- Page 1 EN User Manual | Dishwasher ESA17200UW ESA17200UX...
-
Page 2: Table Of Contents
Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. PRODUCT DESCRIPTION................6 4. CONTROL PANEL..................7 5. -
Page 3: General Safety
• Children of less than 3 years of age should be kept away from the appliance unless continuously supervised. • Children should be supervised to ensure that they do not play with the appliance. • Keep detergents away from children. •... -
Page 4: Safety Instructions
• If the appliance has ventilation openings in the base, they must not be covered e.g. by a carpet. • The appliance is to be connected to the water mains using the new supplied hose-sets. Old hose sets must not be reused. - Page 5 and aquastops, structural and interior WARNING! parts related to door assemblies, printed circuit boards, electronic displays, Dangerous voltage. pressure switches, thermostats and sensors, software and firmware including 2.4 Use reset software. Please note that some of • Do not put flammable products or items these spare parts are only available to that are wet with flammable products in, professional repairers, and that not all...
-
Page 6: Product Description
3. PRODUCT DESCRIPTION Upper spray arm Cutlery basket Lower spray arm Lower basket Filters Upper basket Rating plate Salt container The graphic is a general overview. For Air vent more details, refer to other chapters or documents provided with the appliance. Rinse aid dispenser Detergent dispenser ENGLISH... -
Page 7: Control Panel
4. CONTROL PANEL On/off indicator Start button Programme marker Programme knob Indicators Delay button 4.1 Indicators Indicator Description Drying phase indicator. It is on when you select a programme with the drying phase. It flash‐ es when the drying phase operates. Salt indicator. -
Page 8: Consumption Values
Programme Dishwasher load Degree of soil Programme phases Crockery, cutlery, pots, Normal, lightly dried-on • Prewash pans • Dishwashing 50 °C • Intermediate rinse • Final rinse 60 °C • Drying • AirDry Crockery, cutlery, pots, Normal to heavy, dried- •... -
Page 9: Information For Test Institutes
Water Energy Duration Programme 1)2) (kWh) (min) 0.020 The pressure and the temperature of the water, the variations of the mains supply, the options, the quantity of dishes and the degree of soil can change the values. The values for programmes other than ECO are indicative only. 5.2 Information for test institutes To receive the necessary information for conducting performance tests (e.g. - Page 10 Water hardness German de‐ French de‐ mmol/l mg/l (ppm) Clarke de‐ Water softener grees (°dH) grees (°fH) grees level 47 - 50 84 - 90 8.4 - 9.0 835 - 904 58 - 63 43 - 46 76 - 83 7.6 - 8.3 755 - 834 53 - 57...
-
Page 11: How To Deactivate The Rinse Aid Empty Notification
Each performed softener rinse (possible more for best drying performance, always use rinse than one in the same cycle) may prolong the aid. programme duration by another 5 minutes If standard detergent or multi-tablets without when it occurs at any point at the beginning rinse aid are used, activate the notification to or in the middle of a programme. -
Page 12: How To Deactivate Airdry
How to deactivate AirDry The appliance must be in programme selection mode. Make sure that the programme marker on the knob is set to the on/off position. 1. To enter the user mode, press and hold . At the same time turn the knob counterclockwise until the programme marker indicates the first programme. -
Page 13: How To Fill The Salt Container
7.3 How to fill the rinse aid The salt is used to recharge the resin in the dispenser water softener and to assure good washing results in daily use. 7.2 How to fill the salt container 1. Turn the cap of the salt container counterclockwise and remove it. -
Page 14: Using The Detergent
8.2 Setting and starting a • If the rinse aid indicator is on, fill the programme rinse aid dispenser. 3. Load the baskets. 4. Add the detergent. Starting a programme 5. Start the programme. 8.1 Using the detergent 1. Open the water tap. 2. -
Page 15: Opening The Door While The Appliance Operates
Opening the door while the appliance The Auto Off function operates This function decreases energy consumption by deactivating automatically the appliance Opening the door while a programme is when it is not operating. running stops the appliance. It may affect the energy consumption and the programme The function comes into operation: duration. -
Page 16: Using Salt, Rinse Aid And Detergent
9.2 Using salt, rinse aid and 9.4 Loading the baskets detergent • Always use the whole space of the baskets. • Only use salt, rinse aid and detergent • Use the appliance to wash dishwasher- designed for dishwasher. Other products safe items only. -
Page 17: Care And Cleaning
After the programme is completed, water can still remain on the inside surfaces of the appliance. 10. CARE AND CLEANING WARNING! CAUTION! Before maintenance, deactivate the If unable to remove the foreign objects, appliance and disconnect the mains plug contact an Authorised Service Centre. from the main socket. -
Page 18: Cleaning The Lower Spray Arm
7. Reassemble the filters (B) and (C). 8. Put back the filter (B) in the flat filter (A). Turn it clockwise until it locks. 2. Remove the filter (C) out of filter (B). 3. Remove the flat filter (A). 4. Wash the filters. CAUTION! An incorrect position of the filters can cause bad washing results and damage... -
Page 19: Cleaning The Upper Spray Arm
3. To install the spray arm back, press it downwards. 2. Wash the spray arm under running water. Use a thin pointed tool, e.g. a toothpick, to remove particles of soil from the holes. 10.6 Cleaning the upper spray arm Do not remove the upper spray arm. - Page 20 Problem and alarm code Possible cause and solution The programme does not start. • Make sure that the appliance door is closed. • Press the start button. • If the delay start is set, cancel the setting or wait for the end of the countdown.
- Page 21 Problem and alarm code Possible cause and solution Technical malfunction of the appliance. • Switch the appliance off and on. • The indicator flashes 12 times intermit‐ tently. • The light related to the start button flashes continuously. The level of water inside the appliance is too •...
- Page 22 WARNING! We do not recommend using the appliance until the problem has been completely fixed. Unplug the appliance and do not plug it in again until you are certain that it operates correctly. 11.1 The dishwashing and drying results are not satisfactory Problem Possible cause and solution Poor washing results.
-
Page 23: Technical Information
Problem Possible cause and solution There are residues of detergent in the • The detergent tablet got stuck in the dispenser and was not washed dispenser at the end of the pro‐ away by water. gramme. • Water cannot wash away the detergent from the dispenser. Make sure that the spray arm is not blocked or clogged. -
Page 24: Environmental Concerns
It is possible to find information related to the rating plate of the appliance. Refer to the performance of the product in the EU EPREL chapter "Product description". database using the link https:// For more detailed information about the eprel.ec.europa.eu and the model name and energy label, visit www.theenergylabel.eu. - Page 28 156824150-A-352023...
