Product information on the documentation of the ET
200SP distributed I/O system
SIMATIC
ET 200SP
Product information on the
documentation of the ET 200SP
distributed I/O system
Product Information
09/2019
A5E03799595-BD
Preface
Module overview of
ET 200SP
Supplements to ET 200SP
documentation
1
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIMATIC 200SP and is the answer not in the manual?

Questions and answers

Related Manuals for Siemens SIMATIC 200SP

Summary of Contents for Siemens SIMATIC 200SP

  • Page 1 Product information on the documentation of the ET Preface 200SP distributed I/O system Module overview of ET 200SP Supplements to ET 200SP SIMATIC documentation ET 200SP Product information on the documentation of the ET 200SP distributed I/O system Product Information 09/2019 A5E03799595-BD...

  • Page 2: Legal Information

    Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Preface

    Siemens' products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customers' exposure to cyber threats.

  • Page 4: Table Of Contents

    Table of contents Preface ..............................3 Module overview of ET 200SP ........................5 Possible combinations of BaseUnits and I/O modules ............5 CPUs ............................14 Interface modules ........................16 BaseUnits ..........................18 I/O modules ..........................20 Motor starters ......................... 22 Accessories ..........................

  • Page 5: Module Overview Of Et 200Sp

    This product information includes amendments and corrections to the documentation of the ET 200SP Distributed I/O System (https://support.industry.siemens.com/cs/ww/en/view/109742709). Which I/O modules / motor starters fit on a BaseUnit? The following table provides an overview of the I/O modules / motor starters that fit on the...
  • Page 6 Module overview of ET 200SP 1.1 Possible combinations of BaseUnits and I/O modules I/O module BaseUnit BU15- BaseUnit BU20- Color-coded label for process BU type A0 BU type A1 BU type BU type BU type C0 BU type BU type BU type BU type terminals...
  • Page 7 Module overview of ET 200SP 1.1 Possible combinations of BaseUnits and I/O modules I/O module BaseUnit BU15- BaseUnit BU20- Color-coded label for process BU type A0 BU type A1 BU type BU type BU type C0 BU type BU type BU type BU type terminals...
  • Page 8 Module overview of ET 200SP 1.1 Possible combinations of BaseUnits and I/O modules I/O module BaseUnit BU15- BaseUnit BU20- Color-coded label for process BU type A0 BU type A1 BU type BU type BU type C0 BU type BU type BU type BU type terminals...
  • Page 9 Module overview of ET 200SP 1.1 Possible combinations of BaseUnits and I/O modules I/O module BaseUnit BU15- BaseUnit BU20- Color-coded label for process BU type A0 BU type A1 BU type BU type BU type C0 BU type BU type BU type BU type terminals...
  • Page 10 Module overview of ET 200SP 1.1 Possible combinations of BaseUnits and I/O modules I/O module BaseUnit BU15- BaseUnit BU20- Color-coded label for process BU type A0 BU type A1 BU type BU type BU type C0 BU type BU type BU type BU type terminals...
  • Page 11 Module overview of ET 200SP 1.1 Possible combinations of BaseUnits and I/O modules I/O module BaseUnit BU15- BaseUnit BU20- Color-coded label for process BU type A0 BU type A1 BU type BU type BU type C0 BU type BU type BU type BU type terminals...
  • Page 12 Module overview of ET 200SP 1.1 Possible combinations of BaseUnits and I/O modules Table 1- 2 Possible combinations of BaseUnits and motor starters Selecting the BaseUnit BU-30- BU-30- BU-30- BU-30- BU-30- BU-30- BU-30- BU-30- BU-30- BU-30- MS10 24 V infeed 500 V infeed F-DI terminals (no routing of the F-DI...
  • Page 13 Module overview of ET 200SP 1.1 Possible combinations of BaseUnits and I/O modules F-DS 0.9 - 3RK1308- 3 A HF 0CC00- 0CP0 F-DS 2.8 - 3RK1308- 9 A HF 0CD00- 0CP0 F-DS 4.0 - 3RK1308- 12 A HF 0CE00- 0CP0 F-RS 0.1 - 3RK1308- 0.4 A HF...

