- Page 1 OWNER’S MANUAL DX22+E CONCRETE FLOOR GRINDER USER & MAINTENANCE BOOK SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE...
-
Page 2: Warranty Registration Card
First and Last Name Company Name Address City State Zip Code Phone Number Email Machine Information Machine Type Machine Model Serial # Purchase Date (dd/mm/yy) DiamaPro Systems ® 3343 Peachtree Road NE Suite 145 #24 Atlanta, GA 30326 470-977-2323 www.diamaprosystems.com info@diamaprosystems.com... -
Page 3: Safety Instructions
If these dangers are present are to be missed, clearly mark DiamaPro DX22+E. For your own safety and protection from injury, careful- the area. ly read, understand, and observe the safety instructions described in this 1.10 KEEP WORK AREA CLEAN - DO NOT RUN... -
Page 4: California Prop 65 Warning
It is strictly forbidden to perform wiring work after the machine is con- DiamaPro DX22+E. For your own safety and protection from injury, careful- nected to electricity ly read, understand, and observe the safety instructions described in this A leakage protection device must be used for the input power supply. - Page 5 (Motor, tool plates, etc.) Before performing maintenance: Thoroughly clean the DX22+E. If in doubt about how to perform occasional repairs, contact our Technical Support or an authorized dealer. Upon finishing the job perform a thorough cleaning from processing residues.
- Page 6 MOBIL SCH 630 CAUTION DO NOT REPLACE THE GEARBOX. CONTACT DIAMAPRO SYSTEMS OR THE AUTHORIZED DEALER. Machine stopped /Power Weekly Check belt for proper tension or abnormal wear.
- Page 7 DX22+E Parts list MATERIAL...
-
Page 8: Specifications
SPECIFICATIONS DX22+E ELECTRIC TITLE: MATERIAL VOLTAGE SINGLE PHASE 220V MOTOR 5.5 HP UNLESS OTHERWISE SPECIFIED: FINISH INVERTER PROPRIETARY AND CONFIDENTIAL 7.5 HP DIMENSIONS ARE IN INCHES TOLERANCES: DWG. NO. THE INFORMATION CONTAINED IN THIS CURRENT 10~15 A FRACTIONAL DRAWN BY... -
Page 9: Handle Assembly
HANDLE ASSEMBLY DETAIL SCALE 1 : 5 TITLE: MATERIAL STEP AP214 UNLESS OTHERWISE SPECIFIED: FINISH PROPRIETARY AND CONFIDENTIAL DIMENSIONS ARE IN INCHES TOLERANCES: DWG. NO. THE INFORMATION CONTAINED IN THIS FRACTIONAL DRAWN BY DRAWING IS THE SOLE PROPERTY OF ANGULAR: MACH BEND NM-DX22+E05_HandleAssembly TWO PLACE DECIMAL... - Page 10 HANDLE ASSEMBLY ITEM NO. PART NUMBER DESCRIPTION QTY. DP-DX22-CPEN CONTROL PANEL ENCLOSURE DP-DX22-CPGS CONTROL PANEL GASKET DP-DX22-CPBP CONTROL PANEL BACK PLATE DP-GH-DX0155 M5X10 HSB ROUNDED DP-GH-DX0297 STRAIN RELIEF DP-GH-DX0293 M6X16 HSB DP-DX-CBBU CONTROL BOX BASE UPPER DP-DX22-CBBS CONTROL BOX BASE BOLT SLEEVE DP-DX22-CBBM6 CONTROL BOX BASE BOLT (M6X60 HSB) DP-GH-DX0293...
- Page 11 CARRIAGE TITLE: MATERIAL STEP AP214 UNLESS OTHERWISE SPECIFIED: FINISH PROPRIETARY AND CONFIDENTIAL DIMENSIONS ARE IN INCHES DWG. NO. TOLERANCES: THE INFORMATION CONTAINED IN THIS FRACTIONAL DRAWN BY DRAWING IS THE SOLE PROPERTY OF ANGULAR: MACH BEND NM-DX22+E05_Carriage TWO PLACE DECIMAL NIAGARA MACHINE.
