RCA RC100 User Manual

v1.0 (1.0.1.0) (EN/F)
user manual
guide de l'utilisateur
EN/F
It is important to read this user manual prior to using your new product for the fi rst time.
Nous vous recommandons de lire ce manuel d'instructions avant d'utiliser votre
nouveau produit pour la première fois.
FCC Information
Note: This equipment has been tested Changes or modifi cations not expressly
and found to comply with the limits approved by Audiovox could void
for a Class B digital device, pursuant the user's authority to operate the
to Part 15 of FCC Rules. These limits equipment.
are designed to provide reasonable
protection against harmful interference
This Class B digital apparatus
in a residential installation. This
complies with Canadian ICES-003.
equipment generates, uses, and can
Cet appareil numérique de la classe
radiate radio frequency energy and, if
B est conforme à la norme NMB-003
not installed and used in accordance
du Canada.
with the instructions, may cause harmful
interference to radio communications.
Electrical power
However, there is no guarantee
information
that interference will not occur in a
particular installation. If this equipment
Power Supply: 120 V ~ 60 Hz
does cause harmful interference to
Power Consumption: 5 Watts
radio or television reception, which
can be determined by turning the
equipment off and on, the user is
encouraged to try to correct the
interference by one or more of the
following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an
outlet on a circuit different from
that to which the receiver is
connected.
• Consult the dealer or an
experienced radio/TV technician for
help.
Wake function
Setting wake time Turning off the wake
1. To set time for alarm, press and
alarm or radio
hold ALARM SET/OFF and press
• To silence the wake function
HRS or MIN simultaneously.
momentarily:
To turn off the wake function, press
2. To save and exit the alarm setting,
SNOOZE/SLEEP OFF on the top of
release ALARM SET/OFF.
the unit. The wake alarm or radio
will be switched off temporarily.
Selecting wake source
The alarm or radio will be on again
when the snooze period (9 minutes)
You may be woken up by radio or
is over.
alarm.
1. Set a wake time (see above Snooze function can be used
repeatedly up to 2 hours. After this,
instructions).
the alarm will turn off until the
next alarm conditions are met.
2. Slide ON/OFF/RADIO(WAKE)/
ALARM(WAKE) to RADIO or
• To turn off the wake alarm or
ALARM to select a waking mode
radio:
(by radio or alarm).
Press ALARM SET/OFF. The wake
• Your last tuned radio station will be
alarm or radio will activate again
the wake source if wake by radio is
selected. the next day unless you switch off
the Wake function.
• To disable the wake function
completely:
Slide ON/OFF/RADIO(WAKE)/
ALARM(WAKE) to OFF.

IMPORTANT SAFETY INSTRUCTIONS

two blades and a third grounding
prong. The wide blade or the third
prong is provided for your safety. If
the provided plug does not fi t into
your outlet, consult an electrician
for replacement of the obsolete
outlet.
RC100
• Protect the power cord from being
walked on or pinched particularly at
plugs, convenience receptacles, and
the point where they exit from the
apparatus.
• Only use attachments/accessories
Some of the following information may
specifi ed by the manufacturer.
not apply to your particular product;
• Use only with
however, as with any electronic product,
the cart, stand,
precautions should be observed during
tripod, bracket,
handling and use.
or table
• Read these instructions.
specifi ed by the
• Keep these instructions.
manufacturer,
• Heed all warnings.
or sold with
• Follow all instructions.
the apparatus.
• Do not use this apparatus near
When a cart is used, use caution
water.
when moving the cart/apparatus
• Clean only with dry cloth.
combination to avoid injury from
• Do not block any ventilation
tip-over.
openings. Install in accordance with
• Unplug this apparatus during
the manufacturer's instructions.
lightning storms or when unused
• Do not install near any heat sources
for long periods of time.
such as radiators, heat registers,
• Refer all servicing to qualifi ed
stoves, or other apparatus (including
service personnel. Servicing is
amplifi ers) that produce heat.
required when the apparatus has
• Do not defeat the safety purpose
been damaged in any way, such
of the polarized or grounding-type
as power-supply cord or plug is
plug. A polarized plug has two
damaged, liquid has been spilled
blades with one wider than the
or objects have fallen into the
other. A grounding type plug has
apparatus, the apparatus has been
Before you begin
Power failure indicator
Refer to the "Clock" section and
follow the instructions to set the When AC power is interrupted
clock. (disconnected) for a short period of
time, both time and alarm settings
will change (unless batteries are
Battery back-up operation
installed). After AC power is restored
• This clock radio is equipped with
(reconnected), the Digital Display
a memory holding system that can
will blink to indicate that power was
be powered with a 9-volt alkaline
interrupted and you should re-adjust
battery (not included). The power
the time and alarm settings.
failure protection circuit will not
operate unless battery is installed.
