- Page 1 Vernice TV Stand INSTRUCTION MANUAL Please read these instructions carefully and retain them for future reference. FD-TS-18-02...
-
Page 2: Package Contents
HIGHLIGHTS • Engineered Wood • Steel Legs PACKAGE CONTENTS " • Everfurn Vernice TV Stand • Assembly Parts • Instruction Manual SPECIFICATIONS • Depth: 400 mm • Height: 550 mm • Width: 1800 mm • Top Board Thickness: 15 mm... -
Page 3: Identifying Parts
IDENTIFYING PARTS 16MM 40MM PLASTIC POWER SOFT CLOSING DOWEL SCREW CSK CAP PVC SHELF P/H SCREW MATEL LEG MINIFIX 5654 8X25 M3.5X16 M6X40 SUPPORT NAIL " KT 1010 M4X20MM (250MM) ALLEN KEY HINGES " 8 SETS 1X16 1X48 1X36 Hardware A. - Page 4 INSTRUCTIONS FOR USE ASSEMBLY INSTRUCTIONS Important Note: When tightening any fasteners, ensure not to tighten them more than 90% tightness to prevent damage to the product or the fastener. Step 1: 1. Fix the 8X25 Plastic Dowels x16 (A) into the Outer Right Stand Panel (4), Outer Left Stand Panel (5), Inner Right Stand Panel (2), and the Inner Left Stand Panel (3) .
- Page 5 ASSEMBLY INSTRUCTIONS (Continued) Step 5: 1. Fasten the 250mm Metal Legs (I) to the bottom of the stand using the M3.5X16 CB Screws. • Use a Phillips screwdriver (Not included) to assist with this step. Step 6: 1. Add the Nuts (D2) of the Screw and Nut Set to the insides of the stand panels.
- Page 6 ASSEMBLY INSTRUCTIONS (Continued) Step 9: 1. Attach the Door Handles (H1) to the Left & Right Cupboard Doors (9 & 10) Using the M4X20mm Phillips Screws (H2) • Use a Phillips screwdriver (Not included) to assist with this step. Step 10: 1.
-
Page 7: Safety Precautions
CLEANING AND CARE INSTRUCTIONS - GENERAL • Cleaning: Wipe down the product’s surface using a thickly folded damp cloth. • Do not use harsh or abrasive cleaning chemicals or materials on the product; doing so may damage or scratch the surface finish. •... -
Page 8: Environmentally-Friendly Disposal
DISCLAIMER All product and company names are trademarks™ or registered ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. ENVIRONMENTALLY FRIENDLY DISPOSAL • At the end of its working life, the product must not be disposed of as urban waste. -
Page 9: Warranty
WARRANTY The Everfurn Vernice TV Stand includes a standard 12-month limited warranty against manufacturing defects and faults. Should the product be unboxed with any faulty parts, poor finishing, visible damage, or failure to perform due to a manufacturing defect or poor workmanship, please return it with your proof of purchase (till slip or invoice) to the store of purchase for an exchange, or repair, depending on the store’s returns policy.
