Dorel Home Products 5305306COMS Assembly Instructions Manual

Dorel Home Products 5305306COMS Assembly Instructions Manual

Full size daybed wall bed
Hide thumbs

Advertisement

Table of Contents

5305306COMS (Federal White)
5305335COMS (Nightfall Oak)
Full Size Daybed Wall Bed
Date of Purchase ___ / ___ / ___
Lot Number:
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Visit: www.dorelhome.com
to view the limited warranty valid
in the U.S. and Canada.
THIS INSTRUCTION BOOKLET CONTAINS WARNINGS AND
PRODUCT SAFETY INFORMATION. DO NOT PROCEED WITHOUT
REVIEWING THOUROUGHLY. FOR ANY QUESTIONS, CONTACT
CUSTOMER SERVICE.
Difficulty Meter
Easy
B345305000COMS0
Professional
(see page 2)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5305306COMS and is the answer not in the manual?

Questions and answers

Related Manuals for Dorel Home Products 5305306COMS

Summary of Contents for Dorel Home Products 5305306COMS

  • Page 1 5305306COMS (Federal White) 5305335COMS (Nightfall Oak) Full Size Daybed Wall Bed B345305000COMS0 Date of Purchase ___ / ___ / ___ Lot Number: THIS INSTRUCTION BOOKLET CONTAINS WARNINGS AND PRODUCT SAFETY INFORMATION. DO NOT PROCEED WITHOUT REVIEWING THOUROUGHLY. FOR ANY QUESTIONS, CONTACT CUSTOMER SERVICE.
  • Page 2 Part 1 - Installation • Installation steps will require the use of one professional and one other person to assist. • The second person must be able to lift wall bed components and hold them in position while the professional installs hardware.

  • Page 3: Before You Start

    Before You Start Read through each step carefully and follow the proper order. Separate and count all your parts and hardware before attempting assembly. Parts are labeled on the surface or edge of the part Open your item in an area you plan to keep it. Give yourself enough room for the installation and assembly process.

  • Page 4: Board Identification

    Board Identification Not actual size dorelhome.com...
  • Page 5 Board Identification parts for 5305306COMS (Federal White) Parts List ITEM PART NUMBER DESCRIPTION 35305306010 LEFT PANEL 35305306020 RIGHT PANEL 35305306030 35305306040 BOTTOM 35305306050 VALANCE 35305306060 KICK 35305306071 UPPER BACK PANEL 35305306080 CENTER BACK PANEL 35305306090 BACK SHELF 35305306100 HEADBOARD PANEL...
  • Page 6 Board Identification parts for 5305335COMS (Nightfall Oak) Parts List ITEM PART NUMBER DESCRIPTION 35305335010 LEFT PANEL 35305335020 RIGHT PANEL 35305335030 35305335040 BOTTOM 35305335050 VALANCE 35305335060 KICK 35305335071 UPPER BACK PANEL 35305335080 CENTER BACK PANEL 35305335090 BACK SHELF 35305335100 HEADBOARD PANEL 35305335111 BOTTOM STRINGER 35305335120...

  • Page 7: Part List

    WARNING! CHOKING HAZARD - Hardware bag contains small parts. Keep out of reach of children. Part List Actual Size Note that your unit may contain extra hardware (x26) (x36) (x36) (x19) (x19) #A21660 #A22620 #A22610 #A22920 #A22910 wood dowel cam lock cam bolt connector connector bolt...
  • Page 8 WARNING! CHOKING HAZARD - Hardware bag contains small parts. Keep out of reach of children. Part List Actual Size Note that your unit may contain extra hardware (x4) #A65685 euro hinge plate (x12) (x8) #A53470 #A53460 door bracket door bracket (x4) (x2) (x2)
  • Page 9 Bed Frame Identification Not Actual Size Note: Not all parts will be identified. Mattress Holder (2) Right Assembly Left Assembly 4813096-21c 4813096-21d 4813096-21b 4813096-21a Right Pivot Arm Wood Slat (28) Left Pivot Arm Gas Piston (2) Plastic Cap (56) U-Bracket (4) 4813096-21f 4813096-21g 4813096-21j...

