Page 1 Contents MICROWAVE GENERATOR 6810A SERIES Operating and Remote Programming Manual Document part no. 46892/931...
Page 2 No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, or recorded by any information storage or retrieval system, without permission in writing by Aeroflex International Ltd. (hereafter referred to throughout the document as ‘Aeroflex’). Document part no. 46892/931 (PDF version) Based on Issue 1 of the printed manual.
Page 3 Structure Chapter 1 Provides an introduction to the 6810A Series instruments. It also includes complete performance data and lists the versions, options and accessories available. Chapter 2 Installation details, including connecting to an AC supply, goods-in checks and routine...
Page 4 Contents numbers Preface Precautions Chapter 1 GENERAL INFORMATION Chapter 2 INSTALLATION Chapter 3 LOCAL OPERATION SOURCE key SETUP group keys SYSTEM group keys Chapter 4 REMOTE OPERATION Chapter 5 BRIEF TECHNICAL DESCRIPTION Chapter 6 ACCEPTANCE TESTING Appendices Appendix A INSTRUMENT DEFAULT SETTINGS Appendix B ERROR MESSAGES Appendix C...
Page 5: General Conditions Of Use
PRECAUTIONS Precautions These terms have specific meanings in this manual: WARNING information to prevent personal injury. information to prevent damage to the equipment. important general information. Symbols The meaning of hazard symbols appearing on the equipment and in the documentation is as follows: Symbol Description...
Page 6: Fire Hazard
PRECAUTIONS Fuses Note that there are supply fuses in both the live and neutral wires of the supply lead. If only one of these fuses should rupture, certain parts of the equipment could remain at supply potential. WARNING Fire hazard Make sure that only fuses of the correct rating and type are used for replacement.
Page 7: Static Sensitive Components
This equipment has been designed and manufactured by Aeroflex to perform measurements on RF and microwave components and systems. If the equipment is not used in a manner specified by Aeroflex, the protection provided by the equipment may be impaired.
Page 8: Symboles Signalant Un Risque
PRECAUTIONS Précautions Les termes suivants ont, dans ce manuel, des significations particulières: contient des informations pour éviter toute blessure au personnel. WARNING contient des informations pour éviter les dommages aux équipements. contient d’importantes informations d’ordre général. Symboles signalant un risque La signification des symboles de danger apparaissant sur l'équipement et dans la documentation est la suivante: Symbole...
Page 9 PRECAUTIONS Ne démontez pas le capot de l'instrument, car ceci peut provoquer des blessures. Il n'y a pas de pièces remplaçables par l'utilisateur à l'intérieur. Faites effectuer toute réparation par du personnel qualifié. Contacter un des Centres de Maintenance Internationaux dans la liste jointe à la fin du manuel. Fusibles Notez qu’il y a deux fusibles, l’un pour la phase et l’autre pour le neutre du câble d’alimentation.
Page 10 La protection de l'équipement peut être altérée s'il n'est pas utilisé dans les conditions spécifiées par Aeroflex. Aeroflex n'a aucun contrôle sur l'usage de l'instrument, et ne pourra être tenu pour responsable en cas d'événement survenant suite à une utilisation différente de celle prévue.
Page 11: Allgemeine Hinweise Zur Verwendung
PRECAUTIONS Vorsichtsmaßnahmen Diese Hinweise haben eine bestimmte Bedeutung in diesem Handbuch: dienen zur Vermeidung von Verletzungsrisiken. WARNING dienen dem Schutz der Geräte. enthalten wichtige Informationen. Gefahrensymbole Die Bedeutung der Gefahrensymbole auf den Geräten und in der Dokumentation ist wie folgt: Symbol Gefahrenart Beziehen Sie sich auf die Bedienungsanleitung wenn das...
Page 12 PRECAUTIONS Öffnen Sie niemals das Gehäuse der Geräte das dies zu ernsthaften Verletzungen führen kann. Es gibt keine vom Anwender austauschbare Teile in diesem Gerät. Lassen Sie alle Reparaturen durch qualifiziertes Personal durchführen. Eine Liste der Servicestellen finden Sie auf der Rückseite des Handbuches. Sicherungen Es ist zu beachten, daß...
Page 13 Dieses Gerät wurde von Aeroflex entwickelt und hergestellt um Messungen an HF- und Mikrowellenkomponenten und -Systemen durchzuführen. Sollte das Gerät nicht auf die von Aeroflex vorgesehene Art und Weise verwendet werden, kann die Schutzfunktion des Gerätes beeinträchtigt werden. Aeroflex hat keinen Einfluß auf die Art der Verwendung und übernimmt keinerlei Verantwortung...
Page 14: Simboli Di Pericolo
PRECAUTIONS Precauzioni Questi termini vengono utilizzati in questo manuale con significati specifici: WARNING riportano informazioni atte ad evitare possibili pericoli alla persona. riportano informazioni per evitare possibili pericoli all'apparecchiatura. riportano importanti informazioni di carattere generale. Simboli di pericolo Il significato del simbolo di pericolo riportato sugli strumenti e nella documentazione è il seguente: Simbolo Tipo di pericolo...
Page 15: Pericolo D'incendio
PRECAUTIONS Non rimuovete mai le coperture perché così potreste provocare danni a voi stessi. Non vi sono all’interno parti di interesse all’utilizzatore. Tutte gli interventi sono di competenza del personale qualificato. Vedi elenco internazionale dei Centri di Assistenza in fondo al manuale. Fusibili Notare che un fusibile è...
Page 16 Questo strumento è stato progettato e prodotto da Aeroflex eseguire misure su componenti o sistemi RF e microonde. Se lo strumento non è utilizzato nel modo specificato da Aeroflex, le protezioni previste sullo strumento potrebbero risultare inefficaci. Aeroflex non può avere il controllo sull’uso di questo strumento e non può essere ritenuta...
Page 17: Símbolos De Peligro
PRECAUTIONS Precauciones Estos términos tienen significados específicos en este manual: WARNING contienen información referente a prevención de daños personales. contienen información referente a prevención de daños en equipos. contienen información general importante. Símbolos de peligro El significado de los símbolos de peligro en el equipo y en la documentación es el siguiente: Símbolo Naturaleza del peligro Vea el manual de funcionamiento cuando este símbolo...
Page 18: Peligro De Incendio
PRECAUTIONS Deje todas las tareas relativas a reparación a un servicio técnico cualificado. Vea la lista de Centros de Servicios Internacionales en la parte trasera del manual. Fusibles Se hace notar que el Equipo está dotado de fusibles tanto en el activo como el neutro de alimentación.
Page 19 él. Idoneidad de uso Este equipo ha sido diseñado y fabricado por Aeroflex para realizar medidas en RF y microondas en componentes y sistemas. Si el equipo fuese utilizado de forma diferente a la especificada por Aeroflex, la protección ofrecida por el equipo pudiera quedar reducida.
Page 20: Table Of Contents
Main features Synthesized source The 6810A Series uses a fully synthesized frequency source for precision sweeps with high resolution and frequency stability and low phase noise. The source also provides an accurate CW output and a list mode is available via the menu system. A power sweep mode is provided for gain compression testing.
Page 21: User Interface
Programmable Instrumentation). The commands also enable the instrument to be controlled via the RS-232 (serial) interface. Data storage The 6810A Series has internal non-volatile memory that can be used for instrument settings and calibrations. To store results separately from the instrument there are two USB ports. User calibrations At temperatures outside the range +20 to +30°C (68 to 86°F), the performance of the instruments...
Page 22: Performance Data - 6810A Series
GENERAL INFORMATION Performance data – 6810A Series Source Functionality Synthesized CW Synthesized sweeper for use with scalar analyzer CW power sweep Frequency list mode External frequency modulation Optional internal frequency modulation, FM + pulse driver (Option 023) Optional internal pulse modulator (Option 025)
Page 23 GENERAL INFORMATION 6815A/15AR + Option 013 (70 dB Step Attenuator) 10 MHz to 8 GHz −10 dBm to +6 dBm, +8 dBm typical 8 GHz to 20 GHz −10 dBm to +2 dBm, +4 dBm typical 20 GHz to 24 GHz −10 dBm to +1 dBm, +3 dBm typical 24 GHz to 40 GHz −10 dBm to −3 dBm, 0 dBm typical...
Page 24 GENERAL INFORMATION Phase Noise in dBc/Hz in CW mode (guaranteed) CW Frequency Frequency offset 1 kHz 10 kHz 100 kHz 0.25 GHz −86 −95 −108 0.5 GHz −98 −112 −134 1 GHz −92 −106 −128 2 GHz −86 −100 −122 4 GHz −80 −92...
Page 25 GENERAL INFORMATION Accuracy (1 kHz modulating frequency) 20 - 400 kHz deviation ± 5% of indication ± 1 Hz excluding residual FM Pulse Generator Source Modes Single pulse Pulse Pattern Pulse patterns comprising up to 256 pulse width/PRI pairs can be set up, stored and recalled Trigger Modes External, internal continuous Pulse Widths (PW)
Page 26 GENERAL INFORMATION Source Harmonics (with Pulse Modulation enabled) 50 MHz – 375 MHz <-40 dBc 375 MHz – 24 GHz <-50 dBc 24 GHz – 40 GHz <-20 dBc On/Off Ratio 50 MHz – 10 GHz >60 dB 10 GHz – 26.5 GHz >60 dB (typically >70 dB) 26.5 GHz –...
Page 27: General Features
GENERAL INFORMATION General Features Display Color active matrix TFT liquid crystal display with 16.5 cm (6.5 in) visible diagonal Data Storage and firmware upgrade USB ports (two) Weight — Model and Option dependent 16 kg (35 lb) Size (not including front handles) 230 mm H x 430 mm W x 570 mm D (9 in H x 17 in W x 22 in D) Power Supply...
Page 28: Versions, Options And Accessories - 6810A Series
GENERAL INFORMATION Versions, options and accessories – 6810A Series Versions – Microwave Synthesized Generators 6813A 10 MHz to 20 GHz Synthesized Generator 6815AR 10 MHz to 40GHz Synthesized Generator 6815A 10 MHz to 46GHz Synthesized Generator Options Field Replaceable Precision N (f) and 3.5 mm (f) RF connectors (6813A), 2.92 mm (f) 6815A, 6815AR...
Page 29 GENERAL INFORMATION Miscellaneous 46885/038 Rack Mount Kit for 6810A Series 46880/122 Service Manual (consists of maintenance manual (printed) + operating manual (CD-ROM)) 46882/931 6810A Series Operating/Remote Programming Manual (printed) 46882/922 6810A and 6820A/6840A Series Getting Started Guide (printed) 84501 Soft Carrying Case...
Page 30: Ec Declaration Of Conformity
GENERAL INFORMATION EC Declaration of Conformity Refer to the manufacturer for a copy of the Declaration of Conformity for this instrument 1-11...
Page 31: Installation Requirements
Chapter 2 INSTALLATION Contents Installation requirements ......................2-1 Power requirements ........................2-4 Goods-in checks .......................... 2-4 RS232 connections ........................2-4 GPIB connections........................2-5 AUX connections ........................2-5 MONITOR connections ......................2-6 PARALLEL PORT connections ....................2-6 Rack-mounting the instrument ....................2-6 Battery replacement........................
Page 32: North American
In the event that a molded plug has to be removed from a lead, it must be disposed of immediately. A plug with bare flexible cords is hazardous if engaged in a live socket outlet. Power cords with the following terminations are available from Aeroflex. Please check with your local sales office for availability.
Page 33: Continental Europe
INSTALLATION Continental Europe Country IEC 320 plug type Part number Europe Straight through 23422/006 EARTH Europe Right angled 23422/007 LIVE NEUTRAL EARTH CONTINENTAL EUROPE C3512 The Continental European lead is fitted with a right angle IEC83 standard C4 plug (CEE 7/7) that allows it to be used in sockets with either a male earth pin (standard C 3b) or side earth clips (standard C 2b) the latter is commonly called the German ‘Schuko’...
Page 34: Power Requirements
INSTALLATION Questa spina non dovrebbe invece essere usata in Danimarca in quanto non realizza il collegamento di terra. Power requirements The instrument requires an AC supply in the range 90 V to 265 V, at a frequency of 45 Hz to 65 Hz, or 90 V to 110 V at 400 Hz.
