M e dSyst e m I I I
Pu m p M ode l 2 8 6 5 
With Advanced Dose Rate Calculation and Drug List Editor
User Manual
Novem ber 2012
Mat erial Num ber: 12275767
®
I n fu sion

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MedSystem III and is the answer not in the manual?

Questions and answers

Related Manuals for CareFusion MedSystem III

Summary of Contents for CareFusion MedSystem III

  • Page 1 M e dSyst e m I I I ® I n fu sion Pu m p M ode l 2 8 6 5  With Advanced Dose Rate Calculation and Drug List Editor User Manual Novem ber 2012 Mat erial Num ber: 12275767...
  • Page 2 CareFusion Corporation or one of its subsidiaries. The information in this document is subject to change and does not represent a commitment on the part of CareFusion to provide additional services or All other trademarks are the property of their respective enhancements.

  • Page 3: Table Of Contents

    Contents Chapter 1—Introduction About the MedSystem III® Infusion Pump ............1 Contraindications....................3 Features ........................3 Multi-channel Fluid Delivery System ............3 Lightweight/portable..................3 Unique, rotating pole clamp ................3 Dose Rate Calculator (DRC) ................4 Drug List Editor (DLE) .................. 4 Six Device Types available ................
  • Page 4 Chapter 4—Maintenance Specifications ....................... 61 AC Adapter Model 1565C ................... 63 Check-In ....................... 64 Physical Inspection..................64 Functional Test ..................... 64 Check-In Tests....................65 Electrical Safety Test..................65 Power Tests ....................66 MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 5 Effects of Negative Solution Container Heights........ 82 Pressure Mode ....................82 Electromagnetic Environment................84 FCC Notice....................84 Canadian Notice (Avis Canadien) ..............84 EMC Tables......................85 Standards ......................90 Glossary ................91 MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 6 Contents - Notes - MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 7: Chapter 1-Introduction

    The MedSystem III is intended for facilities that utilize infusion pumps for the delivery of fluids, medications, blood and blood products using continuous or intermittent delivery through clinically acceptable routes of administration;...
  • Page 8 • Dose Rate Calculator (DRC) feature performs volumetric rate and/or dose rate calculations. • With DRC activated, the MedSystem III displays infusion status for rate, dosing regimen and drug name. • Communications Protocol allows clinical monitoring, MedSystem III configuration and maintenance.

  • Page 9: Contraindications

    None known. Features Multi-channel Fluid Delivery System Combines three independent infusion channels in an unparalleled small size. Lightweight/portable The MedSystem III with pole clamp weighs just over 5 pounds (2.3kg) and is easy to transport. MORE START STANDARD ON / OFF...

  • Page 10: Dose Rate Calculator (Drc)

    Operating Room II Free-flow Protection Administration Sets contain a cassette that provides protection from free-flow conditions. Upon removal of the cassette from the MedSystem III, the cassette’s slide clamp is pulled to full extension, occluding the tubing and preventing fluid from flowing.

  • Page 11: Monitoring System

    Features Monitoring System The monitoring system can continuously monitor the MedSystem III conditions and alerts with adjustable audio tones and visual messages. Field Maintenance Software (FMS) Can be modified to accommodate specialized clinical applications. The Device Type parameters, occlusion limit, and air-in-line threshold can be configured with the FMS software.

  • Page 12: System Components

    Piston Slide Clamp Tubing Collar — Channel Indicators Lights Green • Steady-AC power • Flashing- battery power — Channel Indicators Lights • Slow flashing - Advisory • Rapid Flashing - Alert MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 13: Lower Assembly

    Rotating Latch Adjustable Pole Clamp External Power—external power receptacle connects with the power cord. Plug Symbol—green light on indicates AC power is connected; batteries are charging. COMM—communications line receptacle connects with RS-232. MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 14: Pole Clamp

    Adjustable Pole Clamp—jaw with clutch feature, mounts pump to a pole or bedside. NOTE The MedSystem III is designed to function in any orientation. However, the effectiveness of the administration set air trap is diminished when the MedSystem III is not in the vertical position.

