This Owner's Manual is provided and hosted by Appliance Factory Parts.
Napoleon PRO450RSIB
Owner's Manual
Shop genuine replacement parts for Napoleon
PRO450RSIB
Find Your Napoleon Grill Parts - Select From 278 Models
-------- Manual continues below part list --------

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO450RSIB and is the answer not in the manual?

Questions and answers

Related Manuals for Napoleon PRO450RSIB

Summary of Contents for Napoleon PRO450RSIB

  • Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. Napoleon PRO450RSIB Owner's Manual Shop genuine replacement parts for Napoleon PRO450RSIB Find Your Napoleon Grill Parts - Select From 278 Models -------- Manual continues below part list --------...
  • Page 2 Available Replacement Parts for Napoleon PRO450RSIB N240-0016 ELECTRODE FOR MAIN BURNER N350-0054 COLLECTOR BOX FOR ELECTRODE N510-0002 Black Silicone Lid Bumper- Standard Unit N570-0015 Lid Pivot Screw- Standard Unit. N710-0062 GREASE TRAY STANDARD N630-0003 SPRING, CONTROL KNOB BEZEL CENTER RING...
  • Page 3 N455-0063 SIDE BURNER ORIFICE 1.45MM NG ONLY 71450 Warming rack (standard) N305-0026 Wave Cooking Grid. **each** N010-0671 BURNERS, LEFT RIGHT & CENTER S85001 1-Outlet Regulator/Hose Assy. - Propane S83012 side burner grate stainless stl accssry S91005 temperature gauge (standard).
  • Page 4 Notice to Installer: Leave these instructions with the grill owner for future reference. Manufactured by: Napoleon Appliance Corp., 214 Bayview Dr., Barrie, Ontario, Canada L4N 4Y8 Phone: (705)726-4278 Fax: (705)725-2564 email: wecare@napoleonproducts.com web site: www.napoleongrills.com...

  • Page 5: Conditions And Limitations

    NAPOLEON will not be responsible for the installation, labor or any other costs or expenses related to the re-installation of a warranted part, and such expenses are not covered by this warranty.

  • Page 6: Safe Operating Practices

    WARNING! Failure to follow these instructions could result in property damage, personal injury or death. Read and follow all warnings and instructions in this manual prior to operating grill. Safe Operating Practices • This gas grill must be assembled exactly according to the instructions in the manual. If the grill was store assembled, you must review the assembly instructions to confirm correct assembly and perform the re- quired leak tests before operating the grill.

  • Page 7: General Information

    General Information This Gas Barbecue Is Certified Under Canadian And American National Standards, CSA 1.6-2007 and ANSI Z21.58-2007 respectively for Outdoor Gas Grills and should be installed to conform with local codes. In absence of local codes, install to the current CAN/CSA-B149.1 Propane Installation Code in Canada or to the National Fuel Gas Code, ANSI Z223.1 in the United States.

  • Page 8: Leak Testing Instructions

    Bubbles will indicate a gas leak. Either tighten the loose joint or have the part replaced with one recommend- ed by the Napoleon Customer Care department and have the grill inspected by a certified gas installer. If the leak cannot be stopped, immediately shut off the gas supply, disconnect it, and have the grill inspected by a certified gas installer or dealer.

  • Page 9: Lighting Instructions

    Lighting Instructions Side Burner Lighting Hole Igniter Left Burner Centre Burner Rear Burner Right Burner Off Position WARNING! Open lid WARNING! Ensure all burner controls are in the off position. Slowly turn on the gas supply valve. Main Tube Burner Rear Burner Lighting Main Infrared Side Burner Lighting...

  • Page 10: Cooking Instructions

    Should a flare-up occur, move food away from the flames and reduce the heat. Leave the lid open. See Your All Season Grill cookbook by Napoleon for more detailed instructions. Infrared Main Burner Use: Follow the Infrared Burner Ignition procedures and operate on high for 5 minutes with the lid closed or until the ceramic burners glow red.
  • Page 11 Infrared Side Burner Use: The gas grill should be located so that the side burner is protected from the wind, because the wind will adversely affect its performance. The side burner is equipped with a cast iron cook- ing grid which can be positioned at two different heights. The lower position can be used like any range top burner, for gravies, soups, etc.

  • Page 12: Control Setting

    Any juices or oils that escape from the food drip onto the charcoal and vaporize into smoke giving the food its delicious grilled taste. The Napoleon infrared burner cooks in the same way. In each burner, 10,000 ports – each with its own tiny flame – cause the surface of the ceramic tile to glow red. This glow emits the same type of infrared heat to the food as charcoal, without its hassle or mess.