Page 35: Gpib Connections
INSTALLATION GPIB connections Connection to the instrument’s GPIB interface is via the 24-way IEEE-488 Standard connector on the rear panel. A suitable GPIB lead assembly is available as an optional accessory (part number 43129/189). C0683 Data I/O 1 13 DIO 5 Data I/O 2 14 DIO 6 Data I/O 3...
Page 36: Monitor Connections
24 Ground 12 PE 25 Ground 13 SLCT Fig. 2-5 PARALLEL PORT connector contact assignments Rack-mounting the instrument The 6810A Series may be mounted in a standard 19 inch rack using the rack mounting kit 46885/038, available as an optional accessory.
Page 37: Battery Replacement
INSTALLATION Battery replacement The 6810A Series contains non-volatile memory that is powered by a lithium battery when the power is removed. Although battery life can extend to five years, this will depend on conditions of use, e.g. battery life is reduced as the temperature is increased. To avoid loss of data it is recommended that the battery be replaced every two years.
Page 38: Routine Safety Testing And Inspection
INSTALLATION Routine safety testing and inspection In the UK the ‘Electricity at Work Regulations’ (1989) section 4(2) places a requirement on the users of equipment to maintain it in a safe condition. The explanatory notes call for regular inspections and tests together with a need to keep records. The following electrical tests and inspection information is provided for guidance purposes and involves the use of voltages and currents that can cause injury.
Page 39: Insulation Tests
The above information is provided for guidance only. Aeroflex designs and constructs its products in accordance with International Safety Standards such that in normal use they represent no hazard to the operator. Aeroflex reserves the right to amend the above information in the course of continuing its commitment to product safety.
Page 40 General information area..................... 3-13 Error messages........................... 3-13 Data storage ..........................3-14 Copying data between an internal store and removable storage......... 3-14 The 6810A Series Synthesized Generator ................. 3-14 Using an external keyboard ....................... 3-15 International settings ......................... 3-15 User-defined passwords ..................... 3-16 Unauthorized use protection....................
Page 41 Power Cal Funcs ....................3-78 Tests ........................3-79 Test Display ......................3-79 International ......................3-80 New Locale ......................3-81 [PRESET] key ........................... 3-93 Preset........................3-93 [LOCAL] key ..........................3-94 [SOURCE ON/OFF] key......................3-94 List of figures Fig. 3-1 6810A Series front panel ....................3-4...
Page 42 LOCAL OPERATION Fig. 3-2 6810A Series rear panel....................3-6 Fig. 3-3 6810A Series display features..................3-12 Fig. 3-4 General information area .................... 3-13 Fig. 3-5 Source display......................3-31 Fig. 3-6 SOURCE menu......................3-49 Fig. 3-7 SAVE/RECALL menus (sheet 1) ................3-59 Fig.
Page 43: Introduction
LOCAL OPERATION Introduction This chapter explains how to operate 6810A Series instruments using the front-panel controls and soft key menus. The first part of the chapter provides illustrations and descriptions of the front- panel features, the rear-panel features and connectors, and the display. This is followed by descriptions of the main operating features.
Page 44 System Group keys This key group comprises the [UTILITY], [LOCAL], [PRESET] and [SOURCE ON/OFF] keys. They are used for running 6810A Series application programs, presetting the instrument, controlling the RF output and provide various system functions. Liquid crystal This is used for display of source settings, soft key labels and other display information.
Page 45: Rear-Panel Features
GPIB IEEE 488.1 488.2 RS232 PARALLEL PORT MONITOR KEYBOARD C6229 Fig. 3-2 6810A Series rear panel Battery compartment Removal of this cover provides access to the Lithium battery that is cover used to power the instrument's non-volatile memory. FREQ STANDARD...
Page 46 LOCAL OPERATION AC power connector A 3-pin connector that mates with the supplied AC supply cable. RS232 connector A 9-way D-type connector that allows connection to a controller/modem for remote operation of the instrument. AUX connector A 9-way D-type connector that provides two signals: (1) A voltage output that is either a 0 to 10 V ramp voltage proportional to swept frequency or power or (2) a fixed, settable DC voltage.
Page 47: Front-Panel Keys And Soft Key Menus
LOCAL OPERATION Front-panel keys and soft key menus The functions of the 6810A Series are activated from the front panel by the operator using specific function keys (hard keys), eight soft keys for accessing menu options, a numeric entry key group, a rotary control and step up/down keys.
Page 48: Numeric Entry
Detailed descriptions of all the 6810A Series menus are given later in this chapter. At the start of each menu description is shown the path for that menu, i.e. the key-presses the operator must make in order to access the menu.
Page 49 LOCAL OPERATION Numeric keypad. Used to enter digits, decimal point and minus sign for numeric entries, followed by a units terminator. Units terminator keys. These are the four keys to the right of the numeric keypad. They are used to specify the units for numeric entries from the keypad, and at the same time terminate the entries.
Page 50: Text Entry
LOCAL OPERATION Using numeric keys for store and file selection When a store (or file) has to be selected a list of the appropriate stores will be presented with an index number beside each entry. In addition to using the step keys ( ) to select the store, the index number may be entered using the numeric keypad and terminated with the [ENTER / =MKR] key.
Page 51: Display
LABELS C5764 Fig. 3-3 6810A Series display features Soft Key Labels are menu labels displayed on the screen that re-define the functions of the soft keys immediately to the right of the screen. The title of the menu is displayed at the top of the menu area to indicate where the user is within the menu structure.
Page 52: General Information Area
LOCAL OPERATION General information area This area is located at the top of the screen, and provides the user with general information about the instrument. It is displayed in the format shown in Fig. 3-4. UNLOCKED REMOTE INDICATOR INDICATOR REMOTE UNLOC UNLEV UNLEVELLED INDICATOR...
Page 53: Data Storage
Pressing the [Copy] soft key performs the copy operation. Other types of store can be copied/deleted in the same way. The 6810A Series Synthesized Generator The following source settings will be displayed: Source mode (CW, Frequency Sweep, etc.) Leveling mode Start &...
Page 54: Using An External Keyboard
Left / right arrow keys [UTILITY] <Alt> UT International settings The 6810A Series allows various instrument settings to be specified according to the country in which the instrument is to be used. These country specific settings are: Language External keyboard layout...
Page 55: User-Defined Passwords
LOCAL OPERATION User-defined passwords Two levels of user-defined password are provided: The User Level 1 password is a 4-digit code in the range 1000 to 9999, and protects those calibration functions that cannot affect the instrument's factory calibration. The factory-et default password is 9999.
Page 56: Installing A Printer
LOCAL OPERATION Installing a printer Initial setup Connect a PC-compatible USB keyboard and mouse to the USB ports on the front panel. If you have a USB hub, use it to allow the mouse to share the same port as the keyboard. Note: setup is quicker with a mouse, but if you do not have one, you can use the keyboard on its own.
Page 57: Introduction
LOCAL OPERATION Select Add\Add Printer/Class… to run the Add Printer Wizard. Introduction Click Next> to move to the next screen. Backend selection Select Local printer (parallel, serial, USB). Click Next> to move to the next screen. 3-18...
Page 58: Local Port Selection
LOCAL OPERATION Local port selection USB printer The printer should have been recognised by the system and appears under USB on the displayed tree diagram. Select the required printer. Click Next> to confirm the port and move to the next screen. Note: the printer may appear a second time on the list under a separate branch of the tree labelled ‘Others’.
Page 59: Driver Selection
LOCAL OPERATION Driver selection Note that this page appears only if there is more than one driver available for the model of printer selected. If this page does appear, it is generally advisable to accept the recommended default driver, which is highlighted automatically.
Page 60: Banner Selection
LOCAL OPERATION Banner selection Leave the default settings and click Next>to move to the next screen. Printer quota settings Leave the default settings and click Next>to move to the next screen. Users access settings Leave the default settings and click Next> to move to the next screen. General information At this stage, you need to reconnect the keyboard if you disconnected it earlier.
Page 61: Confirmation
LOCAL OPERATION Type a name for the printer (e.g. HPLaserJet). This is the name by which it is identified when selected from the instrument’s front panel. Note that space characters are not allowed. Click Next> to confirm the name and move to the next screen. Confirmation Click Finish to finish the wizard.
Page 62: Substituting A Printer With Another Of The Same Model
LOCAL OPERATION Substituting a printer with another of the same model Some USB printers identify themselves by model via the plug-and-play system, and some by a combination of model and serial number. Printers that identify themselves by model only can be readily substituted with another of the same model, and the new printer will be recognised by the 6810A.
Page 63 LOCAL OPERATION The Printers – System Settings window appears. It shows the currently installed printer(s). Right-click the printer you want to remove. Select Remove from the drop-down menu. When asked, confirm that you want to remove the printer. The printer is removed. 3-24...
Page 64: Setting Up The Lcd
Remote operation The 6810A Series can be controlled remotely via the GPIB or RS-232 (serial) interfaces. The GPIB interface provides instrument control with full talk and listen capability. 3-25...
Page 65: Using The Instrument
LOCAL OPERATION Using the instrument Precautions Microwave connectors Care should be taken when using microwave connectors, both on the instrument and any accessories that are used, such as cables, adapters, attenuators, etc. Complying with the following precautionary notes will ensure longer component lifetime and less equipment downtime due to connector or component failure.
Page 66: Leveling
Leveling is used to control the power level of the instrument’s RF source, via a fast, closed-loop feedback system. The control (feedback) signal used to level the output can be derived from either the internal leveling detector of the 6810A Series, or from an external detector or power meter, connected to the rear-panel EXT LEVEL INPUT Internal leveling provides a constant signal at the SIGNAL SOURCE OUTPUT connector regardless of reflections by adjusting the level of the source, thus improving the source match.
Page 68: Setup Group Keys
SETUP LOCAL OPERATION [SOURCE] key SETUP GROUP KEYS [SOURCE] key The [SOURCE] key provides access to the series of menus illustrated in Fig. 3-6, which are used to define and control all the source functions, e.g. the synthesized sweep generator and the programmable voltage output (AUX connector).
Page 69: Source (Start/Stop Frequency Sweep Mode)
SETUP LOCAL OPERATION [SOURCE] key SOURCE Source This menu enables the source to be set up to provide a linear frequency sweep between (Start/Stop the start frequency and stop frequency values. Frequency Sweep Mode) Reverse frequency sweeps are possible by making Start Frequency > Stop Frequency. Set Start Used to change the start frequency of the source to a value within the range permitted for the Frequency...
Page 70: Source
SETUP LOCAL OPERATION [SOURCE] key More SOURCE Source This is a continuation of the previous menu. Levelling Leads to the Levelling menu, which allows the leveling mode that is used to control the output power to be selected. See page 3-39. Frequency Leads to the Freq Standard menu, which allows the frequency standard to be used by the Standard...
Page 71: Source (Center/Span Frequency Sweep Mode)
SETUP LOCAL OPERATION [SOURCE] key SOURCE Source This menu enables the source to be set up to provide a linear frequency sweep by (Center/Span defining the center and span of the sweep. Frequency Sweep Mode) Reverse frequency sweeps are possible by entering a negative span value. Set Cntr Used to change the center frequency of the sweep to a value within the range permitted for Frequency...
Page 72: Source (Cw Mode)
SETUP LOCAL OPERATION [SOURCE] key SOURCE Source This menu enables the source to be set up to provide a continuous wave (CW) (CW Mode) frequency. The source can also be frequency modulated. Used to change the CW frequency of the source to a value within the range permitted for the Frequency particular instrument.
Page 73 SETUP LOCAL OPERATION [SOURCE] key SOURCE This menu is used for setting up frequency modulation of the source. External modulation is available on all instruments. Instruments with the internal modulation option fitted can also use an internal modulating source. Note that FM is only available when the instrument is in CW mode. Toggles frequency modulation of the source on or off.
Page 74: Source (Power Sweep)
SETUP LOCAL OPERATION [SOURCE] key SOURCE Source This menu enables the source to be set up to provide a linear power sweep between the (Power Sweep) start power and stop power values. Reverse power sweeps are possible by making Start Power > Stop Power. Set Start Used to change the start power level of the source.
Page 75: Source (List Sweep)
SETUP LOCAL OPERATION [SOURCE] key SOURCE Source This menu enables the source to be set up to provide a list sweep of up to 1024 (List Sweep) frequency points. Reverse sweeps are possible. Edit List Leads to a simple editing menu, which allows up to 1024 frequency points to be entered and/or edited.
Page 76: Sweep Time
SETUP LOCAL OPERATION [SOURCE] key Sweep SOURCE Time Sweep Time The sweep time is the time taken for the source to complete one sweep, excluding time required for internal processing of the data. The setting determined by this menu will apply instrument-wide.
