USER'S MANUAL AND OPERATING INSTRUCTIONS
THERMOHEAT
MODELS:
C
ANS Z83.7-2011 CSA 2.14-2011
GHP Group, Inc.
8280 austin ave.
GHP
Morton grove, il 60053-3207
GENERAL HAZARD WARNING
Failure To CoMply wiTh The preCauTionS and inSTruCTionS provided wiTh
ThiS heaTer, Can reSulT in deaTh, SeriouS Bodily injury and properTy loSS,
or daMage FroM The hazardS oF Fire, exploSion, Burn. aSphyxiaTion, CarBon
Monoxide poiSoning, and/or eleCTriCal ShoCk.
only perSonS who Can underSTand and Follow The inSTruCTionS Should
uSe or ServiCe ThiS heaTer.
iF you need aSSiSTanCe or heaTer inForMaTion SuCh aS an inSTruCTion
Manual, laBelS, eTCeTera, ConTaCT The ManuFaCTurer.
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 877-447-4768 8:30 a.m. – 4:30 pm CST, Monday – Friday
50-10-166
PROPANE
CONSTRUCTION HEATER
RMC-FA60/L/L-01
LPFA125/L/L-01
US
CONSUMER: retain this manual for future reference.
or email us at customerservice@ghpgroupinc.com
www.ghpgroupinc.com
(30,000/60,000 BTU/HR,
(70,000/125,000 BTU/HR, FORCED - AIR)
Printed in China
FORCED - AIR)
Rev. 2012-04-12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FA60 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Thermoheat FA60 Series

Summary of Contents for Thermoheat FA60 Series

  • Page 1 PROPANE CONSTRUCTION HEATER USER’S MANUAL AND OPERATING INSTRUCTIONS THERMOHEAT RMC-FA60/L/L-01 (30,000/60,000 BTU/HR, FORCED - AIR) LPFA125/L/L-01 (70,000/125,000 BTU/HR, FORCED - AIR) MODELS: ANS Z83.7-2011 CSA 2.14-2011 GHP Group, Inc. 8280 austin ave. Morton grove, il 60053-3207 GENERAL HAZARD WARNING Failure To CoMply wiTh The preCauTionS and inSTruCTionS provided wiTh ThiS heaTer, Can reSulT in deaTh, SeriouS Bodily injury and properTy loSS, or daMage FroM The hazardS oF Fire, exploSion, Burn.

  • Page 3: Table Of Contents

    Series/LPFA125 Series........

  • Page 4: Introduction & Speciications

    PROPANE CONSTRUCTION HEATER Dyna-Glo ProPane ForceD air construction Heaters The heater is designed and approved for use as a construction heater under ANS Z83.7 CSA 2.14. It is hard CHECK WITH YOUR LOCAL FIRE SAFETY to anticipate every use which may be made of this heater. AUTHORITY IF YOU HAVE QUESTIONS ABOUT APPLICATIONS.

  • Page 5: General Safety Instructions

    PROPANE CONSTRUCTION HEATER General saFety instruction accidents are always tragic especially because so many of them could have been prevented with little care and judgment. There are some basic good practices, we hope you will follow for safe use of your heater. iMPortant saFety instruction •...

  • Page 6: Unpacking Heater

    PROPANE CONSTRUCTION HEATER unPacKinG Heater 1. Remove heater from carton. 2. Remove all protective packing applied to heater for shipment. 3. Retain cartons and packaging material until unit is operated and found in good condition. 4. Check heater for any shipping damage. If heater shows any external or internal damage, promptly inform dealer/distributor where you purchased heater.

  • Page 7: Size & Capacity Of Propane Cylinders

    PROPANE CONSTRUCTION HEATER inForMation on siZe * caPacity oF ProPane Gas cylinDers: The chart below shows the number and size of propane tanks needed to run this heater. *Less gas is vaporized at lower temperatures. You may need two or more 100 pound tanks or one larger tank in colder weather. (See the parts list for your model of heater to get the speciied regulator assembly.) Number of Tanks Temperature...