  • Page 13: Cleaning Instructions

    Cleaning The Outer Grill Surface: Do not use abrasive cleaners or steel wool on any painted, porcelain or stain- less steel parts of your Napoleon Grill. Doing so will scratch the finish. Exterior grill surfaces should be cleaned with warm soapy water while the metal is still warm to the touch. To clean stainless surfaces, use a stainless steel or a non-abrasive cleaner.

  • Page 14: Maintenance Instructions

    Maintenance Instructions We recommend this gas grill be thoroughly inspected and serviced annually by a qualified service person. WARNING! Always wear protective gloves and safety glasses when cleaning your grill. WARNING! Turn off the gas at the source and disconnect the unit before servicing. To avoid the pos- sibility of burns, maintenance should be done only when the grill is cool.
  • Page 15 WARNING! Hose: Check for abrasions, melting, cuts, and cracks in the hose. If any of these conditions exist, do not use the gas grill. Have the part replaced by your Napoleon Gas Grill dealer or qualified gas installer. Aluminum Castings: Clean castings periodically with warm soapy water. Aluminum will not rust, but high temperatures and weathering can cause oxidation to occur on aluminum surfaces.

  • Page 16: Troubleshooting

    Troubleshooting Problem Possible Causes Solution Low heat / Low flame For propane - improper lighting Ensure lighting procedure is followed carefully. All gas when valve turned to procedure. grill valves must be in the off position when the tank high. valve is turned on.
  • Page 17 Cracked ceramic tile. Allow burner to cool and inspect very closely for cracks. If any cracks are found, contact your authorized Napoleon dealer to order a replacement burner assembly. Leaking gasket surrounding the Contact your authorized Napoleon dealer for instructions ceramic tile, or a weld failure in on ordering a replacement burner assembly.

