Summary of Contents for GAMEMAX GP Series
- Page 1 User Manual / Anwenderleitfaden / Manual Do Usuário / Guide de l’utilisateur / Pуководство пользователя / ユーザー ガイド / 使用説明書 / 使用说明书 CopyRight @ 2025.03...
-
Page 3: Cable Configuration
SAFETY REMINDERS GENERAL SPECIFICATION PACKAGE CONTENTS DC CONNECTORS AND PINOUT For more information and product specifications, visit www.gamemaxpc.com CABLE CONFIGURATION... -
Page 4: Safety Reminders
- Visite o site oficial da GameMax www.gamemaxpc.com para obter detalhes sobre a garantie. política de garantia da sua PSU. - Veuillez visiter le site Web officiel de GameMax www.gamemaxpc.com pour plus de détails sur la politique de garantie de votre bloc d'alimentation. - Page 5 - 保証ステッカーを剥がさないでください。ステッカーが破損または剥がれると保証が無効に - Не снимайте гарантийную наклейку. Повреждение или удаление наклейки аннулирует なります。 вашу гарантию. - 電源の保証ポリシーの詳細については、GameMax の公式 Web サイト www.gamemaxpc.com - Пожалуйста, посетите официальный сайт GameMax www.gamemaxpc.com для получения подробной информации о гарантийной политике вашего блока питания. をご覧ください。 繁體中文 简体中文...
-
Page 6: General Specification
General Specification Allgemeine Spezifikation / Especificações gerais / Spécifications générales / Общие характеристики / 一般仕様 / 一般規格 / 一般规格 Life expectancy (MTBF) at maximum output load 100,000 hours Power factor correction (PFC) Active Voltage Input 110-240V Fan type 14CM Smart Temperature Control Fan Protected against Over power Over voltage... -
Page 7: Dc Output Characteristics
AC INPUT CHARACTERISTICS 110-240VAC, 10-5A, 50-60Hz DC OUTPUT CHARACTERISTICS MODEL +3.3V +12V -12V +5VSB 3.3/5V Max.Power Total Power GP 850B 0.3A 2.5A 850W GP 750B 0.3A 2.5A 750W GP 650B 0.3A 2.5A 650W GP 550B 0.3A 2.5A 550W GP 450B 0.3A 2.5A 450W... -
Page 8: Package Contents
Package Contents Packungsinhalt / Conteúdo da embalagem / Contenu du colis / Кoмплект поставки / パッケージ内容 / 包装内容 / 包裝內容 Power supply / Netzteil / Fonte de energia / Fonte de energia / Источник питания / 電源 / 電源供應器 / 电源 User guide (this booklet) / Benutzerhandbuch (diese Broschüre) / Guia do usuário (este livreto) / Guide d'utilisation (ce livret) / Руководство... - Page 9 DC Connectors and Pinout DC-Anschlüsse und Pinbelegung / Conectores DC e Pinagem / Connecteurs CC et brochage / Разъемы постоянного тока и схема расположеHия BыBодоB / DCコネクタとピン出カ / DC 連接器和引腳排列 / 直流连接器和引脚排列 Turning the I/O Switch Off ATX 24-pin [20+4] Before installing the PSU, unplug the AC Power cord Connect 20+4-pin connector to the motherboard.
- Page 10 ATX12V [4+4] / EPS12V 8-pin [8] PIN 5 PIN 8 Connect ATX12V (CPU power) 4-pin or 8-pin (by 4+4-pin) to the motherboard. PIN 1 PIN 4 Signal Signal +12 VDC +12 VDC +12 VDC +12 VDC Detachable 4PIN 8PIN PCI-E 8-pin [6+2] PIN 1 PIN 4 Connect PCIe 6-pin or 8-pin (by 6+2-pin) to graphics card.
- Page 11 SATA PATA Connect SATA connector to devices, i.e. HDD/SSD/ODD. Connect Molex 4-pin connector to devices, i.e. HDD/ODD/ case fan. PIN 1 PIN 5 PIN 1 PIN 4 SATA PATA Signal Signal +3.3 VDC +12 VDC Case Fan +5 VDC +5 VDC +12 VDC...
- Page 12 GP 850B / GP 750B CABLE CONFIGURATION MAIN- 24(20+4)Pin(Pro) BOARD 500±20mm 24(20+4)Pin 650±20mm Mainboard Connector 12V 8(4+4)Pin 500±20mm PCIE PCI-E 8(6+2)Pin 150±10mm SATA Connector PCI-E 8(6+2)Pin 500±20mm PCIE PCI-E 8(6+2)Pin 8(4+4)Pin CPU Connector 150±10mm PCI-E 8(6+2)Pin 4Pin Peripheral PATA PATA PATA Connector 400±20mm...
- Page 13 GP 650B CABLE CONFIGURATION MAIN- 24(20+4)Pin(Pro) BOARD 500±20mm 24(20+4)Pin Mainboard Connector 650±20mm 12V 8(4+4)Pin 500±20mm SATA PCIE PCI-E 8(6+2)Pin Connector 500±20mm 8(4+4)Pin PCIE PCI-E 8(6+2)Pin CPU Connector PATA PATA PATA 4Pin Peripheral 400±20mm 150mm 150mm Connector SATA SATA SATA 400±20mm 150mm 8(6+2)Pin PCI-E Connector...
- Page 14 GP 550B CABLE CONFIGURATION MAIN- 24(20+4)Pin(Pro) BOARD 500±20mm 24(20+4)Pin Mainboard Connector 650±20mm 12V 8(4+4)Pin 500±20mm SATA PCIE PCI-E 8(6+2)Pin Connector 150±10mm PCI-E 8(6+2)Pin 8(4+4)Pin CPU Connector PATA PATA PATA 400±20mm 150mm 150mm 4Pin Peripheral Connector SATA SATA SATA 400±20mm 150mm 8(6+2)Pin PCI-E Connector SATA...
- Page 15 GP 450B CABLE CONFIGURATION MAIN- 24(20+4)Pin(Pro) BOARD 500±20mm 24(20+4)Pin Mainboard Connector 650±20mm 12V 8(4+4)Pin SATA Connector 500±20mm PCIE PCI-E 8(6+2)Pin 8(4+4)Pin CPU Connector SATA PATA PATA SATA/IDE 4Pin Peripheral 400±20mm 150mm 150mm Connector SATA SATA SATA SATA 8(6+2)Pin 400±20mm 150mm 150mm PCI-E Connector...
- Page 16 © 2025 GAMEMAX. All rights reserved. All trademarks are the property of their respective owners.