  • Page 10: Part 1 - Installation

    Part 1 - Installation Installation steps will require the use of one professional and one other person to assist. Installation steps will cover pages 11-47. Professional is required for: • all hardware fastening steps • identifying wall structure and appropriate attachment hardware to use •...
  • Page 11 STEP 1 (x4) (x4) (x6) Proper orientation of Cam Lock Proper orientation of Cam Lock FLIP dorelhome.com...
  • Page 12 STEP 2 (x4) (x6) Proper orientation of Cam Lock Proper orientation of Cam Lock dorelhome.com...
  • Page 13 STEP 3 (x6) (x8) (x4) Proper orientation of Connector Proper orientation of Cam Lock Proper orientation of Cam Lock dorelhome.com...
  • Page 14 STEP 4 (x4) (x2) (x4) Proper orientation of Connector FLIP Proper orientation of Cam Lock Proper orientation of Cam Lock dorelhome.com...
  • Page 15 STEP 5 (x8) dorelhome.com...
  • Page 16 STEP 6 (x4) (x4) dorelhome.com...
  • Page 17 STEP 7 (x3) (x3) Proper orientation of Connector dorelhome.com...
  • Page 18 STEP 8 turn clockwise to lock in place Assembly orientation is critical! Connector bolt (4) is closer to the edge. Center Shelf (P) should be almost flush with Center Shelf Rail (Q). dorelhome.com...
  • Page 19 STEP 9 Proper orientation of Cam Lock (x4) (x2) Proper orientation of Cam Lock dorelhome.com...
  • Page 20 STEP 10 (x2) (x4) (x8) Proper orientation of Cam Lock Proper orientation of Connector Proper orientation of Connector Proper orientation of Cam Lock dorelhome.com...
  • Page 21 STEP 11 (x4) Turn Top (C) over and screw in cam bolts (2) as shown. dorelhome.com...
  • Page 22 STEP 12 (x2) (x4) Proper orientation of Cam Lock Proper orientation of Cam Lock dorelhome.com...
  • Page 23 STEP 13 (x16) dorelhome.com...
  • Page 24 STEP 14 (x8) (x1) The Left Pivot Arm (21e) is located in the 4813096COM Wall Bed Mechanism box dorelhome.com...
  • Page 25 STEP 15 (x16) dorelhome.com...
  • Page 26 STEP 16 (x1) (x8) The Right Pivot Arm (21f) is located in the 4813096COM Wall Bed Mechanism box dorelhome.com...
  • Page 27 STEP 17 turn clockwise to lock in place Assembly orientation is critical! unfinished surface REFERENCE HOLE dorelhome.com...
  • Page 28 STEP 18 turn clockwise to lock in place dorelhome.com...
  • Page 29 STEP 19 turn clockwise to lock in place unfinished surface dorelhome.com...
  • Page 30 STEP 20 dorelhome.com...
  • Page 31 STEP 21 Carefully turn the assembly onto it's back as shown. Assemble Left Partition (M) and Right Partition (N) onto the Top (C). Lock cams. Left & Right Partitions (M & N) finished edges to be facing up. finished edge finished surface finished surface dorelhome.com...
  • Page 32 STEP 22 (x4) Lock cams (x2) dorelhome.com...
  • Page 33 STEP 23 Turn the assembly back onto its side before starting this step. finished surface dorelhome.com...
  • Page 34 STEP 24 unfinished surface dorelhome.com...
  • Page 35 STEP 25 unfinished surface unfinished surface dorelhome.com...
  • Page 36 STEP 26 Start at one end and work your way to the other end to line parts up before locking cams. dorelhome.com...
  • Page 37 STEP 27 (x4) (x4) Carefully, lay the unit onto its front so the glides will be facing the wall. Tap in the Bushings (14) with a hammer and then screw in the Glides (13) all the way. dorelhome.com...
  • Page 38 The next steps are to attach your unit to the wall. Wall attachment steps will cover pages 39-47. The following steps are required to be completed by a professional. The second person may assist by holding the cabinet in position while the professional completes alignment, leveling and installation steps.
  • Page 39 STEP 28 Carefully, place the unit FLUSH against the wall There are notches provided at the back of your unit. These notches are to fit around the baseboard on your wall. If your baseboard is higher or thicker than the notches provided on the unit, you will need to remove the baseboard, cut it down to fit on both sides of your unit, then...