Page 77: Source Mode
SETUP LOCAL OPERATION [SOURCE] key Select SOURCE Source Mode Source Mode This menu enables the instrument’s source to be set up to provide either a CW (continuous wave) output, or a swept output. Start & Stop Sets the source to the swept frequency mode of operation, in which the start and stop values Freq Sweep of the frequency sweep, and its power level, can be defined by returning to the Source menu.
Page 78: Leveling
Leveling This menu is used to select the leveling mode that is used to control the output power of the 6810A Series. Leveling is used for power level control, via a fast, closed-loop feedback system. The control (feedback) signal used to level the output can be derived from either the internal leveling detector of the instrument, or from an external detector or power meter, connected to the rear- panel EXT LEVEL INPUT.
Page 79: Freq Standard
FREQ STANDARD rear connector. Int Std Selects the internal crystal oscillator of the 6810A Series as the frequency standard. In this mode, the instrument provides a 10 MHz reference output at the FREQ STANDARD connector, derived from an internal oscillator.
Page 80: Voltage O/P
SETUP LOCAL OPERATION [SOURCE] key More Voltage SOURCE Output Voltage O/P The VOLTAGE OUTPUT, available on pin 1 of the rear-panel AUX connector, can be programmed to provide a 0–10 V ramp voltage, for swept frequency or power measurements, an adjustable constant bias voltage output, or a live y-axis output. 0–10 V Sets the voltage output to provide a 0–10 V ramp voltage proportional to swept frequency or Ramp...
Page 81: Loop Bandwidth
SETUP LOCAL OPERATION [SOURCE] key More Loop SOURCE Bandwidth Loop Bandwidth The loop bandwidth is the bandwidth of the frequency synthesizer phase-locked loop. This is determined by a filter in both the RF and microwave sections of the source. Low bandwidth reduces the spurious signal content of the source output but slows down the response;...
Page 82: Pulse Mod
SETUP LOCAL OPERATION [SOURCE] key More Pulse Mod SOURCE Pulse Mod This menu is used for setting up pulse modulation of the source. Pulse Mod Enables pulse generator and modulator. Pulse CW Turns RF on continuously, for normalizing external equipment. Internal Selects internal pulse modulation (if Option 23 is fitted).
Page 83: Single Pulse
SETUP LOCAL OPERATION [SOURCE] key More Single Pulse SOURCE Single Pulse This menu lets you set up the modulating pulse’s parameters. It is displayed when the Single Pulse soft key is pressed. Single Pulse This menu is displayed when this soft key is pressed. Pulse Pattern The menu on page 3-45 is displayed when this soft key is pressed.
Page 84 SETUP LOCAL OPERATION [SOURCE] key More Pulse Mod Single Pulse SOURCE Single Pulse This menu lets you set up the modulating pulse’s parameters. It is displayed when the Pulse Pattern soft key is pressed. Single Pulse The menu on page 3-44 is displayed when this soft key is pressed. Pulse Pattern This menu is displayed when this soft key is pressed.
Page 85 SETUP LOCAL OPERATION [SOURCE] key More Pulse Mod Single Pulse Edit Pattern SOURCE Moves up the modulating pulses in the pattern list. Moves down the modulating pulses in the pattern list. Previous Page Goes to the previous page of modulating pulses in the list. Next Page Goes to the next page of modulating pulses in the list.
Page 86: Trigger Mode
SETUP LOCAL OPERATION [SOURCE] key More Pulse Mod Trigger Mode SOURCE Trigger Mode This menu lets you set up the source for the pulse modulator trigger. External A trigger (positive-going TTL) is applied to the rear-panel AUX socket. internal (Option 23 only). Trigger pulses are generated internally to drive the pulse modulator. Continuous Timing parameters of the trigger pulses are set up in the Single Pulse menu or in the Edit Pattern menu.
Page 87: Point Delay
SETUP LOCAL OPERATION [SOURCE] key Point SOURCE Delay Point Delay This menu is used for setting up a delay between the establishment of a new list frequency and the lock output signal being asserted (active high). Lock (source is locked to within 10 kHz) is indicated by a positive TTL-compatible level on the LOCK OUTPUT rear-panel BNC connector.
Page 88 SETUP LOCAL OPERATION [SOURCE] key SOURCE ä ä Sweep Time Freq Standard Automatic Int Std Sweep Time ä ä Source Mode Loop Bandwidth Source User Set Ext Std Sweep Time 1 MHz Set Start Auto ä Start & Stop Source Frequency...
Page 89 SETUP LOCAL OPERATION [SOURCE] key Fig. 3-6 SOURCE menu 3-50...
Page 90: [Save / Recall] Key
SETUP LOCAL OPERATION [SAVE/RECALL] key [SAVE / RECALL] key The [SAVE/RECALL] key provides access to the menus shown in Figs. 3-7 and 3-8, which enable the current instrument settings to be saved to or recalled from a memory location specified by the user.
Page 91: Save/Recall
SETUP LOCAL OPERATION [SAVE/RECALL] key SAVE/RECALL Save/Recall See Fig. 3-7. The Save/Recall menu enables instrument settings to be saved, and then recalled for use in subsequent measurements. The current instrument settings can be stored in a specified memory location in the instrument’s internal non-volatile memory or on removable storage.
Page 92 SETUP LOCAL OPERATION [SAVE/RECALL] key Save SAVE/RECALL Settings Save Settings See Fig. 3-7. This function is used to save the current instrument settings to a memory location specified by the user, or to a file on removable storage. A form is displayed listing the identities of the available settings stores. To save the data to a specific settings store, the store name is selected from the list.
Page 93: Recall Settings
SETUP LOCAL OPERATION [SAVE/RECALL] key Recall SAVE/RECALL Settings Recall Settings See Fig. 3-7. This function is used to recall an instrument settings store. The instrument will be set up according to the stored parameters. A form is displayed listing the identities of the available settings stores. To retrieve the data from a specific store, it is selected from the list.
Page 94: Set Store Info
SETUP LOCAL OPERATION [SAVE/RECALL] key Save Set Store SAVE/RECALL Settings Information Set Store Info See Fig. 3-7. This menu is used to enable / disable password protection for the selected store and to enter arbitrary text to be saved with the store. A form is displayed showing information about the store, including whether or not it is password protected, whether or not it is in the spreadsheet format and the descriptive text.
Page 95: View Settings
SETUP LOCAL OPERATION [SAVE/RECALL] key View Inst SAVE/RECALL Settings View Settings See Fig. 3-8. This function is used to view the instrument’s current, preset default and user preset default settings, plus the contents of the settings stores. A form is displayed on the screen showing the selected settings. The [Print] soft key is used to output the settings to the current printer.
Page 96: Select Store
SETUP LOCAL OPERATION [SAVE/RECALL] key View Inst Select SAVE/RECALL Settings Store Select Store See Fig. 3-8. This menu is used to select an instrument settings store to be viewed. A form is displayed listing the identities of the available settings stores. To view the data in a specific settings store, the store name is selected from the list.
Page 97: Set Store Info
SETUP LOCAL OPERATION [SAVE/RECALL] key Save Set Store SAVE/RECALL Settings Information Set Store Info See Fig. 3-7. This menu is used to enable / disable password protection for the selected store and to enter arbitrary text to be saved with the store. A form is displayed showing information about the store, including whether or not it is password protected, whether or not it is in the spreadsheet format and the descriptive text.
Page 98 SETUP LOCAL OPERATION [SAVE/RECALL] key SAVE/ RECALL Save/Recall Save ä Save Settings Settings Recall Save ä Recall Settings Settings Select Save Settings as User Default View Inst Sheet 2 Settings New Store Name USB Memory USB Memory Set Store ä Set Store Info Information Password...
Page 99 SETUP LOCAL OPERATION [SAVE/RECALL] key Fig. 3-7 SAVE/RECALL menus (sheet 1) 3-60 46882/350...
Page 100 SETUP LOCAL OPERATION [SAVE/RECALL] key From From Sheet 1 Sheet 1 View Settings View Settings Current Current Settings Settings Default Default Settings Settings User Default User Default Settings Settings Settings Settings Store Store Save to ä Save Settings Store Save Settings Save as User Default Print...
Page 101 SETUP LOCAL OPERATION [SAVE/RECALL] key Fig. 3-8 SAVE/RECALL menus (sheet 2) 3-62 46882/350...
Page 102: System Group Keys
SYSTEM LOCAL OPERATION SYSTEM GROUP KEYS [UTILITY] key The [UTILITY] key provides access to the series of menus illustrated in Figs. 3-9 to 3-13. The menus provide utility functions, such as setting up the display and performing various system functions. UTILITY Utility See Fig.
Page 103: Remote
SYSTEM LOCAL OPERATION Remote UTILITY Control Remote See Fig. 3-9. This menu enables the remote control mode to be selected. Controlled In this mode, the instrument will only expect to receive remote commands over the serial bus. by RS232 Controlled In this mode, the instrument will only expect to receive remote commands over the GPIB.
Page 104: Security
SYSTEM LOCAL OPERATION Security UTILITY Security See Fig. 3-9. This menu provides access to the security functions of the instrument. Secret Freq Used to remove all frequency annotation from the display. The soft key has an on/off toggle Display action. Lock Used to blank the display and disable the front-panel keys and remote control.
Page 105: Inc/Dec Steps
SYSTEM LOCAL OPERATION Set Inc UTILITY / Dec Steps Inc/Dec Steps See Fig. 3-9. This menu enables the user to define the step size that is used when changing numeric parameters with the step keys. A form is displayed on the screen showing a list of the step sizes and their current value. The [ ] and [ ] soft keys are used to move between the step sizes which can then be changed as follows: ×...
Page 106: Store Mngmnt
SYSTEM LOCAL OPERATION Store UTILITY Management Store Mngmnt See Fig. 3-9. This menu enables copying of data between the instrument’s internal stores and removable storage. Stores (but not directories) can also be deleted. Stores are actually files on removable storage or on the internal flash card, which stores files in a similar way to a hard disk.
Page 107: Manage Stores
SYSTEM LOCAL OPERATION Store Settings UTILITY Management Store Power UTILITY Management Cals Manage Stores See Fig. 3-9. This menu is used to copy data between the instrument’s internal stores and removable storage. Stores (but not directories) can also be deleted. A form is displayed listing stores of the relevant type, i.e.
Page 108: Service
SYSTEM LOCAL OPERATION Service UTILITY Service See Fig. 3-11. This menu provides various service functions. Set-up Leads to the Set-up menu, which provides several instrument setup functions. See page 3-70. Status Leads to the Status menu, which allows the user to examine the power on test results and the build state of the instrument.
Page 109: Display
SYSTEM LOCAL OPERATION Service Set-up UTILITY Set-up See Fig. 3-12. This menu provides facilities for setting up the display and setting the instrument's real-time clock. Display Leads to the Display menu, which enables the display brightness to be set, and also provides a screen blanking facility.
Page 110: Colour Palettes
SYSTEM LOCAL OPERATION Service Set-up Display UTILITY Display See Fig. 3-12. This menu provides facilities for setting up aspects of the instrument’s LCD. Maximum Sets the LCD backlight to maximum brightness. Brightness High Sets the LCD backlight to high brightness. Brightness Sets the LCD backlight to low brightness.
Page 111: Date & Time
SYSTEM LOCAL OPERATION Service Set-up Set Date UTILITY & Time Date & Time See Fig. 3-12. This function is used to set the instrument's real-time clock and calendar. A form is displayed on the screen showing the current time and date, together with soft keys for parameter selection.
Page 112: Status
A [Print] soft key is displayed which enables a hard copy printout to be obtained. Display Patent Lists any patents relating to the 6810A Series instruments. Information Get ID ROM Displays build state information for each printed circuit board within the instrument, which is Details held in ROM.
Page 113: Instrument Cals
SYSTEM LOCAL OPERATION Service Instrument UTILITY Calibrations Instrument Cals See Fig. 3-13. This menu provides facilities for self-calibration of the instrument. The calibration process is controlled automatically by the instrument. For operations taking more than a few seconds to complete, a percentage complete indicator will be displayed after the function has been initiated.
