Prince Castle Merlin II 741 Series Operating Instructions Manual

OPERATING
INSTRUCTIONS
Slow Cook/Hold Timers
Model No. 741-Series
Horizontal
Pictured Model 741-T88H
Model Description
741-T44H Horizontal Four Channel
741-T66H Horizontal Six Channel
741-T88H Horizontal Eight Channel
ELECTRICAL
741-THCE & THGB Series
230 Volts
50-60 Hz
741-THJ Series
100 Volts
50-60 Hz
Printed in 2005
Prince Castle Inc.
355 East Kehoe Blvd.
Tel: (630) 462-8800
Toll Free: 1-800-PCASTLE

TABLE OF CONTENTS

Installation ..................................................................... 2
Programming ................................................................. 2
Operation ....................................................................... 3
Cleaning ........................................................................ 4
Parts List ....................................................................... 4
Exploded View .............................................................. 5
Troubleshooting ............................................................ 5
Wiring Diagrams ........................................................... 6
LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY
This product is warranted to be free from defects in
material and/or workmanship for a period of one
year from date of original installation, not to ex-
ceed 18 months from date of shipment from our
factory.
Any component which proves to be faulty in material
and/or workmanship will be replaced or repaired (at
the option of Prince Castle, Inc.) without cost to the
customer for parts or labor.
This warranty is subject to the following exceptions/
conditions:
This equipment is portable, charges for on loca-
!
tion service (e.g. trip charges and mileage) are
not included in the provisions of this warranty.
Use of any non-genuine Prince Castle parts
!
voids this warranty. All genuine Prince Castle
replacement spare parts are warranted for ninety
(90) days from date of purchase.
All work must be performed by an authorized
!
Prince Castle Service Agency. Failure to do so
will void this warranty.
Damage caused by carelessness, neglect, and/
!
or abuse (e.g., dropping, tampering or altering
parts), equipment damaged in shipment, by fire,
flood or an act of God is not covered under this
warranty.
Carol Stream, IL 60188
!
Fax: (630) 462-1460
!
PAGE
741-503 rev A