  • Page 40 STEP 29 Using a level, be sure the unit is square (height, width, and depth) to function properly Please note on the following steps: The Valance (E) has been removed to better show the holes in the Upper Back Panel (G). A ladder will be required.
  • Page 41 What type of wall do you have? For Steps 30 & 31 you will need to choose between two types of screws to use based on the type of wall you are installing this product to. Wooden & Metal Studs - Follow Steps 30 & 31 - Wooden &...
  • Page 42 STEP 30 - Wooden & Metal Studs Locate at least 3 DIFFERENT studs, in the horizontal direction, but 4 is better. Locate the studs in the wall, using a stud finder. Using a pencil, mark the stud locations on the upper Average distance between studs (16") surface of the Upper Back Panel (G) where the...
  • Page 43 STEP 31 - Wooden & Metal Studs (x8) (x8) First, make sure that your unit is still level in all directions. As shown in the view to the right, fasten the unit to the wall studs with screw (12) and washer (27).
  • Page 44 STEP 31 continued... Example of 4 screws being placed horizontally in wall studs on part G and part K. Please note this is just an example - all wall stud distances are different. dorelhome.com...
  • Page 45 STEP 30 - Concrete Choose 4 horizontal predrilled holes equally across the Upper Back Panel (G). Carry and use the same predrilled holes down to the Bottom Stringer (K). Using a pencil, mark the locations on the upper surface of the Upper Back Panel (G) where the predrilled holes are provided.
  • Page 46 STEP 31 - Concrete (x8) (x8) First, make sure that your unit is still level in all directions. As shown in the view to the right, fasten the unit to the concrete wall with screw (28) and washer (27). The view shows the Upper Back Panel (G) but do the same for Bottom Stringer (K).
  • Page 47 STEP 31 continued... Example of 4 screws being placed horizontally in wall studs on part G and part K. Please note this is just an example - all wall stud distances are different. dorelhome.com...
  • Page 48 Part 2 - Assembly The next steps are to assemble the metal bed frame mechanism and door panels. Assembly steps will cover pages 49-71. As mentioned on page 2: Choose one of the two options below... • You may continue to use the Professional and a second person, •...
  • Page 49 STEP 32 (x3) (x4) (x1) (x1) First, press each rubber foot (21u) into each hole in the Leg (21c) as shown below. Then, join and assemble the Left & Right bed frame assemblies (21a & 21b) as shown below using bolts (21o) with the provided hex key (21s).
  • Page 50 STEP 33 (x8) (x8) (x1) (x4) Place the four U-Brackets (21i) in the locations. Use the bolts (21o) and washers (21q) to assemble the U-Brackets (21i) to the joined bed frame assemblies (21a & 21b) as shown. Use the provided hex key (21s) to assemble.
  • Page 51 STEP 34 (x1) (x4) (x2) Assemble the mattress holders (21d) to the frame assemblies (21a & 21b) with bolts (21p) as shown to the right. Use the provided hex key (21s) to assemble. dorelhome.com...
  • Page 52 STEP 35 (x4) (x4) (x4) long end short end long end long end Assemble two pistons (21h) to each side of the bed frame assembly The ends of both pistons need with clevis pins (21l) to be inserted into the groove and secure each one of the bed frame when assembled.
  • Page 53 STEP 36 (x1) (x2) (x2) The cabinet is not shown to allow a clear view of the bed frame assembly With a person on each side, lift the bed assembled bed frame, line up the holes of the frame assembly with the large bushing hole of the Left and Right Pivot arm (21e &...
  • Page 54 STEP 37 Critical Step... Please read directions carefully! (x4) (x1) With a person on each side, carefully lift the bed frame in the closed position. While one person pushes the bed frame into the cabinet, beyond the 90 degrees, the other person is to engage the Gas Piston (21h) on each side of the unit, to the pin of the Left and Right Pivot Arm (21e &...