  • Page 14: Cpus

    Module overview of ET 200SP 1.2 CPUs CPUs CPUs Number in pack Article number CPU 1510SP-1 PN with server module Pack of 1 6ES7510-1DJ0x-0AB0 CPU 1510SP F-1 PN with server module Pack of 1 6ES7510-1SJ0x-0AB0 CPU 1512SP-1 PN with server module Pack of 1 6ES7512-1DK0x-0AB0 CPU 1512SP F-1 PN with server module...
  • Page 15 Module overview of ET 200SP 1.2 CPUs Note The CM AS-i Master ST and F-CM AS-i Safety ST communication modules are supported as of firmware V1.8 of the CPUs. Note the following additional requirements: CM AS-i Master ST: • Firmware version of the CM AS-i Master ST: V1.1 •...

  • Page 16: Interface Modules

    Module overview of ET 200SP 1.3 Interface modules Interface modules Interface modules Interface modules Number in pack Article number Interface module IM 155-6 PN BA Pack of 1 6ES7155-6AR00-0AN0 Interface module IM 155-6 PN ST Pack of 1 6ES7155-6AA01-0BN0 with BusAdapter BA 2xRJ45 and server module •...
  • Page 17 Module overview of ET 200SP 1.3 Interface modules Important differences between the interface modules Features IM 155-6 PN BA IM 155-6 PN ST IM 155-6 PN/2 HF IM 155-6 PN HS IM 155-6 DP HF IM 155-6 PN/3 HF Address 32 bytes 798 bytes 1440 bytes...

  • Page 18: Baseunits

    Module overview of ET 200SP 1.4 BaseUnits BaseUnits BaseUnits Table 1- 5 BaseUnits for I/O modules BaseUnits (short Color-coded labels* Packaging unit Article number type name) BU15-P16+A10+2D P16: CC00 to CC05 Pack of 1 6ES7193-6BP20-0DA0 A10: CC71 to CC73 Pack of 10 6ES7193-6BP20-2DA0 BU15-P16+A0+2D P16: CC00 to CC05...
  • Page 19 Module overview of ET 200SP 1.4 BaseUnits Table 1- 6 BaseUnit PotDis PotDis type Potential distributor Color-coded Packaging unit Article number (short name) labels PotDis-BU-P1/D-R CC62 Pack of 1 6ES7193-6UP00-0DP1 PotDis-BU-P1/B-R CC62 Pack of 1 6ES7193-6UP00-0BP1 PotDis-BU-P2/D-B CC63 Pack of 1 6ES7193-6UP00-0DP2 PotDis-BU-P2/B-B CC63...

  • Page 20: I/O Modules

    Module overview of ET 200SP 1.5 I/O modules I/O modules I/O modules Digital I/O modules Packaging unit Article number DI 16x24VDC ST Pack of 1 6ES7131-6BH01-0BA0 Pack of 10 6ES7131-6BH01-2BA0 DI 8x24VDC ST Pack of 1 6ES7131-6BF01-0BA0 Pack of 10 6ES7131-6BF01-2BA0 DI 8x24VDC HF Pack of 1...
  • Page 21 Module overview of ET 200SP 1.5 I/O modules Analog I/O modules Packaging unit Article number AI 8xU BA Pack of 1 6ES7134-6FF00-0AA1 AI 2xU ST Pack of 1 6ES7134-6FB00-0BA1 AI 4xU/I 2-wire ST Pack of 1 6ES7134-6HD01-0BA1 Pack of 10 6ES7134-6HD01-2BA1 AI 2xU/I 2-/4-wire HF Pack of 1...

  • Page 22: Motor Starters

    Module overview of ET 200SP 1.6 Motor starters Communication modules Packaging unit Article number CM 4xIO-Link Pack of 1 6ES7137-6BD00-0BA0 CM AS-i Master ST Pack of 1 3RK7137-6SA00-0BC1 F-CM AS-i Safety ST Pack of 1 3RK7136-6SC00-0BC1 CM PtP Pack of 1 6ES7137-6AA00-0BA0 CM DP (for CPU) Pack of 1...
  • Page 23 Module overview of ET 200SP 1.6 Motor starters Failsafe direct starter Packaging unit Article number F-DS 0.1 - 0.4 A HF Pack of 1 3RK1308-0CA00-0CP0 F-DS 0.3 - 1 A HF Pack of 1 3RK1308-0CB00-0CP0 F-DS 0.9 - 3 A HF Pack of 1 3RK1308-0CC00-0CP0 F-DS 2.8 - 9 A HF...