Page 114: Rf Source Cals
SYSTEM LOCAL OPERATION Service Instrument RF Source UTILITY Calibrations Calibrations RF Source Cals See Fig. 3-13. This menu provides facilities for calibrating the instrument's source and internal frequency standard. Frequency Used to calibrate the instrument's internal frequency standard against an external standard. Standard Cal The user is prompted to connect the external standard to the FREQ STANDARD INPUT/OUTPUT connector on the rear panel and press [Continue] when ready.
Page 115: Bband Power Cal
SYSTEM LOCAL OPERATION Service Instrument RF Source Broadband UTILITY Calibrations Calibrations Power Cal Bband Power Cal See Fig. 3-13. This menu is used to perform a broadband power calibration of the instrument's source, i.e. over its full frequency range. The user is prompted to connect a detector (6230A/L series) to INPUT A and to the SIGNAL SOURCE OUTPUT connector and press [Continue] when ready.
Page 116: Nband Power Cal
SYSTEM LOCAL OPERATION Service Instrument RF Source Narrowband UTILITY Calibrations Calibrations Power Cal Nband Power Cal See Fig. 3-13. This menu is used to perform a narrowband power calibration of the instrument's source, i.e. over a user-defined frequency range. The narrowband calibration facility enables a power calibration to be performed over a limited frequency range.
Page 117: Power Cal Funcs
SYSTEM LOCAL OPERATION Service Instrument RF Source Power Cal UTILITY Calibrations Calibrations Functions Power Cal Funcs See Fig. 3-13. This menu provides additional power calibration functions. Transfer to Transfers a user power calibration into the primary calibration store (contains the factory- Primary Cal generated power calibration data).
Page 118: Tests
SYSTEM LOCAL OPERATION Service Tests UTILITY Tests See Fig. 3-11. This menu enables the operator to verify that the display and keyboard are functioning correctly. Test Allows each key on the front panel to be tested individually, and allows the rotary control to Keyboard be tested for clockwise and anti-clockwise rotation.
Page 119: International
SYSTEM LOCAL OPERATION International UTILITY International See Fig. 3-10. This function enables the following country-specific instrument settings to be set: Language - text is displayed in the selected foreign language, and supports the special character requirements of French, German and Spanish. Keyboard layout - If an external keyboard is used, the layout can be specified according to the country.
Page 120: New Locale
SYSTEM LOCAL OPERATION Install Leads to the New Locale menu, which enables new country setting to be installed from New Locale removable storage. See page 3-81 Parameter selected Select Sets the parameter to the currently selected value in the list. Selects the previous entry in the list of values.
Page 122 SYSTEM LOCAL OPERATION ä Remote ä Controlled Security by RS232 Secret Freq Controlled UTILITY Display by GPIB Lock No External Instrument Controller Set Up ä Set Passwords Utility Passwords RS232 Remote Set Level 1 GPIB Control Password... Address... Set Level 2 Restore Password...
Page 123 SYSTEM LOCAL OPERATION Fig. 3-9 UTILITY menus (sheet 1) 3-84...
Page 124 SYSTEM LOCAL OPERATION Fig. 3-10 UTILITY menus (sheet 2) 3-85...
Page 125 SYSTEM LOCAL OPERATION Fig. 3-10 UTILITY menus (sheet 2) 3-86...
Page 126 SYSTEM LOCAL OPERATION Fig. 3-11 UTILITY menus (sheet 3) 3-87...
Page 127 SYSTEM LOCAL OPERATION Fig. 3-11 UTILITY menus (sheet 3) 3-88...
Page 128 SYSTEM LOCAL OPERATION Fig. 3-12 UTILITY menus (sheet 4) 3-89...
Page 129 SYSTEM LOCAL OPERATION Fig. 3-12 UTILITY menus (sheet 4) 3-90...
Page 130 SYSTEM LOCAL OPERATION From Sheet 3 ä Freq Std Cal Continue Instrument Cals RF Source ä RF Source Cals Calibrations Frequency Standard Cal Perform Frequency Cal Broadband ä Bband Power Cal Power Cal Continue Narrowband ä Nband Power Cal Power Cal Pulse Power Cal Continue...
Page 131 SYSTEM LOCAL OPERATION Fig. 3-13 UTILITY menus (sheet 5) 3-92...
Page 132: [Preset] Key
SYSTEM LOCAL OPERATION [PRESET] key The [PRESET] key provides a menu that enables the instrument to be set to a known condition. PRESET Preset Full User Abort C5765 Fig. 3-14 PRESET menu PRESET Preset This menu is used to set the instrument into a known state. If an application will be automatically run after the preset operation then a message will be displayed giving the application’s name.
Page 133: [Local] Key
SYSTEM LOCAL OPERATION [LOCAL] key The [LOCAL] key does not have an associated menu structure. It is used to return the instrument to local (front panel) operation after being put into the remote state by a controller. If the instrument was being triggered by the controller, then a prompt will appear asking whether or not the instrument is to be returned to the autotrigger mode of operation.
Page 134 GETTING STARTED......................4-13 Introduction ..........................4-13 The remote operation command set................... 4-13 Preparing the 6810A Series for GPIB operation ............... 4-14 Preparing the 6810A Series for RS-232 operation ..............4-14 6810A Series COMMAND SET ..................... 4-15 Common commands subsystem ..................... 4-15 DISPlay subsystem ........................
Page 135: Introduction
GENERAL INFORMATION Introduction 6810A Series instruments are equipped for remote operation via the GPIB interface or the RS-232 (serial) interface. The GPIB (General Purpose Interface Bus) interface provides instrument control with full talk and listen capability. The command syntax for both GPIB and RS-232 conforms to IEEE 488.2.
Page 136: Compound Headers
GENERAL INFORMATION Compound headers Compound headers allow a complex set of commands to be built up from a smaller set of basic elements in a "tree" structure. The elements of a compound header are separated by a colon " : ". Each subsystem in this instrument is organized as a separate tree structure.
Page 137: Default Branches
GENERAL INFORMATION Default branches Some elements within the compound header tree structure are enclosed within square brackets, " [ " and " ] ". These elements may be omitted, if desired, to reduce the length of the compound header. Abbreviations In general, compound header elements have a long and a short form.
Page 138 'This string contains the word ''Hello''' will be interpreted as the string: This string contains the word 'Hello' When receiving string data, the 6810A Series GPIB system interprets character codes as follows: 32 - 126 Standard ASCII characters Copyright symbol ©...
Page 139: Response Data
GENERAL INFORMATION Note that data received from the instrument as <DEFINITE LENGTH ARBITRARY BLOCK RESPONSE DATA> is already in a form suitable for transmission back to the instrument as <ARBITRARY BLOCK PROGRAM DATA>. The definite length form can be used on both GPIB and RS-232 interfaces.
Page 140 GENERAL INFORMATION <NR2> This type of numeric response is used to return real numbers; it includes an explicitly placed decimal point, but no exponent. The decimal point will always be output, with at least one digit before and one digit after the decimal point. A negative number will be preceded with a − sign; a positive number may or may not have a + sign.
Page 141: Terminating Commands
GENERAL INFORMATION Terminating commands GPIB A <PROGRAM MESSAGE TERMINATOR> (as defined in IEEE 488.2) can be a line-feed character (ASCII 10), a line-feed character with the ^END message asserted at the same time, or an ^END message asserted with the final character of the <PROGRAM MESSAGE>. The terminator may be preceded by any number of "white space"...
Page 142 GENERAL INFORMATION Valid values Describes the type of number for numeric parameters, e.g. real or integer, and the allowable range, if applicable. If a parameter is defined as character program data, the allowable <CPD> strings are given. For string program data, the maximum number of characters is specified. In the above example, the first parameter can accept the strings A, B, C or RX;...
Page 143: Status Reporting
GENERAL INFORMATION Status reporting The instruments within a GPIB system contain a set of registers that reflect the current state of the instrument and whether a particular event has occurred. It is also sometimes necessary for an instrument to generate an alert if that condition exists or if that event has occurred. The instrument's status registers contain information about the condition of the instrument.
Page 144 GENERAL INFORMATION Operation Status Register. This is a 16-bit register, defined in SCPI, which further extends the status reporting structure by providing information about what the instrument is doing. It is read by the STATus:OPERation:CONDition? command. The summary bit output of the register is recorded in bit 7 of the Status Byte.
Page 145 GENERAL INFORMATION 1. Determine which register set and which of its bits monitors the condition. 2 Determine how that bit reports to the request service (RQS) bit of the Status Byte (some report directly while others may report indirectly through other register sets). 3.
Page 146: Getting Started
This section provides an introduction to GPIB programming of the 6810A Series. The remote operation command set The first point to notice when controlling the 6810A Series remotely is that there is no straightforward mapping between manual front panel operations and their remote command equivalents.
Page 147: Preparing The 6810A Series For Gpib Operation
Connection to the external controller is made via the rear panel GPIB connector. The 6810A Series GPIB system can operate in two modes, controller or talker/listener. In controller mode, the instrument takes control of the bus in order to drive an external source. This mode is selected by pressing the [No External Controller] soft key.
Page 148: 6810A Series Command Set
6810A Series COMMAND SET Common commands subsystem *CLS *ESE\? *ESR? *IDN? *OPC\? *OPT? *PCB *RST *SRE\? *STB? *TRG *TST? *WAI 4-15...
Page 149 6810A SERIES COMMAND SET *CLS Parameters: none Description: Clear Status clears the Standard Event Status Register, the Error Queue, the Operation Status Event Register and the Questionable Status Event Register. Example: *CLS Clear the status reporting structure. *ESE Parameters: <NRf>...
Page 150 6810A SERIES COMMAND SET *IDN? Parameters: none Response: <ARBITRARY ASCII RESPONSE DATA> Instrument Identification Returned values: Instrument Identification: string Description: The Identification Query command allows information about the instrument to be read. The Instrument Identification is split into four fields:...
Page 151 6810A SERIES COMMAND SET *OPC Parameters: none Description: The Operation Complete command sets the Operation Complete bit in the Standard Event Status Register when execution of all overlapped commands have completed. This command is really only useful after an overlapped command when it will indicate when that command has been completed.
Page 152 6810A SERIES COMMAND SET *OPT? Parameters: none Response: <ARBITRARY ASCII RESPONSE DATA> options Returned values: options: string Description: Read hardware options present. If no options are present a single “0” is returned otherwise the response is a number of strings separated by commas. If the option is present it will return the string shown below, if it is not present nothing is returned for that option.
Page 153 6810A SERIES COMMAND SET *RST Parameters: none Description: Reset the instrument. This command places the instrument in its default state. See Appendix E for details on which parameters are not affected by preset. If the Remote control system fails to respond to *RST, it may be cleared by sending a DEVICE CLEAR command.
Page 154 6810A SERIES COMMAND SET *STB? Parameters: none Response: <NR1> status byte Returned values: status byte: integer. Values are in the range 0 to 255. Description: Read the Status Byte Register. This is an eight-bit register. Bit 6 of the register contains the Master Summary Status.
Page 156: Display Subsystem
DISPlay subsystem DISPlay BLIGht\? CONTrast\? CPALette\? 4-23...
Page 157 6810A SERIES COMMAND SET :DISPlay :BLIGht Parameters: <CPD> backlight brightness Valid values: backlight brightness: [OFF | MINimum | LOW | HIGH | MAXimum]. Values other than those stated are rejected and an error generated. Description: Set the backlight brightness. When using the instrument outside, the backlight on the monochrome LCD is not required and can be turned off by using :DISP:BLIG OFF.
Page 158 6810A SERIES COMMAND SET :DISPlay :CONTrast Parameters: <NUMERIC VALUE> contrast Valid values: contrast: integer. Valid values are 0 to 100. Values outside range are clipped. Suffix: contrast: A suffix of pct is accepted for a value of percent. If no suffix is entered then the default suffix of pct is assumed.
Page 159 6810A SERIES COMMAND SET :DISPlay :CPALette Parameters: <CPD> palette Valid values: palette : [COLour | WHITe | BLACk | GREen | MONochrome]. Values other than those stated are rejected and an error generated. Description: Set the color palette on an instrument equipped with the color LCD. This command will generate an error if it is received on an instrument fitted with the monochrome LCD.
Page 160: Mmemory Subsystem
MMEMory subsystem MMEMory ATTRibutes? CATalog COUNt? [FILes]? SIZes? CDIRectory\? COPY DELete ERASe [ALL] ID\? MDIRectory MSIS\? RDIRectory READ HSETup? SETTings? SOURce FCALibration? FSTandard? PPOWer? UPOWer? REName WRITe HSETup SETTings SOURce FCALibration FSTandard PPOWer UPOWer 4-27...