  • Page 55: Bed Frame

    STEP 37 continued... This image shows the bed frame pushed into the cabinet, beyond 90 degrees. BED FRAME 90 DEGREES (WHEN THE BED FRAME IS IN THE UPRIGHT MOST POSITION) Please note: it is normal to see the bed frame in this state prior to the gas pistons being installed.
  • Page 56 STEP 38 (x2) (x2) (x1) Be sure the bed frame is fully assembled to the unit cabinet. (This step could use both people). Once certain, carefully pull the bed frame down, then assemble the Leg (21c) as shown with the clevis pins (21m) and cotter pins (21n). The cabinet is not shown to allow a clear view of the bed frame assembly...
  • Page 57 STEP 39 (x8) (x4) Proper orientation of bracket unfinished edge dorelhome.com...
  • Page 58 STEP 40 (x2) (x1) Have one person turn and hold the Left Door Assembly (T) steady on its side as shown. The other person will attach the Handle (25) on the opposite side of the brackets (19). dorelhome.com...
  • Page 59 STEP 41 (x8) (x4) Proper orientation of bracket unfinished edge dorelhome.com...
  • Page 60 STEP 42 (x2) (x1) Have one person turn and hold the Right Door Assembly (U) steady on its side as shown. The other person will attach the Handle (25) on the opposite side of the brackets (19). dorelhome.com...
  • Page 61 STEP 43 IMPORTANT: First, unlock and flip the leg into the cabinet. Then, lower the bed frame down a bit to allow clearance to hook door assemblies (T&U). This step could use both people. Carefully lift the Left Door Assembly (T), position the Brackets (19) over the two Support Rails of the Bed Frame, and drop into position.
  • Page 62 STEP 44 (x12) (x12) (x12) Screw (6) attaches the door bracket (20) to the door panel assemblies (T & U). Screw (7) attaches the door bracket (20) to the bed frame. Align the entire assembly so that the edges are lined up with the bed frame and push up against the leg.
  • Page 63 STEP 44 continued... View is looking from the top... showing location of brackets (20). Bed Frame Leg dorelhome.com...
  • Page 64 STEP 45 (x56) (x28) Press a Plastic Cap (21j) at each end of a Wood Slat (21g). Press both Plastic Caps (21j), attached to the Wood Slat, into the holes of the Metal Bed Frame. Repeat the procedure for all 28 wood slats and 56 plastic caps.
  • Page 65 STEP 46 (x5) Press in face connector (10) into the holes in the Fixed Shelf (L) then engage the other end of the face connectors (10) into the holes in the Stop Rail (R). Press the two parts together to lock together. Please note: the parts will be loose in the holes until you press both parts together.
  • Page 66 STEP 47 Front of unit is not shown to allow a clear view of the kick and bottom While one person slightly opens the bed frame and holds it in place, insert the connector bolts installed open frame slightly in the Kick (F) into the connectors of the Bottom (D).
  • Page 67 STEP 48 (x12) Place twelve Shelf Supports (11) in desired locations. Place both Side Shelves (O) and Center Shelf (P). dorelhome.com...
  • Page 68 STEP 49 (x4) (x2) (x8) (x4) (x2) Press in door bumpers (17). Knob (26) will be assembled on the opposite side of the hinges (24). dorelhome.com...
  • Page 69 STEP 50 (x4) dorelhome.com...
  • Page 70 STEP 51 Assemble both Upper Door Assemblies (S) as shown. Slide each hinge (24) from the door into the hinge plates (21) located on the Left Panel (A) and Right Panel (B). Eccentric adjustment screw - shifts the whole hinge up and down.
  • Page 71 STEP 52 This step is optional... Place the glissando soft close (22) on the lower hinge (24) of each door (S). (x2) Hooks dorelhome.com...
  • Page 72 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. This bed is designed to accommodate a Full Size Mattress, up to 10" inches thick. * with a maximum weight of 60 lbs (27.2 kgs) * with a minimum weight of 30 lbs (13.6 kgs) After you have finished installing and...
