System Operation ： Temperature..10 to 40 ℃ Operating ambient conditions Humidity...30 to 85 % Barometric pressure..700 to 1060 hPa 4 ‑ 5...

  • Page 33: System Configuration

    MN2‑0218 SECTION 4 Principle of System Operation 4-2. System Configuration The SSD-1000 ultrasound diagnostic device comprises the following units: Main unit USI-145   TX/RX part   DIU part Operation panel unit L-KEY-64* Trackball L-TB-8 Observation TV monitor IP-1233*(NTSC) / IP-1233*V(PAL) Power supply unit...
  • Page 34 SSD-1000 PCB LIST (1/2) SSD-1000 Unit PCB model Name Description name Mai unit PSC-129 EP420500 CONNECTOR PANEL Connectors for B/W printer, TV signal for VCR, printer control signals EP-3349-4 Connector for foot switch Operation panel unit L-KEY-64 Operation Panel Image storage unit...
  • Page 35 SSD-1000 PCB LIST (2/2) SSD-1000 Unit PCB model Name Description name Mechanical scanner unit SCU-1000 EP400800 MECH. SERVO Transducer position detection, motor drive signal generation, shaking compensation circuit, transmission timing signal generation, Tx circuit for mechanical sector and annular array probes, transmission power supply voltage monitoring circuit EP400300 MECH.
  • Page 36 OUTLET PSC-129 PHYSIO AMP Power Supply Unit PEU-1000 USI-145 (Option) ECG IN PCG IN HUM Filter T ITLE MODEL (Ver.2.0 onward） SSD-1000 SYSTEM BLOCK DIAGRAM DRAWN DESINED CHECKED APPD 3RD ANGLE PROJECTION DRAWING NO. 第 ３ 角 SCALE MA4-0026 UNITS 4 ‑ 9...
  • Page 37 MN2‑0218 SECTION 4 Principle of System Operation (Blank page) 4 ‑ 10...
  • Page 38 MN2‑0218 SECTION 4 Principle of System Operation 4-4. Principles of System Operation 4-4-1. System Control Unit OPERATION PANEL MAIN PRE AMP FOCUS PANEL CPU PROBE ADRS. DATA I.T.F. SELECTOR BUS WINDOW GEU CPU ADRS. DATA CPU ADRS. DATA MECH. PROBE MECH.
  • Page 39 MN2‑0218 SECTION 4 Principle of System Operation 4-4-2. TX/RX Unit The Tx/Rx unit provides functions to generate transmission pulses, conduct analog processing of received echoes, and transfer ultrasound image data to the DIU. The transmission pulses are converted to high-voltage in the driver circuit that drives the oscillator and are then supplied to the selected probe.

  • Page 40: Tx / Pre Amp

    DELAY& 32ch PROBE ADDER CONNECTOR PRE AMP 128ch Annular GAIN CONT- 128-32ch delay & VBPF RELIEF CONT. RAST adder SELECTOR MECH. F0 CONT PRE AMP GAIN CONT CONTRAST RELIEF DELAY& EXCHANGV 32ch ADDER VBPF F0 CONT Annular Annular delay & DSC VIDEO PRE AMP adder...
  • Page 41 MN2‑0218 SECTION 4 Principle of System Operation 4-4-3. DIU Unit The DIU uses a high-speed X-Y system. The ultrasound image data received from the Tx/Rx unit as a digital signal is sent for pre-processing. Pre-processing involves input selection of the ultrasound image data sent from the Tx/Rx unit, frame correlation, and storing in frame memory.
  • Page 42 V50 BUS CPU BUS DITF BUS CPU BUS CINE CINE TO / FROM DMS MANAGER MEMORY DSC VIDEO From TX/RX part FRAME POST TO TV MONITOR/ VIDEO PROCESS PROCESS MEMORY SELECTOR TO / FROM CONNECTOR M PHYSIO. CPU BUS PANEL PHYSIO.

  • Page 43: Main Amp

    MN2‑0218 SECTION 4 Principle of System Operation 4-4-4. ABC (Auto B-Gain Control) Function This function evaluates the brightness from the B-mode ultrasound image data stored in frame memory and automatically maintains the optimal B-mode gain for MAG etc. , regardless of the probe type, frequency, and individual differences between test subjects. The ABC function can be turned ON or OFF and the ABC level can be set at the operation panel.

  • Page 44: Mecha. Servo

    MN2‑0218 SECTION 4 Principle of System Operation 4-4-6. Mechanical Scanner Unit (Option) The mechanical scanner unit comprises a controller unit (MECH. SERVO) and selector unit (MECH. PROBE SELECTOR). The transmission circuit is mounted on the MAIN AMP board. The transmission pulses generated by MAIN AMP are converted to high-voltage in the driver circuit that drives the oscillator and are then supplied to the selected probe.
  • Page 45 MN2‑0218 SECTION 4 Principle of System Operation 4-4-7. Physiological Signal Unit (option) The physiological signal unit is made up of the physiological amplifier unit (PHYSIO AMP), physio. panel, and physiological signal memory unit (PHI). ECG (electrocardiogram) and PCG (phonocardiogram) are input to PHYSIO AMP, where they are amplified by amplifier circuits with isolated power supplies, and are output by the photo-couplers as the isolated signals B_ECG, M_ECG, and M_PCG.
  • Page 46 MN2‑0218 SECTION 4 Principle of System Operation 4-4-8. Power Supply Unit The power supply unit comprises a series power supply and switching power supply. It supplies the power required by the main unit. It also has an isolated power supply for the optional recording device.
  • Page 47 MN2‑0218 SECTION 4 Principle of System Operation 4-5. Principles of PCB Operation 4-5-1. PROBE SELECTOR This board comprises probe connectors, probe select relays, HVS, and the relevant control circuits. LIN/CONV CONNECTOR 1 260-pin connector for linear/convex probe. LIN/CONV CONNECTOR 2 260-pin connector for linear/convex probe.
  • Page 48 TD1(1-128) LIN/CONV CONNECTOR 1 PROBE CODE1 (0-9) TD1(128-1) RELAY TXRX (1-32) TD1(1-128) LIN/CONV CONNECTOR 2 PROBE CODE2 (0-9) HV DATA GEU ADRS (0-3) READ CONTROL & HVDTCLK PROBEON1 PROBE CODE HVADRS(0-2) PROBEON2 INTERFACE GEU DATA(0-7) M_E_SEL GEU BUS RAMEN PROBE CODE2 (0-9) TITLE 名称...
  • Page 49 MN2‑0218 SECTION 4 Principle of System Operation SIGNAL LIST ( PROBE SELECTOR ) J100-1 J100-2 4 ‑ 22...
  • Page 50 MN2‑0218 SECTION 4 Principle of System Operation (Blank page) 4 ‑ 23...
  • Page 51 MN2‑0218 SECTION 4 Principle of System Operation 4-5-2. TX/PRE AMP This board comprises 32 Tx/Rx circuits and transmission trigger signal generation circuits to carry out ultrasound Tx/Rx. TX POWER SUPPLY VOLTAGE DETECTOR A/D converts the transmission power supply voltage and outputs it to the data bus. Carries out electronic probe transmission.
  • Page 52 From GEU I.T.F. USBLK To GEU I.T.F GEU BUS From MAIN AMP DETECTOR GEUDATA TRIG TXRX TX TRIG To PROBE SELECTOR GENE. PRE OUT ENA1 To RX FOCUS PRE AMP ENA2 From GEU I.T.F. DSCLK TXCLK HVLE TXLD_ TXCLR USADRS HVCLK GEUDATA READ...
  • Page 53 MN2‑0218 SECTION 4 Principle of System Operation SIGNAL LIST ( TX/PRE AMP ) J101-1 J101-2 J101-3 4 ‑ 26...
  • Page 54 MN2‑0218 SECTION 4 Principle of System Operation (Blank page) 4 ‑ 27...

  • Page 55: Analog Switch

    MN2‑0218 SECTION 4 Principle of System Operation 4-5-3. RX FOCUS Two of these boards are used to alternately conduct receive focussing and receive dynamic focussing. V/I CONVERTER Converts the PRE AMP voltage output to a current. CROSS POINT SWITCH The CROSS POINT SWITCH connects the received signals (max. 32 channels) to the optimal delay tap.
  • Page 56 MECH. RX H.P.F. From MECH. PROBE To MAIN AMP. CONNECTOR LOG0* P LOG0*N MECH. RX TP10 TP12/13 ANNULAR DELAY & ANALOG ADDER SWITCH ANALOG V.B.P.F LOG AMP ５ SWITCH From TX/PRE AMP PRE OUT CROSS DELAY & H.P.F. POINT SW ADDER FCSE_0 RESET...
  • Page 57 MN2‑0218 SECTION 4 Principle of System Operation SIGNAL LIST ( RX FOCUS 1 ) J102-1 J102-2 J102-3 4 ‑ 30...
  • Page 58 MN2‑0218 SECTION 4 Principle of System Operation SIGNAL LIST ( RX FOCUS2 ) J103-1 J103-2 J103-3 4 ‑ 31...
  • Page 59 MN2‑0218 SECTION 4 Principle of System Operation 4-5-4. MAIN AMP This board switches the receive focus, conducts ultrasound analog processing, and generates the mechanical scanner transmission pulses. RX EXCHANGE Receives the received signals from the two RX FOCUS boards while switching the depth in approximately 1 cm increments.
  • Page 60 From RX FOCUS 1, 2 TP13 To GEU I.T.F. LOG 01 SELECTOR DETECTOR CONTRAST AAF OUT LOG 02 RELIEF GAIN CONT. 3 AGC 3 CONT 3 RELF 3 AAF GAIN STC SELECTOR DATA To RX GENE. F0 CONT. GAIN CONTROLLER To TX / PRE AMP FO/PRE STC PRE STC CONT.
  • Page 61 MN2‑0218 SECTION 4 Principle of System Operation SIGANAL LIST ( MAIN AMP ) J104-1 J104-3 J411 VIDEO_OUT 4 ‑ 34...
  • Page 62 MN2‑0218 SECTION 4 Principle of System Operation (Blank page) 4 ‑ 35...
  • Page 63 MN2‑0218 SECTION 4 Principle of System Operation 4-5-5. GEU I.T.F. This board generates the control signals for the GEU unit, generates the memory write control signals for the DIU unit, and opens the bus between the CPU BUS and the GEU BUS and PANEL BUS.
  • Page 64 MN2‑0218 SECTION 4 Principle of System Operation BEAM ADDRESS Outputs addresses in the B mode by counting a clock signal synchronized with an ultrasound line using a 9-bit counter in which the CPU start and end values can be set. HV CONTROL Generates the HVS DATA 0 to 7 signals from the high-voltage (transmission) data sent from the CPU.
  • Page 65 GEU BUS CPU BUS WINDOW CPU BUS PNL BUS PROBE CONNECTION MODE PROCOD/ PROBE ON/ DETECTOR CONTROL SCNMOD FRAME RATE BEAM USADRS(0-7) FRMEND/ CALCULATOR ADDRESS DSCADRS(0-7) IRQ/ HVS DATA CONTROL HEART RATE IRQ/ CALCULATOR TX CLK/ US BLK/ TIMING DF AREA GENERATOR 0.5M OFCENT/...
  • Page 66 MN2‑0218 SECTION 4 Principle of System Operation SIGNAL LIST ( GEU ITF ) J207-1 J207-2 J207-3 J314 VIDEO_IN J315 VCR_IN VCR_IN_R J316 VCR_OUT VCR_OUT_R 4 ‑ 39...

  • Page 67: Pre Process

    MN2‑0218 SECTION 4 Principle of System Operation 4-5-6. DIU The B/W DIU (Digital Imaging Unit) fetches ultrasound wave digital data coming from the GEU in synchronized with the DIU clock, writing ultrasound wave data to the display memory in XY writing method, then reading out the ultrasound wave data in synchronized with the TV signal.
  • Page 68 MN2‑0218 SECTION 4 Principle of System Operation Echo Erase In order to make physiological signals easy to see, the bottom portion of ultrasound M image data is erased. The erased portion of ultrasound image data is written to image memory as "0" level. This differs from USERASE and ERASE in the point that it is executed when ultrasound image data are stored in image memory.

