RECYCLER GUIDE
SIMATIC
ET 200clean
Reference product: 6ES7143-7BH00-0BB0
This document covers all the variants in the domain
6ES7141-7BH00-0BB0, 6ES7143-7BH00-0BB0, 6ES7148-7JH00-0BB0.
support.industry.siemens.com
mittel
klein
30
26
16
14
10
9
11
10
9
9
9
7,5
Wenn ein Produktfoto verwendet
wird bitte oben rechts ausrichten
If a product photo is used, please
align it to the top right
An oberer Zeile ausgerichtet
Abstände zwischen den Textfeldern einhalten
Aligned to the upper line
Keep the distances between the text fields
Logo buffer zone
Advertisement
Table of Contents
Related Manuals for Siemens SIMATIC ET 200clean
Summary of Contents for Siemens SIMATIC ET 200clean
- Page 1 Abstände zwischen den Textfeldern einhalten Aligned to the upper line Keep the distances between the text fields RECYCLER GUIDE SIMATIC ET 200clean Reference product: 6ES7143-7BH00-0BB0 This document covers all the variants in the domain 6ES7141-7BH00-0BB0, 6ES7143-7BH00-0BB0, 6ES7148-7JH00-0BB0. Logo buffer zone support.industry.siemens.com...
- Page 2 Recycler Guide for SIMATIC ET 200clean About this guide Safety instructions SIMATIC Recommended tool Disassembly instructions Recycler Guide for Explanation of substances SIMATIC ET 200clean and components Received material fractions Product Information Disclaimer of liability 02/2025 A5E56256502-AA...
-
Page 3: Legal Information
Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems. -
Page 4: Table Of Contents
About this guide ............................ 4 Safety instructions ..........................5 Recommended tool ..........................6 Disassembly instructions ........................7 Explanation of substances and components ..................11 Received material fractions ......................... 12 Disclaimer of liability ........................... 13 Recycler Guide for SIMATIC ET 200clean Product Information, 02/2025, A5E56256502-AA... -
Page 5: About This Guide
The Siemens Recycler Guides provide recyclers of electronic products with instructions on how to disassemble products safely in order to maximize resource recycling. The Recycler Guides provide step-by-step disassembly instructions and material composition information to help recyclers direct specific materials to specialized recyclers. -
Page 6: Safety Instructions
Warning against hand injuries Warning against pointed/sharp objects Wear personal protective equipment throughout the recycling process. Wear hand protection Wear a mask Wear eye protection Wear foot protection Wear protective clothing Recycler Guide for SIMATIC ET 200clean Product Information, 02/2025, A5E56256502-AA... -
Page 7: Recommended Tool
Recommended tool For the disassembly of the product, we recommend using the following tool: Slotted screwdriver Torx screwdriver T10 Handsaw Pliers 17 mm open-ended wrench Recycler Guide for SIMATIC ET 200clean Product Information, 02/2025, A5E56256502-AA... -
Page 8: Disassembly Instructions
Lower enclosure Step 3 Hygienic seal Silicone Step 3 Screws Steel Step 4 Assembled PCB Electronics Step 4 Insulating sleeves Step 5 Upper enclosure Step 5 Sealing rings Rubber Step 5 Recycler Guide for SIMATIC ET 200clean Product Information, 02/2025, A5E56256502-AA... -
Page 9: Dismantling The Product
1. Saw into the module at the circumferential hygienic seal using a handsaw. Open the module with a slotted screwdriver. 2. Separate the upper enclosure with the assembled PCB from the lower enclosure with the hygienic seal. Recycler Guide for SIMATIC ET 200clean Product Information, 02/2025, A5E56256502-AA... - Page 10 Remove the circumferential hygienic seal and the hygienic seal parts of the mounting points. Step 4 Remove the 4 screws securing the assembled PCB to the upper enclosure with a T10 Torx screwdriver. Remove the assembled PCB from the upper enclosure. Recycler Guide for SIMATIC ET 200clean Product Information, 02/2025, A5E56256502-AA...
- Page 11 Disassembly instructions Step 5 Press out the insulating sleeves and remove the sealing rings. Recycler Guide for SIMATIC ET 200clean Product Information, 02/2025, A5E56256502-AA...
-
Page 12: Explanation Of Substances And Components
Step 4 Additional information In order to support the recycling economy, SIEMENS creates transparency that goes beyond the regulatory requirements. See the table for additional information on smaller PCBs or displays, as well as metal alloys containing elements that may be critical at the end of the service life, such as beryllium or lead. -
Page 13: Received Material Fractions
The following table contains the main material fractions. The table does not claim to be complete. Position Possible material fractions (not exhaustive) 2, 6, 7 1, 3 Silicone Copper, precious metals, tin Steel Rubber Recycler Guide for SIMATIC ET 200clean Product Information, 02/2025, A5E56256502-AA... -
Page 14: Disclaimer Of Liability
Reuse of dismantled components is not permissible. Siemens therefore assumes no liability for errors or consequences that may result from the use of this information to the greatest possible legal extent.
