Summary of Contents for GAMEMAX GX PRO Series
- Page 1 User Manual / Anwenderleitfaden / Manual Do Usuário / Guide de l’utilisateur / Pуководство пользователя / ユーザー ガイド / 使用説明書 / 使用说明书 CopyRight @ 2025.02...
-
Page 3: Table Of Contents
SAFETY REMINDERS GENERAL SPECIFICATION PACKAGE CONTENTS DC CONNECTORS AND PINOUT For more information and product specifications, visit www.gamemaxpc.com MODULAR CABLE CONFIGURATION... -
Page 4: Safety Reminders
- Visite o site oficial da GameMax www.gamemaxpc.com para obter detalhes sobre a garantie. política de garantia da sua PSU. - Veuillez visiter le site Web officiel de GameMax www.gamemaxpc.com pour plus de détails sur la politique de garantie de votre bloc d'alimentation. - Page 5 - 保証ステッカーを剥がさないでください。ステッカーが破損または剥がれると保証が無効に - Не снимайте гарантийную наклейку. Повреждение или удаление наклейки аннулирует なります。 вашу гарантию. - 電源の保証ポリシーの詳細については、GameMax の公式 Web サイト www.gamemaxpc.com - Пожалуйста, посетите официальный сайт GameMax www.gamemaxpc.com для получения подробной информации о гарантийной политике вашего блока питания. をご覧ください。 繁體中文 简体中文...
-
Page 6: General Specification
General Specification Allgemeine Spezifikation / Especificações gerais / Spécifications générales / Общие характеристики / 一般仕様 / 一般規格 / 一般规格 Life expectancy (MTBF) at maximum output load 100 000 hours Power factor correction (PFC) Active Voltage Input 110-240V Fan type 13.5CM FDB Fan with Turbo Axial Flow and Intelligent Temp Control Protected against Over power... - Page 7 AC INPUT CHARACTERISTICS 110-240VAC, 15-8A, 50-60Hz 110-240VAC, 10-5A, 50-60Hz GX PRO 1250G / GX PRO 1050G / GX PRO 850G GX PRO 750G DC OUTPUT CHARACTERISTICS MODEL +3.3V +12V -12V +5VSB 3.3/5V Max.Power Total Power GX PRO 1250G 104A 0.3A 2.5A 1250W GX PRO 1050G...
-
Page 8: Package Contents
Package Contents Packungsinhalt / Conteúdo da embalagem / Contenu du colis / Кoмплект поставки / パッケージ内容 / 包装内容 / 包裝內容 Power supply / Netzteil / Fonte de energia / Fonte de energia / Источник питания / 電源 / 電源供應器 / 电源 Modular cable kit in storage bag / Modulares Kabelset in Aufbewahrungstasche / Kit de cabo modular em bolsa de armazenamento / Kit de câbles modulaire dans un sac de rangement... -
Page 9: Dc Connectors And Pinout
DC Connectors and Pinout DC-Anschlüsse und Pinbelegung / Conectores DC e Pinagem / Connecteurs CC et brochage / Разъемы постоянного тока и схема расположеHия BыBодоB / DCコネクタとピン出カ / DC 連接器和引腳排列 / 直流连接器和引脚排列 ATX 24-pin [20+4] ATX12V [4+4] / EPS12V 8-pin [8] Connect 20+4-pin connector to the motherboard Connect ATX12V (CPU power) 4-pin or 8-pin (by 4+4-pin) to the motherboard. - Page 10 PCI-E 8-pin [6+2] Signal Signal PIN 1 PIN 4 Connect PCIe 6-pin or 8-pin (by 6+2-pin) to graphics card. +12 VDC +12 VDC Note: Do not connect the PCIe 6+2-pin connector to the ATX12V 8-pin PIN 5 PIN 8 +12 VDC connector.
- Page 11 SATA PATA Connect SATA connector to devices, i.e. HDD/SSD/ODD. Connect Molex 4-pin connector to devices, i.e. HDD/ODD/ case fan. PIN 1 PIN 5 PIN 1 PIN 4 SATA PATA Signal Signal +3.3 VDC +12 VDC Case Fan +5 VDC +5 VDC +12 VDC...
-
Page 12: Modular Cable Configuration
Warning: This PSU is modular version, to be use original GameMax modular cables, Avoid incompatibility and damage devices of PC system! Warnung: Diese PSU ist eine modulare Version, um Original -modulare Gamemax -Kabel zu verwenden, Inkompatibilität zu vermeiden Deutsch und Schäden Sie Geräte des PC-Systems! Português... - Page 13 GX PRO 1250G / GX PRO 1050G CABLE OVERVVIEW 24(20+4)Pin 8(4+4)Pin 8(6+2)Pin 16(12+4)Pin SATA 4Pin Peripheral Mainboard Connector CPU Connector PCI-E Connector 12V-2x6 Connector Connector Connector Connector 550±10mm MAIN- PCIE 24(20+4)Pin(Pro) PCI-E 8(6+2)Pin BOARD 75±10mm 650±10mm PCI-E 8(6+2)Pin 12V-2x6 PCIE5.1 SATA SATA 650±10mm...
- Page 14 GX PRO 850G / GX PRO 750G CABLE OVERVVIEW 24(20+4)Pin 8(4+4)Pin 8(6+2)Pin 16(12+4)Pin SATA 4Pin Peripheral Mainboard Connector CPU Connector PCI-E Connector 12V-2x6 Connector Connector Connector 550±10mm PCIE MAIN- PCI-E 8(6+2)Pin 24(20+4)Pin(Pro) BOARD 75±10mm 650±10mm PCI-E 8(6+2)Pin 12V-2x6 PCIE5.1 SATA SATA SATA 650±10mm...
- Page 16 © 2025 GAMEMAX. All rights reserved. All trademarks are the property of their respective owners.