  • Page 69: Post Process

    MN2‑0218 SECTION 4 Principle of System Operation Erasing is executed by flash write at 160 nsec/1 Row, but when 4 chips are working simultaneously, erasing can be done at high speed, with one 512 x 512 pixel screen erased in approx. 45 µsec. Furthermore, since it is not dependent on ultrasound image data write operations, it differs from USERASE, ECHO ERASE and Memory Erase.
  • Page 70 MN2‑0218 SECTION 4 Principle of System Operation RAM, so selection is made by rewriting the Enhance RAM. Furthermore, for ultrasound M image data, Standard (Linear) is selected automatically. This function is implemented for black and white images only. Overlay display This is for displaying character and graphic.

  • Page 71: Write Control

    MN2‑0218 SECTION 4 Principle of System Operation This function makes the B image display area narrow and increases the frame rate. This is accomplished by varying BOF/, EOF/ and DSCADRS (8:0) in the GEU. Data from BOF/ to EOF/ are written as DIU. Freeze Function This function stops the writing of an image to display memory.

  • Page 72: Display Control

    MN2‑0218 SECTION 4 Principle of System Operation image can be developed in a 4096 x 4096 area, but in reality, the memory area where ultrasound data can be written is only 512 x 512 in size. Therefore, the virtual write area is regarded as off screen area and the writing operation is not performed.

  • Page 73: Timing Generator

    MN2‑0218 SECTION 4 Principle of System Operation display begins, then in accordance with the display area signal, reading of display data from the SAM block is carried out. In the case of complex display, in order to display Left-Right 2 screen main memory according to the display format, while TV display of screen 1 is being carried out, data for display of screen 2 are being transferred to the SAM block (Real Time Read Transfer) to carry out complex display.

  • Page 74: Clock Generator

    MN2‑0218 SECTION 4 Principle of System Operation CLOCK GENERATOR The reference clock generated by the crystal oscillator is divided and 25 MHz, 12 MHz and 6 MHz synchronization clocks are generated. An A/D conversion clock is also generated as a countermeasure for jitter during A/D conversion. Jitter during A/D conversion occurs because the operating frequencies of the GEU and DIU are not synchronized.
  • Page 75 To/From DMS ITF UDIU_PD (0-7) CINE GEU_USDT MD (0-7) MEMORY POST （OPTION） PROCESS PROCESS FFT SPCID SD (0-7) M PHYSIO MEMORY VIDEO M MARK SEL. 512 x 512 x 8 x 2 HRST. IMGA XINC ERE. VCR IN INCX DATA (0-7) YINC ENHA From GEU I.T.F.
  • Page 76 MN2‑0218 SECTION 4 Principle of System Operation SIGNAL LIST ( DIU ) J205-1 J205-2 J205-3 J312 TV_OUT TV_OUT_R CAMERA_OUT CAMERA_OUT_R VCR_OUT VCR_OUT_R VCR_IN VCR_IN_R 4 ‑ 49...
  • Page 77 MN2‑0218 SECTION 4 Principle of System Operation 4-5-7. CPU This board consists of MPU, which control whole system, and Graphic control section (generates characters and graphics). MPU (Micro Processing Unit) This is 32-bit general processing unit. This micro processor equips high performance data operation and peripheral sub systems.
  • Page 78 RXD232C1,2A RTS232C1,2A CH A TXD232C1,2A DRIVER CTS232C1,2A XTAL RXD232C1,2A CH B RTS232C1,2A TXD232C1,2A 32.768KHz CTS232C1,2A CH A CH B MPSC SIOM ID SW ADRS(15:0) DATA_(7:0) Local CPUDEC LREAD SYSTEM LAS_ I.T.F IRQ7_ IRQ5_ IRQ1_ IRQ1_ to ICU IRQ3_ Frame Buffer FONT / IRQ5_ IRQ7_...
  • Page 79 MN2‑0218 SECTION 4 Principle of System Operation SIGNAL LIST ( CPU ) J201-1 J201-2 J201-3 4 ‑ 52...
  • Page 80 MN2‑0218 SECTION 4 Principle of System Operation (Blank page) 4 ‑ 53...
  • Page 81 MN2‑0218 SECTION 4 Principle of System Operation 4-5-8. CINE MANAGER & CINE MEMORY This CINE memory is a large capacity display memory capable of storing 32 screens (in the case of the 1B mode) of ultrasound display image data before freezing. This CINE memory is the same as the 16 blocks of DIU display memory and the arrangement of the CINE memory is the same as that of main memory, with a 2 x 2 chip configuration.
  • Page 82 20MHz WRITE CIN MXA (0-8) CONTROL REA (0/-7/) CPU ADR (0-15) CONT. REB (0/-7/) DISPLAY CPU DATA (0-7) PROCESSOR CIN M8A (0-7) V50 DATA (0-15) CONTROL CIN SOEEN (0-7) (CINE ADDRESS CONTROLLER) CONT. (CPU) CODE ADDRESS V50 ADRS (0-19) DECODER PROCESSER STATUS REGISTER...
  • Page 83 MN2‑0218 SECTION 4 Principle of System Operation SIGNAL LIST ( CINE MANAGER ) J203-1 J203-2 J203-3 4 ‑ 56...
  • Page 84 MN2‑0218 SECTION 4 Principle of System Operation (Blank page) 4 ‑ 57...
  • Page 85 From DIU DIU MD (0:7) To POST PROCESS From DIU CINE MEMORY B/W DIU MA (0:7) 32 FRAMES B/W CINE SD 0-7 From DIU B/W DIU RAS (0:3) MEMORY CONTROLLER CAS (0:3) (0:3) (0:3) (0:3) From CINE MANAGER CIN PSEL 0-7 CIN SOEEN0-7 CIN M8A0-7 TITLE 名称...
  • Page 86 MN2‑0218 SECTION 4 Principle of System Operation SIGNAL LIST ( CINE MEMORY ) J204-1 J204-2 J204-3 4 ‑ 59...
  • Page 87 MN2‑0218 SECTION 4 Principle of System Operation 4-5-9. MECH. SERVO POSITION COUNTER & CENTER ADJ. This has a counter and a peripheral circuit and detects the position of the transducer by A, B, C and Z signals. It also loads center correction values for every probe to the counter and corrects them.
  • Page 88 MN2‑0218 SECTION 4 Principle of System Operation RTS/ CORRECT SIGNAL GENERATOR This has two ROMs and their peripheral circuit and calculates fluctuation values. RTS/ POSITION CALUCULATOR This is for adding and subtracting transmission position data and fluctuation correction values at integer unit. RTS/ GENERATOR This has analog and digital comparators and outputs data as transmission timing signals.
  • Page 89 M_A, B, C, Z (ASU-35) M_A, B, , Z (ASU-64, 65, 66) POSITION POTENTION SIG. COUNTER & M CENT (0-3) CENTER ADJ. AMP& MOTOR ADDER MECHA DRIVER SELECT DRIVE SIG. DRIVE SIG. SELECTOR. SET UP SIG. DRIVE OVER- SIG. SET UP CURRENT CIRCUIT M NO PROBE/...
  • Page 90 MECHA MTRIG0 TX 1 MECHA M_TXRX SELECT MTRIG1 TX 2 MECHA TRIG GENE. TX Voltage Detector ANNULAR A_TXRX0-4 TX 1 - 5 ATRIG0-4 TITLE 名称 MODEL 形名 MECH. SERVO EP4008**...
  • Page 91 MN2‑0218 SECTION 4 Principle of System Operation SIGNAL LIST ( MECHA SERVO ) J105-1 J105-2 J105-3 J410 +350(HVB) N.C. J414 4 ‑ 64...
  • Page 92 MN2‑0218 SECTION 4 Principle of System Operation (Blank page) 4 ‑ 65...
  • Page 93 MN2‑0218 SECTION 4 Principle of System Operation 4-5-10. MECH. PROBE SELECTOR MECH. CONNECTOR 1 (J503) 60-pin connector for the mechanical scanner. MECH. CONNECTOR 2 (J504) 60-pin connector for the mechanical scanner. RELAY Comprises 17 relays to switch between PROBE 1 and PROBE 2 and switch the control signals.
  • Page 94 A1_TRX1-5 M1_MOTOR, VCC, A, B, C, Z M1_TXRX, M1_TX MECHA PC3 (0-7) CONNECTOR 1 M1_CENT(0-3) M_TXRX M_TXRX1-5 M_A, B, C, Z M_,MOTOR+,- M_5V RELAY M_10V PRE AMP MECHA RX A2TRX1-5 M2MOTOR, VCC, A, B, C, Z PRBSEL3_ STC CNT, GND CNT M2TXRX, M2TX PRBSEL4_ MECHA...
  • Page 95 MN2‑0218 SECTION 4 Principle of System Operation SIGNAL LIST (MECHA PROBE SELECTOR) J404 J600 4-4-11. J601 4 ‑ 68...
  • Page 96 MN2‑0218 SECTION 4 Principle of System Operation SIGNAL LIST ( MECHA PROBE SELECTOR ) J503 J504 4 ‑ 69...

  • Page 97: Physio. Amp

    MN2‑0218 SECTION 4 Principle of System Operation 4-5-11. PHYSIO. AMP. This first-stage amplifier for ECG signals provides 20 dB amplification. This amplifier for ECG signals provides 46 dB amplification. OFFSET COMPENSATION Restricts fluctuations in the ECG signal offset voltage. HUM FILTER This filter eliminates hum noise from the commercial power supply.
  • Page 98 MN2‑0218 SECTION 4 Principle of System Operation COMPARETOR (For PCG) Modulates pulses by comparing the hum filter and triangular waveform. PHOTO COUPLER (For PCG) A photo-coupler is used in the output from the comparator to isolate circuits which contact the patient from the circuits in the unit. L.P.F.
  • Page 99 MN2‑0218 SECTION 4 Principle of System Operation Adjusts the buzzer volume and tone. BUZZER Buzzer for R-wave signal. BUFFER AMP Buffer amplifier for the ECG signal. ECG SENSI. VOL / ECG POSI. VOL Adjusts the ECG sensitivity and position using the trimmers on the physiological signal unit operation panel.
  • Page 100 TP102 TP103 TP104 TP301 TO 1/2 GAIN ADJ COMPA- PHOTO L.P.F. ECG IN ECG SIG OFFSET ADJ FILTER RATOR COUPLER TP202 OFFSET COMPEN -SATION FILTER TP105 TP106 TP302 GAIN ADJ COMPA- PHOTO PCG IN L.P.F. OFFSET ADJ RATOR COUPLER TP204 ISOLATED CURCUIT DC-DC PCG FILTER:L...
  • Page 101 TP602 BEEP TIMER IC BUZZER ON/OFF TP502 TP603 R-WAVE R-WAVE FROM 1/2 TO PHI DETECTOR OUTPUT ECG SIG R-WAVE TP402 TO PHI LIMITER ECG SENSI. VOL. B_ECG TP404 TO PHI LIMITER ECG POSI. VOL. M_ECG FROM 1/2 ECG SIG PCG SENSI. VOL. TP407 TO PHI LIMITER...
  • Page 102 MN2‑0218 SECTION 4 Principle of System Operation SIGNAL LIST ( PHYSIO AMP ) J750 J752 J753 ECG GAIN A PCG GAIN C ECG GAIN B PCG POSI ECG GAIN C ECG POSI PCG FL 0 PCG FL 1 B SOUND ON PCG GAIN A PCG GAIN B J754...

  • Page 103: Phi (Physio Memory)

    MN2‑0218 SECTION 4 Principle of System Operation 4-5-12. PHI (PHYSIO MEMORY) This system receives the analog signals from the amplifier, saves the signals in the memory, and outputs them by synchronizing with the TV signals. The unit consists of the plane mode block and sweep mode block.

  • Page 104: Display Mode

    MN2‑0218 SECTION 4 Principle of System Operation the TV display is blanked. Display mode By setting the reading memory, data can be displayed randomly. The left and right channels can also be displayed. The memory can also handle a 2B display request.

