Notes: 1) These model's BD Drive/Main P.C.B. Assembly are:-
- RFKNBT735EBA (For EB);
- RFKNBT735EGA (For EG);
- RFKNBT735EPA (For EP);
- RFKNBT735EEA (For EE);
2) Please refer to the original service manual for:
• Speaker system SB-BT735EG-K, Order No: PSG1003007CE.
Caution:
Pairing of BD Drive and Main P.C.B. as "BD Drive & Main P.C.B. Assembly" have to be replaced together. If
either BD Drive or Main P.C.B. is changed, BD Drive unit has to carry out re-adjustment due to alignment
data for BD Drive Unit is stored in the Main P.C.B.
Blu-ray Disc Home Theater Sound System
Model No.
Volume 1
Product Color: (K)...Black Type
SA-BT735EB
SA-BT735EE
SA-BT735EG
SA-BT735EP
© Panasonic Corporation 2010. All rights reserved.
Unauthorized copying and distribution is a violation
of law.
PSG1003023CE