  • Page 73 Register your product to receive the following: * New trend details - sneak peek on what's new * Surveys - have a voice within our community * Exclusive deals and discount codes * Quick and easy replacement part service To register your product, visit ameriwoodhome.com Visit your local retailer's website, rate your purchased product and leave us some feedback! dorelhome.com...
  • Page 74 Español Portada: Tamaño completo - Cama de día de pared ADVERTENCIAS E INFORMACIÓN SOBRE LA SEGURIDAD DEL PRODUCTO. NO PROCEDA SIN REVISAR DETENIDAMENTE. ANTE CUALQUIER PREGUNTA, CONTÁCTESE CON EL SERVICIO DE ATENCIÓN AL CLIENTE. ¡No devuelva este producto! Contáctese primero con nuestro equipo del servicio de atención al cliente para obtener ayuda. Llame: 1-800-489-3351 (gratuito) Visite: www.dorelhome.com Para ver la garantía limitada válida...
  • Page 75 Español Parte 2: Montaje - Los pasos del montaje requieren emplear a dos personas que deberán ser capaces de alzar y fijar las partes de la cama con elementos de ferretería: - Puede seguir empleando al profesional y a una segunda persona, o bien - Emplear a dos personas que tengan experiencia en el montaje de muebles listos para montar.
  • Page 76 Español Página 4-6: Identificación de la placa J- Panel de cabecera Tamaño no real K- Larguero inferior L- Estante fijo A- Panel izquierdo M- Partición izquierda B- Panel derecho N- Partición derecha C- Arriba Estante lateral O D- Parte inferior P- Estante central E- Cenefa Q- Riel de estante central...
  • Page 77 Español Página 9: Identificación del marco de la cama No es el tamaño real No todas las partes estarán identificadas. 21l - Pasador de horquilla grande 21a - Montaje izquierdo 21m - Pasador de horquilla pequeño 21b - Montaje derecho 21n - Pasador de chaveta 21c - Pata 21o - Perno M6 x 16 mm...
  • Page 78 Español Página 11: Paso 1 Orientación de la cerradura de leva Voltear Página 12: Paso 2 Orientación de la cerradura de leva Página 13: Paso 3 Orientación de la cerradura de leva Orientación correcta del conector Página 14: Paso 4 Orientación de la cerradura de leva Orientación correcta del conector Voltear...
  • Page 79 Español Página 26: Paso 16 El brazo pivotante derecho (21f) se encuentra en la caja del mecanismo de la cama abatible 4813096COM Página 27: Paso 17 Gire en el sentido de las agujas del reloj para bloquearlo en su lugar ¡La orientación del montaje es fundamental! Superficie inacabada Orificio de referencia...
  • Page 80 Español Página 38: Los siguientes pasos consisten en fijar la unidad a la pared. Los pasos de la fijación a la pared abarcarán las páginas 39-47. Advertencia: Instalación profesional requerida. Este producto puede desprenderse de la pared y puede provocar lesiones severas y la muerte si no se lo fija correctamente. Se requiere de una instalación profesional.
  • Page 81 Español Página 39: Paso 28 Con cuidado, coloque la unidad AL RAS de la pared. En la parte trasera de la unidad hay muescas. Estas deben coincidir con el zócalo de la pared. Si el zócalo es más alto o más grueso que las muescas incluidas en la unidad, tendrá que quitar el zócalo, cortarlo para que quepa en ambos lados de la unidad y volver a fijarlo luego a la pared.
  • Page 82 Español Página 43: Paso 31, Montantes de madera y de metal En primer lugar, asegúrese de que la unidad esté nivelada en todas las direcciones. Tal como se muestra en la vista de la derecha, fije la unidad a los montantes con tornillos (12) y arandelas (27).