  • Page 105: Ecg Sync. Mark Display

    MN2‑0218 SECTION 4 Principle of System Operation ECG Sync. mark display The board displays a marker that is synchronized with the R / DLY signal sent from the GEU. The vertical direction display width can be adjusted. The same number of pixels are displayed in the upper and lower segments of the ECG waveform height with the R / DLY phase.
  • Page 106 STORE CONTROL ADRS 0-8 A/D TIMING BFRZ R ADRS0-8 B READ & 12MHz B PHYSIO CONTROL CONTROL ADRS RST/ B SAMPL AD CK V ADRS0-7 AD A0 AD A1 VERTICAL PHI B PHYSIO SAMPLE MEMORY INTER- PHA BECG POLATION PHI B MARKER RDLY PHA MECG VERTICAL...
  • Page 107 MN2‑0218 SECTION 4 Principle of System Operation SIGNAL LIST ( PHI ) J202-1 J202-2 J202-3 4 ‑ 80...
  • Page 108 MN2‑0218 SECTION 4 Principle of System Operation (Blank page) 4 ‑ 81...

  • Page 109: Dms Itf / Vol / Servo

    MN2‑0218 SECTION 4 Principle of System Operation 4-5-13. DMS ITF / VOL / SERVO This board has an interface block for connecting the DMS unit, Volume mode calculating block and motor servo block. Digital data which is sent from DIU or DMS unit converts to analog signal at D/A circuit, then outputs the TV display signal after adding the TV synchronized signal.
  • Page 110 MN2‑0218 SECTION 4 Principle of System Operation Converts analog signal to digital signal. VOL Gamma Table to convert the ultrasound data outputted from ADC to transact the noise reduction. This table data is selectable from menu in the ultrasound system. 10) Opacity Table Table to decide the opacity level in volume mode calculation.
  • Page 111 Servo Probe code Limit SW Input Encoder Feedback Pulse Driver 3D Scanner RS-232C Servo Motor RS-232C Serial Driver controller CPU Data CPU Address Register A.A. Opacity Image Brightness Filter Gamma Table Calc. Cont. Table Image Video Buffer Memory Cont. DMS ITF Monitor Remarks: The circuit in an alternate long and short dash line is not mounted on EP429301.
  • Page 112 MN2‑0218 SECTION 4 Principle of System Operation SIGNAL LIST ( DMS I.T.F. /VOL/SERVO) J206-1 J206-2 J206-3 4 ‑ 85...
  • Page 113 MN2‑0218 SECTION 4 Principle of System Operation (Blank page) 4 ‑ 86...

  • Page 114: Section 5 Schematics Page 5-1〜5-60 (60

    MN2‑0218 SECTION 5 SCHEMATICS USM-23 12inch CBL 804 CBL 318 Monitor note note CBL 21 CBL 20 CBL 314 *3:EU-9075 *1:No option P411 P410 P414 P314 P312 connected *2:DMS-1000 connected CBL 320 CBL 312 J411 J410 J414 P315 P316 P314 93P6 93P5 93P4...
  • Page 115 MN2‑0218 SECTION 5 SCHEMATICS （空白ページ） 5  ‑  2...
  • Page 116 UL1007TR64 AWG22 BLK UL1007TR64 AWG22 BLK UL VINYL TUBE AH-6 AWG3 UL1631 AWG25 ORN FOOTL_ FOOTL_ UL1631 AWG25 YEL FOOTC_ FOOTC_ EP-3349B-4 UL1631 AWG25 BLU FOOTR_ FOOTR_ 10mm 10mm 350mm-0mm +20mm LABEL P311 TIE WRAP T18R TIE WRAP T18R FOOTL_ P311 Housing:5102-06(molex) Terminal:5103PBTL(molex)
  • Page 117 UL1430 REW AWG22 RED +24V UL1430 REW AWG22 BLU LABEL P16 109P0924L402 (山 洋 Housing:1625-02P(molex) Terminal:1560TL(molex) MODEL TITLE CBL16 CO-PSC-129-K 3RD ANGLE PROJECTION DRAWN DESINED CHECKED APPD DRAWING NO. 第 ３ 角 SCALE MC335477 UNITS...
  • Page 118 P411 P314 HC-CECX-75ohm VIDEO_OUT VIDEO_OUT UL1007 TR64 AWG22 UL1007 TR64 AWG22 700mm-0mm +20mm LABEL P314 P411 P314 Housing:5102-02(molex) Housing:5102-02(molex) Terminal:5103PBTL(molex) Terminal:5103PBTL(molex) LABEL P411 TITLE MODEL CBL314 CO-PSC-129-J DRAWN DESINED CHECKED APPD 3RD ANGLE PROJECTION DRAWING NO. SCALE MC335476 UNITS...
  • Page 119 UL VINYL TUBE AH-6 AWG4 P310 P317 UL1430 REW AWG22 BLK DGND SHUTTER UL1430 REW AWG22 RED BUSY BUSY UL1430 REW AWG22 BRN SHUTTER_ DGND 100mm-0mm +20mm TIE WRAP T18R TIE WRAP T18R LABEL P310 P317 P310 Housing:5102-03(molex) Housing:5102-03(molex) Terminal:5103PBTL(molex) Terminal:5103PBTL(molex) LABEL P310 TITLE MODEL CBL317 CO-PSC-129-H...
  • Page 120 P312 HC-CECX-75ohm TV_OUT TV_OUT TV_OUT_R UL1007 TR64 AWG22 BLK P318 HC-CECX-75ohm CAMERA_OUT CAMERA_OUT CAMERA_OUT_R UL1007 TR64 AWG22 BLK UL1007 TR64 AWG22 BLK CAMERA_OUT_R HC-CECX-75ohm VCR_OUT VCR_OUT VCR_OUT_R UL1007 TR64 AWG22 BLK P316 UL1007 TR64 AWG22 BLK VCR_OUT_R HC-CECX-75ohm VCR_IN VCR_IN VCR_IN VCR_IN_R VCR_IN_R...
  • Page 121 P600 P412 GND_MP GND_MP UL1007 TR64 AWG22 BLK UL1007 TR64 AWG22 BLK UL1631 AWG25 GRN M_TXRX1 M_TXRX1 GND_MP GND_MP UL1007 TR64 AWG22 BLK UL1007 TR64 AWG22 BLK UL1631 AWG25 GRN M_TXRX2 M_TXRX2 GND_MP GND_MP UL1007 TR64 AWG22 BLK UL1007 TR64 AWG22 BLK UL1631 AWG25 GRN M_TXRX3 M_TXRX3...
  • Page 122 P601 P413 UL1631 AWG25 YEL M ECHA_RX M ECHA_RX GND_S5 GND_S5 UL1007 TR64 AWG22 BLK UL1007 TR64 AWG22 BLK UL1631 AWG25 YEL M ECHA_RX1 M ECHA_RX1 GND_S5 GND_S5 UL1007 TR64 AWG22 BLK UL1007 TR64 AWG22 BLK UL1631 AWG25 YEL M ECHA_RX2 M ECHA_RX2 GND_S5 GND_S5...
  • Page 123 UL VINYL TUBE AH-6 AWG8/16 UL1015 TEW AWG16 BRN AC_OUT_L UL1015 TEW AWG16 BLU AC_OUT_R UL1015 TEW AWG16 BRN AC_IN_L UL1015 TEW AWG16 BLU AC_IN_R 820mm-0mm +20mm TIE WRAP T18R TIE WRAP T18R LABEL P800 20mm △ 650 Terminal:FVDHDF1.25-250B(JST) P800 Housing:3191-04R1(molex) Terminal:1189ATL(molex) UL VINYL TUBE △...
  • Page 124 UL VINYL TUBE AH-6 AWG3 P801 P306 UL1430 REW AWG18 YEL +5VD +5VD UL1430 REW AWG18 BLK DGND DGND 100mm-0mm +20mm △ TIE WRAP T18R LABEL P306 P801 P306 Housing:3191-02R1(molex) Housing:3191-02R1(molex) Terminal:1189ATL(molex) Terminal:1189ATL(molex) △ TIE WRAP T18R Side View LABEL P801 MODEL TITLE CBL801...
  • Page 125 UL VINYL TUBE AH-6 AWG14/16 P803 P406 UL1015 TEW AWG20 WHT/BRN -150V -150V UL1015 TEW AWG20 BLK UL1015 TEW AWG20 WHT △ △ +40V +40V UL1015 TEW AWG20 BLK UL1015 TEW AWG20 WHT/YEL △ △ +90V +90V P405 UL1015 TEW AWG20 BLK UL1015 TEW AWG20 BLU -15V -15V...
  • Page 126 △ P410 UL VINYL TUBE AH-6 AWG2 P804 UL1015 TEW AWG20 WHT/BLK UL1015 TEW AWG20 BLK GND_MP GND_MP P414 UL1430 REW AWG22 YEL +5VD +5VD UL1430 REW AWG22 BLK △ 900mm -0mm +20mm LABEL TIE WRAP T18R TIE WRAP T18R P410 P804 P410 Housing:5557-04R(molex) Housing:1-178128-3(AMP) Terminal:5556PBTL(molex) Terminal:175196-2(AMP)
  • Page 127 UL VINYL TUBE AH-6 AWG3 P806 UL1430 REW AWG22 RED +24V +24V UL1430 REW AWG22 RED 900mm-0mm +20mm TIE WRAP T18R TIE WRAP T18R LABEL P806 LABEL P16 P806 Housing:1625-02R1(molex) Housing:5025-02R1(molex) Terminal:1560TL(molex) Terminal:5005TL(molex) △ △ △ MODEL TITLE CBL806 CO-PSC-129-E 3RD ANGLE PROJECTION DRAWN DESINED CHECKED APPD...
  • Page 128 UL VINYL TUBE AH-6 AWG2 P807 UL1430 REW AWG18 BLK UL1430 REW AWG18 RED +15V +15V UL1430 REW AWG18 BLK GND_F GND_F HC-CECX-75ohm TV_OUT TV_OUT UL1007 TR64 AWG22 BLK 10mm 1350mm-0mm +40mm 1450mm-0mm +40mm Side View △ LABEL P807 △ △...
  • Page 129 P401 A1,B1,C1,D1 A1,B1,C1,D1 A25,B25,C25,D25 A25,B25,C25, Title Model CBL 301 L-CABLE-592...
  • Page 130 P304 15 16 16 15 P304 P550 SWD 5/ SWD 5/ SWD 4/ SWD 4/ SWD 3/ SWD 3/ SWD 2/ SWD 2/ SWD 1/ SWD 1/ SWD 0/ SWD 0/ REN 0F/ REN 0F/ R SOUND R SOUND ECG ON ECG ON PCG ON PCG ON...
  • Page 131 P307 P754 16 15 15 16 P754 P307 B/ECG PHA_BECG PHA_BECG_R M/ECG PHA_MECG PHA_MECG_R M/PCG PHA_MPCG PHA_MPCG_R R_TRIG R-GATE DGND +5VD DGND +15V +15V DGND -15V -15V DGND N.C. N.C. N.C. N.C. Title Model CBL754 L-CABLE-590...
  • Page 132 P305 P802 10 9 9 10 P802 P305 HVS_DATA0 HVS_DATA0 HVS_DATA1 HVS_DATA1 HVS_DATA2 HVS_DATA2 HVS_DATA3 HVS_DATA3 HVS_DATA4 HVS_DATA4 HVS_DATA5 HVS_DATA5 HVS_A/B HVS_A/B DGND DGND DGND DGND Title Model CBL 802 L-CABLE-545...
  • Page 133 MN2‑0218 SECTION 5 SCHEMATICS 5  ‑  20...
  • Page 134 L-KEY-64...
  • Page 135 L-KEY-64 (2/12)
  • Page 136 L-KEY-64 (3/12)
  • Page 137 L-KEY-64 (4/12)
  • Page 138 L-KEY-64 (5/12)
  • Page 139 L-KEY-64...
  • Page 140 L-KEY-64...
  • Page 141 L-KEY-64 (8/12)
  • Page 142 L-KEY-64 (9/12)
  • Page 143 L-KEY-64 (10/12)
  • Page 144 L-KEY-64 (11/12)
  • Page 145 L-KEY-64 (12/12)
  • Page 146 MN2‑0218 SECTION 5 SCHEMATICS 5  ‑  33...
  • Page 147 MN2‑0218 SECTION 5 SCHEMATICS 5  ‑  34...
  • Page 148 MN2‑0218 SECTION 5 SCHEMATICS 5  ‑  35...
  • Page 149 MN2‑0218 SECTION 5 SCHEMATICS （ B l a nk page ） 5  ‑  36...
  • Page 150 MN2‑0218 SECTION 5 SCHEMATICS 5  ‑  37...
  • Page 151 MN2‑0218 SECTION 5 SCHEMATICS 5  ‑  38...
  • Page 152 MN2‑0218 SECTION 5 SCHEMATICS 5  ‑  39...
  • Page 153 MN2‑0218 SECTION 5 SCHEMATICS 5  ‑  40...
  • Page 158 MN2‑0218 SECTION 5 SCHEMATICS 5  ‑  45...
  • Page 159 MN2‑0218 SECTION 5 SCHEMATICS 5  ‑  46...
  • Page 160 MN2‑0218 SECTION 5 SCHEMATICS 5  ‑  47...
  • Page 161 MN2‑0218 SECTION 5 SCHEMATICS （Blank page） 5  ‑  48...
  • Page 162 MN2‑0218 SECTION 5 SCHEMATICS 5  ‑  49...
  • Page 163 MN2‑0218 SECTION 5 SCHEMATICS （Blank page） 5  ‑  50...
  • Page 173 MN2‑0218 SECTION 5 SCHEMATICS 5  ‑  60...

