- Page 1 USER MANUAL TUI-mid Step-Through ebike PLEASE READ CAREFULLY...
-
Page 2: Table Of Contents
Table of Contents Safety Instructions....................3 Symbols........................3 Introduction......................4 Mode of operation and extent of electronic power assistance..........4 Modes of support......................4 What comes with the bike?..................4 Optional accessories....................4 Components......................5 Basic Safety Tips....................6 For your road safety.....................6 How to use your charger..................6 Safety notes concerning the battery................8 Longterm Storage......................8 Charging the battery....................9 How to remove and insert the battery................9... -
Page 3: Safety Instructions
NZEBIKES is continuously updating and innovating this product. The printed manual may therefore not always include the latest updates. However, we shall make sure that our online manual will always be up to date on evinci.nz/support. We want also encourage you to register your bike with your frame serial number. -
Page 4: Introduction
Introduction You have decided in favour of a Pedelec (Pedal Electric Cycle) - a bicycle that is equipped with an electric motor to give you additional assistance when riding. With this bicycle, you can make better progress in headwinds, when transporting heavy loads or on steep slopes. -
Page 5: Components
Components Colour Display Battery Charge Port Control Buttons Battery Lock Throttle Mid-Drive Motor Dropper Post Control... -
Page 6: Basic Safety Tips
Basic Safety Tips Always pull the brakes and hold the handlebar firm and straight before taking off to make sure you stay in control of the bike when power assistance is in action! For your road safety ● Always wear a suitable bike helmet ●... - Page 7 Any other battery is not compatible and risks to explode • while charging, causing serious injury to people as well as damage to other equipment Using this charger for batteries not supplied by Evinci • could risk catching fire, provoke electric shock and/or cause serious injury Please make sure that the charger is always kept dry •...
-
Page 8: Safety Notes Concerning The Battery
Safety notes concerning the battery Keep the battery out of reach for children • Never try to open the battery. Apart from this being • dangerous, all warranty will be void Do not provoke a shortcut circuit with metal gadgets •... -
Page 9: Charging The Battery
Charging the battery You may charge the battery on the bike or remove it to a more convenient place. Li-Ion battery have no memory effect, this means you can top them up as you go 1. Open the rubber cover and connect the charger plug to the battery 2. -
Page 10: Before Starting To Ride
Before starting to ride Mount or dismount front wheel For easy transport, you may remove the front wheel using the quick release at the front wheel axle. To remove the wheel open the lever to release the pressure. Now hold the lever and turn the nut on the other side about 8-9 times –... -
Page 11: Adjusting The Saddle Angle
Adjusting the saddle angle Best riding comfort is found when the saddle is horizontal, some riders prefer a slight forward angled seat. Never angle a seat backwards as it can quickly lead to back pain or physical injuries 1. Loosen the clamping screws anti-clockwise 2. -
Page 12: Operation
Operation • Turn the display on by pushing the (l) button • Select the desired assistance level with the UP or DOWN buttons. Start riding. • Use the throttle as desired to add additional power to the selected assistance • To change the riding mode (torque/cadence) push the (M) button once •... - Page 13 Battery Level: The display shows the battery level with 5 segments. Each level is about 20% of power. On the last bar it it will flash and the battery should be recharged as fast as possible. Below 10% the controller or battery might turn off when a higher load is applied, i.e.
-
Page 14: Throttle
USB Charging: This display has an USB port below the mounting bracket. Remove the Rubber Protector and plug in your USB cable. To power the port the display must be turned on and then press “UP” for 2 sec. An USB icon will appear on the display to confirm that the port is powered up. -
Page 15: Gears
Gears Only change gears while pedalling otherwise the derailleur might get damaged Your TUI ebike is equipped with a high performance Shimano 9-gear system. Since this ebike uses a mid drive motor which supports the crank, it is essential to choose the right gear depending on your riding situation. -
Page 16: Brakes
Brakes We recommend always using both brakes at the same time – this allows the rider to take the best control over the braking process without stressing the front or rear brake. To brake efficiently, your front brake is there to stop you and the back brake is there to shave off speed. -
Page 17: Safety Points
Safety points We recommend a 12-month interval service or every 1000 km. Important checkpoints are: ▪ Quick-release front and rear ▪ seat post clamp axle ▪ brake caliper screws ▪ headset ▪ spoke tension ▪ stem clamp Spoke tension has to be checked on a regular interval. Failing can cause spoke breakage and will void the warranty Repairing a puncture in the rear wheel Since the rear wheel comes with a quick release axle it is very easy to remove... -
Page 18: Troubleshooting
Troubleshooting Problem Resolution The Battery is charged but the 1. Check plug going from display to frame display won't turn on harness, unplug once and plug back together. 2. If possible measure voltage at the battery socket (left and right pin). If no voltage can be measured, take the battery to your retailer. -
Page 19: Controller
normal operation. An integrated balancer ensures that any differences in voltage between single cells are equalised. In case of a problem with the charging device, the BMS makes sure that the battery cannot be overcharged. A capacity gauge may be included to display the remaining capacity. Controller The controller is the heart of any electric bicycle. - Page 20 NZEBIKES 2016 Ltd 19 Esk Street Tauranga evinci.nz Ph: 022 675 2699 evinci™ is a registered trademark of NZEBIKES 2016 Ltd TDF05E - Rev 1/22...
