  • Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. DYNA-GLO KFA125L-1 Owner's Manual Shop genuine replacement parts for DYNA-GLO KFA125L-1 Find Your DYNA-GLO HVAC Parts - Select From 146 Models -------- Manual continues below --------...
  • Page 2 INDOOR/OUTDOOR PRODUCTS KEROSENE PORTABLE FORCED AIR HEATERS “USER’S MANUAL AND OPERATING INSTRUCTIONS” COMPLIES WITH UL733 AND ANSI A10.10-1998 CAN/CSA/B140.0-03 AND CSA B140.8-1967 MODEL : KFA75L, KFA125L, KFA210L Before the first use of this heater, please read this USER’S MANUAL very carefully.

  • Page 3: Risk Of Electric Shock

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! DANGER: : IMPROPER USE OF THIS HEATER CAN RESULT IN SERIOUS INJURY OR DEATH FROM BURNS, FIRE, EXPLOSION, ELECTRICAL SHOCK AND/OR CARBON MONOXIDE POISONING. WARNINGS: 1. RISK OF INDOOR AIR POLLUTION! Use this heater only in well ventilated areas. Provide at least a three-square foot (2,800 sq. cm.) •...
  • Page 4 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! CONTENTS OF USER’S MANUAL ITEM PAGE # 19&22 20,21&23,24 1. INTRODUCTION Please read this USER’S MANUAL carefully. It will show you how to assemble, maintain, and operate the heater safely and efficiently to obtain full benefits from its many built-in features. 2.
  • Page 5 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Front Handle Rear Handle Upper Shell Hot Air Outlet Shell Lower Cord Wrap Fuel Gauge BTU Control Switch Fuel Cap Side Cover Pressure Gauge Lamp Fan Guard Thermostot Knob Room Temp. Display Power Cord (Piggy Back) Power/Reset Switch 10”...

  • Page 6: Unpacking And Assembly

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 3. UNPACKING AND ASSEMBLY 1. REMOVE THE HEATER AND ALL PACKING MATERIALS FROM THE BOX. (Fig. 4 and 5) NOTE : Save the shipping carton and packing materials for future storage. KFA210L KFA75L KFA125L Wheel Support Frame Wheel...
  • Page 7 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 2. ASSEMBLY Front Guard For KFA75L Models only Screw Handle (Assembly time for this product is 5 minutes) Wedged Portion Tools Required • Medium Phillips Screwdriver. Slit Hole 1) Lift front guard for arrow direction and make sure that guard’s wedged portion fits into the slit Cord Wrap hole on the upper housing.
  • Page 8 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Front Handle Screw Cap Nut S Rear Handle Hot Air Outlet Cord Wrap Flange Screw Fuel Tank Flange Air Inlet Wheel Support Frame Threaded Axle Wheel Wheel Bushing Cap Nut L Figure 7. Assembling Handle, Wheel and Cord wrap CAUTION : DO NOT OPERATE heater without support frame assembled to tank.
  • Page 9 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 5. OVERVIEW OF HEATER’S DESIGN Fuel System : This heater is equipped with an electric air pump that forces air through the air line connected to the fuel intake and then through a nozzle in the burner head. When the air passes in front of the fuel intake it causes fuel to rise from the tank and into the burner nozzle.

  • Page 10: Fueling Your Heater

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 6. FUELING YOUR HEATER NEVER FILL THE HEATER FUEL TANK IN THE LIVING SPACE : FILL THE TANK OUTDOORS. DO NOT OVERFILL YOUR HEATER AND BE SURE HEATER IS LEVELED. IMPORTANT NOTICE REGARDING FIRST IGNITION OF HEATER : The first time you light the heater, it should be done outdoors.
  • Page 11 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! NOTICE : The major electrical components of this heater are protected by a safety fuse mounted to the PCBboard. If your heater fails to start, check this fuse first and replace as necessary. You should also check your power source to insure that proper voltage and frequency are being supplied to the heater.

  • Page 12: Maintenance

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 9. MAINTENANCE WARNING!! : NEVER SERVICE HEATER WHILE IT IS PLUGGED IN OR WHILE HOT! USE ORIGINAL EQUIPMENT REPLACEMENT PARTS. Use of third party or other alternate components will void warranty and may cause unsafe operating conditions.
  • Page 13 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Combustion Chamber Screw E.) NOZZLE Ignitor Wire REMOVE DIRT IN NOZZLE AS NEEDED (SEE PAGE 16). (For KFA75L/125L Models Only) Spark Plug - Remove upper shell (See page 10). Nozzle Adaptor - Remove fan blade (See page 10). - Remove fuel and air line hoses from nozzle adaptor.
  • Page 14 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Screw F.) SPARK PLUG CLEAN AND REGAP EVERY 600 HOURS OPERATION OR REPLACE AS NEEDED. (For KFA75L/125L Models Only) - Remove upper shell (See page 10). Spark Plug - Remove fan (See page 10). - Remove ignitor wire from spark plug.

  • Page 15: Pump Pressure Adjustment

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! H.) FUEL FILTER Fuel Filter CLEAN OR REPLACE TWICE A HEATING Fuel line SEASON OR AS NEED. - Remove side cover screws using medium phillips screwdriver. Switch Wires - Disconnect switch wires from power switch and remove side cover.