  • Page 174: Section 6 Troubleshooting

    MN2‑0218 SECTION 6 TROUBLESHOOTING  Introduction This trouble shooting makes integral part of the Service Manual. And it has been prepared for the persistent purpose of providing for repairing guidelines. What has been described herein, moreover, is subject to the prerequisite for a repair to be made by replacing a PCB.
  • Page 175 SECTION 6 TROUBLESHOOTING To replace or repair a PCB, make certain of its compatibility, etc, in accordance with the "History of SSD-1000". If a wrong ROM should be mounted on a PCB, employ the ROM originally employed in the user's equipment or select an appropriate one in accordance with the History.

  • Page 176: Gray Scale

    MN2‑0218 SECTION 6 TROUBLESHOOTING HOSPITAL : Y] 9 8 / 0 1 / 3 0 NAME 1 2 : 3 0 : 3 2 MEMORY AREA 10Hz 3 . 5 M S - H D V A : 1 0 0 % Gray Scale Ultrasound Image...
  • Page 177 MN2‑0218 SECTION 6 TROUBLESHOOTING Tools and Measuring Instruments Required The tools and measuring instruments which are required for a repair on a standard basis are as follows: 1. Oscilloscope Sensitivity 5mV/div. Frequency band DC〜50MHz Maximum input voltage : 400V or more 2.
  • Page 178 Blowing fan starts running. ↓ LEDs (for Power lamp and Fullkeyboard) on the operation panel come on. ↓ 『 ALOKA SSD-1000 System set-up in progress』 『 SYSTEM:＊ .＊ 』 『 DATABASE: ＊ ＊ ＊ ＊ ＊ 』 appears on the screen. ↓...
  • Page 179 MN2‑0218 SECTION 6 TROUBLESHOOTING Fig.6-2 DIP SWITCHES SETTING EP39660* DIU EP39660* DIU SW1 : Setting is common to all specifications. SW2 : Setting is common to all specifications.  EP399000/EP4305** CPU EP399000/EP4305** CPU SW1 : Setting is common to all specifications. SW2 :Export（NTSC） SW2 :Export (NTSC) Applied for EP4007**KK and after Applied for EP4007**EF, EG and EH SW2 :Export（PAL）...
  • Page 180 MN2‑0218 SECTION 6 TROUBLESHOOTING 6-4-3 Usage of the Functions to be Set by the User Those functions which the user may set as enumerated below are stored in internal memory (random access memory : RAM) as backed up with a battery. In normal use, the memory data so backed up will never disappear.

  • Page 181: Optional Units

    MN2‑0218 SECTION 6 TROUBLESHOOTING 6-4-4 Attention of connecting optional units In the case of connecting the optional units, some optional units require other PCB something like an interface between the main body and optional unit, therefore, refer to the following table about the construction of optional units in advance.
  • Page 182 MN2‑0218 SECTION 6 TROUBLESHOOTING 6-4-5 Resetting the Backup Memory (RAM) A backup feature is available to normally store the user's settings. In normal use, it will not be necessary to erase all the information so stored. It is necessary, however, to reset the backup memory with reference to the item 6-4-6 given below in any of the following events: ●CAUTION●...
  • Page 183 MN2‑0218 SECTION 6 TROUBLESHOOTING 6-4-6 How to reset Backup RAM (1)Method of reset with panel operation Turn PRESET switch ON, then press CTRL(Full Keyboard) and (Full Keyboard) at the same time. Fig.6-3 Method of reset with panel operation Turn PRESET switch ON, then press CTRL and R at the same time.
  • Page 184 MN2‑0218 SECTION 6 TROUBLESHOOTING 6-4-7 Location of unit and PCBs The location of PCBs is shown in Fig.6-4. Please refer for repair or modification. Fig.6-4 Location of PCB Physiological signal display unit Mechanical sector scanner unit Connector board AC outlet Power supply unit 6 ‑ 11...
  • Page 185 MN2‑0218 SECTION 6 TROUBLESHOOTING 6‑4‑8 Location of ROMs  The location of ROMs is shown following figures. Please refer for replacing the ROMs on modification and troubleshooting (refer to Fig. 6-5〜6-7) Fig. 6-5 Location of ROMs EP404400 TX/PRE AMP ROM No. 862* 895* 874* EP400600 RX FOCUS(×2)
  • Page 186 MN2‑0218 SECTION 6 TROUBLESHOOTING Fig. 6-6 Location of ROMs EP39560* GEU ITF ROM No. 56040* 56037* 846* 847* 848* 849* 850* 851* 852* 853* EP39660* DIU ROM No. 710* 880* 881* 889* 66136* PM1000-STD1 *.*-1 PM1000-STD1 *.*-2 PM1000-STD1 *.*-3 66161* EP399000/EP43050* CPU ROM No.
  • Page 187 MN2‑0218 SECTION 6 TROUBLESHOOTING Fig. 6-7 Location of ROMs EP399600 CINE MANAGER ROM No. 96146＊ 712* 713* 750* 751* 752* 753* EP400800 MECHA SERVO ROM No. 864* 865* 866* 867* 868* 869* 882* 883* EP399500 PHYSIO MEMORY ROM No. 9513M* 95239* 777* 778* 779*...
  • Page 188 MN2‑0218 SECTION 6 TROUBLESHOOTING 6-4-9 Correction for fail to start or locking up If the system does not stand to operate or locks up suddenly, following procedures to repair are specially adopted. (1) First, check the output voltage from the power supply unit. Whole of system is controlled by MPUs (Micro Processing Unit), If these MPUs should not be supplied with +5V power from the power supply unit or should have an abnormal voltage, it will bring about a problem affecting the entirety of the...
  • Page 189 MN2‑0218 SECTION 6 TROUBLESHOOTING Tbl.6-2 Input and output of every Bus line MODEL NAME ADRS DATA ADRS DATA ADRS DATA L‑KEY‑64* OPERATION ← ⇔ PANEL EP400400 PROBE ← ⇔ SELECTOR EP404400 TX/PRE AMP ← ⇔ EP400600 RX FOCUS ← ← EP400700 MAIN AMP ←...
  • Page 190 MN2‑0218 SECTION 6 TROUBLESHOOTING 6-4-10 Minimum Start-up In this section, we will explain concerning the minimum start-up as information necessary for repairs (starting up the system with the minimum PCB configuration). Definition of Minimum Start-up The minimum start-up is defined to be the system’s start-up state when the equipment’s power is switched on and the system started, then stabilizing in that state (with nothing displayed in the US image area at that time).
  • Page 191 MN2‑0218 SECTION 6 TROUBLESHOOTING Combination that Enables Minimum Start-up The PCBs necessary for starting the equipment in this system are shown in the minimum units below. ●CAUTION● The power supply unit, Motherboard, Operation Panel and observation monitor are all correctly connected and operating. ●CAUTION●...
  • Page 192 MN2‑0218 SECTION 6 TROUBLESHOOTING TX /PRE AMP US image shows noise only. Other functions are normal. RX FOCUS Two RX FOCUS boards exist. If one of two board is removed, US image is displayed and not displayed every 1cm in axial direction. Other functions are normal. MAIN AMP The equipment does not display US image and noise at all.
  • Page 193 MN2‑0218 SECTION 6 TROUBLESHOOTING 6-4-11 PRESET DATA SHEET Exchanging CPU PCB or resetting the backed-up RAM data to solve software locking up problem will erase presettings, hospital name and so on. To set them all over again after replacing PCB or after resetting the memory, it is necessary to record the set information by the use of a printer, such as “Echo Copier”...
  • Page 194 MN2‑0218 SECTION 6 TROUBLESHOOTING Preset Preset Name Number （Common Preset） C o m m o n P r e s e t C o n t r o l [ I n i t i a l i z e ] [ P r o g r a m ] R e s u m e T i m e r...
  • Page 195 MN2‑0218 SECTION 6 TROUBLESHOOTING A n n o t a t i o n L i b r a r y C o n t r o l [ I n i t i a l i z e ] [ P r o g r a m ] S e l e c t t h e m e n u C o p y w o r d...
  • Page 196 MN2‑0218 SECTION 6 TROUBLESHOOTING （Setup Menu） u Setup P R E S E T S e t - u p M e n u P r e s e t N u m b e r ： P r e s e t N a m e ： A p p l i c a t i o n ：...
  • Page 197 MN2‑0218 SECTION 6 TROUBLESHOOTING u Disp-2 D i s p l a y - 2 C o n t r o l P r e s e t N a m e [ A p p l i c a t i o n [ [ I n i t i a l i z e ] [ P r o g r a m ] Large...
  • Page 198 MN2‑0218 SECTION 6 TROUBLESHOOTING u Measurement (Menu 「B mode」) M e n u C o n t r o l P r e s e t N a m e [ A p p l i c a t i o n [ [ I n i t i a l i z e ] [ P r o g r a m ] M o d e [ B ]...
  • Page 199 MN2‑0218 SECTION 6 TROUBLESHOOTING Measurement （OB→Contents of OB Measurement Program） [Contents of OB Measurement Program page P r e s e t N a m e [ A p p l i c a t i o n [ [ I n i t i a l i z e ] [ P r o g r a m ] G A T a b l e R a t i o...
  • Page 200 MN2‑0218 SECTION 6 TROUBLESHOOTING u Measurement （OB→Anatomy Check List） A n a t o m y C h e c k L i s t P a g e [ I n i t i a l i z e ] [ P r o g r a m ] [ C a n c e l ] [ C o n f i r m ] H e a d i n g : S e l e c t i o n : C o m m e n t s...
  • Page 201 MN2‑0218 SECTION 6 TROUBLESHOOTING u Measurement （OB→Formed Comment） [ I n i t i a l i z e ] [ P r o g r a m ] [ C a n c e l ] [ C o n f i r m ] - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - F o r m a t L e f t...
  • Page 202 MN2‑0218 SECTION 6 TROUBLESHOOTING u Measurement (Cardio→Select Formula of MEASUREMENT PACKAGE) L V F u n c t i o n P a c k a g e [ I n i t i a l i z e ] [ P r o g r a m ] B - M o d e M - M o d e...
  • Page 203 MN2‑0218 SECTION 6 TROUBLESHOOTING M - V a l v e P a c k a g e ( 2 / 2 ) [ I n i t i a l i z e ] [ P r o g r a m ] T r i c u s p i d V a l v e P u l m o n i c V a l v e A W A V E...
  • Page 204 MN2‑0218 SECTION 6 TROUBLESHOOTING M - M o d e V a l v e P a r a m e t e r s ( 1 / 2 ) [ I n i t i a l i z e ] [ P r o g r a m ] M i t r a l V a l v e A o r t i c V a l v e...
  • Page 205 MN2‑0218 SECTION 6 TROUBLESHOOTING u Measurement （Cardio→Formed Comment） [ F o r m e d C o m m e n t ] [ I n i t i a l i z e ] [ P r o g r a m ] [ C a n c e l ] [ C o n f i r m ] - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - F o r m a t L e f t...
  • Page 206 MN2‑0218 SECTION 6 TROUBLESHOOTING u Body MK B o d y M a r k C o n t r o l A p p l i c a t i o n [ P r e s e t N a m e [ [ I n i t i a l i z e ] [ P r o g r a m ] Menu...
  • Page 207 MN2‑0218 SECTION 6 TROUBLESHOOTING u Option O p t i o n C o n t r o l P r e s e t N a m e [ A p p l i c a t i o n [ [ I n i t i a l i z e ] [ P r o g r a m ] E C G...
  • Page 208 MN2‑0218 SECTION 6 TROUBLESHOOTING Check List Map   This Check List Map provides you with the data, based on which you may assume a PCB or unit considered to have caused the equipment failure. It comprises the following information: Phenomenon Code Table General failure phenomena have been classified into codes.
  • Page 209 MN2‑0218 SECTION 6 TROUBLESHOOTING Flow chart for the usage of Check List MAP START Confirm phenomenon Choose Code from Phenomenon Code Table Phenomenon Code is found from table? Choose corresponded Check Code from Apply to Technical Support Check according to Check Procedure assigned with Code Reason of...
  • Page 210 MN2‑0218 SECTION 6 TROUBLESHOOTING 6-5-2 Phenomenon Code Table The general failure phenomena envisaged herein are roughly classified as described below while being code with two alphabetical characters and gives the “Phenomenon Code to refer the MAP : Phenomenon Code Failure on the ultrasound image with any display mode Failure on the display of characters or graphics Failure about the timing synchronization or observational monitor Failure on the general operation or function...
  • Page 211 MN2‑0218 SECTION 6 TROUBLESHOOTING Failure of the ultrasound image UltraSound) Code Problems item Ultrasound image is not all displayed. ○ US-1 Ultrasound image is not all displayed in a particular MODE. ○ Ultrasound image is not all displayed only for LINEAR (or CONVEX ). ○...
  • Page 212 MN2‑0218 SECTION 6 TROUBLESHOOTING Failure on the characters or graphics Character & Graphic) Code Problems item div. ○ Characters are displayed in the entire screen. ○ Only Caliper, Graphic are not displayed. CG-2 ○ Only Caliper, Graphic are abnormally displayed. ○...
  • Page 213 MN2‑0218 SECTION 6 TROUBLESHOOTING Failure about the timing or monitor Timing & Monitor) Code Problems item div. ○ All images are not displayed in any Monitor. TM-1 ○ Image is not displayed in a particular Monitor. ○ All Images are not synchronized in any Monitor. TM-2 ○...
  • Page 214 MN2‑0218 SECTION 6 TROUBLESHOOTING Failure on the general operation or function FUnction) Code Problems item div. ○ System locks up, or panel information is not accepted. FU-1 The ERROR messages are shown on the monit or. ○ ○:Marked items are effective on this system. 6 ‑ 41...
  • Page 215 MN2‑0218 SECTION 6 TROUBLESHOOTING Failure on power supply, recording, switch & controls Power & Memory) Code Problems item ○ Power output is not present, or abnormally outputted. PM-1 ○ Switches and/or Controls are inoperative. PM-2 ○ Switches and/or Controls are abnormally operated. ○...
  • Page 216 MN2‑0218 SECTION 6 TROUBLESHOOTING Failure on the physiological signal display PHysiological Signal) Code Problems item div. ○ ECG (EKG) waveform is not displayed. PH-1 ○ ECG (EKG) waveform is abnormally displayed or sensitivity is low. ○ ECG (EKG) waveform is abnormally displayed in a particular Mode, or not displayed.
  • Page 217 MN2‑0218 SECTION 6 TROUBLESHOOTING 6-5-3   Concerning the typical failure phenomena identified by “Phenomenon Codes”, those PCBs or units which may be deemed to have caused such phenomena are shown below. This MAP has phenomena classified by “Problem Code”. A PCB or unit assumed to be causative of the related phenomenon is marked with a “Check List Code”...
  • Page 218 MN2‑0218 SECTION 6 TROUBLESHOOTING Check List Problem Code US-1 US-2 US-3 US-4 US-5 Item Code 1 2 3 4 1 2 1 ○ ○ ○ Operation External Noise Power Supply ○ ○ ○ ○ ○ ○ (PSU-S1000) ○ ○ ○ ○...

