GAMEMAX GM 800B User Manual

80 plus bronze full modular power supply

Advertisement

User Manual / Anwenderleitfaden /
Manual Do Usuário / Guide de l'utilisateur /
Pуководство пользователя /
ユーザー ガイド / 使用説明書 / 使用说明书
CopyRight @ 2025.03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GM 800B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GAMEMAX GM 800B

  • Page 1 User Manual / Anwenderleitfaden / Manual Do Usuário / Guide de l’utilisateur / Pуководство пользователя / ユーザー ガイド / 使用説明書 / 使用说明书 CopyRight @ 2025.03...
  • Page 3: Table Of Contents

    SAFETY REMINDERS GENERAL SPECIFICATION PACKAGE CONTENTS DC CONNECTORS AND PINOUT For more information and product specifications, visit www.gamemaxpc.com MODULAR CABLE CONFIGURATION...
  • Page 4: Safety Reminders

    - Visite o site oficial da GameMax www.gamemaxpc.com para obter detalhes sobre a garantie. política de garantia da sua PSU. - Veuillez visiter le site Web officiel de GameMax www.gamemaxpc.com pour plus de détails sur la politique de garantie de votre bloc d'alimentation.
  • Page 5 - 保証ステッカーを剥がさないでください。ステッカーが破損または剥がれると保証が無効に - Не снимайте гарантийную наклейку. Повреждение или удаление наклейки аннулирует   なります。 вашу гарантию. - 電源の保証ポリシーの詳細については、GameMax の公式 Web サイト www.gamemaxpc.com - Пожалуйста, посетите официальный сайт GameMax www.gamemaxpc.com для получения подробной информации о гарантийной политике вашего блока питания.    をご覧ください。 繁體中文 简体中文...
  • Page 6: General Specification

    General Specification Allgemeine Spezifikation / Especificações gerais / Spécifications générales / Общие характеристики / 一般仕様 / 一般規格 / 一般规格 Life expectancy (MTBF) at maximum output load 100,000 hours Power factor correction (PFC) Active Voltage Input 110-240V Fan type 14CM Smart Temperature Control Fan Protected against Over power Over voltage...
  • Page 7 AC INPUT CHARACTERISTICS 110-240VAC, 10-5A, 50-60Hz DC OUTPUT CHARACTERISTICS MODEL +3.3V +12V -12V +5VSB 3.3/5V Max.Power Total Power GM 800B 0.3A 2.5A 800W GM 700B 0.3A 2.5A 700W GM 600B 0.3A 2.5A 600W 86mm 160mm 86mm...
  • Page 8: Package Contents

    Package Contents Packungsinhalt / Conteúdo da embalagem / Contenu du colis / Кoмплект поставки / パッケージ内容 / 包装内容 / 包裝內容 Power supply / Netzteil / Fonte de energia / Fonte de energia / Источник питания / 電源 / 電源供應器 / 电源 Modular cables / Modulare Kabel / Cabos modulares / Câbles modulaires / Модульные...
  • Page 9: Dc Connectors And Pinout

    DC Connectors and Pinout DC-Anschlüsse und Pinbelegung / Conectores DC e Pinagem / Connecteurs CC et brochage / Разъемы постоянного тока и схема расположеHия BыBодоB / DCコネクタとピン出カ / DC 連接器和引腳排列 / 直流连接器和引脚排列 Turning the I/O Switch Off ATX 24-pin [20+4] Before installing the PSU, unplug the AC Power cord Connect 20+4-pin connector to the motherboard.
  • Page 10 ATX12V [4+4] / EPS12V 8-pin [8] PIN 5 PIN 8 Connect ATX12V (CPU power) 4-pin or 8-pin (by 4+4-pin) to the motherboard. PIN 1 PIN 4 Signal Signal +12 VDC +12 VDC +12 VDC +12 VDC Detachable 4PIN 8PIN PCI-E 8-pin [6+2] PIN 1 PIN 4 Connect PCIe 6-pin or 8-pin (by 6+2-pin) to graphics card.
  • Page 11 SATA PATA Connect SATA connector to devices, i.e. HDD/SSD/ODD. Connect Molex 4-pin connector to devices, i.e. HDD/ODD/ case fan. PIN 1 PIN 5 PIN 1 PIN 4 SATA PATA Signal Signal +3.3 VDC +12 VDC Case Fan +5 VDC +5 VDC +12 VDC...
  • Page 12: Modular Cable Configuration

    Warning: This PSU is modular version, to be use original GameMax modular cables, Avoid incompatibility and damage devices of PC system! Warnung: Diese PSU ist eine modulare Version, um Original -modulare Gamemax -Kabel zu verwenden, Inkompatibilität zu vermeiden Deutsch und Schäden Sie Geräte des PC-Systems! Português...
  • Page 13 GM 800B / GM 700B CABLE OVERVVIEW MAIN- 24(20+4)Pin(Pro) BOARD 550±20mm 24(20+4)Pin 650±20mm Mainboard Connector 12V 8(4+4)Pin 150±10mm 12V 8(4+4)Pin SATA PCIE 500±20mm Connector PCI-E 8(6+2)Pin 150±10mm 8(4+4)Pin PCI-E 8(6+2)Pin CPU Connector PCIE 500±20mm PCI-E 8(6+2)Pin 4Pin Peripheral 150±10mm Connector...
  • Page 14 GM 600B CABLE OVERVVIEW MAIN- 24(20+4)Pin(Pro) BOARD 24(20+4)Pin 550±20mm Mainboard Connector 650±20mm 12V 8(4+4)Pin SATA Connector PCIE 500±20mm PCI-E 8(6+2)Pin 150±10mm 8(4+4)Pin CPU Connector PCI-E 8(6+2)Pin 4Pin Peripheral SATA SATA PATA Connector 450±20mm 150mm 150mm SATA PATA 8(6+2)Pin PCI-E Connector 350±20mm 150mm...