  • Page 15: Symbols

    Single-Use. Do not reuse. Single-Us DEHP in fluid pathway. DEHP No DEHP in fluid pathway. Product is latex-free. LATEX Product incorporates SmartSite Needle-Free Valve ports and should not be accessed by a needle. MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 16 Introduction Approximate administration set, priming volume. XX ml Drops per milliliter specification for product will be identified on drop symbol. Expiration date for product will be identified near hour glass symbol. MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 17: Chapter 2-Getting Started

    Getting Started NOTE Although the MedSystem III is built and tested to exacting specifications, it is not intended to replace the supervision of IV infusions by medical personnel. The user should become thoroughly familiar with the features and operation of the MedSystem III and exercise vigilance in its use.
  • Page 18 — Chapter 2 Getting Started WARNING The use of any accessory, transducer, or cable with the MedSystem III other than those specified may result in increased emissions or decreased immunity or electromagnetic compatibility performance of the MedSystem III. WARNING Only connect equipment approved to IEC EN 60601-1 or UL 1069 approved medical or hospital signaling equipment.
  • Page 19 WARNING Use only MedSystem III administration sets. MS III administration sets are dedicated for use with the MedSystem III infusion pump. The use of any other administration set may cause improper MedSystem III operation, resulting in an inaccurate fluid delivery or other potential hazard.
  • Page 20 Parallel Infusions There are no contraindications regarding the use of a MedSystem III with any other positive displacement infusion device when ported together into a common IV site location.
  • Page 21 • A list of approved IV sets recommended by CareFusion, for use with the MedSystem III is listed on the Set Compatibility Card. The use of any other set may cause improper MedSystem III operation, resulting in inaccurate fluid delivery.
  • Page 22 Operating Environment Do not use the MedSystem III in the presence of flammable anesthetics. MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 23 Instruments should not be used adjacent to or stacked with other equipment, if adjacent or stacked use is necessary, instrument should be observed to verify normal operation in the configuration used. MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 24: Prepare For Infusion

    20cc to 60cc such as the B-D and Monoject brands can be used. To prepare infusion 1. Connect the container to the IV set. 2. Prime the MedSystem III administration set in accordance with the Administration Set User Manual. Pressure Dome...

  • Page 25: Load The Set

    3. With the tubing down, use a 45-degree upward motion to insert the cassette into the channel. 4. Push on the clear portion of cassette until completely seated. 5. Push in slide clamp flush with entire cassette. MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 26 Chapter 2 Getting Started 6. Pull down gently on tubing collar. Press with thumb to seat tubing collar in recess beneath cassette. NOTE Three beeps sound when the set is properly loaded. MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 27: Front Panel Overview

    Cntrst—(Contrast) Brightens or dims the display. • GP—Indicates the full name of the selected Device Type on the prompt line when selected. NOTE Additional softkey prompts are displayed by pressing the MORE OPTIONS key. MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 28: Programming Page

    Select—moves the highlight bar through programmable infusion parameters. ↑—increases highlighted value. • ↓—decreases highlighted value. • ↑ Fast • —increases highlighted value at greater increments. ↓ Fast • —decreases highlighted value at greater increments. MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 29: The Programming Page

    To turn the pump on 1. From the front panel, press ON/OFF The MedSystem III performs an automatic self test on start up. 2. Listen for a beep to ensure that the audio alarm transducer functions properly. The information page appears momentarily.

