Installation
Electrical Connectors
Kit 18E184
For replacing electrical connectors on Reactor
Important Safety Instructions
Read all warnings and instructions in this
manual and in the Reactor 3 Heated
Hose manual before using the
equipment. Save all instructions.
Ref.
Part
Description
24
---
CONNECTOR, socket, RES
25
---
CONNECTOR, pin, RES
26
---
CONNECTOR, socket, ISO
27
---
CONNECTOR, pin, ISO
Related Manuals
Manual in
Description
English
3A7683
Reactor 3 Heated Hose, Instruction Manual
®
3 heated hoses. For professional use only.
Qty.
1
1
1
1
3A8605B
EN
Advertisement
Related Manuals for Graco 18E184
Summary of Contents for Graco 18E184
- Page 1 Installation Electrical Connectors Kit 18E184 3A8605B ® For replacing electrical connectors on Reactor 3 heated hoses. For professional use only. Important Safety Instructions Read all warnings and instructions in this manual and in the Reactor 3 Heated Hose manual before using the equipment.
- Page 2 Installation Installation NOTE: When installing replacement electrical WARNING connectors, ensure that red connectors are attached to red wires and blue connectors are attached to blue wires. 1. Turn off Reactor power and allow hoses to cool. 2. Push the electrical wire through the back of the BURN HAZARD electrical connector housing.
- Page 3 Notes Notes 3A8605B...
- Page 4 Original instructions. This manual contains English. MM 3A8605 Graco Headquarters: Minneapolis International Offices: Belgium, China, Japan, Korea GRACO INC. AND SUBSIDIARIES • P.O. BOX 1441 • MINNEAPOLIS MN 55440-1441 • USA Copyright 2021, Graco Inc. All Graco manufacturing locations are registered to ISO 9001. www.graco.com...
