- Page 1 OWNER’S MANUAL DX22-E CONCRETE FLOOR GRINDER USER & MAINTENANCE BOOK SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE...
-
Page 2: Warranty Registration Card
First and Last Name Company Name Address City State Zip Code Phone Number Email Machine Information Machine Type Machine Model Serial # Purchase Date (dd/mm/yy) DiamaPro Systems ® 3343 Peachtree Road NE Suite 145 #24 Atlanta, GA 30326 470-977-2323 www.diamaprosystems.com info@diamaprosystems.com... -
Page 3: Safety Instructions
If these dangers are present are to be missed, clearly mark DiamaPro DX22-E. For your own safety and protection from injury, careful- the area. ly read, understand, and observe the safety instructions described in this 1.10 KEEP WORK AREA CLEAN - DO NOT RUN... -
Page 4: California Prop 65 Warning
It is strictly forbidden to perform wiring work after the machine is con- DiamaPro DX22-E. For your own safety and protection from injury, careful- nected to electricity ly read, understand, and observe the safety instructions described in this A leakage protection device must be used for the input power supply. -
Page 5: Maintenance And Repair
(Motor, tool plates, etc.) Before performing maintenance: Thoroughly clean the DX22-E. If in doubt about how to perform occasional repairs, contact our Technical Support or an authorized dealer. Upon finishing the job perform a thorough cleaning from processing residues. - Page 6 MOBIL SCH 630 CAUTION DO NOT REPLACE THE GEARBOX. CONTACT DIAMAPRO SYSTEMS OR THE AUTHORIZED DEALER. Machine stopped /Power Weekly Check belt for proper tension or abnormal wear.
-
Page 7: Specifications
SPECIFICATIONS DX22-E ELECTRIC VOLTAGE SINGLE PHASE 220V MOTOR 5.5 HP INVERTER 7.5 HP CURRENT 10~15 A WATER TANK CAPACITY 18 L WEIGHT 465 LBS DIMENSIONS (LxWxH) 35x22x42.5 IN GRINDING PLATE SPEED 0-560 RPM... -
Page 8: General Parts
GENERAL PARTS ITEM # DESCRIPTION PART # HANDLE ASSEMBLY DP-DX22-HASS HANDLE GEAR BASE-BILATERAL SYMMETRY DP-DX22-HGBS AXLE CARD 25 DP-DX22-AC25 ELECTRIC BOX ASSEMBLY DP-DX22-EBAS HANDLE SPLINT DP-DX22-HANS BODY ASSEMBLY DP-DX22-BODY... -
Page 9: Handle Assembly
HANDLE ASSEMBLY ITEM # PART # DESCRIPTION OPERATION CONTROL BOX DP-DX22-OPCB CONTROL BOX BASE-UPPER DP-DX22-UPCB CONTROL BOX BASE-BOTTOM DP-DX22-BMCB HANDLE HOUSING DP-DX22-HANH OPERATING HANDLE SLEEVE DP-DX22-HASL OPERATION HANDLE DP-DX22-OPHD HANDLE PLATEN DP-DX22-HDPL AXLE CARD 25 DP-DX22-AC25 ROTATION AXLE DP-DX22-RDAX GUIDE SLEEVE DP-DX22-GDSV CONNECTING SLEEVE DP-DX22-CNSV... - Page 10 CARRIAGE ITEM # PART # DESCRIPTION ELECTRIC BOX BRACKET DP-DX22-EBBR WIRE ROD DP-DX22-WORD WIRE ROD BASE DP-DX22-WBSE RACK RIGHT SIDE PANEL DP-DX22-RRSP RACK LEFT SIDE PANEL DP-DX22-RLSP CAM LOCK -A- 2.5IN DP-DX22-CAMA CAM LOCK -B- 2.5IN DP-DX22-CAMB DUST SUCTION PORT DP-DX22-DUSP LED LIGHT DP-DX22-LEDL...
- Page 11 ELECTRICAL BOX / INVERTER ITEM # DESCRIPTION PART # INVERTER CONTROL PANEL DP-DX22-IVCP VENTILATION FILTER DP-DX22-VFTR ELECTRIC BOX DP-DX22-ETCB SWITCHING POWER DP-DX22-PWSC INVERTER DP-DX22-INVT POWER INDICATOR DP-DX22-PWIN WORK INDICATOR DP-DX22-WWIN ELECTRIC BOX DOOR DP-DX22-EBDR ELECTRIC BOX DOOR LOCK DP-DX22-EBDL...
- Page 12 FRAME / WHEEL ASSEMBLY...
- Page 13 FRAME / WHEEL ASSEMBLY cont. ITEM # DESCRIPTION PART # MOTOR DP-DX22-MOTR MOTOR BUSHING DP-DX22-MBSH BELT PULLEY DP-DX22-BTPY MOTOR PLUG DP-DX22-MRPG BELT 1041 (TYPE 9) DP-BELT-10419 MOTOR FLANGE DP-DX22-MRFL LIFT HANDLE DP-DX22-LTHD LIFTING BASE DP-DX22-LTBS-TOP FLAT BEARING 51002 DP-DX22-BEAR-51002-FLAT LIFTING BASE DP-DX22-LTBS-BM LIFTING SCREW DP-DX22-LTSW...
-
Page 14: Drive Assembly
DRIVE ASSEMBLY... - Page 15 DRIVE ASSEMBLY cont. ITEM # DESCRIPTION PART # HEXAGON SOCKET BOLT M8*20 DP-M8X20 BELT PULLEY PLUG DP-DX22-BTPP BELT PULLEY 250 DP-DX22-BTPY-250 8x7x22 PIN DP-PIN-8X7X22 HEXAGON SOCKET HEAD M8x35 DP-HSH-M8X35 HEXAGON SOCKET HEAD M8x20 DP-HSH-M8X20 M8x35 DOWEL PIN DP-PIND-M8X35- WATER PIPE CLAMP DP-DX22-WPCL FILLING PLUG DP-DX22-OPLG...
- Page 16 CONTROLS ITEM # PART # DESCRIPTION VOLTAGE/CURRENT SCREEN DP-DX22-VSCR EMERGENCY STOP SWITCH DP-DX22-EMSW MOTOR FWD/REVERSE DP-DX22-MFWR GRINDING HEAD SPEED DP-DX22-GHSP LED LIGHT DP-DX22-LLED USB PORT DP-DX22-USB CONTROL PANEL OPERATION PROCESS Connect the power > check whether (A) voltage/current is always on > turn clockwise to turn on (B) >...
- Page 17 WIRING...
- Page 18 DiamaPro Systems ® 3343 Peachtree Road NE Suite 145 #24 Atlanta, GA 30326 470-977-2323...