  • Page 30: Select Channel And Display

    ALARM is displayed in the affected channel status line. An alarm condition is displayed on the Standard Display of the affected channel. MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 31: Access Alarm Information

    Press ↑, ↓, Fast ↑ or Fast ↓ to change the rate. The Primary Rate value flashes. 3. Press to confirm. Enter Once the Primary Rate is confirmed, the Volume Remaining (VR) value appears highlighted. MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 32 3. Open the regulating clamp on administration set. 4. Press START to begin infusion. STOP The channel starts infusing. The current date and time are displayed. The green infusion light on channel key remains illuminated. MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 33 Enter The infusion continues with the volume infused reset to zero. The current date and time are displayed. 5. Press to recall the previous VI value, date and time. Recall MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 34: Making Changes While Infusing

    When a channel is Stopped for two minutes with a cassette in place, a Channel Not In Use advisory alert sounds. When a channel is on Standby, the advisory does not sound. 1. Press appropriate channel 2. Press to stop the infusion. START STOP MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 35: Programming Options

    Select 6. Press ↑ or ↓ to select The ↑ and ↓ symbols are not displayed if the pump is infusing. 7. Press to enable programming option. Enter 8. Press channel MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 36: Kvo Status

    The green light on channel key remains on. • The red light on channel key flashes. • A two toned advisory alert sounds. Infusion Complete VR = Alarm Info: Press A Cntrst QUIET MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 37 Enter 4. Press START to resume infusion and stop KVO rate. STOP NOTE If the current infusion rate is set below KVO rate, the channel infuses at the lower rate. MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 38: Secondary Mode

    3. Suspend Secondary solution container at least 8 inches (20 cm) above primary solution container. 8” (20 cm) ON / OFF STANDARD MORE START OPTIONS STOP DISPLAY 4. Press to select channel. MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 39 Clear The date and time are cleared. The Clear softkey toggles to Recall. to confirm, Enter - or-  Press to recall the previous VI value, date and time. Recall MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 40 5. Return to the Standard Display and select a channel. The display reads Setup: Select VR and Rate. 6. Select Set: Select VR and Rate. 7. Press to set a time. Accept MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 41 Press Select to choose line Select Fast 4. Press to highlight value(s) to change. Select 5. Press ↑, ↓, Fast ↑ or Fast ↓ to change value(s). 6. Press to confirm. Enter MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 42 (drug amount and diluent volume) and dosing parameters. If a dose is entered, the volumetric rate is calculated. If a volumetric rate is entered, the dose is calculated. MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 43 2. Press Enter when desired drug name is highlighted. The weight (Wt.) value is highlighted. To program weight 1. Enter the patient’s weight in kilograms using the ↑, ↓, Fast ↑ and Fast ↓ softkeys. MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 44 When rate is changed, dose value is automatically calculated. The VR selection appears in highlight. To change the Volume Remaining 1. Change the VR value using the ↑, ↓, Fast ↑ or Fast ↓ softkeys. MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 45 Enter The new rate begins infusing immediately. 5. Press STANDARD DISPLAY NOTE The display reverts to Standard Display page after one minute. 6. Verify the settings. MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 46: Dose Rate Calculator Programming With Drug

    1. From the Dose Rate Calculator Programming page, select the patient’s weight in kilogram using the ↑, ↓, Fast ↑ and Fast ↓ softkeys. 2. Press when desired weight is displayed. Enter The Conc. value appears in highlight. MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 47 2. Press when the desired rate is displayed. Enter The dose is automatically calculated when the rate is changed. The VR value appears in highlight. To change the Volumetric Remaining MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 48: Facts About Dose Rate Calculator

    Drug name, patient weight, or drug concentration cannot be changed while infusing. Changes to patient weight or concentration recalculates the volumetric rate but maintains the dose rate. • Drug names may be abbreviated if the name contains more than eight letters. MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 49: Device

    • The Secondary option cannot be used when the Dose Rate Calculator is enabled. • If the MedSystem III is off for more than five minutes, the Dose Rate Calculator mode reverts to the primary mode. Device NOTE The Device Type programming selection affects all three channels. It is not possible to independently program different Device Types for a channel.
  • Page 50 The currently selected Device Type appears with an asterisk and is highlighted. Infusing ml/h VR: 450 VI: 50 Stop affects channel A TotVol Device Config Note 4. Press to move the highlight through the list. Select MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 51 Alarm Info: Press channel A CANCEL QUIET The pump will alarm, infusion will stop on affected channel(s), and the display reverts to Standard Display with Alarm indicated for affected channel. 8. Press affected channel MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 52 VR Setting Pump Not in Advisory All Setting Option Option for VR *The channel infuses at the KVO rate shown in the table or at the current infusion rate, whichever is lower. MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 53: Config (Configuration)