  • Page 8: Installation To The Propane Gas Tank

    PROPANE CONSTRUCTION HEATER installation to tHe ProPane Gas tanK IMPORTANT: you must use a propane/lp gas supply cylinder that is compatible with the connection device provided with the hose and regulator. propane/lp regulator Supply valve Fuel gas propane/lp Fitting hose to Tank heater FIGURE 2...

  • Page 9: Leak Checking & Positioning Heater

    PROPANE CONSTRUCTION HEATER ProPane saFety Propane is safe to use when properly handled. Careless handling of the Propane gas tank could result in ire and/or an explosion. Therefore: • Always keep tank/cylinder securely fastened in an upright position. • Avoid tipping tank on its side when connected to a regulator since this may cause damage to diaphragm in regulator.

  • Page 10: Test Firing Heater & Storage

    PROPANE CONSTRUCTION HEATER sHutDoWn instructions WARNING : Motor and fan must be running before lighting, during operation and at shutdown, in order to prevent a lame-out condition which could result in personal injury or property damage. Turn gas valve knob clockwise to OFF position.

  • Page 11: Troubleshooting

    PROPANE CONSTRUCTION HEATER troublesHootinG TROUBLESHOOTING: PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION 1. Gas valve knob is off and unit 1. This heater uses a con7nuous spark 1. No correc7ve ac7on is needed. is clicking/7cking. igni7on system. This unit will con7nue to make a clicking/7cking sound at all 7mes before igni7on, aAer igni7on and during opera7on, regardless of valve knob posi7oning. 2. The unit is 7cking/clicking  1. This heater uses a con7nuous spark 1. No correc7ve ac7on is needed. while the heater is lit. igni7on system. This unit will con7nue to make a clicking/7cking sound at all 7mes before igni7on, aAer igni7on and during opera7on, regardless of valve knob posi7oning. 3. Fan does not turn when 1. No electric power to heater. 1. Check current to electric outlet. If voltage is correct, electrical connec7on is made. check power cord and extension cord for 2.

  • Page 12: Wiring Diagrams

    PROPANE CONSTRUCTION HEATER WirinG DiaGraMs *LPFA125 Series Models Only 100K,125K & 150K Models only *LPFA 125 Series Sólo Modelos 100K,125K & 150KSólo modelos *LPFA125 Séries Les modéles Seulement 100K,125K & 150K Les modèles Seulement...

  • Page 13: Rmc-Fa60 Series/Lpfa125 Series

    PROPANE CONSTRUCTION HEATER rePlaceMent Parts list RMC-FA60 Series/LPFA125 Series MODELS:...

  • Page 14: Replacement Parts List

    PROPANE CONSTRUCTION HEATER rePlaceMent Parts list FA40 THROUGH FA150 STEEL BASE UN ITEM      PART NUMBER DESCRIPTION No.  LPFA125 SERIES FA60 SERIES INNER SHELL  ASS' Y 2304818 2304929 NOZZLE 2325121 5030077* FLAME HOLDER CAP 2325120 2325122 THERMAL SWITCH BRKT. 2304826 2315515 THERMAL SWITCH  2201599 2201373 NOZZLE NUT 2304578 2304945 SPARK PLUG ASSY 2206033 2206034 THERMOCOUPLE ASSY (1130/1474‐425L) 2304885 2304885 GAS TUBING ASS' Y 2304830 2325138 OUTER SHELL ‐ ORANGE 2305403 2325360...

  • Page 15: Warranty

    Warranty LIMITED WARRANTY: This limited warranty is extended to the original retail purchaser of this Forced Air/Convection/Radiant Heater and warrants against any defect in materials and workmanship for a period of one (1) year from the date of retail sale. GHP Group, Inc., at it’s option, will either provide replacement parts or replace or repair the unit, when properly returned to the retailer where purchased or one of our service centers as directed by GHP Group, Inc., within one (1) year of retail purchase.
  • Page 16 WARRANTY REGISTRATION IMPORTANT: We urge you to fill out your warranty registration card within fourteen (14) days of date of purchase. You can also register your warranty on the internet at www.ghpgroupinc.com. Complete the entire serial number. Retain this portion of the card for your records.