• When normal household power
Alkaline (NEDA 1604A/
is interrupted, or AC line cord
IEC 6LR61) battery is
is unplugged, the batteries will
recommended. Carbon-zinc
power the clock radio to keep
battery may be used but memory
track of time and alarm settings
holding time will be substantially
programmed into memory.
reduced. Memory holding time
• When the battery backup functions,
for a fresh alkaline battery is
the digital display will not light,
approximately 8 hours (if radio
however, the function of alarm
or alarm are not operated) which
still occurs during the power
should take care of short, nuisance-
interruption if remaining battery
type AC power failures. To preserve
power is adequate.
battery life, the unit should remain
• Normal operation will resume after
plugged into an AC outlet. As the
AC power is restored so you will not
battery gets older, its voltage drops
have to reset the time or the alarm.
and memory may be lost. Be sure
to replace the battery periodically.
To install the battery:
Battery should be removed if the
1. Remove battery compartment door
unit will be stored for more than
(located at the bottom of the radio)
one month. Leaky battery can
by applying thumb pressure to the
badly damage the clock radio.
tab on battery door and then lift
the door out and off the cabinet.
2. Connect a 9-volt alkaline battery
(not included) to the connector
plug.
3. Replace the compartment door.
Warranty information
Sleep function
Set sleep time manually
12 Month Limited Warranty
Applies to RCA Clock Radios
In sleep function, the unit will turn off
automatically after a specifi ed time.
AUDIOVOX ACCESSORIES CORP. (the
To set the sleep mode: Company) warrants to the original retail
purchaser of this product that should
1. Press and hold SLEEP and press
this product or any part thereof, under
MIN simultaneously to adjust the
normal use and conditions, be proven
sleep time. The time range is from
defective in material or workmanship
from 0:01 to 1:59. (The default time
is 59 minutes.) within 12 months from the date of
original purchase, such defect(s) will be
• The radio will be switched on.
repaired or replaced with reconditioned
product (at the Company's option)
To cancel the sleep mode:
• Press SNOOZE/SLEEP OFF to cancel without charge for parts and repair
labor.
the sleep mode and turn off the
unit.
To obtain repair or replacement
within the terms of this Warranty, the
product is to be delivered with proof
of warranty coverage (e.g. dated bill
of sale), specifi cation of defect(s),
transportation prepaid, to the Company
at the address shown below.
This Warranty does not extend to the
elimination of externally generated
static or noise, to correction of
antenna problems, loss/interruptions of
broadcast or internet service, to costs
incurred for installation, removal or
reinstallation of product, to corruptions
caused by computer viruses, spyware or
other malware, to loss of media, fi les,
data or content, or to damage to tapes,
discs, removable memory devices or
cards, speakers, accessories, computers,
computer peripherals, other media
PLEASE READ AND SAVE THIS FOR FUTURE REFERENCE
exposed to rain or moisture, does
not operate normally, or has been
dropped.
• No naked fl ame sources, such as
ADDITIONAL SAFETY INFORMATION
• Apparatus shall not be exposed to
dripping or splashing and no objects
• Attention should be drawn to the
fi lled with liquids, such as vases,
shall be placed on the apparatus.
• Always leave suffi cient space around
• The use of apparatus in moderate
the product for ventilation. Do
not place product in or on a bed,
rug, in a bookcase or cabinet that
may prevent air fl ow through vent
openings.
• Do not place lighted candles,
]
cigarettes, cigars, etc. on the
product.
• Connect power cord only to AC
power source as marked on the
Portable Cart Warning product.
Plugging in for power
• Care should be taken so that objects
AC OUTLET POWER SUPPLY:
do not fall into the product.
120 V ~ 60 Hz
• Do not attempt to disassemble
the cabinet. This product does
not contain customer serviceable
components.
• The marking information is located
at the bottom of apparatus.
• To be completely disconnect the
power input, the main plug of
completely, turn the plug over and try
apparatus shall be disconnected
to insert it the other way. If it still does
from the mains.
not fi t, contact a qualifi ed electrician
• Main plug is a disconnect device.
to change the outlet, or use a different
The main plug should not be
one. Do not attempt to bypass this
obstructed OR should be easily
safety feature.
accessed during intended use.
• The ventilation should not be
General controls
Right view
• – – VOLUME + – To adjust volume
• TUNING – To adjust radio frequency
Top view
• ON/OFF/RADIO(WAKE)/
• TIME – To adjust the clock time
• ALARM SET – To activate the wake
• SLEEP – To activate sleep function
• AM/FM – To select radio band
• HRS – To adjust hour value when
• MIN – To adjust the minute value
• SNOOZE/SLEEP OFF – To quiet
players, home networks or vehicle for the Company any liability other than
expressed herein in connection with the
electrical systems.
sale of this product.
This Warranty does not apply to any
product or part thereof which, in the Some states do not allow limitations on
opinion of the Company, has suffered how long an implied warranty lasts or
or been damaged through alteration, the exclusion or limitation of incidental
improper installation, mishandling, or consequential damage so the above
misuse, neglect, accident, or by removal limitations or exclusions may not apply
or defacement of the factory serial to you. This Warranty gives you specifi c
legal rights and you may also have
number/bar code label(s). THE EXTENT
OF THE COMPANY'S LIABILITY UNDER other rights which vary from state to
THIS WARRANTY IS LIMITED TO THE state.