  • Page 219: Check List

    MN2‑0218 SECTION 6 TROUBLESHOOTING Check List Problem Code US-6 US-7 US-8 US-9 US-10 Item Code 1 2 ○ ○ ○ Operation External Noise Power Supply ○ ○ ○ (PSU-S1000) ○ ○ Probe/Scanner Monitor (IP-1233*/IP-1233*V) L-KEY-64* OPERATION PANEL EP401500 PROBE SELECTOR EP404400 TX/PRE AMP ○...
  • Page 220 MN2‑0218 SECTION 6 TROUBLESHOOTING Check List Problem Code CG-1 CG-2 CG-3 CG-4 CG-5 CG-6 Item Code 1 2 1 2 Operation External Noise Power Supply ○ (PSU-S1000) Probe/Scanner ○ ○ Monitor(IP-1233*/IP-1233*V) ○ ○ L-KEY-64* OPERATION PANEL EP401500 PROBE SELECTOR EP404400 TX/PRE AMP EP400600 RX FOCUS EP400700 MAIN AMP ○...
  • Page 221 MN2‑0218 SECTION 6 TROUBLESHOOTING Check List Problem Code TM-1 TM-2 TM-3 FU-1 PM-1 PM-2 Item Code 1 2 1 2 1 2 1 2 1 2 3 Operation External Noise Power Supply ○ ○ ○ ○ (PSU-S1000) Probe/Scanner ○ ○ ○...
  • Page 222 MN2‑0218 SECTION 6 TROUBLESHOOTING Check List Problem Code PM-3 PH-1 PH-3 Item Code 1 2 1 2 3 4 1 2 ○ ○ Operation External Noise Power Supply (PSU-S1000) Probe/Scanner Monitor (IP-1233*/IP-1233*V) L-KEY-64* OPERATION PANEL EP401500 PROBE SELECTOR EP404400 TX/PRE AMP EP400600 RX FOCUS EP400700 MAIN AMP ○...
  • Page 223 MN2‑0218 SECTION 6 TROUBLESHOOTING 6-5-4 PCB Check Procedure This “PCB check Procedure” is divided by CHECK CODE". Before use this procedure, find CHECK CODE" corresponding to the symptom using “Problem Code Table” and “MAP”. This procedure shows description to confirm for each “CHECK CODE” listed in “MAP” And this procedure estimates one trouble exits in Ultrasound diagnostic equipment.

  • Page 224: Operation

    MN2‑0218 SECTION 6 TROUBLESHOOTING Operation It is important that you understand the operation and specification. At first, you should be check that the symptom is caused by the operation or its specification, according to SECTION 8 PERFORMANCE CHECK". However, if you cannot judge, you should inquire of Technical Support. ●CAUTION●...
  • Page 225 MN2‑0218 SECTION 6 TROUBLESHOOTING External Noise Factor When the external noise factor may be thought, you should try to change the location of diagnostic equipment. When you check the environment, refer the followings. Is there X-ray unit or some noise maker in the near room? Is there a computer or some noise maker near by? Is there a radio station or something like this near there? Is there a high voltage overhead wires near there?

  • Page 226: Power Supply

    MN2‑0218 SECTION 6 TROUBLESHOOTING Power Supply (PSU-S1000) Check each output voltage according to following table and figures. The checking must be done in following condition. (1) Wait for 30 minutes after turning the power switch on. (2) AC input voltage to the power supply unit must be set within ±10% of standard at worst. Tbl.
  • Page 227 MN2‑0218 SECTION 6 TROUBLESHOOTING Fig 6-9 Location of connector P802(HV CONTROL) P807  (MON.) 2 ３ 4 b0 b1 b2 b3 b4 b5 HVA/HVB GND GND +15(b) F.GND ＲＥＡＲ P805 (DMS) AC(L) AC(L)  A AC(N) AC(N) +15(b)  B P801(DIU) +5.1 P806 P808 AC(H) AC(N) P803(HV OUT) P804(MECH HV)
  • Page 228 MN2‑0218 SECTION 6 TROUBLESHOOTING Probe Confirmation by Use of Another Probe or Unit. Make a checkout of performance, using a probe of the same model number as that in which the failure has taken place, if possible. To check from performance, moreover, connect the apparently failed probe with a system of identical type available as a substitute, if any.
  • Page 229 MN2‑0218 SECTION 6 TROUBLESHOOTING Fig. 6-10 Location of probe code OPEN : 1 GROUND : 0 Reference Pin No.  c1 c2 UST‑979‑3.5 UST‑990‑5 UST‑5524‑7.5 PROBE CODE ( ● : GROUND ) 6 ‑ 56...
  • Page 230 MN2‑0218 SECTION 6 TROUBLESHOOTING IP-1233*/1233*V Monitor If the faulty symptom is peculiar to that monitor and if it is impossible to replace the monitor, “SECTION 5 repair it according to SCHEMATICS”. Check the following items (1) Check the contrast and brightness potentiometers for proper setting. (2) Check whether normally images are printed out by video printer or not.

  • Page 231: Operation Panel

    MN2‑0218 SECTION 6 TROUBLESHOOTING L-KEY-64* OPERATION PANEL See the Section 5 schematics. Phenomenon which may occur by a failure of this unit. (1) Only one switch or Trackball does not act normally. Check the switch itself for normal function. Normal→Proceed to (3). Abnormal→Replace the switch.
  • Page 232 MN2‑0218 SECTION 6 TROUBLESHOOTING EP4015 PROBE SELECTOR “PCB Block The following checking performance should be done by referring to the both Diagram” and “INPUT / OUTPUT SIGNAL LIST” in SECTION 4. Phenomenon which may occur by a failure of this PCB. 1.
  • Page 233 MN2‑0218 SECTION 6 TROUBLESHOOTING EP4006 RX FOCUS The following checking performance should be done by referring to the both "PCB Block Diagram" and "INPUT/OUTPUT SIGNAL LIST" in SECTION 4. Phenomenon which may occur by a failure of this PCB. 1. Existing equal interval display of depth direction on the ultrasound image or a failure of sensitivity.
  • Page 234 MN2‑0218 SECTION 6 TROUBLESHOOTING (2)Check the AAF_OUT signal at TP13. Normal→Refer to “C5” and “C6”. Abnormal→Replace this PCB. (3)Check the F0CONT signal at TP8, and PRESTC_CONT signal at TP9. Normal→Refer to “A3” and “C2”. Abnormal→Replace this PCB. 3. GAIN, STC, AGC, or CONTRAST does not function or abnormally function. (1)Trouble of GAIN.
  • Page 235 MN2‑0218 SECTION 6 TROUBLESHOOTING 3. Existing equal interval display of depth direction on the ultrasound image. (1)Check the EXCHNGEV signal at the connector J107-2. Normal→Refer to “C3” and “C4”. Abnormal→Replace this PCB. 4. The panel switches do not response at all. (1)Check the PNL_DATA0-7, PNL_ADRS0-6,PNL_READ and PNL_EN_ signals at J107-3.
  • Page 236 MN2‑0218 SECTION 6 TROUBLESHOOTING EP3966 The following checking performance should be done by referring to the both "PCB Block Diagram" and "INPUT/OUTPUT SIGNAL LIST" in SECTION 4. Phenomenon which may occur by a failure of this PCB. 1. The ultrasound image is not displayed at all, or the image without gradation is displayed. (1)Check GEU_USDT0-7 at the connector J110-3.
  • Page 237 MN2‑0218 SECTION 6 TROUBLESHOOTING EP3990/EP4305 The following checking performance should be done by referring to the both "PCB Block Diagram" and "INPUT/OUTPUT SIGNAL LIST" in SECTION 4. Phenomenon which may occur by a failure of this PCB. 1. The system does not start up at all. (1)Check the response of the panel switches.

  • Page 238: Cine Memory

    MN2‑0218 SECTION 6 TROUBLESHOOTING EP3996 CINE MANAGER The following checking performance should be done by referring to the both "PCB Block Diagram" and "INPUT/OUTPUT SIGNAL LIST" in SECTION 4. Phenomenon which may occur by a failure of this PCB. 1. The search or store function is abnormal. The frozen image is abnormal. (1)Remove CINE MANAGER board and CINE MEMORY board, then check the ordinary operation.
  • Page 239 MN2‑0218 SECTION 6 TROUBLESHOOTING (2)Check M_TXRX signal at the connector J106-3. Transmission waveform is normal.→Refer to “E2”. Transmission waveform is abnormal.→Proceed to (3). (3)Check HVB, high voltage for transmission, at the connector J410. Normal→Replace this PCB. Abnormal→Refer to “A3”. EP4003 MECHA PROBE SELECTOR The following checking performance should be done by referring to the both "PCB Block...

