Delta Electronics PFC Chokes PFC2815V Series Specifications

PFC2815V Series
Mechanical Dimension:
30.0 Max.
48.5 Max.
39.0 0.5
3.6 0.1
31.0 Max.
Electrical Characteristics
o
AT 25 C, 60Hz/1V
INDUCTANCE
PART NO.
(mH) Min.
230V INPUT
PFC2815V01
Recommended Circuit
INPUT LINE
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
for Power Supply
Unit: mm
140.0 5.0
12.5 Max.
3.6*5 0.1
DCR INPUT POWER
( ) Max.
(reference)
61 4 135W
1
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com
19.0 Max.
10.0 Max.
32.0 Max.
Schematic :
1 BLACK
3 WHITE
WITHOUT FAN
RATED CURRENT TEMPERATURE
(Arms)
RISE ( C) Max.
0.65
3
29
Features
Harmonics current regulation
Low leakage flux suitable for power supply
The PFC (Power Factor Corrector) chokes
is suitable for power supply. It is applied to
regulate the harmonics current and raise the
power factor.
WITH FAN
RATED CURRENT TEMPERATURE
o (Arms)
RISE ( C) Max.
55 0.78
OUTPUT
o
55
