Metal loft bed
Hide thumbs

Advertisement

Available languages

Available languages

Table of Contents

Weight Limit:
200 Lbs / 91 Kgs
E.L. - 7/17/2017
Thank you for purchasing from DHP!
DO NOT RETURN TO THE STORE !
If parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Visit www.dhpfurniture.com/eng/support-home
or call Toll-Free 1-800-267-1739
Date of Purchase
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
5410496WE
Metal Loft Bed
Lot Number
B345410496WE00-10125-M
Twin
White
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the your zone 5410496WE and is the answer not in the manual?

Questions and answers

Related Manuals for Dorel Home Products your zone 5410496WE

Summary of Contents for Dorel Home Products your zone 5410496WE

  • Page 1 5410496WE Metal Loft Bed Twin White Weight Limit: Thank you for purchasing from DHP! 200 Lbs / 91 Kgs DO NOT RETURN TO THE STORE ! If parts are missing or damaged, we will gladly ship your replacement parts free of charge. Visit www.dhpfurniture.com/eng/support-home or call Toll-Free 1-800-267-1739 Date of Purchase...

  • Page 2: Warranty Information

    Warranty Information Read Before Beginning Assembly DHP warrants this product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers one year from the date of original purchase. This is solely limited to the repair or replacement of defective 2.
  • Page 4 Parts Replacement Parts, visit www.dhpfurniture.com/eng/support-home All in 1 big box! There are inner box(es) that include components required to complete this assembly. Before you throw the package, please use the Post Post Post Post End Guard Rails Side Safety Rails Check Box to identify the parts and ensure that T950150 T950200...

  • Page 5: Hardware Pack

    Hardware Pack Hardware Pack #: T5410096-00 1/4" X 3/4" 5/16"X 3/4" X 36 1/4" X 1 9/16" 1/4"X 2 3/16" Washer Please do not completely tighten all the hardware, until the entire assembly is complete, unless otherwise indicated in the step-by-step instructions.
  • Page 6 Step 1 1.1 Attach A to I with 1.2 Attach M to I with 1.3 Attach Z to A,I with...
  • Page 7 Step 2 2.1 Attach L to M,Z with 2.2 Attach T to A with Attach T to Z with...
  • Page 8 Step 3 3.1 Insert L into B; 3.2 Attach I to B with 3.3 Attach T to B with...
  • Page 9 Step 4 4.1 Attach C to I with 4.2 Attach M to I with 4.3 Attach Z to C,I with...
  • Page 10 Step 5 5.1 Attach L to M,Z with 5.2 Attach T to C with Attach T to Z with...
  • Page 11 Step 6 6.1 Insert L into D; 6.2 Attach I to D with 6.3 Attach T to D with...
  • Page 12 Step 7 Please Note: Wide side of 7.1 Attach E to A/D and B/C with the slot should be facing up ! 7.2 Attach G to A/D and B/C with 7.3 Attach J to B,C with...
  • Page 13 Step 8 Insert O into G X 2 as illustrated, then lock O into place with Y.
  • Page 14 Step 9 9.1 Press W onto O; 9.2 Press Q into W alternating left and right.

  • Page 15: Helpful Hints

    Helpful Hints Helpful Hints Weight Limit: 200 Lbs / 91 Kgs lifting and carrying the unit to its new location. Top Cap reassembled to move. T393850 They are illustrated on this page and available for replacement. End Cap T393350...
  • Page 16 WARNINGS for Bunk Bed against the wall to prevent entrapment between the bed and wall. and jump ropes.
  • Page 17 NO LO REGRESE A LA TIENDA ! 5410496WE Metal Loft Bed mucho gusto le enviaremos sus piezas de reemplazo sin cargo extra. Individual Visite www.dhpfurniture.com /spa/support-home o Llame gratis al 1-800-267-1739 Blanco Fecha de compra ESTE INSTRUCTIVO CONTIENE INFORMACION IMPORTANTE DE SEGURIDAD.
  • Page 18 Lea antes de comenzar a ensamblar Partes Piezas de reemplazo, visite www.dhpfurniture.com/spa/support-home utilizado su producto. Todo se incluye en 1 caja grande! Tiempo estimado de ensamble es 2 horas. Hay 1 caja(s) interna(s) que incluyen los componentes necesarios para etiquetadas o selladas en los bordes. completar este ensamblaje.
  • Page 19 Instrucciones Paso 1 1.1 Una A con I con 1.2 Una M con I con 1.3 Una Z con A,I con mudanza. Paso 2 2.1 Una L con M,Z con 2.2 Una T con A con Una T con Z con Paso 3 3.1 Inserte L dentro de B.

  • Page 20: Garantie

    NE RETOURNEZ PAS AU MAGASIN ! 5410496WE Metal Loft Bed gratuitement. Simple Visitez www.dhpfurniture.com/fre/support-home ou appelez au 1-800-267-1739 Blanc Date d'achat Numero de lot IMPORTANTES. Garantie Enregistrez votre produit et participez pour gagner! notre concours trimestriel avec la chance de gagner des prix incroyables. Avantages: pour enregistrer votre produit et vous obtiendrez: Des informations exclusives sur les nouveaux produits...

  • Page 21: Avant De Commencer L'assemblage

    Avant de commencer l'assemblage www.dhpfurniture/fre/support-home 2. Le temps d'assemblage 2 heures. l'assemblage. lors de l'assemblage. Poteau: T950150 Poteau: T950160 Poteau: T950170 Caution Poteau: T950180 Fin garde-corps: T950190 commercial. enfants. Lamelles: T922100 Entretoise latte: T919490 Bouchon de plastique: T392590 Entretoise latte: T919480 Quincaillerie Emballage coque #: T5410096-00 Remarque:...

  • Page 22: Conseils Utiles

    Instructions Limite de Poids: 200 lbs / 91 kgs Conseils utiles 1.1 Attacher A I avec pour soulever et transporter le mobilier vers son nouvel emplacement. 1.2 Attacher M I avec 1.3 Attacher Z A,I avec 2.1 Attacher L M,Z avec page et disponibles pour le remplacement.