  • Page 83 Español Página 48: Parte 2, Montaje Los siguientes pasos consisten en montar el mecanismo del marco metálico de la cama y los paneles de las puertas. Los pasos del montaje abarcarán las páginas 49-71. Tal como se mencionó en la página 2, elija una de las dos opciones siguientes: - Puede seguir empleando al profesional y la segunda persona, o bien - Emplear a dos personas que tengan experiencia con el montaje de muebles listos para montar.
  • Page 84 Español Página 52: Paso 35 Monte dos pistones (21h) en cada lado del ensamblaje del marco de la cama con pasadores de chaveta (21l) y asegure cada uno con una chaveta (21n). Durante su montaje, debe insertar los extremos de ambos pistones en la ranura del marco de la cama. Extremo largo Extremo corto Página 53: Paso 36...
  • Page 85 Español Página 55: Paso 37 (continuación) Esta imagen muestra el marco de la cama empujado hacia el gabinete, más allá de los 90 grados. Marco de la cama 90 GRADOS (CUANDO EL MARCO DE LA CAMA ESTÁ EN LA POSICIÓN MÁS VERTICAL) Tenga en cuenta: Es normal ver el marco de la cama en este estado antes de la instalación de los pistones a gas.
  • Page 86 Español Página 61: Paso 43 IMPORTANTE: Primero, desbloquee y voltee la pata en el gabinete. Luego, baje un poco el marco de la cama para dejar espacio para enganchar los conjuntos de puertas (T&U). Este paso podría usar a ambas personas. Levante con cuidado el conjunto de la puerta izquierda (T), coloque los soportes (19) sobre los dos rieles de soporte del marco de la cama y colóquelos en su posición.
  • Page 87 Español Página 66: Paso 47 La parte delantera de la unidad no se muestra para permitir una vista clara de la patada y la parte inferior Mientras una persona abre ligeramente el marco de la cama y lo mantiene en su lugar, inserte los pernos de conexión instalados en el Kick (F) en los conectores de la parte inferior (D).
  • Page 88 Español Página 72: Cargas máximas Esta unidad ha sido diseñada para soportar las cargas máximas mostradas. Exceder estos límites de carga podría generar un hundimiento, inestabilidad, el desplome del producto o lesiones graves. Esta cama está diseñada para acomodar un colchón tamaño Full, de hasta 10" pulgadas de grosor. * con un peso máximo de 60 libras (27.2 kgs) * con un peso mínimo de 30 libras (13.6 kgs) Una vez que haya terminado de instalar y montar la cama abatible, conserve el manual de...
  • Page 89 Français Couverture : Pleine grandeur - Lit de jour mural AVERTISSEMENTS ET INFORMATIONS RELATIVES À LA SÉCURITÉ DU PRODUIT. NE PROCÉDEZ PAS SANS LES LIRE ATTENTIVEMENT. POUR TOUTE QUESTION, CONTACTEZ LE SERVICE CLIENTÈLE. Ne renvoyez pas ce produit! Contactez d'abord notre service clientèle pour obtenir de l'aide. Appelez-nous : 1-800-489-3351 (gratuit) Rendez-vous sur : www.dorelhome.com pour consulter la garantie limitée valable aux États-Unis et au Canada.
  • Page 90 Français Partie 2 - Assemblage - Les étapes d'assemblage nécessitent l'intervention de deux personnes qui doivent être en mesure de soulever et de fixer les pièces du lit à l'aide de la quincaillerie : - Vous pouvez continuer à utiliser le professionnel et une deuxième personne, ou - Faites appel à...
  • Page 91 Français Page 4-6 : Identification du panneau J- Panneau de tête de lit Taille non réelle K- Lisse inférieur L- Étagère fixe A- Panneau de gauche M- Partition gauche B- Panneau de droite N- Partition de droite C- Haut O- Étagère latérale D- Bas P- Étagère centrale E- Valance...
  • Page 92 Français Page 9 : Identification du cadre de lit Pas la taille réelle Toutes les pièces ne sont pas identifiées. 21l - Grand axe de chape 21a - Assemblage gauche 21m - Petit axe de chape 21b - Assemblage droit 21n - Goupille fendue 21c - Pied 21o - Boulon M6 x 16 mm...