    Allows the pump to be set with a 12 or 24 hour am/pm clock. The factory default is am/pm Hours/Minutes 0000–2359 1–31 Each item can be adjusted when highlighted. Month Jan–Dec Years 00-99 MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 54: Note Softkey

    The BatLog softkey accesses the Battery History Log page. This page is provided for the Biomedical Engineering staff to review and record battery history data. To access the Battery History Log 1. Press STANDARD DISPLAY MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 55 The Battery History page is displayed. 4. Press to exit Battery History page. ON/OFF If you do not press ON/OFF the display reverts to the Standard Display page after 1 minute. MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 56 — Chapter 2 Getting Started MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 57: Chapter 3-Alarms, Advisories, And Prompts

    4. Press START to resume infusion. STOP The channel starts infusing. 5. Press STANDARD DISPLAY NOTE The display reverts to the Standard Display page after one minute. 6. Verify the settings. MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 58: Alarm Response Keys

    Resets resumable fault conditions. Used when attempting to RETRY reestablish normal operation of a channel. Disables use of affected channel. Once pressed, servicing of SERVICE instrument is required before channel can be used. MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 59: Advisories

    Channel Not Two minutes have elapsed since Press STNDBY to place channel in Use cassette was installed or infusion on Standby, was stopped. START Press to start infusion, STOP Remove the cassette. MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 60: Alarms

    Setup the pump at or slightly below the IV site to minimize the formation of micro bubbles. If no significant air is present, START press to resume the STOP infusion MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 61 If the condition continues, try the cassette in a different channel. Replace the administration set if an alarm recurs. Clean the lower assembly according to the cleaning instruction described in the Maintenance section of this document. MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 62 (with unvented container), kinked tubing, empty syringe, or any restriction to flow. Clear the occlusion. Press START to resume infusion. STOP Verify that the fluid is flowing in the drip chamber. MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 63 Pumping Latch Jaw Correct Correct Corrective Action Rate/Vol Rates and/or volumes are Re-enter settings as required. Settings incompatible with the newly Cleared selected Device Type. START Press to resume infusion. STOP MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 64: Fault

    Press to resume each STOP channel that had been infusing. If the Watchdog alarm recurs or the MedSystem III cannot be turned on, replace the pump and notify qualified service personnel. MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 65: Other Conditions

    Press the Cntrst softkey to change the screen contrast. Instrument Shut Off: Low Power. Connect the AC adapter cord to the MedSystem III and plug it into the wall outlet. Instrument shut down after a Battery Depleted alarm had not next to external power been corrected.
  • Page 66 — Chapter 3 Alarms, Advisories, and Prompts - Notes - MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 67: Chapter 4-Maintenance

    (<95°F or 35°C for optimum battery life) Rate Range 0.1 - 999 milliliter per hour (each channel) Volume Range 0.1 - 9999 milliliter (each channel) KVO Rate Range 0.1 - 20.0 milliliter per hour MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 68 0.1 - 0.9 ml/hr. ±10% with a standard deviation of 1.96. Administration Sets Use only MedSystem III Administration Sets. Power Consumption 6 watts AC power. Use only Instrument AC Adapter, Model 1555, 1565, 1560A ordered as part number 2861089.

  • Page 69: Ac Adapter Model 1565C

    Model 1565C is compatible with all previously released MedSystem III Infusion Pumps. The AC adapter Model: 1565C 7.5VDC @ 1.7A includes a 10-foot cord. A ground continuity test is excluded with Model 1565C.The certification to the...

  • Page 70: Check-In

    Report any shipping damage to Customer Service. Check to insure that all accessories are included in the package. Check for any physical damage to the MedSystem III or accessories. If any is found report it to Customer Service.