  • Page 16: Replacing Fuse

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 10. REPLACING FUSE NOTICE : This heater is fuse protected. If your heater fails to ignite, DO NOT RETURN YOUR HEATER TO THE STORE. Please follow the simple instructions below to inspect and change the fuse. PROCEDURE FOR REPLACING FUSE WARNING : SHOCK HAZARD To prevent personal injury, unplug the power cord before replacing fuse.

  • Page 17: Troubleshooting Guide

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 11. TROUBLE SHOOTING GUIDE TROUBLE POSSIBLE CAUSE CORRECTIVE ACTION Heater ignites but MAIN PCB 1. Wrong pump pressure 1. See Pump Pressure Adjustment, assembly shuts heater off after Page 13. a short period of time. 2.

  • Page 18: Wiring Diagram

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 12. WIRING DIAGRAM A) WIRING DIAGRAM (KFA75L/125L Models) CONTROL PCB BLACK SPARK PLUG IGNITOR POWER LAMP BLACK (LED) ORANGE BLACK PUMP WHITE MOTOR CAPACITOR GREEN THERMOSTAT CN2(AC2)/WHT (TEMP. CONTROL) EARTH CN1(AC1)/BLK BLUE BLACK PHOTO ROOM CELL...
  • Page 19 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! B) WIRING DIAGRAM (KFA210L Model) CONTROL PCB BLACK SPARK PLUG BLACK IGNITOR BLACK BLACK POWER LAMP ORANGE BLACK (LED) PUMP WHITE MOTOR CAPACITOR GREEN 20uF/350VAC THERMOSTAT CN2(AC2)/WHT (TEMP. CONTROL) EARTH CN1(AC1)/BLK BLUE BLACK PHOTO ROOM BLUE...

  • Page 20: Specifications

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 13. SPECIFICATIONS 32.0"(813mm) 11.7"(297mm) KFA75L Model 210L 125L 47.4"(1,205 mm) 41.9"(1,063 mm) 21.5"(547 mm) 23.1"(587 mm) 32.4"(824 mm) 33.5"(850 mm) KFA125L/210L Models MODEL KFA75L KFA125L KFA210L HIGH 75,000 125,000 210,000 BTU/Hr. 55,000 100,000 170,000 HIGH 0.57(2.16)
  • Page 21 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 14. EXPLODED PARTS DRAWING (KFA75L/125L Models Only) NOTE : SPECIFY MODEL NUMBER AND PART NUMBER WHEN ORDERING PARTS. BURNER HEAD ASSEMBLY 21-3 21-8 21-5 21-7 21-1 21-2 21-4 21-6 20 21 22 MOTOR AND PUMP ASSEMBLY 24-2 24-5 24-6...
  • Page 22 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 15. PARTS LIST (KFA75L/125L Models Only) PART NO. Quantity DESCRIPTION KEY NO. KFA75L KFA125L Fuel Tank Assembly 2151-0027-00 2151-0028-00 Fuel Drain-Bolt 4329-0072-00 Fuel Gauge 2156-0049-00 2156-0050-00 Fuel Filter Assembly 2155-0005-00 2155-0001-00 Fuel Cap 2151-0003-00 2151-0003-00 Cord Brushing...
  • Page 23 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 15. PARTS LIST (KFA75L/125L Models Only) PART NO. Quantity DESCRIPTION KEY NO. KFA75L KFA125L 24-10 Insert See SP-KFA1000 See SP-KFA1000 24-11 End Pump Cover 3531-0027-00 3531-0027-00 24-12 Elbow 3231-0181-00 3231-0181-00 24-13 Lint Filter See SP-KFA1005 See SP-KFA1005 24-14...
  • Page 24 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 14. EXPLODED PARTS DRAWING (KFA210L Model Only) NOTE : SPECIFY MODEL NUMBER AND PART NUMBER WHEN ORDERING PARTS. BURNER HEAD ASSEMBLY 21-8 21-3 21-7 21-1 21-5 21-2 21-4 21-6 23 13 MOTOR AND PUMP ASSEMBLY 24-2 24-5 24-6...
  • Page 25 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 15. PARTS LIST (KFA210L Model Only) PART NO. Quantity DESCRIPTION KEY NO. KFA210L Fuel Tank Assembly 2151-0029-00 Fuel Drain-Bolt 4329-0072-00 Fuel Gauge 2156-0052-00 Fuel Filter Assembly 2155-0001-00 Fuel Cap 2151-0003-00 Cord Bushing 3712-0013-00 Power Cord 3980-0087-00 Thermistor...
  • Page 26 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 15. PARTS LIST (KFA210L Model Only) PART NO. Quantity DESCRIPTION KEY NO. KFA210L 24-12 Elbow 3231-0181-00 24-13 Lint Filter See SP-KFA10052 24-14 Bolt Flange 4329-0016-00 24-15 Output Filter See SP-KFA10052 24-16 End Filter Cover 3221-0076-00 24-17 Ball...
  • Page 27 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 15. PARTS LIST (WHEELS AND HANDLE) 1) KFA75L MODEL PART NO. Quantity KEY NO. DESCRIPTION KFA75L 3231-0073-00 Handle 3221-0041-00 Cord Wrap HW-KFA1001 Hardware Kit 2) KFA125/210L MODELS PART NO. Quantity KEY NO. DESCRIPTION KFA125L KFA210L Front Handle...
  • Page 29 GHP Group, Inc. 6440 W Howard St Niles, IL 60714-3302 Tel: (877) 447-4768 www.ghpgroupinc.com GHP Group, Inc. 6440 W Howard St Niles, IL 60714-3302...

This manual is also suitable for:

Kfa75lKfa125lKfa210l
