Sony CDP-CX151 Service Manual

— SERVICE MANUAL
Compact disc player
—CDP-CX151-
US Model
Canadian Model
AEP Model
UK Model
Australian Model
KSS-5I0A
SPECIFICATIONS
General
Laser Semiconductor laser Power requirements
Wavelength 780 ~ 790 nm Where purchased Power requirements
Frequency response
2 Hz to 20 kHz + 0.3 dB
USA, Canada
120 V AC, 60 Hz
Signal-to-noise ratio More than 107 dB pustaha 240 V AC, 50 Hz
:
AEP
220 - 230V AC, 50/60 Hz
Dynamic range More than 98 dB Powerconsumption. 15W.
i c distorti Less than 0.0027
Helene cateniee yn, ae Dimensions (approx.) When the front cover is closed
Channel separation More than 100 dB (w/hid) 430 x 240 x 470 mm (17 x 91/2 x 185/8 .
in.) incl. projecting parts
When the front cover is open —_-
Outputs 430 x 380 x 470 mm (17 x 15 x 18 5/8
in.) incl. projecting parts
Jack Maximum Load impedance
type output : ; Mass (approx.) 9.0 kg (19 Ibs 14 oz)
level
LINEOUT Phono 2V Over 10 kilohms Supplied accessories
jacks (at 50 kilohms) Audio cord (2 phono plugs — 2 phono plugs) (1)
: Remote commander (remote) (1)
DIGITAL OUT Optical -18dBm Wave length: 660 nm Sony SUM-3 (NS) batteries (2)
(OPTICAL) output
connector
CD booklet holder (1)
Labels (2)
Design and specifications are subject to change without notice.