  • Page 240: Video Printer

    MN2‑0218 SECTION 6 TROUBLESHOOTING 3. Abnormal Hart Rate value is displayed. ECG sync. does not function properly. (1)Check R-GATE signal at the connector J754. Normal→Refer to “C5”. Abnormal→Replace PHYSIO AMP board in this unit. EP3995 PHYSIO. MEMORY (PHI) The following checking performance should be done by referring to the both "PCB Block Diagram"...

  • Page 241: Video Cassette Recorder

    MN2‑0218 SECTION 6 TROUBLESHOOTING VIDEO CASSETTE RECORDER The following checking should be done by referring to the operation and instruction manuals for the VCR. Check the cable connection with main body, and wrong connection or braking cables does not exist. (1)Check the VIDEO OUT signal to the VCR.
  • Page 242 (2)Check the TV_OUT signal at the connector J4 #1. Normal→Refer to “A5”. (Trouble of TV monitor.) Abnormal→Replace this PCB. 4. Abnormal data communication between the SSD-1000 and DMS-1000. DMS-1000 DATA MANAGEMENT SUBSYSTEM This checking performance should be done by referring to the SERVICE MANUAL for DMU-200.
  • Page 243 MN2‑0218 SECTION 6 TROUBLESHOOTING (Blank page) 6 ‑ 70...
  • Page 244 MN2‑0218 SECTION 6 TROUBLESHOOTING Waveform for Troubleshooting It describes the waveforms from next page for the reference to judgment of defective PCB on the troubleshooting. However, the specified waveforms have been selected to be signified to show with the consideration of specification of measuring equipment and characteristic of signals. The waveforms are taken in the following condition, if it is not specified in each waveform.
  • Page 245 MN2‑0218 SECTION 6 TROUBLESHOOTING l EP404400 TX/PRE AMP MODE : B 20 V / DIV RANGE/DEPTH : 17 cm 100 ns / DIV J2A20 : TXRX1 l EP400600 RX FOCUS PROBE : ASU-35-3 MODE : M 2 μs / DIV J3A2 : MECHA_RX 6 ‑ 72...
  • Page 246 MN2‑0218 SECTION 6 TROUBLESHOOTING EP400700 MAIN AMP MODE : B 50 μs / DIV RANGE/DEPTH : 17 cm TP 1 : LOG OUT MODE : B 50 μs / DIV RANGE/DEPTH : 17 cm TP4 : DETECT OUT MODE : B 50 μs / DIV RANGE/DEPTH : 17 cm TP 13 : AAF_OUT...
  • Page 247 MN2‑0218 SECTION 6 TROUBLESHOOTING l EP400700 MAIN AMP MODE : B RANGE/DEPTH : 17cm MINIMUM : 0,2,5,12 cm 50 μs / DIV MAXIMUM : 1,3,8,18 cm TP10 : GAIN_CNT MODE : B 50 μs / DIV RANGE/DEPTH : 17 cm TP8 : Fo CONT MODE : B 50 μs / DIV...
  • Page 248 MN2‑0218 SECTION 6 TROUBLESHOOTING EP400700 MAIN AMP MODE : B 50 μs / DIV RANGE/DEPTH : 17 cm TP17 : EXCHNGEV TP19 : US BLK 6 ‑ 75...
  • Page 249 MN2‑0218 SECTION 6 TROUBLESHOOTING l EP-395600 GEU ITF MODE : B RANGE/DEPTH : 17 cm 10 ms / DIV J2A4 : US ADR 0 J2C4 : US ADR 1 J2B4 : US ADR 2 J2A5 : US ADR 3 J2C5 : US ADR 4 J2B5 : US ADR 5 J3D4 : GEU_BOF/ J3B4 : GEU_EOF/...
  • Page 250 MN2‑0218 SECTION 6 TROUBLESHOOTING EP395600 GEU ITF MODE : B 200 μs / DIV RANGE/DEPTH : 17 cm J314#1 : A/D INPUT PROBE : ASU-35-3 MODE : B 50 μs / DIV RANGE/DEPTH : 17 cm J2A3 : USBLK J2B9 : M HOLD 6 ‑ 77...
  • Page 251 MN2‑0218 SECTION 6 TROUBLESHOOTING EP39660＊ DIU MODE : B 50 μs / DIV RANGE/DEPTH :17cm J3A5 : GEU_USDT 0 J3C5 : GEU_USDT 1 J3B5 : GEU_USDT 2 J3D5 : GEU_USDT 3 J3A6 : GEU_USDT 4 J3C6 : GEU_USDT 5 MODE : 20 μs / DIV RANGE/DEPTH : 17 cm J312#1 : TV_OUT...
  • Page 252 MN2‑0218 SECTION 6 TROUBLESHOOTING l EP39660* DIU MODE : B RANGE/DEPTH :17cm 50 μs / DIV GAIN : MINIMUM (30) J3B19 : DIU_BGAIN MODE : B 50.0 μs / DIV RANGE/DEPTH : 17 cm GAIN : MAXIMUM (90) J3B19 : DIU_BGAIN 6 ‑ 79...
  • Page 253 MN2‑0218 SECTION 6 TROUBLESHOOTING EP400800 MECHA SERVO PROBE : ASU-35-3 MODE : B RANGE/DEPTH : 15 cm MS LINE DENSITY : HIGH 10 ms / DIV J3A17 : M_A J3C17 : M_B J3B17 : M_C J3D17 : M_Z PROBE : ASU-35-3 MODE : B RANGE/DEPTH : 15 cm 5 ms / DIV...
  • Page 254 MN2‑0218 SECTION 6 TROUBLESHOOTING EP400800 MECHA SERVO PROBE : ASU35-3 MODE : B RANGE/DEPTH : 15 cm 50 μs / DIV MS LINE DENSITY : HIGH J3A19 M_MOTOR+ PROBE : ASU-35-3 MODE : B RANGE/DEPTH : 15 cm 10 ms / DIV MS LINE DENSITY : LOW J1C24 : M US STRT J1D24 : M FRM STRT...
  • Page 255 MN2‑0218 SECTION 6 TROUBLESHOOTING (Blank page) 6 ‑ 82...

  • Page 256: Section 7 Adjustment Procedure

    In order to avoid some new trouble created by this adjustment procedure manual, the person performing this adjustment should be restricted to someone who has undergone the Aloka approved training course and who has a high level of technical expertise and knowledge.
  • Page 257 MN2‑0218 SECTION 7 ADJUSTMENT PROCEDURE Adjustment Procedure 7-4-1 EP400700 MAIN AMP Adjusts PRESTC and STC internally and corrects the movement range of the Purpose of Adjustment STC knobs on the operation panel. Item Conditions Adjustment Measurement Standard Point Point MODE：B Offset Voltage: 0mV±10mV PRESTC （Refer to Fig.7-1）...
  • Page 258 MN2‑0218 SECTION 7 ADJUSTMENT PROCEDURE 7-4-2 EP400700 MAIN AMP Adjust the ultrasound image noise level to the appropriate value. Purpose of Adjustment Adjustment Measuring Item Conditions Standard Point Point Adjust noise MODE：B On TV screen DEPTH/RANGE：19cm level STC：MAX Gain：MAX CONTRAST：1 AGC：OFF RELIEEF：OFF Make the area except the...
  • Page 259 MN2‑0218 SECTION 7 ADJUSTMENT PROCEDURE 7-4-3 EP400600 RX FOCUS To smooth the linkage of ultrasound images in the depth direction. Purpose of Adjustment Adjustment Measuring Item Conditions Standard Point Point Hold the Probe in the Eliminate On TV screen air. difference in MODE：B receiving focus...

  • Page 260: Section 8 Performance Check

    MN2‑0218 SECTION 8 PERFORMANCE CHECK Introduction “Performance Check” describes the items to be confirmed for the maintenance of an equipment quality and safety under the circumstances referred to below. Once a repair work has been done. Once an improvement, for a problem or the like, has been made. Once a change as to upgrade the functions and/or specifications has been made.
  • Page 261 MN2‑0218 SECTION 8 PERFORMANCE CHECK Performance Check Those items which are covered by a performance check vary, in principle, with what is done for the operation requiring the check. In accordance with the chart given below, identify an item or items required (those marked with ●...
  • Page 262 MN2‑0218 SECTION 8 PERFORMANCE CHECK 8-4-1 Function Check Check for normal actions of functions corresponding with control panel switches on the equipment. Checking for Panel Switch Operations Check also the key tops (cap) carefully when the panel peripheral PCBs and/or the switches on the panel are replaced.

  • Page 263: Acoustic Power

    MN2‑0218 SECTION 8 PERFORMANCE CHECK Image Adjustment The following function, which is described “(Function)” after words, it is possible to push one of the Full-key board with function switch. The function which is described “(MENU)” after words is the function inside MENU. B-GAIN Changes both B and M mode images in B/M mode by turning Gain knob.
  • Page 264 MN2‑0218 SECTION 8 PERFORMANCE CHECK RELIEF (MENU) In B/M mode, select RELIEF in MENU. Then, select NEXT. B mode RELIEF MENU becomes M mode one. They change every time NEXT is selected. And RELIEF works B mode or M mode image each other. FTC (MENU) Turning the FTC switch on, M mode image changes as line drawing.

  • Page 265: Looped Play Back

    MN2‑0218 SECTION 8 PERFORMANCE CHECK SCAN AREA In B mode, moves the scanning area by the trackball and expands or reduces the scanning area of ultrasound image by the rotary encoder. (Clockwise (CW) turn for expansion, counterclockwise (CCW) turn for reduction.) ZOOM In B mode, moves the ZOOM area position by the trackball, and increases or decreases the ZOOM magnification by the rotary encoder.
  • Page 266 MN2‑0218 SECTION 8 PERFORMANCE CHECK SOUND Changes (ON/OFF) the sync beep tone for ECG sync. ECG SYNC When ECG wave rises, SYNC mark is displayed. B mode image must change itself in synchronization with SYNC. And SYNC mark is moved by 「←」,「→」switches. Mechanical Scanner （When SCU-1000*（OPTION）is connected）...

  • Page 267: Image Quality Check

    MN2‑0218 SECTION 8 PERFORMANCE CHECK 8-4-2 Image Quality Check To ensure the quality of ultrasound images, check should be made by using a test piece or a similar object. Image Quality OVERALL IMAGE QUALITY Condition：B mode, GAIN set to proper level, STC at center, CONTRAST 4 PROBE : UST-979-3.5 A proper image must be shown with the probe placed on the abdominal region.
  • Page 268 A solid echo of 11 cm or deeper can be seen. Seventh Thread Resolution Use a probe UST-979-3.5. MODE：B Use a test target ASU-32 KG1 (Aloka product), visually check the minimum distance recognizable in water. u Lateral resolution 3 mm or less...

  • Page 269: Safety Check

    When you do the Safety Check, refer to the Electrical Safety Check Manual; MN2-0205. ○IMPORTANT○ In Electrical Safety Checks, the method and rating of check differ in the degree of protection against electric shock. SSD-1000 belongs to “ Type BF applied part ” in the degree of protection against electric shock. 8 ‑ 10...
  • Page 270 MN2‑0218 SECTION 8 PERFORMANCE CHECK SSD-1000 CHECK SHEET（1/2） Checked by Check Item Details Remarks 8-4-1 Functional Check Panel Switch KEY BOARD DEPTH/RANGE MODE FREEZE IMAGE DIRECTION PROBE SELECTOR PRINT Image Adjustment B-GAIN M GAIN ACOUSTIC POWER CONTRAST IMAGE SELECT ABC LEVEL...
  • Page 271 MN2‑0218 SECTION 8 PERFORMANCE CHECK SSD-1000 CHECK SHEET（2/2） Checked by Check Item Details Remarks 8-4-2 Image Quality Check Image Quality Overall Image Quality Coin Check Noise Level Overall Performance test Overall Sensitivity Resolution 8-4-3 Safety Check Checking Protected Earth Cable...

