FAUCET SPECIFICATIONS
Pull-Down Spray Kitchen Faucet
Model VG02014
MODEL VG02014
FEATURES
PACKING LIST
NOTE: All faucets are compliant to CEC 2016 regulations. If you
have inquiries about your water flow, please email
techmail@vigoindustries.com.
DIMENSIONS
MODEL #
HOLE
DIAMETER
VG02014
1 3/8"
8 5/8"
FAUCET
SPRAYER
HEIGHT
REACH
16"
8 5/8"
16"
1 3/8"
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for VIGO VG02014MB
Summary of Contents for VIGO VG02014MB
- Page 1 FAUCET SPECIFICATIONS Pull-Down Spray Kitchen Faucet Model VG02014 MODEL VG02014 FEATURES PACKING LIST DIMENSIONS MODEL # HOLE FAUCET SPRAYER DIAMETER HEIGHT REACH VG02014 1 3/8" 16" 8 5/8" 16" 8 5/8" 1 3/8" NOTE: All faucets are compliant to CEC 2016 regulations. If you have inquiries about your water flow, please email techmail@vigoindustries.com.
- Page 2 1 1/4" 16" 8 5/8" 8 1/4" 6 1/8" 2 5/8" 2 5/8" 1 3/8" SIDE VIEW SPRAY HOSE FRONT VIEW VG02014 THE MEASUREMENTS IN INCHES ARE ROUNDED TO THE NEAREST 3/8"...
- Page 3 Doing so will remove the ability for the product to meet certain low flow standards. Please talk to your local or statewide plumbing enforcement agency prior to modifying. Vigo is not responsible for any alterations and the affects that may come with altering the product post sale and highly advises that the client only install the product that meets the needs of their local plumbing code.
- Page 4 VIEW THE CONNECTIONS AT THE MALE AND FEMALE FLEXIBLE HOSE CONNECTIONS. IF LEAKS ARE DETECTED, REFER BACK If you have any questions please contact the Vigo Technical Support TO THE INSTRUCTIONS AND ADJUST ACCORDINGLY. Department before proceeding with installation.
- Page 5 5.A - Remove and clean aerator. 5.B - Contact Vigo Technical Support for replacement. PARTS LIST - For any parts needed but not shown, please contact Vigo Technical Support PART PART # FINISH SUPPLY DATE INDICATOR (INTERNAL USE ONLY)
- Page 6 VIGO or an authorized VIGO dealer, through the lifetime of the original owner or end-user. VIGO warrants the cartridge component of the Product to be free from defects in workmanship and materials under normal use and service for a period of five (5) years from the initial date of purchase by the owner, contractor, or builder, from VIGO or an authorized VIGO dealer.
- Page 7 VG02014 LISTE D'EMBALLAGE DIMENSIONS VG02014 1 3/8" 16" 8 5/8" 16" 8 5/8" 1 3/8" de la CEC de 2016. Si vous avez des questions au sujet de votre...
- Page 8 1 1/4" 16" 8 5/8" 8 1/4" 6 1/8" 2 5/8" 2 5/8" 1 3/8" TUYAU DU VAPORISATEUR VUE DE FACE VG02014...
- Page 9 responsable des modifications et de la touche qui peut venir avec la modification du poste de vente de produits et Restricteur Vous trouverez le restricteur de 1,8 gpm ici. Il suffit d'enlever le limiteur de 1,8 gpm et installer le robinet comme d'habitude.
- Page 10 ASSEMBLAGE CONTENU DE L'EMBALLAGE 1. COUPEZ L'ALIMENTATION EN EAU. ENLEVEZ L'ANCIEN ROBINET ET LES TUYAUX FLEXIBLES. NETTOYEZ LA SURFACE CONTREPOIDS SUPPORT EN PLASTIQUE ANNEAU EN CAOUTCHOUC ANNEAU DEUX TUYAUX EN ASSUREZ-VOUS D'UTILISER DU RUBAN POUR TUYAU ET NE SERREZ PAS D'ALIMENTATION PUISQUE CELA DU PRODUIT CE QUI POURRAIT ENSEMBLE...
- Page 11 MESURE CORRECTIVE 1.A - Cartouche non assise avec de l'eau chaude et bien asseoir dans le logement. 1.B - Communiquer avec le Soutien technique de Vigo pour un 3 - Fuite aux points de connexion remplacement. 2.B - Encrassement dans tuyau/conduite d'alimentation 2.A - Enlever et faire tremper/nettoyer avec un agent non abrasif...
- Page 12 VIGO INDUSTRIES, LLC ("VIGO") EN VIGUEUR LE 1er AVRIL 2013 original pour usage domestique personnel. Des restrictions additionnelles s'appliquent aux utilisations commerciales. de la vente des produits en cause. Restrictions verre qui pourrait causer des blessures corporelles ou la mort.] constructeur.
- Page 13 ESPECIFICACIONES DEL GRIFO Grifo de cocina con rociador extensible Modelo VG02014 MODELO VG02014 LISTA DE CONTENIDO DIMENSIONES MODELO # ALTURA ALCANCE ORIFICIO GRIFO ROCIADOR VG02014 1 3/8" 16" 8 5/8" 16" 8 5/8" 1 3/8" NOTA: Todos los grifos cumplen con CEC 2016 regulaciones. Si usted tiene preguntas acerca de su flujo de agua, por favor escriba techmail@vigoindustries.com.
- Page 14 1 1/4" 16" 8 5/8" 8 1/4" 6 1/8" 2 5/8" 2 5/8" 1 3/8" VISTA LATERAL MANGUERA DEL ROCIADOR VISTA FRONTAL VG02014...
- Page 15 NORMAS DE CAUDAL La velocidad de flujo con limitador - 1.8 gpm Velocidad de flujo sin restrictor - 2.2 gpm Restrictor el limitador de 1,8 gpm e instalar el grifo como de costumbre. Grifo Limitador 1.8gpm...
- Page 16 MONTAJE CONTENIDO DE LA CAJA 1. CIERRE EL SUMINISTRO DE AGUA. RETIRE EL GRIFO VIEJO Y LAS MANGUERAS FLEXIBLES. LIMPIE LA SUPERFICIE DEL LAVABO CON UN LIMPIADOR NO ABRASIVO PARA COLOCAR EL CONTRAPESO SOPORTE GRIFO NUEVO. ARO DE GOMA TRENZADA EN EL GRIFO (2). DOS MANGUERAS TRENZADAS TUERCA...
- Page 17 1.B - El cartucho es defectuoso 2 - Caudal insuficiente 1.B - 2.A - Suciedad en el aireador Vigo para el reemplazo 4 - Grifo flojo 2.A - Retire y remoje o limpie con un producto no abrasivo (p. ej., vinagre) 2.B -...
- Page 18 JA PARTIR DEL 1 DE ABRIL DE 2013 de la fecha inicial de compra por parte del propietario, contratista o constructor a VIGO o a un distribuidor autorizado de VIGO, de por vida para el propietario original o usuario final.