- Page 12 CARRIAGE ITEM NO. PART NUMBER DESCRIPTION QTY. DP-DX22-PIWE DX22-E+ POWER WIRE DP-DX22-WORD DX22-E+ WIRE ROD DP-DX22-LEDL DX22-E+ LED FRONT WORKING LIGHT DP-DX22-RFPT DX22-E+ REINFORCEMENT PLATE DP-DX22-RRSP DX22-E+ RIGHT FRAME PLATE DP-DX22-HSNT DX22-E+ HANDLE SPLINT DP-DX22-SPAT DX22-E+ SHAFT SPLINT DP-DX22-VLSW DX22-E+ WATER VALVE ASSEMBLY DP-DX22-WWIN DX22-E+ WORK LIGHT DP-DX22-PWIN...
-
Page 13: Lower Frame Assembly
LOWER FRAME ASSEMBLY... - Page 14 LOWER FRAME ASSEMBLY ITEM NO. PART NUMBER DESCRIPTION QTY. DP-DX22-WATK DX22-E+ WATER TANK DP-DX22-ECE0 DX22-E+ ELECTRIC MOTOR BOLTS M12X20 DP-DX22-RVBT DX22-E+ RIBBED V-BELT DP-DX22-ECER DX22-E+ ELECTRIC MOTOR DP-DX22-MBSH DX22-E+ MOTOR BUSHING DP-DX22-BTPY DX22-E+ BELT PULLEY DP-DX22-MRPG DX22-E+ MOTOR PLUG DP-DX22-MRFL DX22-E+ MOTOR PLATE DP-DX22-MSXB DX22-E+ M8X20 HSB...
- Page 15 LOWER FRAME ASSEMBLY ITEM NO. PART NUMBER DESCRIPTION QTY. DP-GH-DX0264 DX22-E+ M10X100 TENSIONING BOLT DP-DX22-GFEG DX22-E+ GREASE FITTING DP-GH-DX0169 DX22-E+ SLIDING SHAFT DP-DX22-LVSL DX22-E+ LEVELING SLEEVE DP-DX22-CNNR DX22-E+ CENTERING COLLAR DP-DX-WCAP DX22-E+ WALKING WHEEL CAP DP-DX-WHEEL DX22-E+ WALKING WHEEL DP-DX22-AXLE DX22-E+ WHEEL AXEL DP-DX-FCL25 DX22-E+ FEMALE CAM...
- Page 16 GEAR BOX...
- Page 17 GEAR BOX ITEM NO. PART NUMBER DESCRIPTION QTY. DP-GH-FLCO FLEX COUPLER DP-GH-GRPL DX22 ALUMINUM TOOL PLATE DP-DX-TPHW-KIT TOOL PLATE HARDWARE KIT DP-DX22-FGBA FULL GEARBOX ASSEMBLY DP-DX-GRCB CLAW BASE DP-KEY-10X8X22 CLAW BASE SHEAR KEY 10X8X22 DP-GH-DX0121-K CLAW BASE HARDWARE KIT DP-DX22-BTPY-250-K LOWER BELT PULLEY KIT DP-GH-DX0122 HEX SOCKET BOLT M8X40...
-
Page 18: Tool Plate Assembly
TOOL PLATE ASSEMBLY ITEM NO. PART NUMBER DESCRIPTION QTY. DETAIL DP-GH-RTSY M6 HEX BEAD SERRATED BOLT UNLESS OTHERWISE SPECIFIED: FINISH: DEBURR AND DO NOT SCALE DRAWING REVISION DIMENSIONS ARE IN MILLIMETERS BREAK SHARP SCALE 3 : 1 SURFACE FINISH: EDGES TOLERANCES: LINEAR: ANGULAR:... - Page 19 CONTROLS ITEM NO. PART NUMBER DESCRIPTION QTY. DP-DX22-VSCR VOLTAGE/CURRENT SCREEN DP-DX22-EMSW EMERGENCY STOP SWITCH DP-DX22-MFWR MOTOR FWD/REVERSE DP-DX22-GHSP GRINDING HEAD SPEED DP-DX22-LLED LED LIGHT DP-DX22-USB USB PORT CONTROL PANEL OPERATION PROCESS Connect the power > check whether (A) voltage/current is always on > turn clockwise to turn on (B) >...
- Page 20 WIRING...
- Page 21 Customer expressly acknowledges that modification of any equipment, machines, or other products purchased from Niagara Machine, Inc. (“Niagara”), including but not limited to DiamaPro Systems Products (collectively, “Products”) through the attempted or actual use or misuse, adjustment, alteration, application of additional components, removal of provided components, repairs or attempted repairs by Customer (collectively, “Modifications”) can lead to Product malfunction causing serious risks.