Page 161 6810A SERIES COMMAND SET :MMEMory :ATTRibutes? Parameters: <STRING PROGRAM DATA> file name Valid values: file name: string. Maximum length of 12 characters excluding quotes. Excess characters will be ignored. Response: <NR1> attributes Returned values: attributes: integer Description: Return the attributes of the specified file. Both file name and extension must be given to ensure one and only one file will be accessed.
Page 162 6810A SERIES COMMAND SET :MMEMory :CATalog? :COUNt? Parameters: <STRING PROGRAM DATA> file type Valid values: file type: string. Maximum length of 3 characters excluding quotes. Excess characters will be ignored. Response: <NR1> total files Returned values: total files: integer Description: Return a count of files of the type specified (or all, if the parameter is an asterisks “*”).
Page 163 6810A SERIES COMMAND SET :MMEMory :CATalog [:FILes]? Parameters: <STRING PROGRAM DATA> file type Valid values: file type: string. Maximum length of 3 characters excluding quotes. Excess characters will be ignored. Response: <STRING RESPONSE DATA>, ..., <STRING RESPONSE DATA> first file name, ..., last file name...
Page 164 6810A SERIES COMMAND SET :MMEMory :CATalog :SIZes? Parameters: <STRING PROGRAM DATA> file type Valid values: file type: string. Maximum length of 3 characters excluding quotes. Excess characters will be ignored. Response: <NR1>, ..., <NR1> first file length, ..., last file length...
Page 165 6810A SERIES COMMAND SET :MMEMory :CDIRectory Parameters: <STRING PROGRAM DATA> directory path Valid values: directory path: string. Maximum length of 144 characters excluding quotes. Excess characters will be ignored. Description: Change the current directory. This only applies to the removable storage. A null directory path will generate an error.
Page 166 6810A SERIES COMMAND SET :MMEMory :DELete Parameters: <STRING PROGRAM DATA> file name Valid values: file name: string. Maximum length of 12 characters excluding quotes. Excess characters will be ignored. Description: Delete the specified file in the current directory. File name and extension must be given.
Page 167 6810A SERIES COMMAND SET :MMEMory Parameters: <STRING PROGRAM DATA>, <STRING PROGRAM DATA> file name, user id Valid values: file name: string. Maximum length of 12 characters excluding quotes. Excess characters will be ignored. user id: string Description: Set the id string of the specified file in the current directory. The id string gives additional details of the file over what can be determined from the file name and extension alone.
Page 168 6810A SERIES COMMAND SET :MMEMory :ID? Parameters: <STRING PROGRAM DATA> file name Valid values: file name: string. Maximum length of 12 characters excluding quotes. Excess characters will be ignored. Response: <STRING RESPONSE DATA> id string Returned values: id string: string Description: Read the id string of the specified file in the current directory.
Page 169 6810A SERIES COMMAND SET :MMEMory :MSIS Parameters: <STRING PROGRAM DATA> storage device Valid values: storage device: string. Maximum length of 1 character excluding quotes. Excess characters will be ignored. Description: Change the currently selected mass storage device. The storage device is defined as: Removable storage.
Page 170 6810A SERIES COMMAND SET :MMEMory :READ :HSETup? Parameters: <STRING PROGRAM DATA> file name Valid values: file name: string. Maximum length of 8 characters excluding quotes. Excess characters will be ignored. Response: <DEFINITE LENGTH ARBITRARY BLOCK RESPONSE DATA> hardcopy setup store contents...
Page 171 6810A SERIES COMMAND SET :MMEMory :READ :SOURce :FCALibration? Parameters: none Response: <DEFINITE LENGTH ARBITRARY BLOCK RESPONSE DATA> store contents Description: Read the source frequency calibration store data. Example: :MMEM:READ:SOUR:FCAL? :MMEMory :READ :SOURce :FM? Parameters: none Response: <DEFINITE LENGTH ARBITRARY BLOCK RESPONSE DATA>...
Page 172 6810A SERIES COMMAND SET :MMEMory :READ :SOURce :PPOWer? Parameters: none Response: <DEFINITE LENGTH ARBITRARY BLOCK RESPONSE DATA> Description: Read the source primary power calibration store data. Example: :MMEM:READ:SOUR:PPOW? :MMEMory :READ :SOURce :UPOWer? Parameters: <STRING PROGRAM DATA> file name Valid values: file name: string.
Page 173 6810A SERIES COMMAND SET :MMEMory :REName Parameters: <STRING PROGRAM DATA>, <STRING PROGRAM DATA> file name old, file name new Valid values: file name old: string. Maximum length of 12 characters excluding quotes. Excess characters will be ignored. file name new: string. Maximum length of 12 characters excluding quotes. Excess characters will be ignored.
Page 174 6810A SERIES COMMAND SET :MMEMory :WRITe :SETTings Parameters: <STRING PROGRAM DATA>,<ARBITRARY BLOCK PROGRAM DATA> file name, settings store contents Valid values: file name: string. Maximum length of 8 characters excluding quotes. Excess characters will be ignored. Description: Write instrument settings data to a settings store. The store will be accessed using...
Page 175 6810A SERIES COMMAND SET :MMEMory :WRITe :SOURce Parameters: <ARBITRARY BLOCK PROGRAM DATA> store contents Description: Send data to source FM calibration store. This command will give an error if the FM option is not fitted. Example: :MMEM:WRIT:SOUR:FM #...etc Send source FM calibration data to source fm store. (Only first byte of data shown).
Page 176: Valid Values
6810A SERIES COMMAND SET :MMEMory :WRITe :SOURce :UPOWer Parameters: <STRING PROGRAM DATA>,<ARBITRARY BLOCK PROGRAM DATA> file name, store contents Valid values: file name: string. Maximum length of 8 characters excluding quotes. Excess characters will be ignored. Description: Send data to user source power calibration store.
Page 178: Source Subsystem
SOURce subsystem 4-45...
Page 179 6810A SERIES COMMAND SET SOURce BLANking\? CALibration FREQuency POWer [BBANd] NBANd SELect\? STANdard TRANsfer DOMain [ASCii]? BINary? [DEViation]\? EXTernal COUPling\? DCNull INTernal FREQuency\? SOURce\? STATe\? FREQuency CENTer\? CENTre\? [CW]\? SPAN\? STANdard\? STARt\? STOP\? LEVelling\? LIST [APPend] CLEar CSWeep LOAD PDELay...
Page 180 6810A SERIES COMMAND SET RF\? SBANdwidth MICRowave\? MODE\? RF\? SWEep AUTO\? POINts\? TIME\? VOUTput MODE\? VALue\? 4-47...
Page 181 6810A SERIES COMMAND SET :SOURce :BLANking Parameters: <BOOLEAN PROGRAM DATA> state Description: Set source RF blanking on or off. Example: :SOUR:BLAN ON Set source RF blanking on. :SOURce :BLANking? Parameters: none Response: <BOOLEAN RESPONSE DATA> state Description: Determine whether source RF blanking is on or off.
Page 182 6810A SERIES COMMAND SET :SOURce :CALibration :POWer [:BBANd] Parameters: <STRING PROGRAM DATA> file name Valid values: file name: string. Maximum length of 8 characters excluding quotes. Excess characters will be ignored. Description: Perform a broadband source power calibration and save data to specified user source power calibration store.
Page 183 6810A SERIES COMMAND SET :SOURce :CALibration :POWer :NBANd Parameters: <NUMERIC VALUE>, <NUMERIC VALUE>, <STRING PROGRAM DATA> start frequency, stop frequency, file name Valid values: start frequency: real stop frequency: real file name: string. Maximum length of 8 characters excluding quotes. Excess characters will be ignored.
Page 184 6810A SERIES COMMAND SET :SOURce :CALibration :SELect Parameters: <STRING PROGRAM DATA> file name Valid values: file name: string. Maximum length of 8 characters excluding quotes. Excess characters will be ignored. Description: Select a source power calibration. If the filename specified is PRIMPWR then the primary power calibration will be selected otherwise the specified user power calibration will be selected.
Page 185 6810A SERIES COMMAND SET :SOURce :CALibration :TRANsfer Parameters: <STRING PROGRAM DATA> file name Valid values: file name: string. Maximum length of 8 characters excluding quotes. Excess characters will be ignored. Description: Transfer a user source power calibration to the primary power calibration.
Page 186 6810A SERIES COMMAND SET :SOURce :DOMain :BINary? Parameters: none Response: <DEFINITE LENGTH ARBITRARY BLOCK RESPONSE DATA> domain data Description: Read the domain values for every source point. The returned data is organized as follows: Each domain value consists of 8 bytes received in the order:...
Page 187 6810A SERIES COMMAND SET :SOURce [:DEViation] Parameters: <NUMERIC VALUE> FM deviation value Valid values: FM deviation value real Suffix: FM deviation value: The following suffixes are accepted for frequency: Hz, kHz, MHz and GHz. If no suffix is entered then the default suffix of Hz is assumed.
Page 188 6810A SERIES COMMAND SET :SOURce :EXTernal :COUPling Parameters: <CPD> external coupling Valid values: external coupling: [AC | DC]. Values other than those stated are rejected and an error generated. Description: Select whether the external FM signal is AC or DC coupled.
Page 189 6810A SERIES COMMAND SET :SOURce :INTernal :FREQuency Parameters: <NUMERIC VALUE> internal frequency value Valid values: internal frequency value: real Suffix: internal frequency value: The following suffixes are accepted for frequency: Hz, kHz and MHz. If no suffix is entered then the default suffix of Hz is assumed.
Page 190 6810A SERIES COMMAND SET :SOURce :SOURce Parameters: <CPD> coupling mode Valid values: coupling mode: [INTernal | EXTernal]. Values other than those stated are rejected and an error generated. Description: Select whether the internal modulator or an external frequency source is being used to generate FM.
Page 191 6810A SERIES COMMAND SET :SOURce :STATe Parameters: <BOOLEAN PROGRAM DATA> state Description: Set FM on or off. This command is only valid if the FM option is fitted to the instrument. Example: :SOUR:FM:STAT ON Set FM on. :SOURce :STATe? Parameters:...
Page 192 6810A SERIES COMMAND SET :SOURce :FREQuency :CENTer Parameters: <NUMERIC VALUE> frequency center value Valid values: frequency center value: real Suffix: frequency center value: The following suffixes are accepted for frequency: Hz, kHz, MHz and GHz. If no suffix is entered then the default suffix of Hz is assumed.
Page 193 6810A SERIES COMMAND SET :SOURce :FREQuency :CENTre Parameters: <NUMERIC VALUE> frequency center value Valid values: frequency center value: real Suffix: frequency center value: The following suffixes are accepted for frequency: Hz, kHz, MHz and GHz. If no suffix is entered then the default suffix of Hz is assumed.
Page 194 6810A SERIES COMMAND SET :SOURce :FREQuency Parameters: <NUMERIC VALUE> CW frequency Valid values: CW frequency: real Suffix: CW frequency: The following suffixes are accepted for frequency: Hz, kHz, MHz and GHz. If no suffix is entered then the default suffix of Hz is assumed.
Page 195 6810A SERIES COMMAND SET :SOURce :FREQuency :SPAN Parameters: <NUMERIC VALUE> frequency span value Valid values: frequency span value: real Suffix: frequency span value: The following suffixes are accepted for frequency: Hz, kHz, MHz and GHz. If no suffix is entered then the default suffix of Hz is assumed.
Page 196 6810A SERIES COMMAND SET :SOURce :FREQuency :STANdard Parameters: <CPD> frequency standard Valid values: frequency standard: [INT | EX1 | EX10]. Values other than those stated are rejected and an error generated. Description: Select a source frequency standard: internal, external 1 MHz or external 10 MHz.
Page 197 6810A SERIES COMMAND SET :SOURce :FREQuency :STARt Parameters: <NUMERIC VALUE> frequency start value Valid values: frequency start value: real Suffix: frequency start value: The following suffixes are accepted for frequency: Hz, kHz, MHz and GHz. If no suffix is entered then the default suffix of Hz is assumed.
Page 198 6810A SERIES COMMAND SET :SOURce :FREQuency :STOP Parameters: <NUMERIC VALUE> frequency stop value Valid values: frequency stop value: real Suffix: frequency stop value: The following suffixes are accepted for frequency: Hz, kHz, MHz and GHz. If no suffix is entered then the default suffix of Hz is assumed.
