  • Page 1 DJ0468BK TV Table...
  • Page 2 IMPORTANT INFORMATION! please read the entire manual before starting to assemble and/or using this product.follow the manual thoroughly and keep it for further reference. AVOID SCRATCHES! In order to avoid scratching this furnuture should be assembled on a soft layer-could be a rug. IMPROVE EFFICIENCY ! Try to find a partner to install with you, which can speed up...

  • Page 3: Board Identification

    Board Identification...

  • Page 4: Parts List

    PARTS LIST...
  • Page 5 PARTS LIST...

  • Page 6: Table Of Contents

    Please prepare the following tools When installing, please carefully confirm whether each screw corresponds to the manual, accessories with similar shapes can be distinguished by size A x 58 D x 4 B x 58 C x 28 7 x 40 mm 15 x 11 mm 8 x 40 mm E x 4...
  • Page 7 B x 48 - Screw the cam bolt (B) into the panel (2) & (14)&(15)&(18) . (Attention: Cam bolt & Insert nut need to be put together)

  • Page 8: A X 20

    A x 20 C x 4 15 x 11 mm 8 x 40 mm - Attach panel (14)&(15) to(18) and lock with cam(A). - Attach panel (12)&(17) to(14) &(15)&(18)and lock with cam(A) and wood dowels(C).
  • Page 9 A x 18 C x 4 8 x 40 mm 15 x 11 mm - Attach panel (2) to(12)&(14)& (15)&(17)&(18)and lock with cam(A) and wood dowels(C). - Attach panel (16) to(2) and lock with cam(A).

  • Page 10: J X 1

    K x 4 J x 1 25 x 25 x 5 mm 6 x 25 mm - Stick the pads(K) on the foot. - Screw the adjustable foot (J) into the panel (16).

  • Page 11: L X 10

    C x 10 L x 10 A x 10 8 x 40 mm 15 x 11 mm - Attach panel (3)&(4)&(5)&(6) to (2)and lock with cam(A) and wood dowels(C). - Stick the hole (L) to the keyhole.
  • Page 12 - Insert panel (13) into the grooves .

  • Page 13: M X 1

    M x 1 B x 10 7 x 40 mm - Screw the cam bolt (B) into the panel (1). - Stick LED band to of the panel (1) . - Fasten the LED band with buckles . (Attention: Cam bolt & Insert nut need to be put together)
  • Page 14 L x 10 A x 10 C x 10 8 x 40 mm 15 x 11 mm - Attach panel (1) to(3)&(4)& (5)&(6)and lock with cam(A) and wood dowels(C). - Stick the hole (L) to the keyhole.
  • Page 15 H x 16 5 x 17 mm - Insert layer pin (H) into board (3)&(4)&(5)&(6) . - place shelf panel (7)&(8)&(9) in as shown.
  • Page 16 F x 4 E x 4 G x 16 3.5 x 14 mm - Install the feet (E) on (10) with screws (G). - Install the feet (F) on (11) with screws (G).
  • Page 17 G x 32 3.5 x 14mm - Install the panel (10)&(11) on (3)&(4)&(5) with screws (G).
  • Page 18 D x 4 - Install handle (D) to panel (10) & (11) with bolts.
  • Page 19 I x 12 G x 12 3.5 x 14mm - Insert buckle (I) into back slots and fix with screw (G) as shown.
  • Page 20 M x 1...

  • Page 21: Installation Complete

    -LED lamp with effective remote control distance of 5 meters Take out the remote control gasket Align romote controller to the RGB Control box to adjust the color mode - Installation complete.

  • Page 22: Led Controller

    RF Wireless Remote Functions Advanced LED Controller I n s t r u c t i o n s MODE SPEED SPEED DEMO 22 Dynamic Modes Card Type RF Remote BRIGHT COLOR MODE 20 Dynamic Color UltraSlim Design BRIGHT COLOR Very Smooth Effects Dynamic Demo Mode Speed Adjustable...