  • Page 272: Section 9 Disassembling Procedure

    MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE SSD-1000 Disassembly Procedures     １．Part Names   ２．Unit Configuration   ３．Disassembly Flowchart   ４．Removing Covers   ５．Setting Operation Panel Height   ６．JB-224   ７．JB-212/JB-213/JB-215   ８．Operation Panel   ９．PC Board, Motherboard 10．Monitor 11．USM-23 12．Power Supply 13．SCU-1000 14．PEU-1000 9 ‑ 1...

  • Page 273: Part Names

    MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE １．Part Names Monitor IP-1233B/ IP-1233BV Cable hanger L-Ki-630 Operation panel L-KEY-64 9 ‑ 2...

  • Page 274: Unit Configuration

    MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE ２．Unit Configuration   Physio unit （PEU-1000） Mechanical sector scanner unit （SCU-1000）   Image storage unit Connector terminal （USM-23） block（JB-224） AC plug socket （JB-212/JB-213/   JB-215） Power supply unit （PSU-S1000） 9 ‑ 3...

  • Page 275: Disassembly Flowchart

    MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE ３．Disassembly Flowchart The disassembly procedures explained in this manual are based on the flowchart as illustrated below.  Proceed with disassembly in accordance with it. The code numbers provided in the flowchart correspond with the chapters of this manual. Left side ４- 1 ４- 1 - 1 cover PC board 9 - 1 Setting panel Rear Cover Monitor Monitor arm ４- 2 5 - 1 1 0 - 1 1 0 - 2 height USM-23 4 - 5 Top cover...

  • Page 276: Removing Covers

    MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE ４．Removing Covers ４-１．Left Side Cover When removing Loosen the two  screws (BNK3×8Fe,Ni) at the rear part and remove the left side Loosen two cover. screws Left side Remove the cover by opening the rear (BNK3×8Fe,Ni) cover part as the front part is locked with a Fan connector dual-lock fastener (magic fastener).           When mounting Connect the fan connector with the corresponding connector port and remount the removed left side cover. Strike to fix Fix the cover Strike the top and bottom of the cover as the cover in in place with the front part is locked with a dual-lock place two screws fastener (magic fastener) to fix the cover (BNK3×8Fe,Ni)） in place. (Verify that no part is inserted Left side cover halfway.) Strike to fix Tighten the loosened two screws (BNK3 the cover in...

  • Page 277: Rear Cover

    MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE 2 screws Remove the two  screws (M5 × 10pot (M5×10 pot head). head) Take off the shield board to remove the fan. Shield board Left side shield cover         ４-２．Rear Cover Remove two When removing screws (BNK3× 8Fe,Ni) Remove the two screws (BNK3×8Fe,Ni) and take off the rear cover. Rear cover   Remount the removed rear cover. When mounting       Insert one accordion layer into the Accordion layers U-shaped groove, remount the rear Top cover cover, and fix the cover firmly in place with the removed two screws (BNK3x8Fe, Ni). Two screws (BNK3×8Fe,Ni),       Rear cover U-shaped groove 9 ‑ 6...

  • Page 278: Right Side Cover

    MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE ４-３．Right Side Cover When removing Loosen the two  screws (BNK3×8Fe,Ni) at the rear part and remove the right side cover. Loosen two screws Remove the cover by opening the rear (BNK3×8Fe,Ni) part as the front part is locked with a dual-lock fastener (magic fastener). Right side cover             Remount the removed right side cover. When mounting Strike the top and bottom of the cover as Strike to the front part is locked with a dual-lock Fix the cover Fix the cover fastener (magic fastener) and fix the in place in place two screws cover in place. (Verify that no part is Right side inserted halfway.) cover Tighten the loosened two screws (BNK3 × 8Fe,Ni) at the rear part to fix the cover Strike to Fix the cover firmly in place. in place            ...

  • Page 279: Top Cover

    MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE When mounting Remount the removed base cover. Strike to fix the Strike the top of the cover as the cover is  cover in place Strike to fix the locked with a dual-lock fastener (magic  cover in place fastener).  (Verify that no part is inserted halfway.)       ４-５．Top Cover Remove the four caps and four  screws (BNK3 × 8Fe,Ni) and take off the top cover. Four caps Remove four screws (BNK3×8Fe,Ni)     9 ‑ 8...
  • Page 280 MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE ５．Setting Operation Panel Height ５-１．Setting Operation Panel Height Loosen the four screws. Enlarged view of the area Four locking screw Loosen locking screws      Stopper Raise the handler and adjust the Highest operation panel at a desired height (on a level 15 mm pitched stopper, 8 steps). Adjusting the operation panel height is based on a one-way mechanism which 15 mm allows no readjustments once raised up pitched, to the highest level unless pulling the 8 steps Free handler all the way down to the lowest Range allowed falling for mounting level to redo the adjustment.  Follow the of the physio unit readjustment procedures explained on the proceeding page.       Lowest Reminder when making readjustments : level Guide tape When mounting the physio unit, adjust...
  • Page 281 MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE ･ Screw location at the stopper ･ Screw location at the stopper                    S/N 1010021〜               S/N 1010001〜1010020 Screw at the stopper Screw at the stopper                         Loosen one of the screws at the stopper for height readjusting. 【  Caution:  】 The operation panel is unlocked when Supporting raised all the way up to the highest level, with a hand simultaneously starting free falling.  Be sure to support the operation panel with           a hand when returning to the lowest level for height readjusting. ･ Screw location at the stopper ･ Screw location at the stopper          S/N 1010021〜        S/N 1010001〜1010020 Screw at Locking the stopper screw...
  • Page 282 MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE ６． JB-224 ６-１．JB-224 Remove the ten  screws (BNK3×Fe,  Ni) Right side Right shield cover         and take off the right shield cover. JB-224 Remove ten screws  (BNK3×8Fe,Ni)            Loosen the three screws and remove the Loosen three connectors, P317 and P808. screws P317 P808         Shift the position of the JB-224 upward to disconnect the connector with ease and remove the connector JB-224. P318           9 ‑ 11...
  • Page 283 MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE ６-２．Connector Terminal Block PC Board Connector terminal block PC board Remove the four screws (CNK3×8Fe,Ni) and take off the connector terminal block PC board. Remove four screws (CNK3×8Fe,Ni)         ７． JB-212/JB-213/JB-215 ７-１．JB-212/JB-213/JB-215        Remove the connector J808 and take Right side off the two screws (BNK3×8Fe,Ni). Remove the JB-212(JB-213/JB-215). JB-212 (JB-213/JB-215) Remove two screws (BNK3 x 8Fe,Ni) J808        9 ‑ 12...

  • Page 284: Operation Panel

    MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE ８．Operation Panel ８-１．Operation Panel Operation panel Remove the five  screws (BNK3 × 10Fe,Ni) underneath the operation panel. Remove five  screws (BNK3×10Fe,Ni) Raise the operation panel and hold it right Operation panel there. Remove the earth locking  screw (CNK3 ×  6Fe,Ni) at the right side of the connector to take off the earth and connector, and then remove the Connector Earth cable operation panel. 【  Caution:  】 When mounting the PEU-1000, remove the connectors, P762 and J762, to take off the cable connector P551 and panel switch PC board connector J551, as J551 illustrated in the picture to the left. P551 J762 P762 9 ‑ 13...

  • Page 285: Panel Pc Board

    MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE ８-２．Panel PC Board Remove the three knobs and STC knobs STC knobs from the operation panel. 【  Caution:  】 Two encoder To mount the encoder  knob, insert the knobs knob into the shaft in the vertical direction. knob Remove 20 screws Remove 20 screws (CNK3×5Fe,Ni) (CNK3×5Fe,Ni) Connector 【 Caution-1:  】 Perform maintenance tasks by    Connector placing the entire panel upside down (as illustrated in the picture) Remove one of the connector as the key top guides (black parts) connections from the track ball and take at the full-key area easily come off the panel. off the 20 screws (CNK3×5Fe,Ni). Remove the panel PC board. 【  Caution:  】 -1 ...

  • Page 286: Track Ball

    MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE ８-３．Key tops Push the key  tops and take them out from the upper surface of the operation panel.   Pushing from under ８-４．Track Ball Remove the four screws (CNK3×6Fe,Ni) Remove four screws and one of the connector connections (CNK3 x 6Fe,Ni) from the track ball. Connector   9 ‑ 15...
  • Page 287 MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE ９．PC Board, Motherboard ９-１．PC Board Loosen the four  screws (BNK4 × Left side 10Fe,Ni) and shift the potbellied holes Loosen four screws upward to remove the PC holder. (BNK4×10Fe,Ni) PC holder        Remove all of the PCBs (006, 044, 956, 969, 997, 996, 995, and 990) without 0 0 8   0 0 7   0 0 6   0 0 6   0 4 4 exception. 【  Precautions about PCBs:  】 ※PCB 015 Remove the two ...
  • Page 288 MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE ９-２．Motherboard Right side Remove all of the connectors at the lower area of the right side. Remove all of the connectors connecting J 8 0 4  J 8 0 3  J 8 0 2 with the motherboards, EP4016 and EP4017, and clamp, as illustrated in the J 8 0 8   J 8 0 6   J 8 0 1   J 8 0 5   J 8 0 7 picture to the left.
  • Page 289 MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE Four screws and nuts Right side ※EP4016 (B tight M3×8 and PW3) EP4016 Remove the four  screws and nuts (B tight M3×8 and PW3). Loosen the hexagon-shaped supports, A, B, and C, and take off the S/N1010001 to 1010019 and S/N1010070 and above. Hexagon- Remove the hexagon-shaped support D shaped by taking off the screw at the left side, as support the support is fixed in place with the screw and nut (CNK3×10 Fe,Ni and YC 20A) from the other side, as illustrated in Figure 1. Lower part of the right side Remove the motherboard EP4016. EP4017 【  Caution:  】 Remove the S/N1010020 to 1010069 by taking off the screw at the left side, as the hexagon-shaped support B is fixed in place with the  screw and nut (CNK3× 10  Fe,Ni and YC 20A) from the other side, as illustrated in Figure 1. 11 screws and nuts ※EP4017 (B tight M3×8 and W3)
  • Page 290 MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE １０．Monitor １０-１．Monitor Perform the removal by raising the Lower area of the monitor monitor up to the highest level. Remove the four screws (BNK3×8Fe,Ni) with stabilizing screwdriver (jewelers screwdriver). Remove four screws (BNK3×8Fe,Ni)         Lower the accordion layers and remove the connector P10.        Pull off the connector P10.      9 ‑ 19...
  • Page 291 MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE Remove the three screws (BNK4×10Fe, Right side Ni). 【  Caution:  】 Remove the screw A by turning the panel in either the left or right direction.           Left side           Remove the monitor and pull off the cable.    Monitor     １０-２．Monitor Arm Remove the eight  screws (BNK4 × 10Fe,Ni) and pull off the cable by raising Monitor arm the arm. Eight screws (BNK4×10Fe,Ni) 9 ‑ 20...
  • Page 292 MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE 11．USM-23 11-１．USM-23     Remove all of the connectors from the Right side lower area of the right side. J804 J802 J803 P800 Power switch J808 J806 J801 J805 J807    Remove the connectors, P304, P70, and Earth P307, connecting with the lower motherboard and the earth. P304 P307       Remove the two  screws (CNK3 × 10Fe,Ni) from the lower area of the right side. Two screws (CNK3×10Fe,Ni)     9 ‑ 21...
  • Page 293 MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE Remove the two  screws (CNK3 × Left side 10Fe,Ni) from the lower area of the left side. Two screws (CNK3×10Fe,Ni)           Two screws Remove the four screws (two at the top, Rear   (BNK4×10Fe,Ni) BNK4×10Fe,Ni and two at the bottom, BNK3×8Fe,Ni) at the rear part.     Two screws          (BNK3×8Fe,Ni) Remove the unit by supporting with Right side hands the black-and-white printer mounting board at the right side and the PC holder at the left side, as illustrated in the picture to the left. Black-and-white printer mounting 【  Caution:  】 board Be careful not to have the cable caught under the unit when placing the unit on            the floor after the removal.
  • Page 294 MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE １２．Power Supply １２-１．PSU-S1000 Five screws   As to S/N1010020 and above, remove (S3×8Fe, Ni) the five  screws (S3 × 8Fe,Ni) and four  screws  (CNK3 × 10Fe,Ni) and take off the power supply cover. 【  Caution:  】 As to S/N1010001 to 1010019, remove the three  screws C, D, and E, due to no use of the two screws, A and B    Four screws (S3×8Fe,Ni). (CNK3×10Fe,Ni) Four screws Four screws   (BNK5×12Fe,Ni) (BNK5×12Fe,Ni) Connector terminal block panel Connector terminal block panel Two screws  ...
  • Page 295 MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE １２-２．EU-6025 Five screws As to S/N1010020 and above, (S3×8Fe,Ni) the five  screws (S3 × 8Fe,Ni) and four  screws  (CNK3 × 10Fe,Ni) and take off the power supply cover. 【  Caution:  】 As to S/N1010001 to 1010019, remove the three  screws C, D, and E, due to no use of the two screws, A and B Four screws      (S3×8Fe,Ni). (CNK3×10Fe,Ni) Four screws   (BNK3×8Fe,Ni) Four screws   (BNK3×8Fe,Ni) Earth Connector terminal block panel Connector terminal       ...