  • Page 71: Check-In Tests

    1. Refer to the operation manual for the electrical safety tester for the proper setup and measurement technique. 2. Connect the AC adapter to the MedSystem III infusion pump. 3. Plug the AC adapter into the electrical safety tester. 4. Measure the ground continuity and leakage current. Any point of an instrument with an aluminum chassis can be used for testing.

  • Page 72: Power Tests

    Leakage current not to exceed 100µA. • Power Tests Charge the MedSystem III for at least one hour prior to performing a power test. To perform a Power Up test 1. Disconnect the AC adapter from the pump. 2. Remove any cassettes installed in the pump.
  • Page 73 8. Verify that the green LEDs for each channel key steadily illuminated. If they are flashing, the MedSystem III is not recognizing that AC power is connected. To perform the cassette and sensor test The cassette and sensor test is used to verify the proper functioning of the cassette and latch sensors, as well as the latching mechanisms.
  • Page 74 Instrument and the patient. Repeat the following steps for each of the three channels, A, B, and C. 1. Configure the MedSystem III in the Controller Pressure Device Type. 2. Prime a set, which contains no filters or check valves, and has macrobore tubing on the patient side.

  • Page 75: New Instrument Volume Accuracy Test

    7. Slowly raise the tubing outlet to 3' 8" (96.52 cm) above the cassette. The CUT should sound an alarm within 10 seconds. 8. After completing steps 1-7 for all three channels configure the MedSystem III in the General Purpose Device Type.
  • Page 76 10. Press the ↑ arrow soft key to toggle setting to Select VR and Time. 11. Press to accept setting. ENTER 12. Press to highlight Pri VolRem (VR). SELECT 13. Press the ↑ arrow soft key until the (VR) is set to 18 ml. MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 77 1. From the Standard Display, press two times. OPTIONS A softkey labeled Demo WD appears. 2. Press the Demo WD soft key and follow the directions on the screen for completing the watchdog test. MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 78: Cleaning

    Take special care to observe any cracks or punctures in the pump’s outer surface that may allow fluid to enter. Cleaning Solutions You can use any of the following cleaning solutions to clean the MedSystem III. • Use solutions of non-abrasive, non-staining detergent (such as, commercially available, alcohol-free, dish washing liquid) well diluted with warm water.
  • Page 79 Check-In To clean the MedSystem III’s lower housing, slide link and latch 1. Wipe the pump’s exterior using a cloth dampened with cleaning solution. 2. Remove the lower housing to access the lower assembly by pressing all four black release tabs simultaneously while pulling straight down.
  • Page 80 Water may be sprayed on the cleaned surfaces to rinse areas that are difficult to reach with a swab. Slide Link Assembly Pump Latch 6. Dry with a lint-free swab or cloth, or allow to air dry. MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 81 Air Sensor NOTE Defective air-in-line sensor modules must be replaced before using MedSystem III. 2. Place the pump in the upright position. 3. Clean the tubing recess, using a downward motion, with a lint-free swab dampened with the appropriate cleaning solution, as specified in Cleaning Solutions on page 72.
  • Page 82 Damage or breakage of the valve actuator tips could cause an uncontrolled flow condition. CAUTION Do not use isopropyl alcohol to clean the valve actuators. 1. Place the pump in the upright position. MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 83 Lightly push the valve actuators tips from side to side with a dry lint- free swab. If a valve actuator tip is not rigid, it is broken and must be replaced before using the pump. MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 84: Inspection Requirements

    MedSystem III and ensuring the current hospital configurations and/or Drug List. If a MedSystem III shows evidence of damage in transit, notify the carrier’s agent immediately. Do not return damaged equipment to the factory before the carrier’s agent has authorized repairs.

  • Page 85: Technical Support

    Inspection Requirements If the MedSystem III fails to respond as described in this document and the cause cannot be determined, do not use the pump. Contact qualified CareFusion service personnel. If it is necessary to return the pump for service, obtain a return authorization number prior to shipment.

  • Page 86: Warranty

    CareFusion, and CareFusion does not give or grant, directly or indirectly, the authority to any representative or other person to assume on behalf of CareFusion any other liability in connection with the sale or use of Alaris System products.