Page 199 6810A SERIES COMMAND SET :SOURce :LEVelling Parameters: <CPD> leveling mode Valid values: leveling mode: [INTernal | POSitive | NEGative | PMETer]. Values other than those stated are rejected and an error generated. Description: Set the source leveling mode: INTernal Internal leveling...
Page 200 6810A SERIES COMMAND SET :SOURce :LIST :CLEar Parameters: none Description: Clears the list. Subsequent :SOUR:LIST:APP commands will build a new list starting with point 0. This command is only valid on variants that support list sweep. Example: :SOUR:LIST:CLE :SOURce :LIST...
Page 201 6810A SERIES COMMAND SET :SOURce :LIST :PDELay :AUTO Parameters: <BOOLEAN PROGRAM DATA> state Valid values: state: OFF | ON Description: Sets the point delay time automatically to achieve the fastest possible stepping rate. This command is only valid on variants that support list sweep.
Page 202 6810A SERIES COMMAND SET :SOURce :LIST :PDELay :TIME Parameters: <NUMERIC VALUE> Valid values: point delay: real Suffix: A suffix of either ms or s is accepted for time. If no suffix is entered then the default suffix of s is assumed.
Page 203 6810A SERIES COMMAND SET :SOURce :LIST :RESet Parameters: none Description: Resets the list sweep to point 0. This command is only valid on variants that support list sweep. Example: :SOUR:LIST:RESet :SOURce :LIST :REVerse Parameters: <BOOLEAN PROGRAM DATA> state Description: Determines the sweep direction for a list sweep. This command is only valid on variants that support list sweep.
Page 204 6810A SERIES COMMAND SET :SOURce :LIST :STEP Parameters: Description: Steps to the next point in a list sweep. This command is equivalent to *TRG or an IEEE488.1 group execute trigger (GET) command. This command is only valid on variants that support list sweep and when the list trigger mode is set to “internal single”.
Page 205 6810A SERIES COMMAND SET :SOURce :MODE Parameters: <CPD> source mode Valid values: source mode: [POWer | FREQuency | CW]. Values other than those stated are rejected and an error generated. Description: Set the source mode. Valid source modes are: POWer...
Page 206 6810A SERIES COMMAND SET :SOURce :POWer :LEVel Parameters: <NUMERIC VALUE> power level Valid values: power level: real Suffix: power level: A suffix of dBm is accepted for power. If no suffix is entered then the default suffix of dBm is assumed.
Page 207 6810A SERIES COMMAND SET :SOURce :POWer :STARt Parameters: <NUMERIC VALUE> power start value Valid values: power start value: real Suffix: power start value: a suffix of dBm is accepted for power. If no suffix is entered then the default suffix of dBm is assumed.
Page 208 6810A SERIES COMMAND SET :SOURce :POWer :STOP Parameters: <NUMERIC VALUE> power stop value Valid values: power stop value: real Suffix: power stop value: A suffix of dBm is accepted for power. If no suffix is entered then the default suffix of dBm is assumed.
Page 209 6810A SERIES COMMAND SET :SOURce Parameters: <BOOLEAN PROGRAM DATA> state Description: Set RF output on or off. Example: :SOUR:RF ON Set RF on. :SOURce :RF? Parameters: none Response: <BOOLEAN RESPONSE DATA> state Description: Determine whether RF output is on. Example:...
Page 210 6810A SERIES COMMAND SET :SOURce :SBANdwidth :MICRowave Parameters: <CPD> loop bandwidth state Valid values: loop bandwidth state: [FAST | SLOW]. Values other than those stated are rejected and an error generated. Description: Set the loop bandwidth state for the source output block.
Page 211 6810A SERIES COMMAND SET :SOURce :SBANdwidth :MODE Parameters: <CPD> loop bandwidth mode Valid values: loop bandwidth mode: [AUTO | MANual]. Values other than those stated are rejected and an error generated. Description: Set the loop bandwidth mode. Setting AUTO mode will make the instrument determine the appropriate values for the RF and microwave loop bandwidth settings.
Page 212 6810A SERIES COMMAND SET :SOURce :SBANdwidth Parameters: <CPD> loop bandwidth state Valid values: loop bandwidth state: [FAST | SLOW]. Values other than those stated are rejected and an error generated. Description: Set the loop bandwidth state for the core block.
Page 213 6810A SERIES COMMAND SET :SOURce :SWEep :AUTO Parameters: <BOOLEAN PROGRAM DATA> state Description: Enable/disable automatic setting of sweep time. Example: :SOUR:SWE:AUTO OFF Enable sweep time to be set by the user. :SOURce :SWEep :AUTO? Parameters: none Response: <BOOLEAN RESPONSE DATA>...
Page 214 6810A SERIES COMMAND SET :SOURce :SWEep :POINts Parameters: <NUMERIC VALUE> number of points Valid values: number of points: integer Suffix: number of points: No suffix is allowed. Description: Set the number of sweep points. See Appendix D for the special values that may be entered instead of a numeric value for NUMERIC VALUE.
Page 215 6810A SERIES COMMAND SET :SOURce :SWEep :TIME Parameters: <NUMERIC VALUE> sweep time Valid values: sweep time: real Suffix: sweep time: A suffix of either ms or s is accepted for time. If no suffix is entered then the default suffix of s is assumed.
Page 216 6810A SERIES COMMAND SET :SOURce :VOUTput :MODE Parameters: <CPD> voltage output mode Valid values: voltage output mode: [VRAMp | YAXis | FVOLtage]. Values other than those stated are rejected and an error generated. Description: Set the mode for the VOLTAGE OUTPUT located on the rear panel. The...
Page 217 6810A SERIES COMMAND SET :SOURce :VOUTput :VALue Parameters: <NUMERIC VALUE> voltage Valid values: voltage: real Suffix: voltage: A suffix of either mV or V is accepted for voltage. If no suffix is entered then the default suffix of V is assumed.
Page 218: Status Subsystem
STATus subsystem STATus OPERation CONDition? ENABle\? [EVENt]? NTRansition\? PTRansition\? PRESet QUEStionable CONDition? ENABle\? [EVENt]? NTRansition\? PTRansition\? 4-85...
Page 219 6810A SERIES COMMAND SET :STATus :OPERation :CONDition? Parameters: none Response: <NR1> register contents Returned values: register contents: integer. Values are in the range 0 to 32767. Description: Read the contents of the Operation Status Condition Register. This register returns the current state of the instrument. Reading the register does not affect its contents.
Page 220 6810A SERIES COMMAND SET :STATus :OPERation :ENABle Parameters: <NRf> mask Valid values: mask: integer. Valid values are 0 to 65535. Values outside range are rejected and an error generated. Description: Sets the enable mask, which allows true conditions in the Operation Status Event Register to be reported in the summary bit (bit 7 in the Status Byte Register).
Page 221 6810A SERIES COMMAND SET :STATus :OPERation [:EVENt]? Parameters: none Response: <NR1> event register contents Returned values: event register contents: integer. Values are in the range 0 to 32767. Description: Read the contents of the Operation Status Event Register. Reading the register will clear it.
Page 222 6810A SERIES COMMAND SET :STATus :OPERation :NTRansition Parameters: <NRf> negative transition mask Valid values: negative transition mask: integer. Valid values are 0 to 65535. Values outside range are rejected and an error generated. Description: Sets the negative transition filter, which allows transitions from 1 to 0 in the Operation Status Condition Register to be latched into the Operation Status Event Register.
Page 223 6810A SERIES COMMAND SET :STATus :OPERation :PTRansition Parameters: <NRf> positive transition mask Valid values: positive transition mask: integer. Valid values are 0 to 65535. Values outside range are rejected and an error generated. Description: Sets the positive transition filter, which allows transitions from 0 to 1 in the Operation Status Condition Register to be latched into the Operation Status Event Register.
Page 224 6810A SERIES COMMAND SET :STATus :QUEStionable :CONDition? Parameters: none Response: <NR1> register contents Returned values: register contents: integer. Values are in the range 0 to 32767. Description: Read the contents of the Questionable Status Condition Register. This register returns the current state of the instrument. Reading the register does not affect its contents.
Page 225 6810A SERIES COMMAND SET :STATus :QUEStionable :ENABle Parameters: <NRf> mask Valid values: mask: integer. Valid values are 0 to 65535. Values outside range are rejected and an error generated. Description: Sets the enable mask, which allows true conditions in the Questionable Status Event Register to be reported in the summary bit (bit 3 in the Status Byte Register).
Page 226 6810A SERIES COMMAND SET :STATus :QUEStionable [:EVENt]? Parameters: none Response: <NR1> event register contents Returned values: event register contents: integer. Values are in the range 0 to 32767. Description: Read the contents of the Questionable Status Event Register. Reading the register will clear it.
Page 227 6810A SERIES COMMAND SET :STATus :QUEStionable :NTRansition Parameters: <NRf> negative transition mask Valid values: negative transition mask: integer. Valid values are 0 to 65535. Values outside range are rejected and an error generated. Description: Sets the negative transition filter, which allows transitions from 1 to 0 in the Questionable Status Condition Register to be latched into the Questionable Status Event Register.
Page 228 6810A SERIES COMMAND SET :STATus :QUEStionable :PTRansition Parameters: <NRf> positive transition mask Valid values: positive transition mask: integer. Valid values are 0 to 65535. Values outside range are rejected and an error generated. Description: Sets the positive transition filter, which allows transitions from 0 to 1 in the Questionable Status Condition Register to be latched into the Questionable Status Event Register.
Page 230: Step Subsystem
STEP subsystem STEP FREQuency AUTO\? [VALue]\? POWer DB\? WATTs\? TIME DELay\? [TIME]\? UNITs\? VOLTage\? 4-97...
Page 231 6810A SERIES COMMAND SET :STEP :FREQuency :AUTO Parameters: <BOOLEAN PROGRAM DATA> state Description: Set whether the user or the instrument sets the frequency step. If the instrument is automatically setting the frequency step then changing the span will alter the frequency step so that it is always 0.1 times the span.
Page 232 6810A SERIES COMMAND SET :STEP :FREQuency [:VALue] Parameters: <NUMERIC VALUE> frequency step Valid values: frequency step: real Suffix: frequency step: The following suffixes are accepted for frequency: Hz, kHz, MHz and GHz. If no suffix is entered then the default suffix of Hz is assumed.
Page 233 6810A SERIES COMMAND SET :STEP :POWer Parameters: <NUMERIC VALUE> db step Valid values: db step: real Suffix: db step: A suffix of dB is accepted for power. If no suffix is entered then the default suffix of dB is assumed.
Page 234 6810A SERIES COMMAND SET :STEP :POWer :WATTs Parameters: <NUMERIC VALUE> watts step Valid values: watts step: real Suffix: watts step: The following suffixes are accepted for power: mW, W and kW. If no suffix is entered then the default suffix of W is assumed.
Page 235 6810A SERIES COMMAND SET :STEP :TIME :DELay Parameters: <NUMERIC VALUE> delay time step Valid values: delay time step: real Suffix: delay time step: The following suffixes are accepted for time: ps, ns, us, ms and s. If no suffix is entered then the default suffix of s is assumed.
Page 236 6810A SERIES COMMAND SET :STEP :TIME [:TIME] Parameters: <NUMERIC VALUE> time step Valid values: time step: real Suffix: time step: The following suffixes are accepted for time: ms and s. If no suffix is entered then the default suffix of s is assumed.
Page 237 6810A SERIES COMMAND SET :STEP :UNITs Parameters: <NRf> units step Valid values: units step: real Description: Set the units step. This is the amount that is added/subtracted from the current value when UP or DOWN is sent as a parameter instead of a numeric value. The units step set is only used when the parameter being altered is unitless.
Page 238 6810A SERIES COMMAND SET :STEP :VOLTage Parameters: <NUMERIC VALUE> voltage step Valid values: voltage step: real Suffix: voltage step: The following suffixes are accepted for voltage: mV, V and kV. If no suffix is entered then the default suffix of V is assumed.
Page 240: System Subsystem
SYSTem subsystem 4-107...
Page 241 6810A SERIES COMMAND SET SYSTem ADDRess [SELF]\? SOURce\? CONTroller\? DATE\? DIAGnostics DISPlay ERRor? FREQuency STANdard\? HOURs? IPRights? ISETtings COUNtry CURRent? DISK INSTall LIST? NUMBer? VERSion? LIST? NUMBer? REMove [SELect] VERSion? DATE\? DPOint\? KEYBoard CURRent? DISK INSTall LIST? NUMBer? VERSion? LIST?