  • Page 18: Getting Started

    CAUTION! During unpacking and assembly we recommended you wear work gloves and safety glasses for your protection. Although we make every effort to make the assembly process as problem free and safe as possible, it is characteristic of fabricated steel parts that the edges and corners might be sharp and could cause cuts if handled incorrectly.
  • Page 19 4 X N570-0026 (#14 x 1/2”) 3/8”(10mm) If necessary the center panel and cross beam can be tapped down with a rubber mallet. Si nécessaire, le panneau central et barre de traverse peut être enfoncé avec un maillet en caoutchouc. 8 X N570-0026 (#14 X1/2”) 3/8”(10mm) www.napoleongrills.com...
  • Page 20 1 x N570-0026 (#14 x 1/2”) 3/8”(10mm) Propane Only Propane Seulement 4 x N570-0026 (#14 x 1/2”) 3/8”(10mm) Ensure the front casters are unlocked as they can not be accessed without lifting the unit. Assurez-vous que les roulettes avant sont déverrouillées, car la seule façon de les accéder est de soulever l’appareil.
  • Page 21 4 x N570-0026 (#14 x 1/2”) 3/8”(10mm) Two people are required for this step. Deux personnnes son nécessaires pour cette étappe. www.napoleongrills.com...
  • Page 22 2 x N570-0026 (#14 x 1/2”) 3/8”(10mm) Propane Only Propane Seulement disposable grease tray jetable du récipient à graisse www.napoleongrills.com...
  • Page 23 2 x N570-0026 (#14 x 1/2”) 3/8”(10mm) 4 x N570-0038 (1/4-20 X 1/2”) 2 x N105-0015 WARNING! Do not over tighten the screws, as this will cause the handle to crack. AVERTISSEMENT! Ne serrez pas trop les vis, car cela pourrait faire craquer la poignée.
  • Page 24 2 x N570-0026 (#14 x 1/2”) 3/8”(10mm) If necessary the doors can be adjusted by sliding the leveling brackets. Si nécessaire, les portes peuvent être ajustées en glissant les sup- ports de mise à niveau. www.napoleongrills.com...
  • Page 25 4 x N570-0038 (1/4-20 X 1/2”) 3/8”(10mm) 4 x N570-0087 (1/4-20 X 7/8”) WARNING! Do not over tighten the screws, as this will cause the handle to crack. AVERTISSEMENT! Ne serrez pas trop les vis, car cela pourrait faire craquer la poignée.
  • Page 26 450RSIB MODEL 4 x N570-0080 (#14 X1/2”) 1 x N160-0016 Fit orifice into burner tube and secure with hose retainer clip supplied. Placez l’orifice dans le brûleur et fixez à l’aide de l’attache de retenue fournie. WARNING! The Infrared side burner is supplied with a drip pan which holds only a minimal amount of grease.
  • Page 27 450RSIB MODEL 2 x N715-0093 Tabs located on either side of ice bucket must engage notches in side shelf. Les pattes situées de chaque côté du bac à glace doivent s’engager dans les fentes de la tablette latérale. N305-0021 N305-0022 Ensure holes in sear plates are postitoned to the front of the grill.
  • Page 28 Rotisserie Kit Assembly Instruction (included with most rear burner units) Assemble rotisserie kit components as shown. Instructions D’assemblage De L’ensemble De Rôtissoire (inclus avec la plupart des appareils avec brûleur arrière) Assemblez les composantes de la rôtissoire tel qu’illustré. Ensure stop bushing is tightened on the inside of hood casting.
  • Page 29 Propane Only – Proper Hose Connection Propane Seulement - Branchement Adéquat Du Boyau WARNING! Ensure the hose does not contact any high temperature surfaces, or it may melt and leak causing a fire. AVERTISSEMENT! Assurez-vous que le boyau ne touche à aucune surface à haute température sinon il risque de fondre, de provoquer une fuite et causer un feu.
  • Page 30 WARNING – FIRE HAZARD ATTENTION - RISQUE D’INCENDIE WARNING! Do not route hose underneath drip pan. AVERTISSEMENT! Ne pas passer le tuyau d’alimentation sous le tiroir d’égouttement afin de garder. WARNING! Hose must be routed through right side panel only. Do not route hose through left side panel and underneath drip pan.
  • Page 31 Bubbles will indicate a gas leak. Either tighten the loose joint or have the part replaced with one recommended by the Napoleon Customer Care department and have the grill inspected by a certified gas installer. If the leak cannot be stopped, immediately shut off the gas supply, disconnect it, and have the grill inspected by a certified gas installer or dealer.
  • Page 32 Test De Détection De Fuites AVERTISSEMENT! Il doit être fait avant la première utilisation, annuellement et à chaque fois qu’une pièce du système de gaz est remplacée ou réparée AVERTISSEMENT! N’utilisez pas une flamme nue pour vérifier pour des fuites de gaz. Assurez-vous qu’il n’y ait aucune étincelle ni flamme nue à...
  • Page 33 / couvercle pare-chaleur n010-0655 lid handle / poignée du couvercle n385-0191 NAPOLEON logo/ logo NAPOLEON w450-0005 logo spring clips / écrous à ressort pour logo n510-0002 black silicone lid bumper / pare-chocs du couvercle (silicone noir) n080-0253g lid handle cover / couverture poignée du couvercle...
  • Page 34 Parts List / Liste Des Pièces PRO450RB Item Part # Description 450RB n120-0014g side shelf end cap, right / embout en de le tablette latéral, droite n570-0038 1/4-20 x 1/2” screw / vis 1/4-20 x 1/2” n570-0087 1/4-20 x 7/8” screw / vis 1/4-20 x 7/8” n325-0064 shelf handle side / poignée de tablette latéral n325-0063...
  • Page 35 Parts List / Liste Des Pièces PRO450RB Item Part # Description 450RB n010-0217 rear burner orifice assembly / ensemble des orifices brûleur arrière n240-0001 rear burner electrode / électrode du brûleur arrière n240-0016 main burner electrode / électrode du brûleur principal n350-0054 collector box - main burner / boîte du collecteur du brûleur principal n020-0137...
  • Page 36 Parts Diagram / Liste Des Pièces PRO450RB www.napoleongrills.com...
  • Page 37 Parts List / Liste Des Pièces PRO450RSIB Item Part # Description 450RSIB n135-0034g left side lid casting / moulage gauche du couvercle n135-0035g right side lid casting / moulage droite du couvercle n715-0091 trim left side lid casting / gamiture moulage gauche du couvercle...
  • Page 38 Parts List / Liste Des Pièces PRO450RSIB Item Part # Description 450RSIB w450-0005 logo spring clips / écrous à ressort pour logo n385-0185 pro logo / logo pro n120-0014g side shelf end cap, right / embout en de le tablette latéral, droite n570-0038 1/4-20 x 1/2”...
  • Page 39 Parts List / Liste Des Pièces PRO450RSIB Item Part # Description 450RSIB n080-0193g bracket, door adjust / support, ajustement de porte n105-0002 1.5 “ snap bushing / 1.5 “ bague à pression n450-0025 1/4” - 20 nut / écrou 1/4” - 20...
  • Page 40 Parts Diagram / Liste Des Pièces PRO450RSIB www.napoleongrills.com...