  • Page 24: Accessories

    Module overview of ET 200SP 1.7 Accessories Accessories Accessories General accessories Packaging unit Article number BusAdapter Pack of 1 6ES7193-6AR00-0AA0 BA 2×RJ45 (PROFINET BusAdapter with standard Ethernet socket) • Pack of 1 6ES7193-6AF00-0AA0 BA 2×FC (PROFINET BusAdapter with FastConnect Ethernet connec- •...
  • Page 25 Module overview of ET 200SP 1.7 Accessories Accessories, color identification labels (push- Packaging unit Article number in terminals), 15 mm wide 16 process terminals (you can find additional information in the I/O Module manual) Pack of 10 6ES7193-6CP00-2MA0 Gray (terminals 1 to 16); color code CC00 •...
  • Page 26 Module overview of ET 200SP 1.7 Accessories Accessories, color identification labels (push- Packaging unit Article number in terminals), 20 mm wide 12 process terminals (you can find additional information in the I/O Module manual) Pack of 10 6ES7193-6CP41-2MB0 Gray (terminals 1 to 4), red (terminals 5 to •...
  • Page 27 Module overview of ET 200SP 1.7 Accessories Accessories, color identification labels (push- Packaging unit Article number in terminals) PotDis PotDis-BU, 16 potential terminals Pack of 10 6ES7193-6CP62-2MA0 Red for PotDis-BU-P1/x-R (terminals 1 to • 16); color code CC62 Pack of 10 6ES7193-6CP63-2MA0 Blue for PotDis-BU-P2/x-B (terminals 1 to •...
  • Page 28 Module overview of ET 200SP 1.7 Accessories Accessories, color identification labels (push- Packaging unit Article number in terminals) PotDis PotDis-TB-BR-W, 18 potential terminals Pack of 10 6ES7193-6CP11-2MT0 Yellow/green (terminals 1 to 18); color • code CC11 Pack of 10 6ES7193-6CP12-2MT0 Red (terminals 1 to 18);...

  • Page 29: Supplements To Et 200Sp Documentation

    The Technical Specifications section in the CPU equipment manuals indicates the status of the technical specification at the respective edition date. You can find a data sheet including daily updated technical specifications on the Internet (https://support.industry.siemens.com/cs/ww/en/ps/13888/td). Manual CPU 1512SP-1 PN, Edition 09/2016 Section 4.1 Status and error display of the CPU...
  • Page 30 Supplements to ET 200SP documentation 2.2 CPU manuals Section 6 Technical specifications Technical specifications of the BusAdapters BA 2×SCRJ, BA SCRJ/RJ45, BA SCRJ/FC The maximum length of the PCF-GI fiber-optic cable is 250 m. Device manuals CPU 1510SP-1 PN and CPU 1512SP-1 PN, Edition 09/2016 "LED"...

  • Page 31: Interface Module Manuals

    Supplements to ET 200SP documentation 2.3 Interface module manuals Interface module manuals Configuration notes on interface modules depending on the I/O modules Module IM 155-6 PN ST IM 155-6 PN HF IM 1 IM 155-DP HF 155-6 IM 155-6 PN/2 HF V4.2 and higher PN BA 6 PN IM 155-6 PN/3 HF V4.2 and higher...
  • Page 32 Supplements to ET 200SP documentation 2.3 Interface module manuals Module IM 155-6 PN ST IM 155-6 PN HF IM 1 IM 155-DP HF 155-6 IM 155-6 PN/2 HF V4.2 and higher PN BA 6 PN IM 155-6 PN/3 HF V4.2 and higher Firm- V3.2 V4.0...

  • Page 33: Response Times

    Supplements to ET 200SP documentation 2.3 Interface module manuals IM 155-6 PN ST Manual, Edition 04/2017 Response times The response time of the IM 155-6 PN ST is made up of: ● Backplane bus cycle time ● Operating system processing Note Validity of the formula The following formula applies to the ET 200SP backplane bus.
  • Page 34 Supplements to ET 200SP documentation 2.3 Interface module manuals Explanation of the parameters: Number_m: Total number of all modules (incl. server module) Bytes_out: Sum of all output bytes Bytes_in: Sum of all input bytes Calculating the response time Response time output The response time output of the IM 155-6 PN ST is made up of: ●...