Page 242 6810A SERIES COMMAND SET REMove [SELect] VERSion MINimum? [NUMBer]? SEParator\? TIME\? OPTions? PRESet SECRet\? SERial BAUD\? BITS\? FCONtrol\? PARity\? SBITs\? SETTings ID\? RECall SAVE TIME\? 4-109...
Page 243 6810A SERIES COMMAND SET :SYSTem :ADDRess [:SELF] Parameters: <NRf> address Valid values: address: integer. Valid values are 0 to 30. Values outside range are rejected and an error generated. Description: Set the GPIB address of the instrument. It is recommended that a *OPC? is executed prior to this command (and the resulting 1 read by the controller) and a delay is inserted after using this command to give the instrument time to execute it.
Page 244 6810A SERIES COMMAND SET :SYSTem :ADDRess :SOURce Parameters: <NRf> address Valid values: address: integer. Valid values are 0 to 30. Values outside range are rejected and an error generated. Description: Set the GPIB address of the external source that the instrument controls during some calibrations.
Page 245 6810A SERIES COMMAND SET :SYSTem :APPLication :ARUN [:SELect] Parameters: <STRING PROGRAM DATA> application Valid values: application: string. Maximum length of 256 characters excluding quotes. Excess characters will be ignored. Description: Selects the application that should be auto-run at power up and on preset.. The application string must be one of the strings read using :SYST:APPL:LIST? or an error will be generated.
Page 246 6810A SERIES COMMAND SET :SYSTem :CONTroller Parameters: <CPD> controller Valid values: controller: [SERial | GPIB | NONE]. Values other than those stated are rejected and an error generated. Description: This command sets how the instrument is being controlled. It can be controlled by either a controller on the GPIB bus or by a controller over RS-232.
Page 247 6810A SERIES COMMAND SET :SYSTem :DATE Parameters: <NRf>, <NRf>, <NRf> year, month, day Valid values: year: integer month: integer. Valid values are 1 to 12. Values outside range are rejected and an error generated. day: integer. Valid values are 1 to 31. Values outside range are rejected and an error generated.
Page 248 6810A SERIES COMMAND SET :SYSTem :DIAGnostics :DISPlay Parameters: <CPD> display diagnostics mode Valid values: display diagnostics mode: [WHITe | BLACk | NORMal]. Values other than those stated are rejected and an error generated. Description: This command allows the display to be tested for stuck pixels.
Page 249 6810A SERIES COMMAND SET :SYSTem :FREQuency :STANdard Parameters: <CPD> frequency standard Valid values: frequency standard: [INT | EX1 | EX10]. Values other than those stated are rejected and an error generated. Description: Select a frequency standard for the instrument: internal, external 1 MHz or external 10 MHz.
Page 250 6810A SERIES COMMAND SET :SYSTem :IPRights? Parameters: none Response: <STRING RESPONSE DATA> message Returned values: message: string Description: Return intellectual property rights message. Example: :SYST:IPR? Return IPR message. :SYSTem :ISETtings :COUNtry :CURRent? Parameters: none Response: <STRING RESPONSE DATA> country in use Returned values: country in use: string.
Page 251 6810A SERIES COMMAND SET :SYSTem :ISETtings :COUNtry :DISK :INSTall Parameters: <STRING PROGRAM DATA> country Valid values: country: string. Maximum length of 30 characters excluding quotes. Excess characters will be ignored. Description: Install a new country into the instrument along with its associated language and keyboard.
Page 252 6810A SERIES COMMAND SET :SYSTem :ISETtings :COUNtry :DISK :NUMBer? Parameters: none Response: <NR1> number of countries Returned values: number of countries: integer Description: This command is to be used in conjunction with :SYST:ISET:COUN:DISK:LIST. This command determines how many countries will be returned by the :SYST:ISET:COUN:DISK:LIST? command.
Page 253 6810A SERIES COMMAND SET :SYSTem :ISETtings :COUNtry :LIST? Parameters: none Response: <STRING RESPONSE DATA>, ..., <STRING RESPONSE DATA> first country, ..., last country Returned values: first country: string. Maximum length of 30 characters excluding quotes. last country: string. Maximum length of 30 characters excluding quotes.
Page 254 6810A SERIES COMMAND SET :SYSTem :ISETtings :COUNtry :REMove Parameters: <STRING PROGRAM DATA> country Valid values: country: string. Maximum length of 30 characters excluding quotes. Excess characters will be ignored. Description: Remove a county from the instrument. Example: :SYST:ISET:COUN:REM “FRANCE” Remove France country settings from the instrument.
Page 255 6810A SERIES COMMAND SET :SYSTem :ISETtings :COUNtry :VERSion? Parameters: <STRING PROGRAM DATA> country Valid values: country: string. Maximum length of 30 characters excluding quotes. Excess characters will be ignored. Response: <NR1> version number Returned values: version number: integer Description: Determine the version number of the specified country file installed in the instrument.
Page 256 6810A SERIES COMMAND SET :SYSTem :ISETtings :DATE Parameters: <CPD>, <CPD> date order, date separator Valid values: date order: [MDY | YMD | DMY]. Values other than those stated are rejected and an error generated. date separator: [SLASh | MINus | DOT]. Values other than those stated are rejected and an error generated.
Page 257 6810A SERIES COMMAND SET :SYSTem :ISETtings :DPOint Parameters: <CPD> decimal point character Valid values: decimal point character: [DOT | COMMa]. Values other than those stated are rejected and an error generated. Description: Sets which character (‘.’ or ‘,’) is used to separate the integral and fractional part of real numbers.
Page 258 6810A SERIES COMMAND SET :SYSTem :ISETtings :KEYBoard :CURRent? Parameters: none Response: <STRING RESPONSE DATA> keyboard in use Returned values: keyboard in use: string. Maximum length of 30 characters excluding quotes. Description: Determine which keyboard is in use. The instrument will always have at least one keyboard available : UK.
Page 259 6810A SERIES COMMAND SET :SYSTem :ISETtings :KEYBoard :DISK :LIST? Parameters: none Response: <STRING RESPONSE DATA>, ..., <STRING RESPONSE DATA> first keyboard, ..., last keyboard Returned values: first keyboard: string. Maximum length of 30 characters excluding quotes. last keyboard: string. Maximum length of 30 characters excluding quotes.
Page 260 6810A SERIES COMMAND SET :SYSTem :ISETtings :KEYBoard :DISK :VERSion? Parameters: <STRING PROGRAM DATA> keyboard Valid values: keyboard: string. Maximum length of 30 characters excluding quotes. Excess characters will be ignored. Response: <NR1> version number Returned values: version number: integer Description: Determine the version number of the specified keyboard file on the removable storage.
Page 261 6810A SERIES COMMAND SET :SYSTem :ISETtings :KEYBoard :NUMBer? Parameters: none Response: <NR1> number of keyboards Returned values: number of keyboards: integer Description: This command is to be used in conjunction with :SYST:ISET:KEYB:LIST. This command determines how many keyboards will be returned by the :SYST:ISET:KEYB:LIST? command.
Page 262 6810A SERIES COMMAND SET :SYSTem :ISETtings :KEYBoard [:SELect] Parameters: <STRING PROGRAM DATA> keyboard Valid values: keyboard: string. Maximum length of 30 characters excluding quotes. Excess characters will be ignored. Description: Select a keyboard. The keyboard string must be one of the strings read using :SYST:ISET:KEYB:LIST? or an error will be generated.
Page 263 6810A SERIES COMMAND SET :SYSTem :ISETtings :LANGuage :CURRent? Parameters: none Response: <STRING RESPONSE DATA> language in use Returned values: language in use: string. Maximum length of 30 characters excluding quotes. Description: Determine which language is in use. The instrument will always have at least one language available : ENGLISH.
Page 264 6810A SERIES COMMAND SET :SYSTem :ISETtings :LANGuage :DISK :LIST? Parameters: none Response: <STRING RESPONSE DATA>, ..., <STRING RESPONSE DATA> first language, ..., last language Returned values: first language: string. Maximum length of 30 characters excluding quotes. last language: string. Maximum length of 30 characters excluding quotes.
Page 265 6810A SERIES COMMAND SET :SYSTem :ISETtings :LANGuage :REMOVABLE STORAGE :VERSion? Parameters: <STRING PROGRAM DATA> language Valid values: language: string. Maximum length of 30 characters excluding quotes. Excess characters will be ignored. Response: <NR1>, <NR1> version number of display strings, version number of error strings...
Page 266 6810A SERIES COMMAND SET :SYSTem :ISETtings :LANGuage :LIST? Parameters: none Response: <STRING RESPONSE DATA>, ..., <STRING RESPONSE DATA> first language, ..., last language Returned values: first language: string. Maximum length of 30 characters excluding quotes. last language: string. Maximum length of 30 characters excluding quotes.
Page 267 6810A SERIES COMMAND SET :SYSTem :ISETtings :LANGuage :REMove Parameters: <STRING PROGRAM DATA> language Valid values: language: string. Maximum length of 30 characters excluding quotes. Excess characters will be ignored. Description: Remove specified language support from the instrument. Example: :SYST:ISET:LANG:REM “SPANISH”...
Page 268 6810A SERIES COMMAND SET :SYSTem :ISETtings :LANGuage :VERSion :MINimum? Parameters: none Response: <NR1>, <NR1> version number of display strings, version number of error strings Returned values: version number of display strings: integer version number of error strings: integer Description: Determine the minimum language version numbers that can be used with the instrument.
Page 269 6810A SERIES COMMAND SET :SYSTem :ISETtings :SEParator Parameters: <CPD> separator Valid values: separator: [SEMicolon | COMMa]. Values other than those stated are rejected and an error generated. Description: Sets which character (‘;’ or ‘,’) is used to separate the values output to CSV format memories.
Page 270 6810A SERIES COMMAND SET :SYSTem :ISETtings :TIME Parameters: <BOOLEAN PROGRAM DATA>, <CPD> 24 hour format, time separator Valid values: time separator: [COLon | COMMa | DOT]. Values other than those stated are rejected and an error generated. Description: Selects whether times are output as twelve (OFF) or twenty-four (ON) hour format and which character is placed between the three numbers that are output.
Page 271 6810A SERIES COMMAND SET :SYSTem :OPTions? Parameters: none Response: <NR1> options Returned values: options: integer. Values are in the range 0 to 32767. The returned value is a sixteen bit value with each set bit representing the presence of an option:...
Page 272 6810A SERIES COMMAND SET :SYSTem :SECRet Parameters: <BOOLEAN PROGRAM DATA> secret frequency display Description: When selected, all X-axis frequency information will be removed from the display and hardcopy. Does not affect frequency values returned to remote controllers. Example: :SYST:SECR ON Stop displaying frequency information.
Page 273 6810A SERIES COMMAND SET :SYSTem :SERial :BAUD Parameters: <NRf> baud rate Valid values: baud rate: integer. Valid values are 1200 to 115200. Values outside range are clipped. Description: Set the serial interface baud rate. The same rate is used for transmission and reception of data.
Page 274 6810A SERIES COMMAND SET :SYSTem :SERial :BITS Parameters: <NRf> data bits Valid values: data bits: integer. Valid values are 7 to 8. Values outside range are clipped. Description: Set the number of data bits sent/received over the RS232 serial bus.
Page 275 6810A SERIES COMMAND SET :SYSTem :SERial :FCONtrol Parameters: <CPD> flow control method Valid values: flow control method: [NONE | XON | HARDware]. Values other than those stated are rejected and an error generated. Description: Set the flow control method for the RS232 serial port: NONE No flow control method in use.
Page 276 6810A SERIES COMMAND SET :SYSTem :SERial :PARity Parameters: <CPD> parity Valid values: parity: [NONE | EVEN | ODD]. Values other than those stated are rejected and an error generated. Description: Set the parity for the RS232 serial interface: NONE No parity checking in use.
Page 277 6810A SERIES COMMAND SET :SYSTem :SERial :SBITs? Parameters: none Response: <NR1> stop bits Returned values: stop bits: integer. Values are in the range 1 to 2. Description: Determine the number of stop bits used for transmissions over the serial interface.
Page 278 6810A SERIES COMMAND SET :SYSTem :SETTings :RECall Parameters: <STRING PROGRAM DATA> file name Valid values: file name: string. Maximum length of 8 characters excluding quotes. Excess characters will be ignored. Description: Recall instrument settings from a store. The store will be accessed using the file...