  • Page 93 Français Page 11 : Étape 1 Orientation du verrouillage de la came Tourner Page 12 : Étape 2 Orientation du verrouillage de la came Page 13 : Étape 3 Orientation du verrouillage de la came Orientation correcte du connecteur Page 14 : Étape 4 Orientation du verrouillage de la came Orientation correcte du connecteur Tourner...
  • Page 94 Français Page 26 : Étape 16 Le bras pivotant droit (21f) est situé dans la boîte du mécanisme de lit pliant 4813096COM Page 27 : Étape 17 Tournez dans le sens des aiguilles d’une montre pour le verrouiller en place L’orientation de l’assemblée est essentielle ! Surface non finie Trou de référence...
  • Page 95 Français Page 38: Les étapes suivantes consistent à fixer votre appareil au mur. Les étapes de la fixation murale sont décrites aux pages 39 à 47. Avertissement - Une installation professionnelle est nécessaire - Ce produit peut se détacher du mur et provoquer des blessures graves, voire mortelles, s'il n'est pas correctement fixé.
  • Page 96 Français Page 39: Étape 28 Placez soigneusement l'appareil à plat contre le mur. Des encoches sont prévues à l'arrière de votre appareil. Ces encoches s'adaptent à la plinthe de votre mur. Si votre plinthe est plus haute ou plus épaisse que les encoches prévues sur l'appareil, vous devrez retirer la plinthe, la couper pour qu'elle s'adapte aux deux côtés de l'appareil, puis la fixer à...
  • Page 97 Français Page 43: Étape 31 - Montants en bois et en métal Tout d'abord, assurez-vous que votre appareil est toujours de niveau dans toutes les directions. Comme le montre la vue de droite, fixez l'appareil aux montants du mur à l'aide de la vis (12) et de la rondelle (27).
  • Page 98 Français Page 48: Partie 2 - Assemblage Les étapes suivantes consistent à assembler le mécanisme du cadre de lit en métal et les panneaux de porte. Les étapes de l'assemblage sont décrites aux pages 49 à 71. Comme indiqué à la page 2 : choisissez l'une des deux options ci-dessous... - Vous pouvez continuer à...
  • Page 99 Français Page 52: Étape 35 Montez deux pistons (21h) de chaque côté du cadre de lit avec des goupilles fendues (21l) et fixez chacun avec un clavier (21n). Pendant l’assemblage, vous devez insérer les extrémités des deux pistons dans la fente du cadre de lit. Long End Fin courte Page 53: Étape 36...
  • Page 100 Français Page 55 : Étape 37 suite... Cette image montre le cadre de lit poussé dans l’armoire, au-delà de 90 degrés. Cadre de lit 90 DEGRÉS (LORSQUE LE CADRE DU LIT EST DANS LA POSITION LA PLUS VERTICALE) Veuillez noter qu'il est normal de voir le sommier dans cet état avant l'installation des pistons à gaz. Page 56: Étape 38 Assurez-vous que le cadre de lit est entièrement assemblé...
  • Page 101 Français Page 61 : Étape 43 IMPORTANT : Tout d’abord, déverrouillez et retournez la jambe sur l’armoire. Ensuite, abaissez un peu le cadre de lit pour permettre à la place d’accrocher les assemblages de porte (T &U). Cette étape pourrait utiliser les deux personnes. Soulevez soigneusement l’ensemble de porte gauche (T), placez les supports (19) sur les deux rails de support du cadre de lit et placez-les en position.
  • Page 102 Français Page 66 : Étape 47 L’avant de l’unité n’est pas affiché pour permettre une vue claire du coup de pied et du bas Pendant qu’une personne ouvre légèrement le cadre de lit et le maintient en place, insérez les boulons de connexion installés sur le kick (F) dans les connecteurs sur le fond (D).
  • Page 103 Français Page 72: Charges maximales Cet appareil a été conçu pour supporter les charges maximales indiquées. Le dépassement de ces limites de charge peut entraîner un affaissement, une instabilité, un effondrement du produit et/ou des blessures graves. Ce lit est conçu pour accueillir un matelas full, jusqu'à 10 pouces d'épaisseur. * avec un poids maximum de 60 livres (27.2 kg) * avec un poids minimum de 30 livres (13.6 kg) Après avoir terminé...