  • Page 296: Power Switch

    MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE １２-３．Power Switch Remove the two screws (B tight M3×8) and take off the power switch.           Two screws (B tight M3×8) １２-４．Fuse    Remove the two  screws (S3 × 8Fe,Ni) Two screws   and take off the fuse cover. (S3×8Fe,Ni)）       Remove the  screws by inserting a minus screwdriver in the groove on the Fuses upper surface of the fuses and turning in the right direction.           9 ‑ 25...
  • Page 297 MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE １３．SCU-1000 １３-１．SCU-1000    Insert a piece of paper between the main system body and the bottom of the mechanical sector PC board (EP400300 Paper to keep t **) so as to keep the screws from falling he screws from inside the main system body. falling inside Remove the nine screws (BNK3×8Fe,Ni) and take off the locking board. Locking  board Nine screws   (BNK3×8Fe,NI) Connectors Remove the four plastic supports (SF5.5-11) and copper support (SB5.5- 11) and take off the PC board. Pull off the connectors at two locations. Four plastic Pull off the inserted paper after removing supports (SF5.5-11) the screws. Copper support （SB5.5-11） 9 ‑ 26...
  • Page 298 MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE Pull off the connector at the right side of the PC board and remove the PC board. Connectors 9 ‑ 27...
  • Page 299 MN2‑0218 SECTION 9 DISASSEMBLING PROCEDURE １４．PEU-1000 １４-１．PEU-1000    Remove the four  screws (BNK4×12Fe, 4-BNK4×12Fe,Ni Ni) and take off the  physio unit (PEU- 1000) Square holes of   by putting the two cables through the the cabinet square holes of the cabinet. Cable Physio unit （PEU-1000） １４-２．PC Board Remove the six screws and take off the  Top cover top cover. Remove all of the connectors on the PC board. Loosen the two screws and remove the Physio Physio two internal  knobs and two external panel (1) amplifier knobs. EP4206＊ EP4012＊ Loosen the two screws and remove the  Physio   small knob. panel (2) Remove the screws and take off the PC EP4207＊...
  • Page 300 MN2‑0218 SECTION 10 PARTS LIST 10-1 Contents of Parts List Parts are separately shown as each portion of equipment. When you find the part, firstly choose the portion the part belonged, then open the page suggested with “INDEX”. MONITOR SEE INDEX 04 DMS UNIT(OPTION) OPERATION PANEL SEE INDEX 12...
  • Page 301 MN2‑0218 SECTION 10 PARTS LIST 10-2 Appliance of Parts List This Parts List consists of the parts for technical service and maintenance. Therefore, the parts model name (PARTS No.) is only valid to the technical support. When you order the parts shown in the List, please apply to our technical support section.
  • Page 302 MN2‑0218 SECTION 10 PARTS LIST 10-4 Explanation of Parts List This Parts List is divided by some blocks (INDEX), and each block consists of the illustration and list. S/N serial number of revision INDEX block number Name of block UNIT model of block INDEX MAIN BODY UNIT...
  • Page 303 MN2‑0218 SECTION 10 PARTS LIST If the same block or unit will be revised, it will be distinguished with UNIT, and this shows the beginning of production change. ITEM Relation numbers between illustration and List. CODE No Code number applied one by one to each parts. However, at this time (APR. ’97), it is not acceptable to order.
  • Page 304 MN2‑0218 SECTION 10 PARTS LIST 10-6 Parts List The parts List is shown from next page. It consists of “INDEX”. For the portion of equipment suggested with “INDEX”, refer to the figure described in page 10-1. 10  ‑  5...
  • Page 305 MN2‑0218 SECTION 10 PARTS LIST UNIT MAIN BODY USI‑145* ⑦ ⑥ ⑤ ⑧ ④ ③ ② ① ⑬ ⑪ ⑨ ⑩ ⑫ 10  ‑  6...
  • Page 306 MN2‑0218 SECTION 10 PARTS LIST UNIT MAIN BODY USI‑145* ⑲ ⑭ ⑱ KNOB CUSHON ⑰ ⑯ ⑳ ⑮   〈 拡大図 〉 〈 〉 Expansion figure ⑲ ⑱ KNOB ⑰ CUSHON 10  ‑  7...
  • Page 307 MN2‑0218 SECTION 10 PARTS LIST 10  ‑  8...
  • Page 308 MN2‑0218 SECTION 10 PARTS LIST 10  ‑  9...

  • Page 309: Operation Panel

    MN2‑0218 SECTION 10 PARTS LIST UNIT OPERATION PANEL L‑KEY‑64* ⑥ ⑤ ④ ① ②  P CB ③ 10  ‑  10...
  • Page 310 MN2‑0218 SECTION 10 PARTS LIST UNIT OPERATION PANEL L‑KEY‑64* ⑧ ⑦ ⑩ SW : Full keyboard ⑪ SW : except for ⑩⑫ switch ② ⑨ ⑫ 〈 部品面より見る 〉 SW : Print、Freeze､Mark Ref 〈 Part side 〉 ⑬ Panel case Ass’y ・Case    ・Chassis    ・Key top...
  • Page 311 MN2‑0218 SECTION 10 PARTS LIST UNIT OPERATION PANEL L‑KEY‑64* 10  ‑  12...
  • Page 312 MN2‑0218 SECTION 10 PARTS LIST UNIT OPERATION PANEL L‑KEY‑64* 10  ‑  13...
  • Page 313 MN2‑0218 SECTION 10 PARTS LIST 10  ‑  14...
  • Page 314 MN2‑0218 SECTION 10 PARTS LIST 10  ‑  15...
  • Page 315 MN2‑0218 SECTION 10 PARTS LIST 10  ‑  16...
  • Page 316 MN2‑0218 SECTION 10 PARTS LIST 10  ‑  17...
  • Page 317 MN2‑0218 SECTION 10 PARTS LIST 10  ‑  18...
  • Page 318 MN2‑0218 SECTION 10 PARTS LIST 10  ‑  19...
  • Page 319 MN2‑0218 SECTION 10 PARTS LIST UNIT PCB UNIT USM‑23* 10  ‑  20...
  • Page 320 MN2‑0218 SECTION 10 PARTS LIST 10  ‑  21...
  • Page 321 MN2‑0218 SECTION 10 PARTS LIST UNIT MONITOR IP‑1233B 10  ‑  22...
  • Page 322 MN2‑0218 SECTION 10 PARTS LIST UNIT MONITOR IP‑1233C 10  ‑ 23...
  • Page 323 MN2‑0218 SECTION 10 PARTS LIST 10  ‑  24...
  • Page 324 MN2‑0218 SECTION 10 PARTS LIST UNIT AC OUTLET JB‑212* ① ② 10  ‑ 25...
  • Page 325 MN2‑0218 SECTION 10 PARTS LIST UNIT AC OUTLET JB‑215* ③ ④ 10  ‑  26...
  • Page 326 MN2‑0218 SECTION 10 PARTS LIST 10  ‑ 27...

  • Page 327: Connector Panel

    MN2‑0218 SECTION 10 PARTS LIST UNIT CONNECTOR PANEL JB‑224* ③ Chassis ① ② Label 10  ‑  28...
  • Page 328 MN2‑0218 SECTION 10 PARTS LIST 10  ‑ 29...

  • Page 329: Power Supply Unit

    MN2‑0218 SECTION 10 PARTS LIST UNIT POWER SUPPLY UNIT PSU‑S1000* FUSE HOLDER 10  ‑  30...
  • Page 330 MN2‑0218 SECTION 10 PARTS LIST 10  ‑ 31...
  • Page 331 MN2‑0218 SECTION 10 PARTS LIST UNIT CABLE SSD‑1000* 10  ‑  32...
  • Page 332 MN2‑0218 SECTION 10 PARTS LIST UNIT CABLE SSD‑1000* 10  ‑ 33...
  • Page 333 MN2‑0218 SECTION 10 PARTS LIST 10  ‑  34...
  • Page 334 MN2‑0218 SECTION 10 PARTS LIST 10  ‑ 35...
  • Page 335 MN2‑0218 SECTION 10 PARTS LIST 10  ‑  36...
  • Page 336 MN2‑0218 SECTION 10 PARTS LIST (Blank page) 10  ‑ 37...
  • Page 337 MN2‑0218 SECTION 10 PARTS LIST UNIT MECHANICAL SECTOR SCANNER UNIT SCU‑1000* ① Chassis ②     ③ Plastic support ④ Metal support 10  ‑  38...
  • Page 338 MN2‑0218 SECTION 10 PARTS LIST 10  ‑ 39...
  • Page 339 MN2‑0218 SECTION 10 PARTS LIST UNIT PHYSIO UNIT PEU‑1000* 10  ‑  40...
  • Page 340 MN2‑0218 SECTION 10 PARTS LIST 10  ‑ 41...
  • Page 341 MN2‑0218 SECTION 10 PARTS LIST UNIT DMS UNIT DMS‑1000* ③ ① ② DMU-200 ④ 10  ‑  42...
  • Page 342 MN2‑0218 SECTION 10 PARTS LIST 10  ‑ 43...
  • Page 343 MN2‑0218 SECTION 10 PARTS LIST UNIT VOLMODE UNIT EU‑9075* ① 10  ‑  44...
  • Page 344 MN2‑0218 SECTION 10 PARTS LIST 10  ‑ 45...
  • Page 345 MN2‑0218 SECTION 10 PARTS LIST （(Blank page) 10  ‑  46...

  • Page 346: Section 11 Service Information

    MN2‑0218 SECTION 11 SERVICE INFORMATION 11-1 Introduction “Service Information” describes other useful information for making service engineer’s repair service convenient. 11-2 Assignment of CTRL key and those usage In order to use special functions, press “CTRL” and the following key in keyboard at the same time.

  • Page 347: System Preset

    1,2,4,8,16,32,Default are not effective at present.) OFF, ON Edit of IPS. TEST PRESET OFF, ON TEST PRESET ON：PRESET1〜4 are used for adjustment. FOCUS MARK DISPLAY OFF, ON Display of Focus mark. ALOKA LOGOTYPE OFF, ON Display “Aloka” mark. DISPLAY 11  ‑  2...
  • Page 348 11-3. A pop-up menu display for probe registration On preset set-up menu display of SSD-1000, you can register up to six kinds of probes in a pop-up menu to be connected to the equipment. However, when plural probes in same electrical specification for transducer in spite of different shape exist, the typical probe model is only displayed in a pop-up menu, others are not displayed.
  • Page 349 MN2‑0218 SECTION 11  SERVICE INFORMATION (Blank page) 11  ‑  4...
  • Page 350 MN2‑0218 SSD-1000 SERVICE MANUAL Appendix Appendix-1 Introduction This appendix is described the revised history of this service manual as Manual Change Information. Appendix-2 Manual Change Information Revisions Rev. Date Note Contents Pages 25 / Sept. / ’98 1st. issue Apndx  ‑  1...
  • Page 351 MN2‑0218 SSD-1000 SERVICE MANUAL Appendix ( Blank page ) Apndx  ‑  2...
  • Page 352 SSD-1000 SERVICE MANUAL    ALOKA CO., LTD. Head Quater 6-22-1 Mure, Mitaka-Shi, Tokyo, Japan. Issued by TOKYO WORKS, ME Service Center 3-7-19 Imai, Ome-Shi, Tokyo, Japan. Telephone : **-81-428-32-3720 Facsimile : **-81-428-32-3155 FILE 1...

Table of Contents