  • Page 35: Section 6 Compatibility

    Supplements to ET 200SP documentation 2.3 Interface module manuals Equipment manual IM 155-6 PN/3 HF, Edition 10/2018 Section 2.2 Functions The "Interface-local coupling of IO data" function can also be used in addition to GSDML with STEP 7 (TIA Portal) as of V15.1 with HSP285. Table 2-1 Version dependencies of the module functions The "Interface-local coupling of IO data"...

  • Page 36: Section 7 Technical Specifications

    Supplements to ET 200SP documentation 2.3 Interface module manuals IM 155-6 PN HS manual, Edition 09/2016 Section 3.1 Pin assignment PROFINET interface X1 Port 2: If autonegotiation is disabled, the RJ-45 socket (X1 Port 2) has the switch assignment (MDI-X). Section 7 Technical specifications ●...

  • Page 37: I/O Module Manuals

    Supplements to ET 200SP documentation 2.4 I/O module manuals I/O module manuals Configuration notes on the I/O modules (supplement to Product overview section in the manual) I/O module Article number Firmware STEP 7 (TIA STEP 7 V5.5 version Portal) Digital input modules DI 16x24VDC ST 6ES7131-6BH00- V1.1.0...
  • Page 38 Supplements to ET 200SP documentation 2.4 I/O module manuals I/O module Article number Firmware STEP 7 (TIA STEP 7 V5.5 version Portal) Analog input modules AI 8xU BA 6ES7134-6FF00- V1.0.0 HSP0126 HSP0227 V5.0 0AA1 AI 2xU ST 6ES7134-6FB00- V1.0.0 HSP0160 HSP0227 V6.0 0BA1 V13 SP1 or...

  • Page 39: Digital Module Device Manuals

    Supplements to ET 200SP documentation 2.4 I/O module manuals 2.4.1 Digital module device manuals Manuals for I/O modules ST, BA When you have deactivated all channels of the I/O module, a diagnostics alarm is still generated in the case of a fault if the "Missing supply voltage L+" diagnostics is enabled. For the following I/O modules, this behavior is corrected as of firmware version >...

  • Page 40: Section A.2 Parameter Assignment And Structure Of Parameter Data Record

    Supplements to ET 200SP documentation 2.4 I/O module manuals Manual DI 8xNAMUR HF, Edition 02/2014 Section A.2 Parameter assignment and structure of parameter data record With data records 0 to 7, you can configure individual channels. When the interface module IM 155-6 DP HF (PROFIBUS DP) is used and data records 0 and 1 are read, the module returns the diagnostics data records and not the parameter data records of the DI 8xNAMUR HF.

  • Page 41: Section 3.1 Wiring And Block Diagram

    Supplements to ET 200SP documentation 2.4 I/O module manuals DQ 4x24..230VAC/2A HF Manual, Edition 02/2018 Section 3.1.1. und 4.1.1 Wiring and block diagram The following figure shows an example for the terminal assignment of the digital output module DQ 4x24...230VAC/2A HF on the BaseUnit BU type U0 (3-wire connection) in combination with a potential distribution module and terminal block.

  • Page 42: Analog Module Device Manuals

    Supplements to ET 200SP documentation 2.4 I/O module manuals 2.4.2 Analog module device manuals Manuals for analog input modules Manual Edition AI 8xI 2-/4-wire BA 03/2015 AI 8xU BA 03/2015 AI 2xU ST 12/2015 AI 4xI 2-wire 4..20mA HART 11/2014 AI 2xU/I 2-/4-wire HF 12/2015 Section 5.2 Parameters...
  • Page 43 Supplements to ET 200SP documentation 2.4 I/O module manuals In the manual for Energy Meter 480VAC ST, Edition 12/2015 In the device manual for Energy Meter 480VAC ST, the measured value ID and the associated measured variables for the complete performance are reversed. The correct association is shown in the table below: Measured value Measured variables...

  • Page 44: Communications Module Manuals

    Supplements to ET 200SP documentation 2.4 I/O module manuals Manual for AQ 2xU/I HF, Edition 02/2014 Section 3.1 Wiring and block diagram, pin assignment You can now also use the 3-wire connection in addition to the 2-wire and 4-wire connection for the analog module AQ 2xU/I HF.
  • Page 45 Supplements to ET 200SP documentation 2.4 I/O module manuals Communications module IO-Link Master CM 4xIO-Link, Edition 10/2017 Section Connecting, Wiring and block diagram Connection: 2-wire and 3-wire connection in DQ operating mode: ① 2-wire connection 1 A to 10 A AUX terminals ②...