  • Page 87: Trumpet And Start-Up Curves

    Appendix A Trumpet and Start-Up Curves In the MedSystem III, as with all infusion systems, the action of the pumping mechanism and variations in individual administration sets cause short-term fluctuations in rate accuracy. The following curves show typical performance of the system in two ways: •...

  • Page 88: Flow Characteristics Under Varying Delivery Conditions

    Effects of Negative Solution Container Heights With a negative head height of -0.5 meters, the MedSystem III typically exhibits a long term accuracy offset of approximately -0.4%. Resulting Trumpet observation points typically track that of accuracy. Therefore, no significant change in short term variations result under back pressure conditions.
  • Page 89 Mi n . Rate Error Overall Rate Error Mi n . Rate Error Overall Rate Error Max Rate Error Max Rate Error Observation Time Observation Time Observation Time (minutes) Observation Time (minutes) MedSystem III ® Infusion Pump Model 2865 User Manual...

  • Page 90: Electromagnetic Environment

    The authority to operate this equipment is conditioned by the requirement that no modifications will be made to the equipment unless the changes or modifications are expressly approved by CareFusion. Canadian Notice (Avis Canadien) This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.

  • Page 91: Emc Tables

    Guidance and Manufacturer’s Declaration - Electromagnetic Emissions The MedSystem III is intended for use in the electromagnetic environment specified below. Customer or user of MedSystem III should assure that it is used in such an environment. Electromagnetic Environment - Emissions Test...
  • Page 92 Table 2 Guidance and Manufacturer’s Declaration—Electromagnetic Immunity The MedSystem III is intended for use in the electromagnetic environment specified below. Customer or user of MedSystem III should assure that it is used in such an environment. IEC 60601-1-2 Compliance Electromagnetic...
  • Page 93 Guidance and Manufacturer’s Declaration—Electromagnetic Immunity Life Support Equipment The MedSystem III is intended for use in the electromagnetic environment specified below. Customer or user of MedSystem III should assure that it is used in such an environment. IEC 60601-1-2 Compliance...
  • Page 94 RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the MedSystem III is used exceeds the applicable RF compliance level above, the MedSystem III should be observed to verify normal operation.
  • Page 95 RF communications equipment and the MedSystem III The MedSystem III is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. Customer or user of the MedSystem III can help prevent electromagnetic interference by...

  • Page 96: Standards

    Appendix A Standards Standards The MedSystem III Infusion System has been assessed and complies with the following standards: IEC EN 60601-1, including amendments A1 and A2;IEC EN 60601-2-24; CISPR 11, Group 1, Class B Emissions; IEC EN 60601-1-2; UL 60601-1, CAN/CSA No.

  • Page 97: Glossary

    Glossary 1° Pri Primary infusion 2° Sec Secondary infusion AAMI American Association of Medical Instrumentation acrylonitrile-butadiene-styrene alternating current (electrical power) BatLog Battery History Log Calc Calculator MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 98 ClrAir Clear Air centimeter Cntrst Contrast COMM Communications Port Conc Concentration Config Configuration Controller Pressure Canadian Standards Association DemoWD Demonstrate Watchdog Dose Infused Electrocardiogram Electrostatic Field Maintenance Software gram General Purpose MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 99 JCAHO Joint Commission on the Accreditation of Health Care Organizations 1,000 for numbers 10,000 or greater KG; kg kilogram keep vein open LB;lb pound microgram milliequivalent milligram min; mn minute MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 100 µl microliter not applicable Neontl Neonatal NextPg Next Page Nanogram NiCd nickel-cadmium Operating Room OR II Operating Room II Primary pounds per square inch Secondary Stnd Disp Standard Display STNDBY Standby MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 101 TotVol Total Volume time remaining Underwriters Laboratories, Inc. unit Volts volume infused volume VolRem volume remaining volume remaining weight MedSystem III ® Infusion Pump Model 2865 User Manual...
  • Page 102 - Notes - MedSystem III ® Infusion Pump Model 2865 User Manual...
