- Page 1 88580 ANGLE GRINDER INSTRUCTION MANUAL 230V~50HZ 950W SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.
-
Page 2: General Power Tool Safety Warnings
SAFETY IMPORTANT SAFETY INFORMATION General Power Tool Safety Warnings WARNING: Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term ”power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. - Page 3 SAFETY 14. Remove any adjusting key or wrench before children and do not allow persons unfamiliar turning the power tool on. A wrench or a key with the power tool or these instructions to le attached to a rotating part of the power tool operate the power tool.
-
Page 4: Safety Warnings Common For Grinding, Sanding Or Wire Brushing Operations
SAFETY Safety Warnings Common for Grinding, Sanding or Wire Brushing Operations 1. This power tool is intended to function as a cracks, tear or excess wear, wire brush for loose grinder, sander or wire brush. Read all safety or cracked wires. If power tool or accessory is warnings, instructions, illustrations and dropped, inspect for damage or install an specifications provided with this power tool. -
Page 5: Safety Warnings Specific For Sanding Operations
SAFETY make exposed metal parts of the power tool unreadable or missing, contact Tolsen Tools for a “live“ and shock the operator. replacement. 11. Position the cord clear of the spinning 18. Avoid unintentional starting. Prepare to begin accessory. If you lose control, the cord may be work before turning on the tool. -
Page 6: Specifications
SPECIFICATIONS SPECIFICATIONS Electrical Rating 230V~50Hz Rated Power 950W Motor No Load Speed 9500rpm Max. Accessory Diameter 125mm (sold separately) Max. Accessory Thickness Arbor Hole Diameter 22.2mm Spindle Thread Note: Symbology Double Insulated China Quality Certification Centre WARNING mark concerning Risk of Eye Injury. - Page 7 FUNCTIONS Functions Side Cover Side Handle...
-
Page 8: Before Use
SETUP SETUP Before Use Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. WARNING: TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Turn the Power Switch of the tool off... -
Page 9: Tool Set Up
OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS Tool Set Up WARNING: TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Turn the Power Switch of the tool off and unplug the tool from its electrical outlet before installing accessories Installing a Non-threaded Grinding Wheel 1. The Grinding Wheel (sold separately) MUST be: should be centered on the grinding wheel and •... - Page 10 OPERATING INSTRUCTIONS 1. The accessory MUST be: 2. Press in and hold the Spindle Lock Button to • rated to at least 10,000 RPM. prevent the Spindle from turning. • no larger than 125mm in diameter. 3. Remove the Outer Flange and the Inner Flange •...
-
Page 11: Maintenance And Servicing
MAINTENANCE AND SERVICING MAINTENANCE AND SERVICING WARNING: TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Turn the Power Switch of the tool off and unplug the tool from its electrical outlet before performing any inspection, maintenance, or cleaning procedures. TO PREVENT SERIOUS INJURY FROM TOOL FAILURE: Do not use damaged equipment. If abnormal noise or vibration occurs, have the problem corrected before further use. -
Page 12: Troubleshooting
MAINTENANCE AND SERVICING Troubleshooting Problem Possible Causes Likely Solu�ons Tool will not 1. Cord not connected. 1. Check that cord is plugged in. start. 2. No power at outlet. 2. Check power at outlet. If outlet is 3. Tool’s thermal reset breaker tripped unpowered, turn off... -
Page 13: Ce Declaration Of Conformity
CE DECLARATION OF CONFORMITY SUZHOU TOLSEN TOOLS CO.,LTD. 198 HUASHAN ROAD, ZHANGJIAGANG, JIANGSU, CHINA Declare that the product 88580 Angle Grinder(G20-125C) 220-230V~, 50Hz, n: 9500/min, Class II Serial number: N/A Complies with the essential health and safety requirements of the following... - Page 14 SUZHOU TOLSEN TOOLS CO.,LTD. www.tolsentools.com TOLSEN is a trademark or registered trademark of TOLSEN TOOLS. All rights reserved. SCAN TO VISIT TolsenWorld MADE IN CHINA PRODUCT LINK...
