Delta Electronics Delphi E48SC Datasheet page 2

SPECIFICATIONS
GENERAL SPECIFICATIONS
Input Voltage
Switching Frequency Typical
Isolation Voltage In/Out
Typical
Isolation Capacitance
Isolation Resistance Minimum
MTBF Bellcore (5.0V)
Size (2.30"x0.90"x0.35")
PART NUMBERING SYSTEM
E 48 S
Type of Input Number of
Product Voltage Outputs
E - Eighth 48- 36~75V S - Single
Brick
MODEL LIST
MODEL NAME
E48SC05012NR A
MECHANICAL DRAWINGS
Surface-mount module
CONTACT: www.delta.com.tw/dcdc
USA:
Telephone:
East Coast: (888) 335 8201
West Coast: (888) 335 8208
Fax: (978) 656 3964
Email: DCDC@delta-corp.com
36~75V
350KHz
2250V
1000PF
10MΩ
TBD
58.4x22.8x9.0mm
C 050
Product Output Output
Series Voltage Current
C - Improved 050 - 5.0V 12 - 12A N - Negative
E48SR
INPUT
36V~75V 2.1A
Europe:
Phone: +41 31 998 53 11
Fax: +41 31 998 53 53
Email: DCDC@delta-es.com
OUTPUT SPECIFICATIONS
Voltage Accuracy Typical
Line Regulation Typical
Load Regulation Typical
Ripple & Noise Typical (5.0V)
Current Limits Typical
Over Voltage Typical
Voltage Trim
12 N R
ON/OFF Pin Length
Logic
R - 0.170"
P - Positive N - 0.145"
OUTPUT
5.0V 12A
Through-hole module
Asia & the rest of world:
Telephone: +886 3 4526107 ext 6220
Fax: +886 3 4513485
Email:
±1%
±0.2%
±0.2%
50 mV
125%
120%
+10%, -10%
F A
Space Option
Code
F - RoHS 6/6 A - Standard
Space - RoHS 5/6 Function
EFF @ 100% LOAD
91.5%
DCDC@delta.com.tw
2