REPAIR OR REPLACEMENT PROVIDED
ABOVE AND, IN NO EVENT, SHALL THE Recommendations before returning
COMPANY'S LIABILITY EXCEED THE your product for a warranty claim:
PURCHASE PRICE PAID BY PURCHASER • Properly pack your unit. Include
FOR THE PRODUCT.
This Warranty is in lieu of all other
express warranties or liabilities. ANY
IMPLIED WARRANTIES, INCLUDING
ANY IMPLIED WARRANTY OF
MERCHANTABILITY, SHALL BE LIMITED
TO THE DURATION OF THIS WRITTEN
WARRANTY. ANY ACTION FOR BREACH
• Note that product will be returned
OF ANY WARRANTY HEREUNDER
INCLUDING ANY IMPLIED WARRANTY
OF MERCHANTABILITY MUST BE
BROUGHT WITHIN A PERIOD OF 24
MONTHS FROM DATE OF ORIGINAL
PURCHASE. IN NO CASE SHALL THE
COMPANY BE LIABLE FOR ANY
CONSEQUENTIAL OR INCIDENTAL
DAMAGES FOR BREACH OF THIS OR
ANY OTHER WARRANTY. No person or
representative is authorized to assume
Important battery
impeded by covering the ventilation
openings with items such as
precautions
newspaper, table-cloths, curtains etc.
• Any battery may present a risk of
fi re, explosion, or chemical burn
lighted candled, should be placed
if abused. Do not try to charge a
on the apparatus.
battery that is not intended to be
recharged, do not incinerate, and
environmental aspects of battery
do not puncture.
disposal.
• Non-rechargeable batteries, such as
alkaline batteries, may leak if left in
climates.
your product for a long period of
This is class II
time. Remove the batteries from the
equipment designed
product if you are not going to use
with double or
it for a month or more.
reinforced insulation
• If your product uses more than one
so it does not require
battery, do not mix types and make
a safety connection to
sure they are inserted correctly.
electrical earth (US:
Mixing types or inserting incorrectly
ground).
may cause them to leak.
• Discard any leaky or deformed
battery immediately. They may
cause skin burns or other personal
injury.
The AC power plug is • Please help to protect the
polarized (one blade is environment by recycling or
wider than the other) disposing of batteries according to
and only fi ts into AC federal, state, and local regulations.
power outlets one
way. If the plug will
not go into the outlet
Clock
Setting clock
1. Press and hold TIME.
2. Press HRS or MIN to set the clock
time.
• AM indicator lights when the time is
set to AM.
• PM indicator lights when the time is
set to PM.
3. To save and exit the clock setting,
release TIME.
ALARM(WAKE) – To turn radio on
or off; to change wake mode (radio/
alarm)
settings
setting clock, wake and sleep modes
when setting clock, wake and sleep
modes
the wake alarm or wake radio
temporarily (9 minutes); to cancel
sleep function
Audiovox Electronics Corp.
Attn: Service Department.
150 Marcus Blvd.
Hauppauge N.Y. 11788
1-800-645-4994
For Canada Customers, please ship to:
Audiovox Return Centre
c/o Genco
6685 Kennedy Road,
Unit#3, Door 16,
Mississuaga, Ontario
L5T 3A5
any remotes, memory cards, cables,
etc. which were originally provided
with the product. However DO NOT
return any removable batteries,
even if batteries were included
with the original purchase. We
recommend using the original
carton and packing materials. Ship
to the address shown below.
with factory default settings.
Consumer will be responsible to
restore any personal preference
settings.
WARNING: The battery (battery or
batteries or battery pack) shall not
be exposed to excessive heat such as
sunshine, fi re or the like.
Ecology
Help protect the environment - we
recommend that you dispose of used
batteries by putting them into specially
designed receptacles.
Radio
Selecting radio mode
Slide ON/OFF/RADIO(WAKE)/
ALARM(WAKE) to ON to switch on
radio. Slide to OFF to switch off radio.
Switching band
Slide the band switch AM/FM to select
FM or AM band.
Tuning the radio
Rotate the TUNING knob on the
right of the unit to adjust the radio
frequency with reference to the tuning
dial scale. Note that the unit of AM
frequency shown on the tuning knob
"x10kHz 170" is equivalent to 1700 kHz.
Built-in AFC
The Built In Automatic Frequency
Control (AFC) works only on FM. It helps
reducing drift on FM reception and
keeping the radio locked in on the FM
station to which it is tuned.
When tuning in FM stations, you may
notice that the station you are tuning
can be well-tuned on two or three
nearby points on the dial. Always tune
carefully at the loudest and clearest
point.
AM antenna
A built-in ferrite rod antenna eliminates
the need for an outside antenna for
AM reception. Rotating the unit slightly
may improve reception of distant AM
stations.
Illustrations contained within this
publication are for representation only
and subject to change.
The descriptions and characteristics
given in this document are given as
a general indication and not as a
guarantee. In order to provide the
highest quality product possible,
we reserve the right to make any
improvement or modifi cation without
prior notice.
Visit http://store.audiovox.com to find the best
accessories for your products.
© 2011 Audiovox Accessories Corporation
111 Congressional Blvd., Suite 350
Carmel, IN 46032
Trademark(s) ® Registered
Printed in China
