Prince Castle 755 Series Operation Manual

Operation
Manual
LIMITED WARRANTY
This product is warranted to be free from defects in material and/or
workmanship for a period of 1 year from date of original installation, not to
exceed 18 months from the date of manufacture.
Any component which proves to be faulty in material and/or workmanship
will be replaced or repaired (at the option of Prince Castle, Inc.) without
cost to the customer for parts and labor. This equipment is portable;
charges for on-location service (e.g., trip charges, mileage) are not
included in the provisions of this warranty.
This warranty is subject to the following exceptions/conditions:
• Use of any non-genuine Prince Castle parts voids this warranty.
• All labor to be performed during regular work hours. Overtime premium
(the incremental amount) will be charged to the customer.
• Damage caused by carelessness, neglect and/or abuse (e.g., dropping,
tampering or altering parts, equipment damaged in shipment, by fire,
flood or an act of God) is not covered under this warranty.
• All problems due to operation at voltages other than that specified on
equipment nameplates are not covered by this warranty. Conversion to
correct voltage is the customer's responsibility.
• This equipment must be serviced by Prince Castle Authorized Service
Agency or a Prince Castle Service Technician during the warranty
period.
The power cord on this product is rated for a maximum surface
temperature of 194°F (90°C). If the cord comes into contact with the fryer
or rethermalizer or any other heated surface, it may be damaged and/or
cause damage to the product and/or injury to the user. The power cord
may also be damaged if placed directly in the path of the high temperature
exhaust emitting from the flue of the fryer or rethermalizer. Damage
resulting from any such misuse may result in a voided Warranty at the sole
discretion of the manufacturer.
755-503revB
Product Identification
The Prince Castle Model 755 Series Multi-display 10-Channel Timer and 16-Channel Timer
are easy-to-use timers that count down in minutes and seconds, or hours and minutes. Each
channel has its own display and can be programmed independently. Slide in replaceable
menu strips identify the product being timed on each channel, and are replaceable as
restaurant menus change. Both auditory and visual signals are used to alert busy staff people
when a function is complete.
The Prince Castle Model 755 Series Single-display 4-Channel Timer and 10-Channel Timer
are easy-to-use timers that count down in minutes and seconds, or hours and minutes. Each
channel can be programmed independently. Slide in replaceable menu strips identify the
product being timed on each channel, and are replaceable as restaurant menus change. Both
auditory and visual signals are used to alert busy staff people when a timing function is
completed.
Product Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exploded View and Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
355 East Kehoe Blvd. • Carol Stream, IL 60188 USA
Telephone: 630-462-8800 • Toll Free: 1-800-PCASTLE
Fax: 630-462-1460 • www.princecastle.com
755 Series
TABLE OF CONTENTS
Printed in USA 12/06 © 2006
Timers
1
2
2
2
2
4 – 7
8