Page 279 6810A SERIES COMMAND SET :SYSTem :SETTings :SAVE Parameters: <STRING PROGRAM DATA> file name Valid values: file name: string. Maximum length of 8 characters excluding quotes. Excess characters will be ignored. Description: Save current instrument settings to a store. The store will be accessed using the...
Page 280 6810A SERIES COMMAND SET :SYSTem :TIME Parameters: <NRf>, <NRf>, <NRf> hours, minutes, seconds Valid values: hours: integer. Valid values are 0 to 23. Values outside range are rejected and an error generated. minutes: integer. Valid values are 0 to 59. Values outside range are rejected and an error generated.
Page 281: Brief Technical Description
Fig. 5-1 System block diagram....................5-5 Introduction The description which follows is intended as an overview of the 6810A Series hardware, and relates to the functional block of the instrument as shown in Fig. 5-1, which is a simplified block schematic diagram of the instrument.
Page 282: Frequency Standard Board, A2
BRIEF TECHNICAL DESCRIPTION The software for both processors resides on a Compact Flash (CF) memory card (one per processor). The CF card on the Phar-Lap side is also used to store factory pre-set data and user data. Additionally, the A1/1 board provides the following features: GPIB interface Non-volatile RAM (NOVRAM) Interface to front panel keyboard...
Page 283: Frequency Band Selection & Control Board, As2
BRIEF TECHNICAL DESCRIPTION Frequency Band Selection & Control Board, AS2 In addition to generating signals from 1 MHz to 3 GHz, the AS2 board also acts as the master controller for the source, communicating with the System Control Board via the ISA bus. The 1.5–3 GHz output from AS1 is divided by two and four to produce signals in the range 750–...
Page 284: Power Supply
BRIEF TECHNICAL DESCRIPTION Power supply The power supply is a switched-mode unit that runs directly from the AC supply. The unit can accept AC voltages in the range 90 V–265 V at a frequency of 45 Hz to 65 Hz. It supplies DC voltages of +5 V, +6.5 V, +21.5 V, +24 V and ±18 V.
Page 285 BRIEF TECHNICAL DESCRIPTION FM ROUTING CORE SYNTHESIZER, AS1 FREQUENCY BAND SELECTION & CONTROL, AS2 SIGNAL CONDITIONING, AS3 FM TO AS1 NO OPTION FROM REAR PANEL FM FROM 1.5 - 3 GHz PIN DIODE MODULATOR SWITCHED FILTERS REAR PANEL 1.5 - 3 GHz FRACTIONAL- N OPTION 23 1 MHz - 3 GHz...
Page 286 BRIEF TECHNICAL DESCRIPTION System block diagram...
Page 287: Acceptance Testing
Chapter 6 ACCEPTANCE TESTING Contents Introduction ..........................6-1 Power-on and configuration check..................6-2 Source power check ......................6-2 Introduction The following procedure is intended as a quick and convenient method for checking the basic functionality of a new instrument. For a full test of instrument performance against the published specification, refer to the 6800 Series Maintenance Manual.
Page 288 ACCEPTANCE TESTING Power-on and configuration check (1) Connect an AC supply lead to the input connector on the rear panel and set the supply switch to the ‘1’ position. Check on the front panel that the yellow LED adjacent to the SUPPLY switch is lit, indicating standby power is present.
Page 289 ACCEPTANCE TESTING (9) Increase the source output level to maximum by pressing: [SOURCE] [Set Output Power...] on standard units , or [1] [0] [ENTER/=MKR] on units with step attenuator options installed [8] [ENTER/=MKR] Reduce by 0.5 dB if optional field replaceable connectors are fitted. Check that the output has increased to the correct level and that the “...
Page 290: Instrument Default Settings
Appendix A INSTRUMENT DEFAULT SETTINGS The default settings of the most commonly encountered instrument parameters and functions are given below. These are the settings that exist after [PRESET] [Full] has been pressed. Parameters followed by * apply globally; these are instrument configuration settings and are not affected by PRESET (or recalling instrument settings).
Page 292: Error Messages
Appendix B ERROR MESSAGES This Appendix lists in alphabetical order all the errors that can be reported to the user via the display. The errors are grouped as follows: System Error. This usually implies a hardware fault or corruption of data in a non- volatile store (page App B-2).
Page 293: System Error
ERROR MESSAGES System error A printer driver failed to load A printer driver failed to load at power on. Try re-installing the printer driver. Refer to the Maintenance Manual if the problem persists, or contact Customer Support (contact details at rear of manual). Detector EEPROM data corrupted: Input: <input identifier>...
Page 294 ERROR MESSAGES IDROM checksum failure A checksum failure was detected when reading the ID ROM on one of the instrument modules. Refer to the Maintenance Manual if the problem persists, or contact Customer Support (contact details at rear of manual). Software upgrade failed A problem has occurred while attempting to upgrade the instrument software.
Page 295 ERROR MESSAGES Instrument warning Cannot abort. No printing in progress A request to abort a print has been requested when there is no print in progress. Cannot find the specified keyboard layout file Remote control error. Cannot find the specified keyboard layout file. The most probable cause is mistyping the file name.
Page 296 ERROR MESSAGES Cannot send print data to another file A file containing print data that was generated earlier can only be directed to the USB or parallel ports, but not another file. Cannot set the Primary Password Setting the Primary Password is not allowed. Cannot transfer data to specified store Remote control error.
Page 297 ERROR MESSAGES Insufficient free space to perform software upgrade The software upgrade cannot be performed because there is insufficient free space on the instrument's flash card. Additional space should be created by using the Store Management function (accessed via the [UTILITY] key) to delete unwanted files.
Page 298 ERROR MESSAGES Source power calibration requires a detector type 6230A to be connected to input A Source power calibration requires the use of a calibrated detector, i.e. an EEPROM model such as the 6230A. Specified hard copy device driver not found Remote control error.
Page 299 ERROR MESSAGES Character data not allowed Remote control error. Character data was received but is not allowed by the instrument at this point. Command header error Remote control error. An error was detected in the header. This error is displayed when the instrument cannot detect more specific errors.
Page 300 ERROR MESSAGES Invalid date An invalid date was entered. This could result from attempting to set the month to a number greater than 12, entering an invalid day for the month (for example February 31), or entering a year before 1980 or after 2099. Invalid directory Remote control error.
Page 301 ERROR MESSAGES Password out of range An out of range value was entered when attempting to set up a user-defined password. Valid ranges for passwords are: Level 1: 1000 to 9999Level 2: 100000 to 999999 Security: 100000000 to 999999999 Passwords do not match The value entered to confirm a password change was not the same as the value originally entered.
Page 302 ERROR MESSAGES Upper limit is less than lower limit for in segment <position> <number> Within a limit specification, a lower limit cannot be set higher than an upper limit. App. B-11...
Page 304: Status Byte When Read By *Stb
Appendix C GPIB STATUS REPORTING STRUCTURE Status Byte when read by *STB MNEM DESCRIPTION Not used Not used Error queue contains at least one error QUES Questionable Status Event Register Summary Bit Message available in output queue (Queue not empty) Standard Event Status Register Summary Bit True when the device has at least one reason for requesting service OPER...
Page 305 GPIB STATUS REPORTING STRUCTURE Standard Event Status Register (as defined in IEEE 488.2) MNEM DESCRIPTION Operation Complete Request Control. The instrument is requesting permission to become the active IEEE 488 controller in charge Query Error Device-Specific Error Execution Error Command Error User Request - Not implemented in this instrument Power on App.
Page 306 GPIB STATUS REPORTING STRUCTURE Operation Status Condition / Event / Enable Registers MNEM DEFAULT DESCRIPTION TRANSITION Not Used Not Used Not Used Sweeping Not Used TRIG Waiting for Trigger Not Used Not Used Not Used Not Used Not Used Not Used Not Used Not Used Not Used...
Page 307 GPIB STATUS REPORTING STRUCTURE Notes The default transitions listed above are those set at power on and when :SYSTem:PRESet is received. Note that the Operation Status Enable Register is cleared to all zeros at power on and on receipt of :SYSTem:PRESet so it is necessary to enable the appropriate bits before the summary bit in the status byte register will be enabled.
Page 308 GPIB STATUS REPORTING STRUCTURE Questionable Status Condition / Event / Enable Registers MNEM DEFAULT DESCRIPTION TRANSITION Not Used Not Used Not Used Source power unleveled XSTD External standard not present or standard unlocked FREQ Source unlocked Not Used Not Used Calibration failure Not Used Not Used...
Page 309 GPIB STATUS REPORTING STRUCTURE Notes The default transitions listed above are those set at power on and when :SYSTem:PRESet is received. Note that the Questionable Status Enable Register is cleared to all zeros at power on and on receipt of :SYSTem:PRESet so it is necessary to enable the appropriate bits before the summary bit in the status byte register will be enabled.
Page 310 Appendix D NUMERIC ENTRY HANDLING All commands that take a NUMERIC VALUE must also accept the following special forms of numbers: MINimum Set the parameter to be the smallest value that can be settable for that parameter, i.e. the value nearest to negative infinity. MAXimum Set the parameter to be the largest value that can be settable for that parameter, i.e.
Page 312 Appendix E PARAMETERS NOT AFFECTED BY PRESET This Appendix lists which parameters are not affected by preset (i.e. *RST). All other parameters are defaulted on receipt of this command. Serial baud rate :SYST:SER:BAUD Serial data bits :SYST:SER:BITS Serial stop bits :SYST:SER:SBIT Serial parity :SYST:SER:PAR...
Page 314: Overlapped Commands
Appendix F OVERLAPPED COMMANDS All commands accepted by this instrument are sequential commands apart from those listed below: SOUR:CAL:FM SOUR:CAL:FREQ SOUR:CAL:POW:BBAN SOUR:CAL:POW:NBAN SOUR:CAL:STAN The only way of determining the end of the source calibration is by using *OPC, *OPC? or *WAI. App.
Page 316 Appendix G EMULATION OF IEEE488.1 ON THE SERIAL INTERFACE Since the RS-232 interface does not have the extra control lines that the IEEE488.1 interface possesses, it is necessary to emulate the extra functionality. This is done using two mechanisms: the first is the break facility and the second is by sending specific control codes over the RS232 interface, which are interpreted to mean specific IEEE488.1 behavior.
Page 317 INDEX setting address 3-64 GPIB connector 3-7 GPIB operation AC power switch 3-6 command layout 4-8 Active function 3-8 command set overview 4-13 AUX connector 2-5, 3-7 Input connector 3-5 BACK SPACE key 3-10 Instrument settings Battery replacement 2-7 copying 3-14 International settings 3-15, 3-80 Center/span frequency sweep mode 3-32 Color palette 3-71...
Page 318 INDEX Printers, installing 3-17 pulse modulation 3-27 Pulse modulation 3-27 Source control 3-26 edit pattern 3-46 SOURCE key 3-29 set pattern 3-45 Source mode 3-29, 3-38 single pulse 3-44 SOURCE ON/OFF key 3-94 source 3-43 Start/stop frequency sweep mode 3-30 trigger 3-47 Step keys 3-10 defining step size 3-66...
Page 319 This document is an Agreement between the user of this Licensed Software, the Licensee, and Aeroflex International Limited (‘Aeroflex’), the Licensor. By installing or commencing to use the Licensed Software you accept the terms of this Agreement. If you do not agree to the terms of this Agreement do not use the Licensed Software.
Page 320 6.3 If during the appropriate Warranty Period the Licensed Software does not conform substantially to the Software Product Descriptions, Data Sheets or Product Specifications Aeroflex will provide: 6.3.1 In the case of Embedded Software and at Aeroflex’s discretion either a fix for the problem or an effective and efficient work-around.
Page 321 Licensed Software at the commencement of this Agreement. 7.3 Aeroflex shall not be liable to the Licensee for any loss of use or for loss of profits or of contracts arising directly or indirectly out of any such infringement of patent, registered design, trademark or copyright. Notwithstanding anything in this Agreement...
Page 322 As we are always seeking to improve our products, the information in this document gives only a general indication of the product capacity, performance and suitability, none of which shall form part of any contract. We reserve the right to make design changes without notice. web www.aeroflex.com Email info-test@aeroflex.com November 2005...

This manual is also suitable for:

6815ar6815a6813a

Aeroflex 6810A Series Programming Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Aeroflex 6810A Series

Summary of Contents for Aeroflex 6810A Series

This manual is also suitable for:

Table of Contents
