- Page 1 EN User Manual | Dishwasher ESA63200SX...
-
Page 2: Table Of Contents
Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. PRODUCT DESCRIPTION................6 4. CONTROL PANEL..................7 5. -
Page 3: General Safety
• Children of less than 3 years of age should be kept away from the appliance unless continuously supervised. • Children should be supervised to ensure that they do not play with the appliance. • Keep detergents away from children. •... -
Page 4: Safety Instructions
• If the appliance has ventilation openings in the base, they must not be covered e.g. by a carpet. • The appliance is to be connected to the water mains using the new supplied hose-sets. Old hose sets must not be reused. - Page 5 2.4 Use sensors, software and firmware including reset software. The following spare parts • Do not put flammable products or items are available for at least 10 years after the that are wet with flammable products in, model has been discontinued: door hinge near or on the appliance.
-
Page 6: Product Description
3. PRODUCT DESCRIPTION Worktop Lower basket Upper spray arms Upper basket Lower spray arm Cutlery drawer Filters Rating plate The graphic is a general overview. For Salt container more details, refer to other chapters or documents provided with the appliance. Air vent Rinse aid dispenser Detergent dispenser... -
Page 7: Control Panel
4. CONTROL PANEL On/off button Option button Program button Indicators Programme indicators Start button Display Delay button 4.1 Indicators Indicator Description Salt indicator. It is on when the salt container needs refilling. It is always off while the pro‐ gramme operates. Rinse aid indicator. -
Page 8: Programmes
Indicator Description ExtraHygiene indicator. 5. PROGRAMMES The order of the programmes in the table may not reflect their sequence on the control panel. Programme Dishwasher Degree of Programme phases Options load soil Crockery, cut‐ Normal, lightly • Prewash • ExtraPower lery, pots, pans dried-on •... -
Page 9: Consumption Values
Programme Dishwasher Degree of Programme phases Options load soil None Cleaning the • Cleaning 70 °C appliance inte‐ • Intermediate rinse rior • Final rinse • AirDry • Prewash This programme offers the most efficient use of water and energy consumption for crockery and cutlery with normal soil. -
Page 10: Options
For any other questions regarding your dishwasher, refer to the service book provided with your appliance. 6. OPTIONS prevents rapid changes in the dishwashing temperature of the selected programme and reduces it to 45 °C. Desired options must be activated every time before you start a programme. -
Page 11: How To Set The Programme Selection Mode
The saved settings remain valid until you To enter user mode, press and hold change them again. simultaneously until the indicators flash and the How to set the programme selection display is blank. mode 7.2 The water softener The appliance is in programme selection The water softener removes minerals from mode when the programme indicator the water supply, which would have a... -
Page 12: The Rinse Aid Level
Regeneration process when it occurs at any point at the beginning For the correct water softener operation, the or in the middle of a programme. resin of the softener device needs to be regenerated regularly. This process is automatic and is the part of the normal All the consumption values mentioned in dishwasher operation. -
Page 13: Before First Use
When AirDry opens the door, the display • The indicator still flashes. shows the remaining time of the running • The remaining indicators are off. programme. • The display shows the current setting: e.g. = level 4. CAUTION! 2. Press repeatedly to change the Do not try to close the appliance door setting. -
Page 14: Daily Use
8.2 How to fill the rinse aid The salt is used to recharge the resin in the dispenser water softener and to assure good washing results in daily use. How to fill the salt container 1. Turn the cap of the salt container counterclockwise and remove it. -
Page 15: Using The Detergent
9.2 Setting and starting a • If the rinse aid indicator is on, fill the programme rinse aid dispenser. 3. Load the baskets. 4. Add the detergent. The Auto Off function 5. Set and start a programme suitable for the type of load and the degree of soil. This function decreases energy consumption 9.1 Using the detergent by deactivating automatically the appliance... -
Page 16: Cancelling The Delay Start While The Countdown Operates
energy consumption and the programme Press and hold simultaneously duration. After closing the door, the appliance until the appliance is in programme selection continues from the point of interruption. mode. Cancelling the programme If the door is opened for more than 30 seconds during the drying phase, the Press and hold simultaneously running programme ends. -
Page 17: Using Salt, Rinse Aid And Detergent
– Make sure that the current level of the 3. Start the shortest programme with a water softener agrees with the rinsing phase. Do not add detergent and hardness of the water supply. do put dishes in the baskets. – Follow the instructions in the chapter 4. -
Page 18: Care And Cleaning
10.6 Unloading the baskets 1. Let the tableware cool down before you After the programme is completed, water remove it from the appliance. Hot items can still remain on the inside surfaces of can be easily damaged. the appliance. 2. First remove items from the lower basket, then from the upper basket. -
Page 19: Cleaning The Lower Spray Arm
7. Reassemble the filters (B) and (C). 8. Put back the filter (B) in the flat filter (A). Turn it clockwise until it locks. 2. Remove the filter (C) out of filter (B). 3. Remove the flat filter (A). 4. Wash the filters. CAUTION! An incorrect position of the filters can cause bad washing results and damage... - Page 20 2. Wash the spray arm under running water. 1. Pull out the upper basket. Use a thin pointed tool, e.g. a toothpick, 2. To detach the spray arm, turn the to remove particles of soil from the holes. mounting element clockwise. 3.
-
Page 21: Troubleshooting
12. TROUBLESHOOTING Refer to the below table for information on WARNING! possible problems. Improper repair of the appliance may With some problems, the display shows an pose a danger to the safety of the user. alarm code. Any repairs must be performed by qualified personnel. - Page 22 Problem and alarm code Possible cause and solution Technical malfunction of the appli‐ • Switch the appliance off and on. ance. The display shows iC0 or iC3. The level of water inside the appli‐ • Switch the appliance off and on. ance is too high.
- Page 23 12.1 The dishwashing and drying results are not satisfactory Problem Possible cause and solution Poor washing results. • Refer to "Daily use", "Hints and tips" and the basket loading leaf‐ let. • Use more intensive washing programme. • Activate the ExtraPower option to improve the washing results of a selected programme.
-
Page 24: Technical Information
Problem Possible cause and solution Limescale deposits on the tableware, • The level of salt is low, check the refill indicator. on the tub and on the inside of the • The cap of the salt container is loose. door. •... -
Page 25: Environmental Concerns
For more detailed information about the energy label, visit www.theenergylabel.eu. 14. ENVIRONMENTAL CONCERNS appliances marked with the symbol with Recycle materials with the symbol . Put the the household waste. Return the product to packaging in relevant containers to recycle it. your local recycling facility or contact your Help protect the environment and human municipal office. - Page 28 156825470-A-442023...
